Stern AEROSMITH PRO User manual

AEROSMITH
SERVICE AND OPERATION MANUAL
Games congured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe UK, Australia).
Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA; each pinball machine has unique characteristics that make it a one-of-a-kind American-made
product. Each machine will have variations in appearance resulting from differences in the machine’s particular wood parts, individual silk screened art and mechanical
assemblies. Stern Pinball has inspected each game element to ensure it meets our quality standards.
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to certain visual images, in-
cluding ashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that can cause “photosensitive epileptic seizures”
due to certain visual images, ashing lights or patterns. Symptoms can include light-headedness, altered vision, eye or face twitching, jerking or shaking of arms or legs,
disorientation, confusion, momentary loss of awareness, and loss of consciousness or convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
1-800-KICKERS - [email protected]
www.sternpinball.com - facebook.com/sternpinball
MANUAL #780-50I5-00
AEROSMITH PRO #500-55I5-01
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.

2
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
TABLE OF CONTENTS
1. Setup and Moving .................................. 3
1.1 First-Time Setup Instructions ............................... 3
1.2 Adjustments Menu ............................................... 6
1.3 Transporting the Game ........................................ 7
1.4 Maintenance ........................................................ 8
1.5 Maintenance Kits ................................................. 8
1.6 Common Parts ..................................................... 8
2. SPIKE System and Node Guide ............ 9
2.1 SPIKE System Overview ...................................... 9
2.2 Node Bus Cabling ................................................ 9
2.3 System Power ...................................................... 9
2.4 SPIKE Node addresses ........................................ 9
2.5 SPIKE Node Programming................................. 10
2.6 SPIKE System Terminology ............................... 10
2.7 Common SPIKE Node Boards ........................... 10
3. Light, Switch, and Driver Reference... 11
3.1 SPIKE Node Boards ........................................... 11
3.2 Driver Reference ................................................ 11
3.3 Switch Reference ............................................... 13
3.4 Light Reference .................................................. 16
3.5 Motor Reference ................................................ 21
4. Electronic Pinouts and Schematics.... 22
4.1 SPIKE-2 CPU Node 0 ........................................ 22
4.2 Node 1 Cabinet .................................................. 24
4.3 Lower Playeld 48V Driver Pinout Node 8 ......... 25
4.4 Mid Upper Playeld 48V Driver Pinout Node 9 . . 26
4.5 Feature LED Board 8b ....................................... 27
4.6 Right LED Board 8c ........................................... 27
4.7 Left LED Board 8d ............................................. 28
4.8 Serial Motor Driver Board 8e ............................. 28
4.9 Center LED Board 9a ......................................... 29
4.10 Through Serial Opto Receiver Extension 8a ...... 29
4.11 Main Power Supply ............................................ 29
4.12 Power Distribution Board ................................... 30
4.13 Power Plug Wiring.............................................. 30
5. Parts Reference.................................... 31
5.1 Playeld Rubber Parts ....................................... 31
5.2 Rubber Size Chart .............................................. 31
5.3 Playeld Assemblies, Top .................................. 32
5.4 Playeld Assemblies, Bottom ............................ 33
5.5 Backbox Parts.................................................... 34
5.6 Speaker Panel Parts .......................................... 34
5.7 Cabinet Parts ..................................................... 35
5.8 Ball Shooter Assembly ....................................... 36
5.9 Auto Launch Assembly ...................................... 36
5.10 Ball Trough Assembly......................................... 37
5.11 40 Degree Kicker Assembly ............................... 37
5.12 40 Front Mold Assembly .................................... 37
5.13 Flipper Assembly, Left ........................................ 38
5.14 Flipper Assembly, Right ..................................... 38
5.15 Pop Bumper Assembly ...................................... 39
5.16 Eject VUK Assembly #1 ..................................... 40
5.17 Eject VUK Assembly #2 ..................................... 40
5.18 Riveted Assembly - BUTY 12 ............................ 41
5.19 Ball Guide Assembly 04 ..................................... 41
5.20 Buty Assembly 02 .............................................. 41
5.21 Buty Assembly 04 .............................................. 41
5.22 Buty Assembly 05 .............................................. 42
5.23 Buty Assembly 09 .............................................. 42
5.24 Buty Assembly 10 .............................................. 42
5.25 Buty Assembly 12 .............................................. 42
5.26 Buty Assembly 14 .............................................. 43
5.27 Buty Assembly 30 .............................................. 43
5.28 Buty Assembly 32 .............................................. 43
5.29 Buty Assembly 35 .............................................. 43
5.30 Buty Assembly 40 .............................................. 44
5.31 Buty Assembly 41 .............................................. 44
5.32 Pop Bumper Assembly ...................................... 44
5.33 Bumper Ring Top Assembly............................... 44
5.34 Toy Box Plate Assembly .................................... 45
5.35 Ark Slider-Crank Assembly ................................ 45
5.36 Toy Box Up Kicker Assembly ............................. 46
5.37 Gate Assembly ................................................... 46
5.38 Toy Box Tube Assembly ..................................... 46
5.39 Toy Box Bumper Assembly ................................ 46
5.40 Toy Box Front Plate Assembly ........................... 47
5.41 Back Panel Assembly ........................................ 47
5.42 Left Ramp Assembly .......................................... 47
5.43 Right Ramp Assembly ....................................... 47
6. Specications ....................................... 48
6.1 Game Dimensions .............................................. 48
6.2 Warranty ............................................................. 49
6.3 Warnings, Compliance, and Legal Notices ........ 49

1. SETUP AND MOVING
2
2
557
7
1
9
8
11
15
11
8
6
14
14
SETUP AND MOVING
3
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
1.1 FIRST-TIME
SETUP INSTRUCTIONS
CAUTION: AT LEAST TWO (2)
PEOPLE ARE REQUIRED TO
MOVE AND MANEUVER THE
GAME. USE PROPER MOVING
EQUIPMENT AND EXTREME
CARE WHILE HANDLING. STERN
PINBALL MACHINES WEIGH
OVER 250LBS BOXED.
TOOLS REQUIRED
• 5/8” Socket Wrench
• Utility Knife
• Snips
• An Assistant
Your brand new Stern Pinball Machine is
carefully packed for safety and security.
For your safety, exercise caution and use
the correct tools and sufcient help when
setting up your new game.
1. Locate the side labeled “TRUCK
THIS SIDE ONLY”. The bottom of
the game faces this side.
2. Open the top box aps by pulling
hard in an upward motion on each
ap. If the aps are taped, cut the
tape rst, taking care to avoid the
box staples.
3. Remove the four (4) foam pieces
and two (2) narrow box tubes
which contain the four (4) identical
legs with levelers.
4. DO NOT CUT STRAPPING YET.
Keep backbox secured in the
down position.
5. With the utility knife, carefully cut
down the left and right corners of
the box.
6. Let the face fall forward and
remove the entire side by carefully
cutting the bottom.
7. With the game still in its folded po-
sition, use a ⅝” wrench to loosen
and remove the 2 leg bolts on each
side of the front cabinet. Ensure
the leg levelers are screwed all the
way into the legs.
8. Install front legs using the bolts
removed from the cabinet. Secure
tightly.
9. Have someone help you carefully
set the game down on the front
legs.
10. Set aside the open box.
11. With a ⅝” socket wrench, loosen
and remove the 2 leg bolts on
each side of the rear cabinet, 4
total.
12. Using supports or two people,
prop the rear of the cabinet up.
13. Ensure the rear leg levelers are
screwed all the way into the legs.
14. Install rear legs using the 4 bolts
removed from step 11.

