Stern Pinball IRON MAN User manual

IRON MAN
SERVICE AND OPERATION MANUAL
Games congured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe UK, Australia).
1-800-KICKERS - [email protected]
www.sternpinball.com - facebook.com/sternpinball
MANUAL #780-50B0-00
IRON MAN PRO VAULT EDITION #500-55B0-01
Iron Man 2, the Movie © MVL Film Finance LLC. Marvel, Iron Man, all character names and their distinctive likenesses:
TM & © Marvel Entertainment, LLC and it’s subsidiaries. All Rights Reserved.
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to certain visual images,
including ashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that can cause “photosensitive epileptic
seizures” due to certain visual images, ashing lights or patterns. Symptoms can include lightheadedness, altered vision, eye or face twitching, jerking or shaking of arms or
legs, disorientation, confusion, momentary loss of awareness, and loss of consciousness or convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA. Stern Pinball has inspected each game element to ensure it meets our quality standards.
Each pinball machine has unique characteristics that make it a one-of-a-kind American made product. Each will have variations in appearance resulting from differences
in the machine’s particular wood parts, individual printed art and mechanical assemblies. No playeld is perfectly at and varies depending on the season. Game play will
result in playeld dimpling as the harder steel ball contacts the wood and coating; over time multiple dimples will blend to make them less noticeable. Normal plastic insert
crazing (tiny stress cracks) and ghosting (small cloudy areas around insert edges) are often seen in pinball machines, due to a combination of plastic mold stress, pushing of
inserts into purposely undersized holes, and heating and breaking of inserts’ plastic “skin” when the playeld is sanded.
ATTENTION! IMPORTANT WARRANTY INFORMATION
The electronics system, node network architecture, mechanical devices and associated software control systems in this pinball machine are designed to work with genuine
Stern Pinball accessories and devices.
Installation of non-authorized accessories, lamps, LED’s, motors or other devices or modication of electro-mechanical devices may damage the system and will void your
warranty.

2
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
TABLE OF CONTENTS
1. Setup and Moving .................................. 3
1.1 First-Time Setup Instructions ............................... 3
1.2 Adjustments Menu ............................................... 6
1.3 Transporting the Game ........................................ 8
1.4 Maintenance ........................................................ 9
1.5 Maintenance Kits ................................................. 9
1.6 Common Parts ..................................................... 9
1.7 Updating Game Code for the S.A.M. System .... 10
1.8 Fuses and Cabinet Switches ............................. 11
1.9 Service Switch & CPU DIP Switch Settings ....... 12
1.10 Diagnostic Aids .................................................. 13
1.11 CPU DIP Switch Settings ................................... 13
1.12 Switch Locations................................................ 17
1.13 Lamp Locations ................................................. 19
1.14 Coil Locations .................................................... 21
2. Service Menu System .......................... 22
2.1 Service Menu Introduction ................................. 22
2.2 Service Menu Icon Tree...................................... 23
2.3 Problem/Solution Table ...................................... 25
2.4 Diagnostics Menu .............................................. 26
3. PartsIdentication&Location ........... 34
3.1 Backbox Parts.................................................... 34
3.2 Speaker Panel Parts .......................................... 34
3.3 Cabinet Parts ..................................................... 35
3.4 Playeld Top - Main Assem. & Switches ............ 36
3.5 Playeld Bottom - Main Assem. and Switches . . 37
3.6 Playeld - Rubber Parts ..................................... 38
3.7 Rubber Size Chart .............................................. 38
4. Major Assemblies................................. 39
4.1 Ball Shooter Assembly ....................................... 39
4.2 Auto Launch Assembly ...................................... 39
4.3 Flipper Assembly, Left ........................................ 40
4.4 Flipper Assembly, Right ..................................... 40
4.5 Slingshot Assembly............................................ 41
4.6 4-Ball Trough Assembly ..................................... 41
4.7 Pop Bumper Assembly ...................................... 42
4.8 Left Ramp Assembly .......................................... 43
4.9 Right Ramp Assembly ....................................... 44
4.10 Kicker Assembly ................................................ 45
4.11 Ball Guide #2 Assembly ..................................... 45
4.12 Back Panel Assembly ........................................ 45
4.13 Ball Guide #3 Assembly ..................................... 45
4.14 Monger Motor & Switch Assembly .................... 46
4.15 Iron Monger Lift Assembly ................................. 46
4.16 Iron Monger Lift Assembly ................................. 47
4.17 Iron Monger Fastened Assembly ....................... 47
5. Schematics,Wiring&PCBs ................ 48
5.1 Backbox Wiring .................................................. 48
5.2 Playeld Wiring .................................................. 51
5.3 Cabinet and Coin Door Wiring ........................... 55
5.4 Printed Circuit Boards ........................................ 58
6. Specications ....................................... 86
6.1 Game Dimensions .............................................. 86
6.2 Warranty ............................................................. 87
6.3 Warnings, Compliance, and Legal Notices ........ 87

1. SETUP AND MOVING
2
2
557
7
1
9
8
11
15
11
8
6
14
14
SETUP AND MOVING
3
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
1.1 FIRST-TIME
SETUP INSTRUCTIONS
CAUTION: AT LEAST TWO (2)
PEOPLE ARE REQUIRED TO
MOVE AND MANEUVER THE
GAME. USE PROPER MOVING
EQUIPMENT AND EXTREME
CARE WHILE HANDLING. STERN
PINBALL MACHINES WEIGH
OVER 250LBS BOXED.
TOOLS REQUIRED
• 5/8” Socket Wrench
• Utility Knife
• Snips
• An Assistant
Your brand new Stern Pinball Machine is
carefully packed for safety and security.
For your safety, exercise caution and use
the correct tools and sufcient help when
setting up your new game.
1. Locate the side labeled “TRUCK
THIS SIDE ONLY”. The bottom of
the game faces this side.
2. Open the top box aps by pulling
hard in an upward motion on each
ap. If the aps are taped, cut the
tape rst, taking care to avoid the
box staples.
3. Remove the four (4) foam pieces
and two (2) narrow box tubes
which contain the four (4) identical
legs with levelers.
4. DO NOT CUT STRAPPING YET.
Keep backbox secured in the
down position.
5. With the utility knife, carefully cut
down the left and right corners of
the box.
6. Let the face fall forward and
remove the entire side by carefully
cutting the bottom.
7. With the game still in its folded po-
sition, use a ⅝” wrench to loosen
and remove the 2 leg bolts on each
side of the front cabinet. Ensure
the leg levelers are screwed all the
way into the legs.
8. Install front legs using the bolts
removed from the cabinet. Secure
tightly.
9. Have someone help you carefully
set the game down on the front
legs.
10. Set aside the open box.
11. With a ⅝” socket wrench, loosen
and remove the 2 leg bolts on
each side of the rear cabinet, 4
total.
12. Using supports or two people,
prop the rear of the cabinet up.
13. Ensure the rear leg levelers are
screwed all the way into the legs.
14. Install rear legs using the 4 bolts
removed from step 11.