19
21
17
25
26
27
FIRST-TIME SETUP CONTINUED
27
4
SETUP AND MOVING
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
15. Cut nylon strapping and remove
protective strap corner guards.
16. Locate the factory keys, either on
the shooter rod or taped to the
playeld glass.
17. Using snips, cut the tie-wrap secur-
ing the keys if required. One set of
keys is for the front coin door, the
other set of keys is for accessing
components in the backbox.
18. Open the front coin door.
19. Reach into the game and remove
the retaining clip at the rear of the
cash box.
20. Remove the cash box lid by sliding
it toward you.
21. Store the backbox keys, if desired,
on the metal hook located in the
coin door.
22. Locate and remove the pinballs,
plumb bob, and backbox bolts
from the cash box.
23. Replace the cash box lid and
retaining clip for future use.
24. Locate the two (2) backbox bolts in
the cash box.
25. Carefully raise backbox to upright
position while ensuring that cables
are not pinched.
26. Use the ⅝” wrench to Install the
two (2) backbox bolts to secure the
backbox as indicated on the back
of the cabinet.
27. Reach inside the cabinet and lift
the two latches located on either
side of the coin door.
28. Remove the front top molding.
29. Remove the playeld glass by
sliding it toward you and carefully
place it in a safe location.
Remove all playeld shipping
tie downs, shipping blocks, and
packing foam, and follow any
game-specic unpacking instruc-
tions included in the playeld, if
present.
CAUTION: PLAYFIELD GLASS IS MADE FROM HIGH-STRENGTH TEMPERED
GLASS. TEMPERED GLASS IS SENSITIVE TO EXTREME TEMPERATURE SHIFTS
AND CORNER NICKS, WHICH CAN CAUSE THE GLASS TO FAIL CATASTROPHI-
CALLY. TAKE CARE TO STORE THE GLASS ON A SOFT, ROOM-TEMPERATURE
SURFACE AND PREVENT THE CORNERS FROM BEING DAMAGED.

SETUP AND MOVING
5
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
30. If pinballs were already installed into the lower ball
trough, remove them before lifting the playeld.
31. Grasp the lower arch between the ippers, and rmly
but gently pull directly up to raise the playeld 8 to 12
inches.
32. While holding the playeld up, pull the playeld toward
you until the two playeld supports are over the front
edge of the cabinet.
33. Rest the playeld on the front edge of the cabinet.
34. Raise the playeld and rest it against the backbox.
35. Visually inspect all cabinet cables and connector termi-
nations; ensure no wires or cables are pinched and that
cable harnesses are not pulled tight.
36. Locate the plumb bob in the parts bag in the cash box.
37. Slide plumb bob onto the hanger wire. Note: the vertical
position of the plumb bob affects tilt sensitivity - higher
makes the game more sensitive to tilting.
38. Tighten the thumb screw nger-tight.
39. Install the correct number of pinballs. Refer to the decal
on the lock down assembly for the correct number of
pinballs.
LOCATING, LEVELING, AND FINAL SETUP
1. Select a location that is indoors, out of direct sunlight,
and climate controlled. Excessive moisture/humidity
can cause long-term damage to your game.
2. Adjust the front or rear levelers as necessary to position
the playeld level bubble, located on the front right of
the playeld next to the shooter lane, to oat between
the two (2) black lines. This will place the playeld at the
recommended 6.5° pitch. Playeld angles greater than
6.5° can be achieved by turning out the rear leg level-
er(s) for increased difculty and faster gameplay.
3. Use a pinball to roll down the center of the playeld for
side-to-side leveling, or use an external bubble level,
digital level, or smartphone level app.
4. Plug into a grounded outlet and check for proper opera-
tion through DIAGNOSTICS.
5. Check the coin door: With the door closed, insert coins
to verify proper operation.
6. Play game: Check for satisfactory operation and adjust
game volume (push the Red Buttons inside the Coin
Door).
7. If desired, perform any game diagnostics, game adjust-
ments, and pricing settings at this time.
FIRST-TIME SETUP CONTINUED
SPIKE PINBALL SOFTWARE
UPDATE INSTRUCTIONS
1. Obtain game software update le (lename ends
in “.spk”) from www.sternpinball.com or from
authorized Stern distributor.
2. Place game software update le ( “.spk”) in root
directory of a blank FAT32-formatted USB ash
drive
3. Use backbox power switch to turn off game
4. Plug in USB ash drive to CPU board USB
connector (CN20 or CN21). Refer to www.
sternpinball.com
5. Turn on game
6. The game will automatically begin software
update
7. Select the correct .spk update le from list.
8. Press Enter on the service switches to start
update
9. When the display indicates “Update Complete”,
turn off game
10. Remove USB ash drive from CPU board
11. Turn game on to complete the update and play
pinball!
12. Detailed instructions and troubleshooting tips
are available in the game manual, www.sternpin-
ball.com and authorized Stern distributors.

6
SETUP AND MOVING
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
1.2 ADJUSTMENTS MENU
STANDARD ADJUSTMENTS
Perform the below steps to review the adjustments.
Enter the Service Menu, then enter the Standard Adjustments
Menu.
Press SELECT. Press BACK to exit or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the S.P.I. icon. Press SELECT.
STANDARD ADJUSTMENT #1 appears with the adjustment
name ashing. While the adjustment name is ashing press [<]
[>] to move between adjustments.
To change the adjustment setting press SELECT. While the
adjustment setting is ashing, press [<] [>] repeatedly until
the desired setting appears. Press the SELECT button to
“install” the change. The adjustment comment (bottom line) will
indicate if the factory default setting is selected or will display
INSTALLED if the change is not a factory default setting.
ID Adjustment Name Default Setting
1 REPLAY TYPE AUTO
2REPLAY PERCENTAGE 10%
3REPLAY AWARD CREDIT
4 REPLAY LEVELS 1
5 AUTO REPLAY START 20,000,000
6 DYNAMIC REPLAY START 60,000,000
7REPLAY LEVEL #1 15,000,000
8REPLAY LEVEL #2 30,000,000
9REPLAY LEVEL #3 45,000,000
10 REPLAY LEVEL #4 60,000,000
11 REPLAY BOOST YES
12 SPECIAL LIMIT 1
13 SPECIAL PERCENTAGE 10%
14 SPECIAL AWARD CREDIT
15 FREE GAME LIMIT 5
16 EXTRA BALL LIMIT 5
17 EXTRA BALL PERCENTAGE 25%
18 GAME PRICING USA 11
19 MATCH PERCENTAGE 9%
20 MATCH AWARD CREDIT
21 BALLS PER GAME 3
22 TILT WARNINGS 2
23 CREDIT LIMIT 30
24 ALLOW HIGH SCORES YES
25 HIGH SCORE AWARD CREDIT
26 GRAND CHAMPION AWARDS 1
27 HIGH SCORE #1 AWARDS 1
28 HIGH SCORE #2 AWARDS 0
29 HIGH SCORE #3 AWARDS 0
30 HIGH SCORE #4 AWARDS 0
31 GRAND CHAMPION SCORE 75,000,000
32 HIGH SCORE #1 55,000,000
33 HIGH SCORE #2 40,000,000
ID Adjustment Name Default Setting
34 HIGH SCORE #3 30,000,000
35 HIGH SCORE #4 25,000,000
36 HSTD INITIALS 3 INITIALS
37 HSTD RESET COUNT 2000
38 FREE PLAY NO
39 LANGUAGE ENGLISH
40 PLAYER LANGUAGE SELECT YES
41 CUSTOM MESSAGE ON
42 FLASH LAMP POWER NORMAL
43 COIL PUSLE POWER NORMAL
44 KNOCKER VOLUME NORMAL
45 GAME RESTART YES
46 BILL VALIDATOR NO
47 MUSIC VOLUME 1
48 BALL SAVE TIME 0:05
49 TIMED PLUNGER OFF
50 FLIPPER BALL LAUNCH OFF
51 COINDOOR BALL SAVER NO
52 COMPETITION MODE NO
53 CONSOLATION BALL YES
54 FAST BOOT YES
55 Q24 OPTION COIN METER
56 TICKET DISPENSER NO
57 PLAYER COMPETITION YES
58 TEAM SCORES NO
59 LOCATION ID 0
60 GAME ID 0
61 TIME FORMAT 12-HOUR
62 COIN INPUT DELAY 30
63 LOST BALL RECOVERY YES
64 COIN DOOR DISABLE TILT NO
65 BACKBOX BRIGHTNESS 100%
66 COIN DOOR OPEN B.BOX BRIGHTNESS 10%
FEATURE ADJUSTMENTS
Each table has feature adjustments specic to the
characteristics of that game. To access feature adjustments
enter the Service Menu and then enter the Adjustments Menu.
Press SELECT to access the Service Menu. Press BACK to exit
or escape at any time.
Press [>]. Go to the ADJ icon. Press SELECT.
Go to the game icon. Press SELECT.
FEATURE ADJUSTMENT #1 appears with the adjustment name
ashing. With the adjustment name ashing press [<] [>] to
move between adjustments. Feature adjustments are changed
similarly to standard adjustments using the SELECT button
to choose options and the [<] [>] buttons to cycle through
available settings.