19
21
17
25
26
27
FIRST-TIME SETUP CONTINUED
27
4
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
15. Cut nylon strapping and remove
protective strap corner guards.
16. Locate the factory keys, either on
the shooter rod or taped to the
playeld glass.
17. Using snips, cut the tie-wrap secur-
ing the keys if required. One set of
keys is for the front coin door, the
other set of keys is for accessing
components in the backbox.
18. Open the front coin door.
19. Reach into the game and remove
the retaining clip at the rear of the
cash box.
20. Remove the cash box lid by sliding
it toward you.
21. Store the backbox keys, if desired,
on the metal hook located in the
coin door.
22. Locate and remove the pinballs,
plumb bob, and backbox bolts
from the cash box.
23. Replace the cash box lid and
retaining clip for future use.
24. Locate the two (2) backbox bolts in
the cash box.
25. Carefully raise backbox to upright
position while ensuring that cables
are not pinched.
26. Use the ⅝” wrench to Install the
two (2) backbox bolts to secure the
backbox as indicated on the back
of the cabinet.
27. Reach inside the cabinet and lift
the two latches located on either
side of the coin door.
28. Remove the front top molding.
29. Remove the playeld glass by
sliding it toward you and carefully
place it in a safe location.
Remove all playeld shipping
tie downs, shipping blocks, and
packing foam, and follow any
game-specic unpacking instruc-
tions included in the playeld, if
present.
CAUTION: PLAYFIELD GLASS IS MADE FROM HIGH-STRENGTH TEMPERED
GLASS. TEMPERED GLASS IS SENSITIVE TO EXTREME TEMPERATURE SHIFTS
AND CORNER NICKS, WHICH CAN CAUSE THE GLASS TO FAIL CATASTROPHI-
CALLY. TAKE CARE TO STORE THE GLASS ON A SOFT, ROOM-TEMPERATURE
SURFACE AND PREVENT THE CORNERS FROM BEING DAMAGED.

SETUP AND MOVING
5
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
30. If pinballs were already installed into the lower ball
trough, remove them before lifting the playeld.
31. Grasp the lower arch between the ippers, and rmly
but gently pull directly up to raise the playeld 8 to 12
inches.
32. While holding the playeld up, pull the playeld toward
you until the two playeld supports are over the front
edge of the cabinet.
33. Rest the playeld on the front edge of the cabinet.
34. Raise the playeld and rest it against the backbox.
35. Visually inspect all cabinet cables and connector termi-
nations; ensure no wires or cables are pinched and that
cable harnesses are not pulled tight.
36. Locate the plumb bob in the parts bag in the cash box.
37. Slide plumb bob onto the hanger wire. Note: the vertical
position of the plumb bob affects tilt sensitivity - higher
makes the game more sensitive to tilting.
38. Tighten the thumb screw nger-tight.
39. Install the correct number of pinballs. Refer to the decal
on the lock down assembly for the correct number of
pinballs.
LOCATING, LEVELING, AND FINAL SETUP
1. Select a location that is indoors, out of direct sunlight,
and climate controlled. Excessive moisture/humidity
can cause long-term damage to your game.
2. Adjust the front or rear levelers as necessary to position
the playeld level bubble, located on the front right of
the playeld next to the shooter lane, to oat between
the two (2) black lines. This will place the playeld at the
recommended 6.5° pitch. Playeld angles greater than
6.5° can be achieved by turning out the rear leg level-
er(s) for increased difculty and faster gameplay.
3. Use a pinball to roll down the center of the playeld for
side-to-side leveling, or use an external bubble level,
digital level, or smartphone level app.
4. Plug into a grounded outlet and check for proper opera-
tion through DIAGNOSTICS.
5. Check the coin door: With the door closed, insert coins
to verify proper operation.
6. Play game: Check for satisfactory operation and adjust
game volume (push the Red Buttons inside the Coin
Door).
7. If desired, perform any game diagnostics, game adjust-
ments, and pricing settings at this time.
FIRST-TIME SETUP CONTINUED

6
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
1.2 ADJUSTMENTS MENU
STANDARD ADJUSTMENTS
Perform the below steps to review the adjustments.
Enter the Service Menu, then enter the Standard Adjustments
Menu.
Press SELECT. Press BACK to exit or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the S.P.I. icon. Press SELECT.
STANDARD ADJUSTMENT #1 appears with the adjustment
name ashing. While the adjustment name is ashing press [<]
[>] to move between adjustments.
To change the adjustment setting press SELECT. While the ad-
justment setting is ashing, press [<] [>] repeatedly until the de-
sired setting appears. Press the SELECT button to “install” the
change. The adjustment comment (bottom line) will indicate if
the factory default setting is selected or will display INSTALLED
if the change is not a factory default setting.
ID Adjustment Name Default Setting
1 REPLAY TYPE AUTO
2 REPLAY PERCENTAGE 10%
3REPLAY AWARD CREDIT
4 REPLAY LEVELS 1
5 AUTO REPLAY START 20,000,000
6 DYNAMIC REPLAY START 60,000,000
7 REPLAY LEVEL #1 15,000,000
8REPLAY LEVEL #2 30,000,000
9REPLAY LEVEL #3 45,000,000
10 REPLAY LEVEL #4 60,000,000
11 REPLAY BOOST YES
12 SPECIAL LIMIT 1
13 SPECIAL PERCENTAGE 10%
14 SPECIAL AWARD CREDIT
15 FREE GAME LIMIT 5
16 EXTRA BALL LIMIT 5
17 EXTRA BALL PERCENTAGE 25%
18 GAME PRICING USA 11
19 MATCH PERCENTAGE 9%
20 MATCH AWARD CREDIT
21 BALLS PER GAME 3
22 TILT WARNINGS 2
23 CREDIT LIMIT 30
24 ALLOW HIGH SCORES YES
25 HIGH SCORE AWARD CREDIT
26 GRAND CHAMPION AWARDS 1
27 HIGH SCORE #1 AWARDS 1
28 HIGH SCORE #2 AWARDS 0
29 HIGH SCORE #3 AWARDS 0
30 HIGH SCORE #4 AWARDS 0
31 GRAND CHAMPION SCORE 75,000,000
32 HIGH SCORE #1 55,000,000
33 HIGH SCORE #2 40,000,000
ID Adjustment Name Default Setting
34 HIGH SCORE #3 30,000,000
35 HIGH SCORE #4 25,000,000
36 HSTD INITIALS 3 INITIALS
37 HSTD RESET COUNT 2000
38 FREE PLAY NO
39 LANGUAGE ENGLISH
40 PLAYER LANGUAGE SELECT YES
41 CUSTOM MESSAGE ON
42 FLASH LAMP POWER NORMAL
43 COIL PUSLE POWER NORMAL
44 KNOCKER VOLUME NORMAL
45 GAME RESTART YES
46 BILL VALIDATOR NO
47 MUSIC VOLUME 1
48 BALL SAVE TIME 0:05
49 TIMED PLUNGER OFF
50 FLIPPER BALL LAUNCH OFF
51 COINDOOR BALL SAVER NO
52 COMPETITION MODE NO
53 CONSOLATION BALL YES
54 FAST BOOT YES
55 Q24 OPTION COIN METER
56 TICKET DISPENSER NO
57 PLAYER COMPETITION YES
58 TEAM SCORES NO
59 LOCATION ID 0
60 GAME ID 0
61 TIME FORMAT 12-HOUR
62 COIN INPUT DELAY 30
63 LOST BALL RECOVERY YES
64 COIN DOOR DISABLE TILT NO

SETUP AND MOVING
7
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
FEATURE ADJUSTMENTS
Each table has feature adjustments specic to the character-
istics of that game. To access feature adjustments enter the
Service Menu and then enter the Adjustments Menu.
Press SELECT to access the Service Menu. Press BACK to exit
or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the game icon. Press SELECT.
FEATURE ADJUSTMENT #1 appears with the adjustment name
ashing. With the adjustment name ashing press [<] [>] to
move between adjustments. Feature adjustments are changed
similarly to standard adjustments using the SELECT button to
choose options and the [<] [>] buttons to cycle through avail-
able settings.

8
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
1. SECURE THE BACKBOX
1. Ensure that the pinballs are re-
moved from the playeld, and se-
cure any free-moving mechanisms
that may get damaged in transport
2. Remove the backbox securing
bolts
3. Carefully lower the backbox onto
the side rails. Use a piece of card-
board or suitable padding between
the backbox and the game.
4. Securely strap the back box to the
game
5. The game may be transported with
the legs on. If the legs must be re-
moved, follow the remaining steps.
2. REMOVE THE LEGS AND
STAND UP
1.3 TRANSPORTING THE GAME
2
3
4
6. Remove the legs, rear legs rst. Use
a stool or a friend to support the
rear of the game.
7. Rest the rear of the game on the
ground.
6
CAUTION
NEVER TRANSPORT THE GAME
IN A MOVING VEHICLE WITH THE
BACKBOX RAISED! TWO PEOPLE
ARE REQUIRED TO REMOVE THE
LEGS!
10. Secure all loose parts and trans-
port with a hand truck in the
upright position.
8. Stand the game up on its back.
8
9. Remove the front two legs.
9
When transporting the game, such as in the back of a truck or with a hand truck, the
game’s backbox must be secured to prevent damage to the side rails.
TOOLS REQUIRED
• STRAP (500LB OR GREATER)
• AN ASSISTANT
• HAND TRUCK

SETUP AND MOVING
9
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
1.4 MAINTENANCE
REGULAR MAINTENANCE - (MONTHLY/500
GAMES)
• Remove the playeld glass
• Enter the software diagnostics menu, start lamp test, then
clean and wax the playeld.
• While cleaning the playeld, identify and repair malfunctioning
lights, loose parts, cracked plastics and worn rubber parts.
• While in diagnostics, enter the switch test (Select the "SW"
Icon, then "TEST" Icon).
• Use a pinball to actuate all switches and verify the correct
switch registers with the switch test.
• The game will play a sound to conrm the switch.
• Lift the playeld and inspect all assemblies for loose parts,
broken wires or excessive wear. Look at the bottom of the
cabinet for any parts that may have worked loose, then nd
the source.
• Check all coin door mechanisms and bill acceptor (if installed)
for proper operation
• Play the game to ensure all coils and features are working
• Check the playeld to ensure it is level and set to the proper
pitch using the bubble level on the right side wood rail.
• Check game audits: Replay % and Ball Time and note abnor-
mal values which can indicate problems.
• Ensure game volume is set appropriately for the location.
• Clean both sides of the playeld glass and reinstall.
• Check and clean pinballs and replace if excessively worn or
scuffed. Dirty pinballs accelerate game wear.
OVERHAUL MAINTENANCE (5000 GAMES)
• Verify latest game software is installed
• Check ippers for excessive wear. Excessive ipper sloppi-
ness (vertical or horizontal) or weakness indicates a ipper
rebuild is required.
• Clean machine inside and out and check leg levelers for free
operation.
• Visual check for loose or broken playeld and cabinet parts
and repair as necessary.
• Electrical check: Plug into grounded outlet and check for
proper operation through DIAGNOSTICS.
• Replace worn or dirty rubbers.
• Replace pinballs.
• Check all playeld switches with a pinball.
• Check all settings (refer to manual for factory settings).
• Check coin door: With door closed, insert coins to verify
proper operation.
• Check for proper adjustment of the plumb bob tilt.
• Play game: Check for satisfactory operation.
COMMON PINBALL TOOLS
• Common nut drivers (¼”, 5/16”, 11/32", ⅜”)
• Phillips screwdriver
• Standard Allen wrench/Hex key set
• ⅝” Socket with ratchet
• Adjustable wrench (5/8" & 9/16")
• 6" Torpedo Level (or use a pinball
• Flashlight or headlamp
• Soldering Iron (60w with at tip), lead-free solder
• Wire cutter
• Wire stripper
• Long nose (“needle nose”) pliers
1.5 MAINTENANCE KITS
Description Part Number
Iron Man Pro Vault Edition Maintenance Kit
8 oz pinball playeld wax (Novus # 2) (675-0003-01)
Standard Pinball (260-5000-00)
Cleaning Cloth
All Playeld Rubber Rings
Spare Fuses
502-6002-B0
Iron Man Pro Vault Edition Deluxe Maintenance Kit
All standard kit items, plus:
Flipper rebuild kits, Left and Right (500-6307-10,-00)
502-6003-B0
Iron Man Pro Vault Edition Playeld Plastics Kit 803-5000-B0
Iron Man Pro Vault Edition Playeld Decals Kit 802-5000-B0
Iron Man Pro Vault Edition Backbox Decal Left 820-66B0-01
Iron Man Pro Vault Edition Backbox Decal Right 820-66B0-02
Iron Man Pro Vault Edition Cabinet Decal Left 820-66B0-03
Iron Man Pro Vault Edition Cabinet Decal Right 820-66B0-04
Iron Man Pro Vault Edition Cabinet Decal Front 820-66B0-05
Iron Man Pro Vault Edition Playeld, Bare 830-5100-B0
Iron Man Pro Vault Edition Translite 830-52B0-00
1.6 COMMON PARTS
Description Part Number
8 oz Pinball Playeld wax (Novus # 2) 675-0003-01
Standard Pinball, 1-1/16 in 260-5000-00
Flipper Rebuild Kit Left (Standard) 500-6307-10
Flipper Base Plate Kit Left 515-6617-01
Flipper Rebuild Kit Right 500-6307-00
Flipper Base Plate Kit Right 515-6617-00