SETUP AND MOVING
7
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
1. SECURE THE BACKBOX
1. Ensure that the pinballs are re-
moved from the playeld, and se-
cure any free-moving mechanisms
that may get damaged in transport
2. Remove the backbox securing
bolts
3. Carefully lower the backbox onto
the side rails. Use a piece of card-
board or suitable padding between
the backbox and the game.
4. Securely strap the back box to the
game
5. The game may be transported with
the legs on. If the legs must be re-
moved, follow the remaining steps.
2. REMOVE THE LEGS AND
STAND UP
1.3 TRANSPORTING THE GAME
2
3
4
6. Remove the legs, rear legs rst. Use
a stool or a friend to support the
rear of the game.
7. Rest the rear of the game on the
ground.
6
CAUTION
NEVER TRANSPORT THE GAME
IN A MOVING VEHICLE WITH THE
BACKBOX RAISED! TWO PEOPLE
ARE REQUIRED TO REMOVE THE
LEGS!
10. Secure all loose parts and trans-
port with a hand truck in the
upright position.
8. Stand the game up on its back.
8
9. Remove the front two legs.
9
When transporting the game, such as in the back of a truck or with a hand truck, the
game’s backbox must be secured to prevent damage to the side rails.
TOOLS REQUIRED
• STRAP (500LB OR GREATER)
• AN ASSISTANT
• HAND TRUCK

8
SETUP AND MOVING
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
1.4 MAINTENANCE
REGULAR MAINTENANCE - (MONTHLY/500
GAMES)
• Remove the playeld glass
• Enter the software diagnostics menu, start lamp test, then
clean and wax the playeld.
◊ While cleaning the playeld, identify and repair malfunction-
ing lights, loose parts, cracked plastics and worn rubber
parts.
• While in diagnostics, enter the switch test (Select the "SW"
Icon, then "TEST" Icon).
◊ Use a pinball to actuate all switches and verify the correct
switch registers with the switch test.
◊ The game will play a sound to conrm the switch.
• Lift the playeld and inspect all assemblies for loose parts,
broken wires or excessive wear. Look at the bottom of the
cabinet for any parts that may have worked loose, then nd
the source.
• Check all coin door mechanisms and bill acceptor (if in-
stalled) for proper operation
• Play the game to ensure all coils and features are working
• Check the playeld to ensure it is level and set to the prop-
er pitch using the bubble level on the right side wood rail.
• Check game audits: Replay % and Ball Time and note
abnormal values which can indicate problems.
• Ensure game volume is set appropriately for the location.
• Clean both sides of the playeld glass and reinstall.
• Check and clean pinballs and replace if excessively worn or
scuffed. Dirty pinballs accelerate game wear.
OVERHAUL MAINTENANCE - (5000 GAMES)
• Verify latest game software is installed
• Check ippers for excessive wear. Excessive ipper sloppi-
ness (vertical or horizontal) or weakness indicates a ipper
rebuild is required.
• Clean machine inside and out and check leg levelers for
free operation.
• Visual check for loose or broken playeld and cabinet parts
and repair as necessary.
• Electrical check: Plug into grounded outlet and check for
proper operation through DIAGNOSTICS.
• Replace worn or dirty rubbers.
• Replace pinballs.
• Check all playeld switches with a pinball.
• Check all settings (refer to manual for factory settings).
• Check coin door: With door closed, insert coins to verify
proper operation.
• Check for proper adjustment of the plumb bob tilt.
• Play game: Check for satisfactory operation.
COMMON PINBALL TOOLS
• Common nut drivers (¼”, 5/16”, 11/32", ⅜”)
• Phillips screwdriver
• Standard Allen wrench/Hex key set
• ⅝” Socket with ratchet
• Adjustable wrench (5/8" & 9/16")
• 6" Torpedo Level (or use a pinball
• Flashlight or headlamp
• Soldering Iron (60w with at tip), lead-free solder
• Wire cutter
• Wire stripper
• Long nose (“needle nose”) pliers
1.5 MAINTENANCE KITS
Description Part Number
Aerosmith Maintenance Kit
• 8 oz pinball playeld wax (Novus # 2)
(675-0003-01)
• Standard Pinball (260-5000-00)
• Cleaning Cloth
• All Playeld Rubber Rings
• Spare Fuses
502-6002-I5
Aerosmith Deluxe Maintenance Kit
• All standard kit items, plus:
• Flipper rebuild kits, Left and Right
(500-6307-10,-00)
502-6003-I5
Aerosmith Playeld Plastics Kit 803-5000-I5
Aerosmith Playeld Decals Kit 802-5000-I5
Aerosmith Backbox Decal Left 820-78I5-01
Aerosmith Backbox Decal Right 820-78I5-02
Aerosmith Cabinet Decal Left 820-78I5-03
Aerosmith Cabinet Decal Right 820-78I5-04
Aerosmith Cabinet Decal Front 820-78I5-05
Aerosmith Playeld, Bare 830-5000-I5
Aerosmith Translite 830-52I5-00
1.6 COMMON PARTS
Description Part Number
8 oz Pinball Playeld wax (Novus # 2) 675-0003-01
Standard Pinball, 1-1/16 in 260-5000-00
Flipper Rebuild Kit Left (Standard) 500-6307-10
Flipper Base Plate Kit Left 515-6617-01
Flipper Rebuild Kit Right 500-6307-00
Flipper Base Plate Kit Right 515-6617-00