10
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
1.7 UPDATING GAME CODE FOR THE S.A.M. SYSTEM
Game code is subject to change. Update this game with the latest code downloaded from our website, from another game, or order
from your local distributor.
Upon powering up, the display will describe the version of code installed in your game. When directed to do so (via Service Bulletin or
website announcment) you will need to update your code with the boot ash EPROM installed, here’s how:
STEP 1
Open the backbox and locate the 8-position DIP switch (SW1 on
the CPI/Sound board)
STEP 2
Switch DIP switch #8 to ‘ON’ (Boot ash EPROM must be in-
stalled)
STEP 3
Press the white reset button (S1 RESET on the CPU/Sound
board) or power cycle the game OFF/ON (ON/OFF switch is
located on the outside of the cabinet bottom, front right).
STEP 4
Using the 4-button service switch set (inside the coin door):
4A: Press [SELECT] to begin.
4B: With the “UPDT” icon highlighted, press [SELECT].
4C: Insert the memory stick (with the latest les) into the USB
port.
4D: If more than one le is present on the memory stick, press [<]
or [>] to locate your le. Press [SELECT] to update.
4E: Follow on-screen prompts.
GreenButton
Press to escape
back (or exit)
RedButtons
Press to move <Left, Right>.
Press to - Decrease or +
Increase values or to change
settings.
CPU/SOUND BOARD (S.A.M. SYSTEM)

SETUP AND MOVING
11
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
1.8 FUSES AND CABINET SWITCHES
FOR PROPER OPERATION OF THIS
PINBALL GAME, <4> PINBALLS MUST
BE INSTALLED IN THE 4-BALL TROUGH!

12
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
1.9 SERVICE SWITCH & CPU DIP SWITCH SETTINGS
SERVICE SWITCH X4 SET OVERVIEW
The fours buttons (inside the coin door) have dual functions
depending on if you have entered the Service Menu or not.
Open the coin door to access the service switch X4 set.
FUNCTIONS IN GAME OR ATTRACT MODE
FUNCTIONS IN THE SERVICE MENU
GreenButton
Press for
Service
Credit(s).
RedButtons
Press for Volume
Adjustment
- for less (quieter)
+ for more (louder)
BlackButton
Press for
Service Menu
entry.
GreenButton
Press to Escape
Back (or Exit).
RedButtons
Press to move
< Left , Right >
Press to - Decrease
or + Increase
values or to change
settings.
BlackButton
Press to Enter
Select (or
‘OK’).
EXAMPLE
To enter the Service Menu, then enter the Switch Test Menu via
the Diagnostics Menu, perform the below steps.
STEP 1
Press [Select].
STEP 2
With the “DIAG” icon hightlighted, press [Select].
STEP 3
With the “SW” icon highlighted, press [Select].
STEP 4
With the “TEST” icon highlighted, press [Select].
Press any switch. If wired correctly, the information in the display
will match the information in the Switch Matrix.
Press [<] or [>] to move left or right through the menus.
Press [Back] to get back a menu, exit, or escape at any time.

SETUP AND MOVING
13
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
1.10 DIAGNOSTIC AIDS
1.11 CPU DIP SWITCH SETTINGS
This audible/visual alert display is shown when the 50V/20V power is
disabled (by opening the coin door). Pull out the interlock switch only while
in the service menu for coil, switch, or play testing when the coin door is
required to stay open for service button use! Pulling out the power interlock
switch or pressing the ‘escape’ green [BACK] button will remove the alert
display. Initial display presentation is accompanied by 3 audible tones (the
bright display warning will go dim after approximately 30 seconds).
This alert display is shown momentarily during game mode or powering up
to alert the operator of a device malfunction (device or mechanism doesn’t
energize or is energized repeatedly). OPERATOR ALERT! works by moni-
toring any switch activated device that has the potential to trap a ball when
disabled (e.g. in the shooter lane, scoop, or eject holes, etc.). This alert
can also appear if a switch associated with a device (e.g. ball trough, auto
plunger, etc.) is stuck closed (caused by a switch jam or stuck ball); the
game will activate the device a predetermined number of times and if the problem is still detected, this device or switch will be
noted in Switch Alerts and/or Technical Alerts.
Upon entering the service menu, if an asterisk “ * ” is displayed after the
words “SERVICE MENU”, the game has detected possible fualty devices,
switched, and/or missing pinballs. Press either of the red buttons (short-
cut to the technical alerts menu) or continue into the service menu (press
the black button again), select the “DIAG” icon and “TECH” icon or the
technical alerts information.

14
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
USA & INTERNATIONAL (NON-EURO)
STANDARD PRICING SELECT TABLE
*

SETUP AND MOVING
15
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
EURO SUMMARY & INTERNATIONAL (EURO)
STANDARD PRICING SELECT TABLE
CPU/SOUND PCB
DIP SWITCH SW1
SETTING
COUNTRY
SETTING
OPTION(S)
COIN MECHANISMS (SWITCHES)PRICING SCHEME
Number of Plays (Credits) for Price Amount Shown
See "AppendixJ" for Coin Cards Examples& Info!
Requires SPI
C O INS T H R U . . . SLO T : Coin Card(s)
LEFTCENTERRIGHT4THPart Number
Pos. Default Highlighted EUR// EUROPEAN UNION EUROS // [ ]
ON SEEBE L O W Euro 1 1/0.50 755-5401-01-
Y
OFF S E T T I N G S Euro 2
1/0.50 2/1.00 3/1.505/2.00755-5401-02-
Y
Euro 1-12 are alternate settings for
countries using the Euro. Euro 3 1/0.503/1.00755-5401-03-
Y
Euro 4 1/0.50 2/1.00 3/1.506/2.00755-5401-04-
Y
=Factory Default
= Not Shown on Coin
Card
Euro 5 optional 1/0.50 3/1.00 4/1.507/2.00755-5401-05-
Y
Euro 6 2/0.50755-5401-06-
Y
Euro 7 1/1.00 2/2.003/3.005/4.00755-5401-07-
Y
Euro 8 optional1/1.003/2.00755-5401-08-
Y
Euro 9 1/1.002/1.503/2.00755-5401-09-
Y
Euro 10 1/1.003/2.007/3.00755-5401-10-
Y
Euro 11 1/1.004/2.00755-5401-11-
Y
Euro 12 2/1.004/2.006/3.009/4.00755-5401-12-
Y
For a differentEuro Pricing Scheme (other than Factory Default listed below), scroll through Standard Adjustment 18:
Euro 1-12 or CUSTOM*for new setting (reference above Euro 1-12 Summary). Keep the Country Dip Switch Setting the same as listed below.
Pos. Default Highlighted EUR// EUROPEAN UNION EUROS // [ ]
ON AUSTRIA755-5401-09-
Y
OFF Euro 9
Pos. Default Highlighted
ON BELGIUM755-5401-01-
Y
OFF Euro 1
Pos. Default Highlighted
ON FINLAND755-5401-08-
Y
OFF Euro 8
Pos. Default Highlighted
ON FRANCE755-5401-10-
Y
OFF Euro 10
Pos. Default Highlighted
ON GERMANY 1 1/0.50755-5401-01-
Y
OFF GERMANY 2
1/0.50 2/1.00 3/1.505/2.00755-5401-02-
Y
GERMANY 3 1/0.50 2/1.00 3/1.506/2.00755-5401-04-
Y
Pos. Default Highlighted
ON GREECE 3/2.00755-5401-08-
Y
OFF Euro 8
Pos. Default Highlighted
ON ITALY 1 1/0.50755-5401-01-
Y
OFF ITALY 2 1/1.003/2.00755-5401-08-
Y
Pos. Default Highlighted
ON NETHERLANDS 755-5401-03-
Y
OFF Euro 3
Pos. Default Highlighted
ON PORTUGAL 755-5401-01-
Y
OFF
Pos. Default Highlighted
ON SPAIN755-5401-08-
Y
OFF Euro 8
=Factory Default =Not Shown on Coin Card
HIGHLIGHTED
HIGHLIGHTED
HIGHLIGHTED
HIGHLIGHTED