SPIKE SYSTEM AND NODE GUIDE
9
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
2. SPIKE SYSTEM AND NODE GUIDE
2.1 SPIKE SYSTEM OVERVIEW
The SPIKE Pinball system is a rugged, distributed, and em-
bedded platform custom-designed for the rigors of the pinball
machine environment. SPIKE takes advantage of modern tech-
nologies to deliver an immersive pinball experience that supports
modern features, reduces cabling, and increases serviceability
and reliability.
A Stern Pinball machine based on the SPIKE system will have at
least two nodes networked together with the SPIKE node bus,
a custom industrial pinball control bus that is designed around
industry standards and optimized for the pinball environment.
The primary CPU node is networked to one or more input/output
nodes over standard Category 5 UTP (unshielded twisted pair)
ethernet cabling.
There are ve primary types of nodes that are found in the game.
• CPU node (Node 0) - The primary node that controls other
nodes in the system. Contains the primary game software
for the system and provides SPIKE node bus power for other
nodes.
• Cabinet 48V node (Node 1) - Specialized node with specic
inputs and outputs for coin doors, tilt mechanisms, and other
bottom-cabinet devices.
• 48V playeld node - Controls high power devices such
as coils and ashers, and also supports a few switch and
low-power outputs. Powered by the system 48V power sup-
ply.
• Light and switch node - High-density switch and low-power
LED outputs, bus-powered from the node bus. These boards
contain as many 32 switch inputs and light outputs.
• Node extensions - These sub-nodes add additional low-pow-
er input and outputs to a specic Power or I/O node and are
connected with simple serial bus.
2.2 NODE BUS CABLING
The SPIKE node bus utilizes standard Ethernet-style RJ45 8-pin
modular jacks, and off-the-shelf Category 5e or better ethernet
cabling. The node bus is electrically different from Ethernet and
does not utilize Ethernet or TCP/IP protocols or signaling stan-
dards. SPIKE nodes are not compatible with standard computer
networking equipment.
CAUTION: Plugging a SPIKE Node or CPU board into a standard
Ethernet port may damage one or both devices and void your
warranty.
2.3 SYSTEM POWER
The SPIKE System is powered from an 48V DC power supply
bus. Each SPIKE node converts this voltage to lower voltages
required by the node and its specic components. A SPIKE 48V
node typically controls high-power outputs such as game coil
mechanisms and high-brightness LEDs. These powered nodes
are supplied directly with 48V system power. SPIKE standard I/O
nodes are low-power nodes that read switch inputs and output to
standard-brightness LEDs. Standard I/O nodes use the node bus
power, which is supplied by the main CPU node over the node
bus modular jack connectors.
2.4 SPIKE NODE ADDRESSES
Each SPIKE node has a unique address ranging from 0 to 15. Not
all addresses are used in all games. Nodes can be of the same
part number, so the address is specied on the DIP switches on
each node. When replacing a node, be certain that the correct
address is set. Nodes can have 3-position and 4-position DIP
switches. Refer to the appropriate table to set the address for
each type of Node. The correct address for a node can be found
in the SPIKE node reference section of the manual or in the game
diagnostic software. Address 0 is reserved for the backbox CPU
node, where the game software resides. Address 1 is reserved for
the cabinet node, located inside the coin door. These two nodes
do not have DIP switches as their address is not congurable.
Address 1 2 3
8OFF OFF OFF
9OFF OFF ON
10 OFF ON OFF
11 OFF ON ON
12 ON OFF OFF
13 ON OFF ON
14 ON ON OFF
15 ON ON ON
SPIKE node addresses for nodes with 3-position DIP switches.
Addresses 0-7 are not used by SPIKE nodes with 3-position DIP
switches.
Address 1 2 3 4
8OFF OFF OFF OFF
9OFF OFF ON OFF
10 OFF ON OFF OFF
11 OFF ON ON OFF
12 ON OFF OFF OFF
13 ON OFF ON OFF
14 ON ON OFF OFF
15 ON ON ON OFF
SPIKE node addresses for nodes with 4-position DIP switches.
Addresses 0-7 are reserved for xed-function nodes and do not
require conguration.

10
SPIKE SYSTEM AND NODE GUIDE
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
SPIKE SYSTEM AND NODE GUIDE CONTINUED
2.5 SPIKE NODE PROGRAMMING
The SPIKE nodes are smart nodes that have on-board pro-
cessors and run embedded code. The nodes are programmed
automatically by the CPU node whenever software updates are
installed to the CPU. When replacing a node, the CPU node will
detect and update the node to the latest software with no user
intervention. Always replace nodes with the power to the game
turned OFF.
2.6 SPIKE SYSTEM TERMINOLOGY
MULTI GENERAL ILLUMINATION LIGHTING
General Illumination Lighting is two or more lights powered by
one control source. These are often a number of LEDs connect-
ed in parallel and the system controls these as one large LED. A
missing LED will not affect these circuits, however a shorted LED
can cause the entire string of LEDs to turn off.
SINGLE LIGHTS
Single lights and LEDs are direct-controlled from SPIKE node
boards. A common power source is grounded by individual
transistors to turn individual LEDs on and off. Groups of LEDs,
usually by node connector, share a common power source, so if
a group of LEDs is out, check the wiring for the power source.
FLASHERS
SPIKE games treat ashers the same as single LEDs that draw
more power. Flashers are controlled from the same circuits that
power regular lights.
DRIVERS
A driver is a circuit that controls a high power-device such as a
coil, magnet, or motor. Each device has a common 48V power
source that is then connected to ground by a dedicated control
transistor. Each driver is protected against shorting, static elec-
tricity, and over-current conditions. Take caution as 48V is always
present on a device even when it is not energized.
OPTOS
Certain types of optical switches (“optos”) require external signal
conditioning. For these optos, they will interface to a SPIKE node
via an opto signal conditioning board. Other optical switches
connect directly to the Spike node board.
System Protections
CAUTION: Unless explicitly directed by an Authorized Stern Re-
pair technician, perform ALL work on your pinball machine with
the power disabled!
INPUT/OUTPUT PROTECTIONS
SPIKE features built-in short-circuit, static electricity, and other
protections to maximize reliability. If an LED, coil or other device
shorts, it will be disabled but will not shut down the entire system
in most circumstances. Groups of LEDs, coils, and switches often
share common power supplies or other circuits, so it is possible
that a bad device will affect the group of related devices and
require removal or repair to x the group. The system diagnostics
will inform the technician of shorted or otherwise malfunctioning
devices whenever possible. While the system is protected against
permanent damage, it is strongly recommended to repair or
replace these bad components as soon as possible to minimize
downtime and maximize game earnings.
2.7 COMMON SPIKE NODE BOARDS
Description Type Part Number
SPIKE CPU Node Node 509-1000-00
Cabinet Node Node 520-6967-00
Playeld 48V Core-Driver Node Node 520-7017-72
Through Serial Opto Receiver Extension Extension 520-7001-00

LIGHT, SWITCH, AND DRIVER REFERENCE
11
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
3. LIGHT, SWITCH, AND DRIVER REFERENCE
3.1 SPIKE NODE BOARDS
CABINET
CABINET NODE 1
BACKBOX
CPU NODE 0
CN5 CN4
CN11 CN22
CN13
CN1
CN3
CN3
CN1
CN3
CN1
CN3
CN1
CN4
CN1
CN2
CN1
755-7512-I5 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
When replacing node boards,
ensure DIP address switches
are set correctly! PLAYFIELD REAR
PLAYFIELD FRONT
Node Bus Cable (RJ45)
Serial Data Cable
NODE BOARD ID INSTRUCTION SHEET
NODE 0
CN4
NODE 8b
NODE 8c
NODE 8d
NODE 8a
NODE 8
NODE 9
NODE 9a
NODE 8e
ID DIP Address Description Location Part Number
Node 0 n/a SPIKE 2 CPU Node Backbox 509-1000-00
Node 1 n/a Cabinet Node Cabinet 520-6967-72
Node 8 OFF-OFF-OFF-OFF Lower Playeld 48V Core-Driver Node Lower Playeld 520-7017-72
8a n/a Trough Serial Opto Receiver Extension Playeld 520-7001-00
8b n/a Feature LED Board Playeld 520-7004-00
8c n/a Right LED Board Playeld 520-7006-00
8d n/a Left LED Board Playeld 520-7005-00
8e n/a Serial Motor Driver Board Playeld 520-6996-00
Node 9 OFF-OFF-ON-OFF Playeld 48V Core-Driver Node Playeld 520-7017-72
9a n/a Center LED Board Playeld 520-7007-00
PRO
Continued on next page...
3.2 DRIVER REFERENCE
ID DIP Address Description Location Part Number
Node 0 n/a SPIKE 2 CPU Node /Wand Board Backbox 509-1000-00
Node 1 n/a Cabinet Node Cabinet 520-6967-72
Node 8 OFF-OFF-OFF-OFF Lower Playeld 48V Core-Driver Node Lower Playeld 520-7017-72
8a n/a Trough Serial Opto Receiver Extension Playeld 520-7001-00
8b n/a Feature LED Board Playeld 520-7004-00
8c n/a Right LED Board Playeld 520-7006-00
8d n/a Left LED Board Playeld 520-7005-00
8e n/a Serial Motor Driver Board Playeld 520-6996-00
Node 9 OFF-OFF-ON-OFF Playeld 48V Core-Driver Node Playeld 520-7017-72
9a n/a Center LED Board Playeld 520-7007-00
ID Name Node Connector Ret. Pin Ret. Wire Voltage V+ Pin V+ Color Location Type Address Part Number
1 Trough 8CN8 7ORG GRY 48V 4 GRY ORG Playeld Coil - 27-1500 8-DR-1 090-5004-ND
2Auto Plunger 8CN8 9ORG WHT 48V 6 GRY ORG Playeld Coil - 23-800 8-DR-4 090-5001-ND
3Left Flipper 8CN8 6 ORG YEL 48V 4 GRY ORG Playeld Coil - 23-1100 8-DR-5 090-5030-ND
4 Right Flipper 8CN8 5 ORG GRN 48V 6 GRY ORG Playeld Coil - 23-1100 8-DR-0 090-5030-ND
5 Left Slingshot 8CN8 11 ORG BLU 48V 1-4 GRY ORG Playeld Coil - 26-1200 8-DR-3 090-5044-ND

12
SPIKE SYSTEM AND NODE GUIDE
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
Figure 3.2.1. Playeld driver locations (top view).
DRIVER REFERENCE

SPIKE SYSTEM AND NODE GUIDE
13
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
3.3 SWITCH REFERENCE
Continued on next page...
DRIVER REFERENCE CONTINUED
ID Name Node Connector Ret. Pin Ret. Wire Voltage V+ Pin V+ Color Location Type Address Part Number
6 Right Slingshot 8CN8 10 ORG VIO 48V 1-4 GRY ORG Playeld Coil - 26-1200 8-DR-2 090-5044-ND
7Shaker Motor 1 CN2 1 BLU 48V 5 RED Cabinet Motor 1-DR-0 041-5029-04
8
9Left Scoop 8CN7 2YEL RED 48V 1 GRY ORG Playeld Coil - 26-1200 8-DR-8 090-5044-ND
10 Top Scoop 8CN7 3YEL BRN 48V 1 GRY ORG Playeld Coil - 26-1200 8-DR-6 090-5044-ND
11 Toy Box Lid-Power 9CN7 3ORG 48V 1 GRY BRN Playeld Coil - 23-620 9-DR-6 090-5083-06-
ND
12 Toy Box Lid-Hold 9CN7 4 YEL GRN 48V 1 GRY BRN Playeld Coil - 30-3900 9-DR-7 090-5083-06-
ND
13
14 Left Pop Bumper 9CN8 10 ORG BLK 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-2 090-5044-ND
15 Right Pop Bumper 9CN8 11 ORG BRN 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-3 090-5044-ND
16 Top Pop Bumper 9CN8 9ORG RED 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-4 090-5044-ND
17
18
19 Right Eject 9CN8 7YEL ORG 48V 1-4 GRY BRN Playeld Coil - 26-1200 9-DR-1 090-5044-ND
20
21 Toy Box Magnet 9CN8 5 BRN BLK 48V 1-4 GRY BRN Playeld Coil - 22-650 9-DR-0 511-5065-ND
22
23
24
25
26
27
28
29
30
31
32
33 Coin Meter 1 CN3 2BLK 12V 1 RED Cabinet Digital Out 1-DR-2 500-9946-00
34 Ticket Meter 1 CN4 2BLK 12V 1 RED Cabinet Digital Out 1-DR-3 500-9946-00
35 Ticket Dispenser 1 CN11 312V 1 Cabinet Digital Out 1-DR-4
ID Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
1 Left Outlane 8- CN11 4 LGN RED 11-12 BLK ORG Playeld Rollover 8-SW-17 500-9935-04
2Left Return Lane-Left 8- CN11 5 LGN ORG 11-12 BLK ORG Playeld Rollover 8-SW-18 500-9935-04
3Left Return Lane-Right 8- CN11 8LGN VIO 11-12 BLK ORG Playeld Rollover 8-SW-21 500-9935-04
4
5 Right Return Lane 8- CN11 6 LGN YEL 11-12 BLK ORG Playeld Rollover 8-SW-19 500-9935-03
6 Right Outlane 8- CN11 7LGN BLU 11-12 BLK ORG Playeld Rollover 8-SW-20 500-9935-04
7Left Slingshot 8- CN10 4 GRY BLU 8BLK GRN Playeld Leaf 8-SW-30 180-5231-00
8Right Slingshot 8- CN10 3GRY VIO 8BLK GRN Playeld Leaf 8-SW-29 180-5231-00
9Left Flipper Button 8- CN9 4 GRY BRN 7BLK GRN Cabinet Leaf 8-SW-25 180-5160-01
10 Right Flipper Button 8- CN9 3GRY RED 7BLK GRN Cabinet Leaf 8-SW-24 180-5160-01
11 Left Flipper EOS 8- CN10 6 GRY YEL 9BLK GRN Playeld Leaf 8-SW-16 180-5149-00
12 Right Flipper EOS 8- CN10 5 GRY GRN 9BLK GRN Playeld Leaf 8-SW-31 180-5149-00
13
14
15 Trough 6 8 8a CN14 - -Playeld Opto 8-SW-32 520-5344-00 tx
520-7001-00 rx
16 Trough 5 8 8a CN14 - -Playeld Opto 8-SW-33 520-5344-00 tx
520-7001-00 rx