16
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
180-5119-02
Below P/F
SW.
180-5119-02
below playfield
SW.
180-5119-02
below playfield
SW. SW. SW. SW.
180-5157-01
below playfield
SW.
500-6227-04
below playfield
SW.
500-6227-03
below playfield
SW.
180-5054-00
2 per Asm.
SW.
180-5054-00
2 per Asm.
SW.
500-6227-03
below playfield
SW.
500-6227-04
below playfield
SW. SW. SW.
RESERVED
( )4-BALL
TROUGH
#4 (L) TROUGH
#3
( )
4-BALL TROUGH
#2
( )
4-BALL TROUGH
#1 (R)
( )
VUK OPTO TROUGH
JAM
( )
STACK OPTO SHOOTER
LANE
LEFT
SLING-
SHOT
RIGHT
SLING-
SHOT LEFT
BUMPER RIGHT
BUMPER BOTTOM
BUMPER
SW.
WHT-BRN
J6-P9
IC-U22A
180-5010-04
below playfield
SW.
01
Q1
GRN-BRN
J1-P1
DRIVE
CPU/
Sound
Board WHT-RED
J6-P8
IC-U22B
02
180-5010-04
below playfield
SW.
Q2
GRN-RED
J1-P3
DRIVE
Q3
GRN-ORG
J1-P4
DRIVE
Q4
GRN-YEL
J1-P5
DRIVE
WHT-ORG
J6-P7
IC-U22C
03
WHT-YEL
J6-P6
IC-U22D
04
WHT-GRN
J6-P5
IC-U16A
05
WHT-BLU
J6-P3
IC-U16B
06
WHT-VIO
J6-P2
IC-U16C
07
WHT-GRY
J6-P1
IC-U16D
08
TAN-BLK
J12-P9
IC-U36A
09
TAN-RED
J12-P8
IC-U B36
10
TAN-ORG
J12-P7
IC-U C36
11
TAN-YEL
J12-P6
IC-U D36
12
TAN-GRN
J12-P4
IC-U40A
13
TAN-BLU
J12-P3
IC-U B40
14
TAN-VIO
J12-P2
IC-U C40
15
TAN-WHT
J12-P1
IC-U D40
16
SW.
520-5292-00
below playfield
SW. SW. SW.
ORBIT
ROLLOVER
LEFT
500-6227-03
above playfield
SW. SW.
500-6227-04
below playfield
SW. SW.
180-5010-04
above playfield
SW.
180-5087-00
above playfield
SW. SW. SW.
TOURNA-
MENT
START
180-5174-00
In Cabinet
CABINET
SW.
START
BUTTON
SW.
# 1 # 2 # 3 # 4 # 5 # 6 # 7 # 8 # 9 # 10 # 11 # 12 # 13 # 14 # 15 # 16
180-5174-00
In Cabinet
RETURN
180-5119-02
below playfield
RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN RETURN
« D.O.T.S. »
01 02 03 04
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » CABINET
NOT USED « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. »
IRONMAN
#4 TOP IRONMAN
#3 IRONMAN
#2 IRONMAN
#1
RIGHT
RAMP
EXIT
TOP
LANES
LEFT
515-6227-04
below playfield
IRONMAN
#5 TOP
515-7568-02
below playfield
IRONMAN
#6
515-7568-02
below playfield 515-7568-02
below playfield 180-5087-00
above playfield
DRONE
GROUND
515-7581-05
below playfield 515-7581-05
below playfield 515-7581-05
below playfield
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. »« D.O.T.S. »
515-7568-06
below playfield 515-7568-06
below playfield
SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW.
LEFT
RAMP
180-5087-00
above playfield 515-7581-05
below playfield
NOT
USED
180-0000-00
a / b playfield
NOT
USED
180-0000-00
a / b playfield
NOT
USED
180-0000-00
a / b playfield
NOT
USED
180-0000-00
a / b playfield
NOT
USED
180-0000-00
a / b playfield
NOT
USED
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. »
« D.O.T.S. » 180-0000-00
a/bplayfield
SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW. SW.
# 49 # 50 # 51 # 52 # 53 # 54 # 55 # 56 # 57 # 58 # 59 # 60 # 61 # 62 # 63 # 64
SW. D-17
502-5032-00
Optional Kit
SW. D-18
180-0000-00
a/b playfield
SW. D-19 SW. D-20 SW. D-21 SW. D-22
180-5192-02
Coin Door
SW. D-23
180-5192-00
Coin Door
SW. D-24
TILT
PENDULUM
(PLUMB BOB)SLAM
TILT TICKET
NOTCH NOT
USED
X
BACK
(GREEN
BUTTON)
MINUS
(</– RED
BUTTON)
XPLUS
(+/>RED
BUTTON)
XSELECT
(BLACK
BUTTON)
X
PNK-BRN
J2-P2
LEFT
COIN
SLOT
180-5204-00
Coin Door
SW. D-1
-RED
J2-P3
PNK
CENTER
COIN
SLOT
180-5204-00
Coin Door
SW. D-2
-ORG
J2-P4
PNK -YEL
J2-P6
PNK -GRN
J2-P7
PNK -BLU
J2-P8
PNK -VIO
J2-P9
PNK -GRY
J2-P10
PNK GRY-BRN
J3-P1 -RED
J3-P2
GRY -ORG
J3-P4
GRY -YEL
J3-P5
GRY -GRN
J3-P6
GRY -BLU
J3-P7
GRY -VIO
J3-P8
GRY -BLK
J3-P9
GRY
RIGHT
COIN
SLOT
180-5204-00
Coin Door
SW. D-3
FOURTH
COIN
SLOT
180-5204-00
Coin Door
SW. D-4
FIFTH
COIN
SLOT
180-0000-00
a/b playfield
SW. D-5
NOT
USED
180-0000-00
a/b playfield
SW. D-6
HOME
SWITCH
180-5160-01
Cabinet Side
SW. D-7
AWAY
SWITCH
180-5160-01
Cabinet Side
SW. D-8
L. (EFT)
FLIPPER
BUTTON
180-5160-01
Cabinet Side
SW. D-9
LEFT
FLIPPER
E.O.S.
180-5149-00
Flipper Asm.
SW. D-10
R. (IGHT)
FLIPPER
BUTTON
180-5164-01
Cabinet Side
SW. D-11
RIGHT
FLIPPER
E.O.S.
180-5149-00
Flipper Asm.
SW. D-12
NOT
USED
180-5160-01
Cabinet Side
SW. D-13
NOT
USED
180-5149-00
Flipper Asm.
SW. D-14
NOT
USED
SW. D-15
NOT
USED
SW. D-16
180-5192-04
Coin Door 180-5192-02
Coin Door
180-5119-02
Below P/F
NOT USED
LGN-BRN
J13-P1 -RED
J13-P3
LGN -ORG
J13-P4
LGN -YEL
J13-P5
LGN -BLK
J13-P6
LGN -BLU
J13-P7
LGN -VIO
J13-P8
LGN GRY
J13-P9
LGN-
TRANS. / REC.
TX
RX 515-0173-00
515-0174-00
TRANS. / REC.
TX
RX 515-0173-00
515-0174-00
NOT USED NOT USED NOT USED NOT USED IF USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USEDNOT USED
NOT USED OPTIONAL IF USED NOT USED NOT USED NOT USED NOT USED NOT USED
See Sec. 4,
Chp. 1, Pg. 63
for cab. parts
# 17 # 19 # 20 # 21 # 22 # 23 # 24 # 25 # 26 # 27 # 28 # 29 # 30 # 31 # 32
# 18
# 33 # 34 # 35 # 36 # 38 # 39 # 40 # 41 # 42 # 43 # 44 # 45 # 46 # 47 # 48
# 37
SWITCH MATRIXGRID[#1–#64]{Switch Locations:nextpage}
« D.O.T.S. »
GROUND
(BLK)
J2-P1/11
& J3-P10
GROUND
(BLK)
J13-P10
IC-U2 IC-U2
IC-41
IC-41
IC-U4
IC-U4
IC-41
IC-41 IC-41
IC-41 IC-41
IC-41 IC-41
IC-41 IC-41IC-41 IC-41IC-41 IC-41
IC-41
IC-U2
IC-U2 IC-U2IC-U2 IC-U2
IC-U2 IC-U2
IC-U2 IC-U2IC-U2 IC-U2IC-U2 IC-U2IC-U2 IC-U4
IC-U4 IC-U4
IC-U4 IC-U4IC-U4 IC-U4
IC-U4 IC-U4IC-U4 IC-U4
IC-U4 IC-U4
IC-U4
DedicatedSwitches[#D-1–#D-32]{DedicatedSwitch Locations:nextpage}
CPU/SND
Board
CPU/SND
Board
180-5015-04
below playfield 180-5015-04
below playfield 180-5015-04
below playfield
DIP
SWITCH
POSITION
ON/OFF
#1
DIP
SWITCH
POSITION
ON/OFF
#2
DIP
SWITCH
POSITION
ON/OFF
#3
DIP
SWITCH
POSITION
ON/OFF
#4
DIP
SWITCH
POSITION
ON/OFF
#5
DIP
SWITCH
POSITION
ON/OFF
#6
DIP
SWITCH
POSITION
ON/OFF
#7
DIP
SWITCH
POSITION
ON / OFF
#8
CPU/SOUND BD. SW1 DIP SWITCH (located between Connectors J3/J13)
SW. D-25 SW. D-26 SW. D-27 SW. D-28 SW. D-29 SW. D-30 SW. D-31 SW. D-32
BLK
Black YEL
Yellow
WHT
White
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
Brown
Blue
BLU GRY
Gray LGN
Light Grn. PNK
Pink TAN
Tan
Wire Color Abbreviations used: BLK
Black GRY
Gray LGN
Light Grn. PNK
Pink TAN
Tan WHT
White YEL
Yellow
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
BrownBlue
BLU
NOT
USED
NOT
USED
NOT
USED
NOT
USED
NOT
USED
NOT
USED
NOT
USED
ORBIT
ROLLOVER
RIGHT
IRONMAN
#7
RIGHT
RAMP
ENTER
SWITCH 1
(DOWN)
MOTOR
SWITCH 2
(UP)
MOTOR
SHOULDERS
MONGER L.
520-5292-00
below playfield 520-5292-00
below playfield
LEGS
MONGER
SHOULDERS
MONGER R. NOT
USED
MACHINE
OPTO
WAR
TRANS. / REC.
TX
RX 515-0215-00
515-0215-01
LEFT
RAMP
ENTER LANE
SPINNER
CENTER
ORBIT
SPINNER
RIGHT
ORBIT
SPINNER
LEFT
180-5010-04
above playfield 180-5010-04
above playfield
LEFT
OUTLANE LEFT
RETURN RIGHT
RETURN RIGHT
OUTLANE
500-6227-04
below playfield
180-5087-00
above playfield
515-7568-02
below playfield
515-7568-02
below playfield
515-7568-02
below playfield
515-7568-02
below playfield
TOP
LANES
RIGHT DRONE
AIR DRONE
TACTICAL
WHIPLASH
TARGET
LEFT
WHIPLASH
TARGET
RIGHT
EXIT DRONE
SEA NOT
USED
NOT
USED