14
SPIKE SYSTEM AND NODE GUIDE
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
SWITCH REFERENCE CONTINUED
Continued on next page...
ID Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
17 Trough 4 8 8a CN14 - -Playeld Opto 8-SW-34 520-5344-00 tx
520-7001-00 rx
18 Trough 3 8 8a CN14 - -Playeld Opto 8-SW-35 520-5344-00 tx
520-7001-00 rx
19 Trough 2 8 8a CN14 - -Playeld Opto 8-SW-36 520-5344-00 tx
520-7001-00 rx
20 Trough 1 8 8a CN14 - -Playeld Opto 8-SW-37 520-5344-00 tx
520-7001-00 rx
21 Trough Jam 8 8a CN14 - -Playeld Opto 8-SW-38 520-5344-00 tx
520-7001-00 rx
22 Shooter Lane 8- CN10 2GRY WHT 7BLK GRN Playeld Rollover 8-SW-28 180-5157-01
23
24 (A)EROSMITH Target 8- CN11 2LGN BLK 11-12 BLK ORG Playeld Leaf, Target 8-SW-26 515-9783-00-00
25 A(E)ROSMITH Target 8- CN11 9LGN GRY 11-12 BLK ORG Playeld Leaf, Target 8-SW-22 515-9783-00-00
26 AE(R)OSMITH Target 8- CN11 8LGN WHT 11-12 BLK ORG Playeld Leaf, Target 8-SW-23 515-9783-00-00
27
28 Left Scoop 8- CN12 2WHT BRN 10 BLK RED Playeld Micro 8-SW-8 180-5209-00
29 Toy Box Enter 1 9- CN13 2WHT RED 10 BLK GRY Playeld Opto 9-SW-0 520-7036-00 tx
520-7037-00 rx
30 Toy Box Enter 2 9- CN13 3WHT ORG 10 BLK GRY Playeld Opto 9-SW-1 520-7036-00 tx
520-7037-00 rx
31 Toy Box Enter 3 9- CN13 4 WHT YEL 10 BLK GRY Playeld Opto 9-SW-2 520-7036-00 tx
520-7037-00 rx
32 Toy Box Lid 9- CN13 5 WHT GRN 10 BLK GRY Playeld Micro 9-SW-3 180-5119-02
33 AEROSMIT(H) Target 8- CN12 6 WHT GRN 10 BLK RED Playeld Leaf, Target 8-SW-12 515-9783-00-00
34 AEROSMI(T)H Target 8- CN12 7WHT BLU 10 BLK RED Playeld Leaf, Target 8-SW-13 515-9783-00-00
35 AEROSM(I)TH Target 8- CN12 8WHT VIO 10 BLK RED Playeld Leaf, Target 8-SW-14 515-9783-00-00
36 AEROS(M)ITH Target 8- CN12 9WHT GRY 10 BLK RED Playeld Leaf, Target 8-SW-15 515-9783-00-00
37
38 Spinner 8- CN13 2PNK BLK 10 BLK BRN Playeld Micro 8-SW-0 180-5010-04
39 Motor Home 8- CN13 3PNK BRN 10 BLK BRN Playeld Micro 8-SW-1 180-5010-04
40 Motor Away 8- CN13 4 PNK RED 10 BLK BRN Playeld Micro 8-SW-2 180-5010-04
41 Top Scoop 8- CN13 5 PNK ORG 10 BLK BRN Playeld Micro 8-SW-3 180-5209-00
42
43
44
45 Left Pop Bumper 9- CN10 2GRY BLK 7-9 BLK YEL Playeld Leaf 9-SW-28 180-5232-00
46 Right Pop Bumper 9- CN10 3GRY BRN 7-9 BLK YEL Playeld Leaf 9-SW-29 180-5232-00
47 Top Pop Bumper 9- CN10 4 GRY RED 7-9 BLK YEL Playeld Leaf 9-SW-30 180-5232-00
48
49 AER(O)SMITH Target 9- CN11 4 TAN ORG 11-12 BLK BLU Playeld Leaf, Target 9-SW-17 515-9785-00-00
50 AERO(S)MITH Target 9- CN11 5 TAN YEL 11-12 BLK BLU Playeld Leaf, Target 9-SW-18 515-9785-00-00
51
52 Left Orbit 9- CN10 5 GRY ORG 7-9 BLK YEL Playeld Rollover 9-SW-31 500-9935-04
53 Left Ramp Exit 9-CN11 8TAN VIO 11-12 BLK BLU Playeld Micro 9-SW-21 180-5087-00
54
55
56 Toy Box Hit 9- CN10 6 GRY 7-9 BLK YEL Playeld Opto 9-SW-16 515-0215-00 tx
515-0215-01 rx
57 Toy Box Target-Left 9- CN11 2TAN BLK 11-12 BLK BLU Playeld Leaf, Target 9-SW-26 515-9785-00-00
58 Toy Box Target-Right 9- CN11 3TAN RED 11-12 BLK BLU Playeld Leaf, Target 9-SW-27 515-9785-00-00
59
60
61 Right Eject 9- CN11 6 TAN GRN 11-12 BLK BLU Playeld Micro 9-SW-19 180-5186-01

SPIKE SYSTEM AND NODE GUIDE
15
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
SWITCH REFERENCE CONTINUED
Continued on next page...
Figure 3.3.1. Playeld switch locations (top view).

16
SPIKE SYSTEM AND NODE GUIDE
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
SWITCH REFERENCE CONTINUED
ID Name Node Node
Ext
Conn. Input
Pin
Input Wire GND
Pin
Ground Wire Location Type Address Part Number
62 Right Orbit 9- CN11 7TAN BLU 11-12 BLK BLU Playeld Rollover 9-SW-20 500-9935-03
63 Right Ramp Exit 8- CN12 3WHT RED 10 BLK RED Playeld Micro 8-SW-9 180-5087-00
64
65
66
67
68
69
70 Lockdown Button 1 - CN7 8TAN WHT 5 BLK WHT Cabinet Leaf 1-SW-2 180-5218-00
71
72
73 Start Button 1 - CN6 10 GRY 5 BLK WHT Cabinet Micro 1-SW-11 180-5174-00
74 Tournament Start Button 1 - CN6 9GRY WHT 5 BLK WHT Cabinet Micro 1-SW-12 180-5174-00
75
76 Left Coin 1 - CN5 9PNK BRN 3BLK Cabinet Micro 1-SW-16 180-5204-00
77 Right Coin 1 - CN5 7PNK ORG 3BLK Cabinet Micro 1-SW-18 180-5204-00
78 Center Coin 1 - CN5 8PNK RED 3BLK Cabinet Micro 1-SW-17
79 Fourth Coin 1 - CN5 6 -Cabinet - 1-SW-19
80 Fifth Coin 1 - CN5 5 -Cabinet - 1-SW-20
81 Tilt Pendulum 1 - CN6 7WHT 5 BLK WHT Cabinet Plumb Bob 1-SW-14 516-0007-00
82 Sixth Coin 1 - CN9 5 -Cabinet - 1-SW-21
83 Ticket Notch 1 - CN11 5 -Cabinet - 1-SW-8
84 Slam Tilt 1 - CN5 4 LGN RED 3BLK Cabinet - 1-SW-22
85
86
87
88
89
91
92
93
C1 DIP 1 0 - - - -CPU Node 0-SW-0 -
C10 Service Plus 0 - CN25 3LGN VIO 6 BLK Coin Door 0-SW-9 180-5192-02
C11 Service Minus 0 - CN25 2LGN BLU 6 BLK Coin Door 0-SW-10 180-5192-02
C12 Service Back 0 - CN25 1 LGN BLK 6 BLK Coin Door 0-SW-11 180-5192-00
C24 DC Sense 0 - CN7 4 GRY RED 1 BLK - 0-SW-23 -
C17 Headphone Detect 0 - - - - - - Coin Door 0-SW-16 -
C18 Headphone Kit Cable
Detect
0 - CN3 5 BLK 4 BLK CPU Node 0-SW-17 -
C19 Volume Encoder 1 0 - CN3 6 WHT 1 DRAIN CPU Node 0-SW-18 -
C20 Volume Encoder 2 0 - CN3 7GRN 1 DRAIN CPU Node 0-SW-19 -
C2 DIP 2 0 - - - -CPU Node 0-SW-1 -
C3 DIP 3 0 - - - -CPU Node 0-SW-2 -
C4 DIP 4 0 - - - -CPU Node 0-SW-3 -
C5 DIP 5 0 - - - -CPU Node 0-SW-4 -
C6 DIP 6 0 - - - -CPU Node 0-SW-5 -
C7 DIP 7 0 - - - -CPU Node 0-SW-6 -
C8 DIP 8 0 - - - -CPU Node 0-SW-7 -
C9 Service Select 0 - CN25 4 LGN GRY 6 BLK Coin Door 0-SW-8 180-5192-04