SETUP AND MOVING
17
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
1.12 SWITCH LOCATIONS
Switch Menu: Switch, Active, Single, & Service

18
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
BLK
Black YEL
Yellow
WHT
White
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
Brown
Blue
BLU GRY
Gray
Wire Color Abbreviations used: BLK
Black GRY
Gray WHT
White YEL
Yellow
VIO
Violet
RED
Red
ORG
Orange
GRN
Green
BRN
BrownBlue
BLU
START
BUTTON
# 1
LED
TOURNAMENT
START BUTTON
# 2
LED
SHOOT
AGAIN
# 3
LED # 4
LED # 5
LED
RETURN LANE
# 6
LED # 7
LED
« D.O.T.S. » OPTIONAL
112-5033-08 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 8
LED
C. LANE
ARROW
# 9
LED
C. LANE
MONGER
# 10
LED
POP BUMPER
# 11
LED
TACTICAL
# 12
LED
DRONE
AIR
# 13
LED
LEFT RAMP
ARROW
# 14
LED
LEFT ORBIT
IRON MONGER
# 15
LED
« D.O.T.S. » « D.O.T.S. »
112-5033-08 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 16
LED
IRONMAN
#4 (TOP)
# 17
LED # 18
LED # 19
LED # 20
LED # 21
LED # 22
LED # 23
LED
LEFT RAMP
(200K)
« D.O.T.S. » « D.O.T.S. »
112-5033-08 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 24
LED
(100K)
LEFT RAMP
# 25
LED
RIGHT RAMP
ARROW
# 26
LED
SHIELD
# 27
LED
MONGE(R)
# 28
LED
MONG(E)R
# 29
LED
MON(G)ER
# 30
LED
MO(N)GER
# 31
LED
M(O)NGER
« D.O.T.S. » « D.O.T.S. »
112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 32
LED
(M)ONGER
# 33
LED BD
RIGHT LOOP
ARROW
# 34
LED BD
RIGHT ORBIT
IRON MONGER
# 35
LED BD
IRONMAN
#5 (TOP)
# 36
LED BD
IRONMAN
#6
# 37
LED BD
IRONMAN
#7
# 38
LED BD
RIGHT RAMP
(400K)
# 39
LED BD
RIGHT RAMP
(300K)
« D.O.T.S. » « D.O.T.S. »
112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 40
LED
# 41
LED BD # 42
LED BD # 43
LED BD # 44
LED BD
WIZARD MODE
WAR MACHINE
# 45
LED BD
WIZARD MODE
IRON MONGER
# 46
LED BD
WIZARD MODE
WHIPLASH
# 47
LED BD
WIZARD MODE
DRONES
« D.O.T.S. » « D.O.T.S. »
112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 48
LED
MARK
V
# 49
LED
MARK
IV
# 50
LED
MARK
III
# 51
LED
MARK
II
# 52
LED
MARK
I
# 53
LED
LEFT LOOP
ARROW
# 54
LED
MARK
VI
# 55
#555 Clear
SPECIAL
« D.O.T.S. » « D.O.T.S. »
112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. » 112-5033-08
# 56
#555 Clear
# 57
LED # 58
LED # 59
LED
LEFT
POP BUMPER
# 60
LED
RIGHT
POP BUMPER
# 61
LED
BOTTOM
POP BUMPER
# 62
LED
R. ORBIT LIGHT
POP BUMPER
# 63
LED
« D.O.T.S. » « D.O.T.S. »
112-5033-08 112-5033-08 « D.O.T.S. » 112-5033-08 112-5033-08 112-5033-08 112-5033-08 « D.O.T.S. » 112-5033-08 « D.O.T.S. »
# 64
# 65 # 66 # 67 # 68 # 69 # 70 # 71
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. » « D.O.T.S. »
# 72
# 73
Q33
RED-BRN
J12-P1
01
GROUND
Q34
RED-BLK
J12-P2
02
GROUND
Q35
RED-ORG
J12-P3
03
GROUND
Q36
RED-YEL
J12-P4
04
GROUND
Q37
RED-GRN
J12-P5
05
GROUND
Q38
RED-BLU
J12-P6
06
GROUND
Q39
RED-VIO
J12-P8
07
GROUND
Q40
RED-GRY
J12-P9
08
GROUND
Q41
RED-WHT
J12-P10
09
GROUND
Q42
RED
J12-P11
10
GROUND
#555 Clear # 74 # 75 # 76 # 77 # 78 # 79
#555 Clear # 80
#555 Clear
LAMP MATRIXGRID[#1–#80]{Lamp Locations:nextpage}
YEL-RED
J13-P8
IC-U16
02
YEL-ORG
J13-P7
IC-U15
03
YEL-BRN
J13-P9
IC-U17
01
18VDC
YEL-BLK
J13-P6
IC-U14
04
YEL-GRN
J13-P5
IC-U13
05
YEL-BLU
J13-P4
IC-U12
06
YEL-VIO
J13-P3
IC-U11
07
YEL-GRY
J13-P1
IC-U10
08
I/O
Power
Driver
Board
18VDC 18VDC 18VDC 18VDC 18VDC 18VDC 18VDC
« D.O.T.S. » « D.O.T.S. » « D.O.T.S. »
[ C. = CENTER ][L. = LEFT][ R. = RIGHT ]
112-5033-08
RIGHT
C. LANE DRONE
112-5033-08 112-5033-08
RIGHT RAMP
(200K)
112-5033-08
RIGHT RAMP
(100K) DRONE
GROUND WIZARD MODE
IRONMAN
LEFT
TOP LANES SEA
DRONES
RIGHT
TOP LANES
LEFT
OUTLANE LEFT
RETURN LANE RIGHT
OUTLANE EXTRA
BALL
LEFT ORBIT
POP BUMPER
IRONMAN
#3 IRONMAN
#2 IRONMAN
#1 (BOT) WAR
MACHINE LEFT RAMP
(400K) LEFT RAMP
(300K)