SPIKE SYSTEM AND NODE GUIDE
17
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
3.4 LIGHT REFERENCE
Continued on next page...
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src. Wire Location Type Light
Color
Address Part Num-
ber
1 Coin Enable 1 - CN8 6 BLK GRY 2GRY RED Coin Door Digital Out 1-LP-0
2Start Button 1 - CN6 3YEL BRN 1 RED Cabinet Feature White 1-LP-2 112-5033-08
3Tournament Start 1 - CN6 2YEL RED 1 RED Cabinet Feature White 1-LP-3 112-5033-08
4 Lockdown Button-RED 1 - CN7 2RED WHT 1 RED Cabinet Feature RGB 1-LP-5 520-5333-00
5 Lockdown Button-GRN 1 - CN7 3GRN WHT 1 RED Cabinet Feature RGB 1-LP-4 520-5333-00
6 Lockdown Button-BLU 1 - CN7 4 BLU WHT 1 RED Cabinet Feature RGB 1-LP-7 520-5333-00
7
8
9
10
11 Left Outlane 8- CN14 6 ORG RED 7-8 YEL Playeld Feature White 8-LP-3 520-5307-00
12
13
14 Shoot Again 88b CN5 4 ORG WHT 1 RED Playeld Feature White 8-LP-19 520-5307-00
15 Last Child 88b - LED9 - - - Playeld Feature White 8-LP-16 520-7004-00
16 Walk This Way 88b - LED7 - - - Playeld Feature White 8-LP-14 520-7004-00
17 Same Old Song N Dance 88b - LED8 - - - Playeld Feature White 8-LP-15 520-7004-00
18 Sweet Emotion 88b - LED6 - - - Playeld Feature White 8-LP-13 520-7004-00
19 Dude Looks Like A Lady 88b - LED4 - - - Playeld Feature White 8-LP-11 520-7004-00
20 Back In The Saddle 88b - LED5 - - - Playeld Feature White 8-LP-12 520-7004-00
21 Rats In The Cellar 88b - LED3 - - - Playeld Feature White 8-LP-10 520-7004-00
22 Toys In The Attic 88b - LED1 - - - Playeld Feature White 8-LP-8 520-7004-00
23 Love In An Elevator-RED 88b - LED14 - - - Playeld Feature RGB 8-LP-23 520-7004-00
24 Love In An Elevator-GRN 88b - LED14 - - - Playeld Feature RGB 8-LP-22 520-7004-00
25 Love In An Elevator-BLU 88b - LED14 - - - Playeld Feature RGB 8-LP-21 520-7004-00
26
27 Right Outlane 8- CN14 3ORG BLU 7-8 YEL Playeld Feature White 8-LP-6 520-5307-00
28
29 (A)EROSMITH 88d - LED5 - - - Playeld Feature White 8-LP-38 520-7005-00
30 A(E)ROSMITH 88d - LED4 - - - Playeld Feature White 8-LP-37 520-7005-00
31 AE(R)OSMITH 88d - LED3 - - - Playeld Feature White 8-LP-36 520-7005-00
32 Left Scoop X 88d - LED8 - - - Playeld Feature White 8-LP-41 520-7005-00
33 Extra Ball 88d - LED7 - - - Playeld Feature White 8-LP-40 520-7005-00
34 Left Scoop-3 88d - LED6 - - - Playeld Feature White 8-LP-39 520-7005-00
35 Left Scoop Arrow-RED 88d - LED1 - - - Playeld Feature RGB 8-LP-34 520-7005-00
36 Left Scoop Arrow-GRN 88d - LED1 - - - Playeld Feature RGB 8-LP-33 520-7005-00
37 Left Scoop Arrow-BLU 88d - LED1 - - - Playeld Feature RGB 8-LP-32 520-7005-00
38 Left Scoop-Rect 88d - LED2 - - - Playeld Feature White 8-LP-35 520-7005-00
39 Bilboard-1 88d CN5 3BRN GRN 1 RED Playeld Feature White 8-LP-44 520-5307-00
40 Bilboard-2 88d CN5 4 BRN BLU 1 RED Playeld Feature White 8-LP-45 520-5307-00
41
42 AEROSMIT(H) 8 8c - LED1 - - - Playeld Feature White 8-LP-24 520-7006-00
43 AEROSMI(T)H 8 8c - LED2 - - - Playeld Feature White 8-LP-25 520-7006-00
44 AEROSM(I)TH 8 8c - LED3 - - - Playeld Feature White 8-LP-26 520-7006-00
45 AEROS(M)ITH 8 8c - LED4 - - - Playeld Feature White 8-LP-27 520-7006-00
46 Right Ramp X 8 8c CN3 3GRN YEL 1 RED Playeld Feature White 8-LP-30 520-5307-00
47
48
49
50
51
52 Left Pop Bumper-RED 9 9a CN3 4 RED BLK 1 RED Playeld Feature RGB 9-LP-42 520-6971-00
53 Left Pop Bumper-GRN 9 9a CN3 3GRN BLK 1 RED Playeld Feature RGB 9-LP-41 520-6971-00

18
SPIKE SYSTEM AND NODE GUIDE
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
LIGHT REFERENCE CONTINUED
Continued on next page...
Figure 3.4.1. Playeld light locations (top view).

SPIKE SYSTEM AND NODE GUIDE
19
© 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights. AEROSMITH PRO MANUAL 500-55I5-01
LIGHT REFERENCE CONTINUED
Continued on next page...
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src. Wire Location Type Light
Color
Address Part Num-
ber
54 Left Pop Bumper-BLU 9 9a CN3 2BLU BLK 1 RED Playeld Feature RGB 9-LP-40 520-6971-00
55 Right Pop Bumper-RED 9 9a CN3 7RED BRN 1 RED Playeld Feature RGB 9-LP-45 520-6971-00
56 Right Pop Bumper-GRN 9 9a CN3 6 GRN BRN 1 RED Playeld Feature RGB 9-LP-44 520-6971-00
57 Right Pop Bumper-BLU 9 9a CN3 5 BLU BRN 1 RED Playeld Feature RGB 9-LP-43 520-6971-00
58 Top Pop Bumper-RED 9 9a CN3 10 RED WHT 1 RED Playeld Feature RGB 9-LP-48 520-6971-00
59 Top Pop Bumper-GRN 9 9a CN3 9GRN RED 1 RED Playeld Feature RGB 9-LP-47 520-6971-00
60 Top Pop Bumper-BLU 9 9a CN3 8BLU RED 1 RED Playeld Feature RGB 9-LP-46 520-6971-00
61
62 Left Orbit Arrow-RED 9 9a CN4 7RED ORG 1 RED Playeld Feature RGB 9-LP-54 520-5333-00
63 Left Orbit Arrow-GRN 9 9a CN4 6 GRN ORG 1 RED Playeld Feature RGB 9-LP-53 520-5333-00
64 Left Orbit Arrow-BLU 9 9a CN4 5 BLU ORG 1 RED Playeld Feature RGB 9-LP-52 520-5333-00
65 Left Orbit-Elevator 88b CN7 4 ORG RED 1 RED Playeld Feature White 8-LP-9 520-5307-00
66
67 Left Orbit X 9 9a CN4 3BRN 1 RED Playeld Feature White 9-LP-50 520-5307-00
68
69 AER(O)SMITH 9 9a - LED1 - - - Playeld Feature White 9-LP-8 520-7007-00
70 AERO(S)MITH 9 9a - LED2 - - - Playeld Feature White 9-LP-9 520-7007-00
71
72 Toy Box Target-Left 9 9a CN4 2BRN BLK 1 RED Playeld Feature White 9-LP-49 520-5307-00
73 Toy Box Target-Right 9 9a - LED15 - - - Playeld Feature White 9-LP-22 520-7007-00
74
75 Lock 1 9 9a - LED10 - - - Playeld Feature White 9-LP-17 520-7007-00
76 Lock 2 9 9a - LED11 - - - Playeld Feature White 9-LP-18 520-7007-00
77 Lock 3 9 9a - LED12 - - - Playeld Feature White 9-LP-19 520-7007-00
78 Lock 4 9 9a - LED13 - - - Playeld Feature White 9-LP-20 520-7007-00
79 Lock 5 9 9a - LED14 - - - Playeld Feature White 9-LP-21 520-7007-00
80 Lock 6 9 9a - LED9 - - - Playeld Feature White 9-LP-16 520-7007-00
81 Toy Box Arrow-RED 9 9a - LED19 - - - Playeld Feature RGB 9-LP-32 520-7007-00
82 Toy Box Arrow-GRN 9 9a - LED19 - - - Playeld Feature RGB 9-LP-31 520-7007-00
83 Toy Box Arrow-BLU 9 9a - LED19 - - - Playeld Feature RGB 9-LP-30 520-7007-00
84 Toy Box X 9 9a - LED3 - - - Playeld Feature White 9-LP-10 520-7007-00
85
86 Left Ramp Arrow-RED 9 9a - LED21 - - - Playeld Feature RGB 9-LP-38 520-7007-00
87 Left Ramp Arrow-GRN 9 9a - LED21 - - - Playeld Feature RGB 9-LP-37 520-7007-00
88 Left Ramp Arrow-BLU 9 9a - LED21 - - - Playeld Feature RGB 9-LP-36 520-7007-00
89 Left Ramp X 9 9a - LED8 - - - Playeld Feature White 9-LP-15 520-7007-00
90
91 Top Scoop Arrow-RED 9 9a - LED20 - - - Playeld Feature RGB 9-LP-35 520-7007-00
92 Top Scoop Arrow-GRN 9 9a - LED20 - - - Playeld Feature RGB 9-LP-34 520-7007-00
93 Top Scoop Arrow-BLU 9 9a - LED20 - - - Playeld Feature RGB 9-LP-33 520-7007-00
94 Top Scoop-Rect 9 9a - LED7 - - - Playeld Feature White 9-LP-14 520-7007-00
95 Top Scoop X 9 9a - LED6 - - - Playeld Feature White 9-LP-13 520-7007-00
96
97 Right Eject Arrow-RED 9 9a - LED18 - - - Playeld Feature RGB 9-LP-29 520-7007-00
98 Right Eject Arrow-GRN 9 9a - LED18 - - - Playeld Feature RGB 9-LP-28 520-7007-00
99 Right Eject Arrow-BLU 9 9a - LED18 - - - Playeld Feature RGB 9-LP-27 520-7007-00
100 R Eject-2 9 9a - LED5 - - - Playeld Feature White 9-LP-12 520-7007-00
101 Right Eject X 9 9a - LED4 - - - Playeld Feature White 9-LP-11 520-7007-00
102
103 Right Ramp Arrow-RED 9 9a - LED17 - - - Playeld Feature RGB 9-LP-26 520-7007-00
104 Right Ramp Arrow-GRN 9 9a - LED17 - - - Playeld Feature RGB 9-LP-25 520-7007-00
105 Right Ramp Arrow-BLU 9 9a - LED17 - - - Playeld Feature RGB 9-LP-24 520-7007-00
106

20
SPIKE SYSTEM AND NODE GUIDE
AEROSMITH PRO MANUAL 500-55I5-01 © 2016 Rag Doll Merchandising, Inc. Under License to Epic Rights.
LIGHT REFERENCE CONTINUED
Continued on next page...
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src. Wire Location Type Light
Color
Address Part Num-
ber
107 Right Orbit Arrow-RED 9- CN14 6 RED YEL 7-8 YEL Playeld Feature RGB 9-LP-3 520-5333-00
108 Right Orbit Arrow-GRN 9- CN14 5 GRN YEL 7-8 YEL Playeld Feature RGB 9-LP-4 520-5333-00
109 Right Orbit Arrow-BLU 9- CN14 4 BLU YEL 7-8 YEL Playeld Feature RGB 9-LP-5 520-5333-00
110 Right Orbit-Elevator 88b CN7 5 ORG YEL 2RED Playeld Feature White 8-LP-20 520-5307-00
111
112 Right Orbit X 9- CN14 2BRN ORG 7-8 YEL Playeld Feature White 9-LP-7 520-5307-00
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130 Coin Door GI 1 - CN5 2YEL 1 YEL-WHT Coin Door G.I. White 1-LP-1 112-5033-08
131 Playeld GI-1 8- CN15 5 WHT BLK 1 YEL BLK Playeld G.I. White 8-LP-0 112-5034-08
132 Playeld GI-2 8- CN15 6 RED BLK 2YEL RED Playeld G.I. White 8-LP-1 112-5034-08
133 Playeld GI-3 9- CN15 5 BLU BLK 1 YEL BLU Playeld G.I. White 9-LP-0 112-5034-08
134 GI-Backpanel 9- CN15 6 GRN BLK 2YEL GRN Backpanel G.I. White 9-LP-1 112-5034-xx
135
136
137 Left Sling Flash 88b CN4 3ORG 1 RED Playeld Flash White 8-LP-18 520-7000-00
138 Right Sling Flash 88b CN2 3ORG 1 RED Playeld Flash White 8-LP-17 520-7000-00
139 Lower Left Flash 88d CN4 3ORG GRN 1 RED Playeld Flash White 8-LP-43 520-7000-00
140 Left Scoop Flash 88d CN2 3ORG BRN 1 RED Playeld Flash White 8-LP-42 113-5045-08
141 Right Orbit Flash 8 8c - LED5 - - - Playeld Flash White 8-LP-28 520-7006-00
142 Spinner Flash 8 8c CN2 3ORG BLK 1 RED Playeld Flash White 8-LP-29 113-5045-08
143 Right Ramp Flash 8 8c CN3 4 ORG GRY 1 RED Playeld Flash White 8-LP-31 520-7000-00
144 Pop Bumpers Flash 9 9a CN4 8YEL BRN 1 RED Playeld Flash White 9-LP-55 520-7000-00
145 Toy Box Lid Flash 9 9a CN5 2YEL ORG 1 RED Playeld Flash White 9-LP-56 113-5045-08
146 Toy Box Enter Flash (x2) 9 9a CN5 3YEL VIO 1 RED Playeld Flash White 9-LP-57 113-5045-08
147 Toy Box Flash (x2) 9 9a - LED22 - - - Playeld Flash White 9-LP-39 520-7007-00
148 Top Scoop Flash 9 9a CN5 4 YEL GRY 1 RED Playeld Flash White 9-LP-58 520-7000-00
149 Left Ramp Flash 9 9a - LED16 - - - Playeld Flash White 9-LP-23 520-7007-00
150 L Orbit-Rect 9 9a CN4 4 BRN RED 1 RED Playeld Flash White 9-LP-51 113-5045-08
151 R Orbit-Rect 9- CN14 3BRN YEL 7-8 YEL Playeld Flash White 9-LP-6 113-5045-08
152 Left Return Lane-Left 8- CN14 5 ORG 7-8 YEL Playeld Flash White 8-LP-4 113-5045-08
153 Left Return Lane-Right 8- CN14 2ORG VIO 7-8 YEL Playeld Flash White 8-LP-7 113-5045-08
154 Right Return Lane 8- CN14 4 ORG YEL 7-8 YEL Playeld Flash White 8-LP-5 113-5045-08
155 Upper Ramp Flash (x2) 9- CN15 7BRN WHT 3YEL Playeld Flash White 9-LP-2 520-7000-00