SETUP AND MOVING
19
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01
TM & © MARVEL
1.13 LAMP LOCATIONS
Lamp Menu: One, All, Row, Column, & Ordered

20
SETUP AND MOVING
IRON MAN PRO VAULT EDITION MANUAL 500-55B0-01 TM & © MARVEL
Drive
Transistor Driver Ouput PCB Power Line
Color Power Line
Connection Power Voltage Drive Transistor Control Line Color D.T. Control
Line Connect Coil GA-Turn or Bulb Type
#1 TROUGH UP-KICKER Q1
I/O
Power
Driver
YEL-VIO J10-P9/10 50VDC BRN-BLK J8-P126-1200
090-5044-ND
#2 AUTO LAUNCH Q2 YEL-VIO J10-P9/10 50VDC BRN-REDJ8-P323-8000
090-5001-ND
#3 IRON MONGER MAGNETQ3 VIO-YEL J10-P8 50VDC BRN-ORGJ8-P422-6500
090-5076-00
#4 WHIPLASH MAGNET Q4 VIO-YEL J10-P8 50VDC BRN-YELJ8-P522-650
090-5076-00
#5 WAR MACHINE KICK BACK Q5 YEL-VIO J10-P9/10 50VDC BRN-GRN J8-P6
#6 ORBIT UP-POST Q6 YEL-VIO J10-P9/10 BRN-BLU J8-P7
#7 Q7 BRN-VIOJ8-P8
#8 SHAKER MOTOR (OPTIONAL) Q8 RED-WHT J17-P7 50VDC BRN-GRY J8-P9
Drive
Transistor Driver Ouput PCB Power Line
Color Power Line
Connection Power Voltage Drive Transistor Control Line Color D.T. Control
Line Connect Coil GA-Turn or Bulb Type
#9 TOP LEFT POP BUMPER Q9
I/O
Power
Driver
YEL-VIO J10-P9/10 50VDC BLU-BRNJ9-P126-1200
090-5044-ND
#10 TOP RIGHT POP BUMPER Q10YEL-VIO J10-P9/10 50VDC BLU-REDJ9-P226-1200
090-5044-ND
#11 BOTTOM POP BUMPER Q11 YEL-VIO J10-P9/10 50VDC BLU-ORGJ9-P426-1200
090-5044-ND
#12 CENTER LANE UP-POST Q12YEL-VIO
J10-P9/10 50VDC BLU-YELJ9-P523-1200
#13 Q13BLU-GRNJ9-P6
#14 Q14BLU-BLK J9-P7
#15 LEFT FLIPPER (50v RED/YEL) Q15GRY-YEL~3A
Fuse~RED-YEL J10-P6/750VDC ORG-GRY J9-P8 22-900
#16 RIGHT FLIPPER (50v RED/YEL) Q16BLU-YEL~3A
Fuse~RED-YEL J10-P6/750VDC ORG-VIO J9-P9 23-1100
090-5030-ND
Drive
Transistor Driver Ouput PCB Power Line
Color Power Line
Connection Power Voltage Drive Transistor Control Line Color D.T. Control
Line Connect Coil GA-Turn or Bulb Type
#17 Q17
I/O
Power
Driver
VIO-BRNJ7-P2
#18 Q18VIO-REDJ7-P3
#19 IRON MONGER MOTOR Q19BROWN J7-P1 20VDC VIO-ORGJ7-P4
#20 POP BUMPER AREA FLASH Q20ORANGE J6-P10 20VDC VIO-YEL J7-P6
#21 LEFT RAMP (TOP) FLASH Q21ORANGE J6-P1020VDC VIO-GRN J7-P7 LED
113-5034-08
#22 Q22VIO-BLU J7-P8
#23 MONGER (CENTER LANE) FLASH Q23ORANGE J6-P1020VDC VIO-BLK J7-P9LED
113-5034-08
#24 OPTIONAL (e.g. COIN METER) Q24RED J16-P4-8 5VDC VIO-GRY J7-P10 Optional
5VDC
Coil Note: -ND means ’No Diode’. -00Bor -00Tcan be used for coil replacements, but the diode must be removed. Call for more info.
Drive
Transistor Driver Ouput PCB Power Line
Color Power Line
Connection Power Voltage Drive Transistor Control Line Color D.T. Control
Line Connect Coil GA-Turn or Bulb Type
#25 IRON MONGER FLASH (X2) Q25
I/O
Power
Driver
ORANGE J6-P1020VDC BLK-BRNJ6-P1LED
113-5034-08
#26 RIGHT RAMP (TOP) FLASH Q26ORANGE J6-P1020VDC BLK-REDJ6-P2LED
113-5034-08
#27 WAR MACHINE FLASH (X3) Q27ORANGE J6-P1020VDC BLK-ORGJ6-P3LED
113-5034-08
#28 IRON MONGER CHEST FLASH (X3) Q28ORANGE J6-P1020VDC BLK-YELJ6-P4LED
113-5034-08
#29 WHIPLASH FLASH (X2) Q29ORANGE J6-P1020VDC BLK-GRNJ6-P5LED
113-5034-05
#30 MARK VI FLASH (X2) Q30ORANGE J6-P1020VDC BLK-BLU J6-P6LED
113-5034-08
#31 LEFT RAMP BOTTOM FLASH Q31ORANGE J6-P1020VDC BLK-VIOJ6-P7LED
113-5034-08
#32 RIGHT RAMP BOTTOM FLASH Q32BLK-GRY J6-P8
Note:In Test Flash Lamps Menu ("Flash" Icon), only Flashers are tested in numeric order.
Drive Driver Power Line Power Line Power Drive Transistor D.T. Control Coil GA-Turn
23-800
090-5001-ND
50VDC 26-1200
090-5044-ND
502-5027-00
LED
113-5034-08
24VDC MTR
041-5107-00
RIGHT SLINGSHOT
LEFT SLINGSHOT
WAR MACHINE (FRONT) FLASH (X2)
090-5044-ND
090-5020-20-ND
BROWN 23-800
090-5001-ND
BROWN 23-800
090-5001-ND
J7-P1
J7-P1
20VDC
20VDC
ORANGE J6-P1020VDC LED
113-5034-08
ORANGE J6-P1020VDC LED
113-5034-08
