STIEBEL ELTRON Ultronic-1 Plus Instruction Manual

OPERATION AND INSTALLATION
FUNCIONAMIENTO E INSTALACIÓN
FONCTIONNEMENT ET INSTALLATION
Touchless Automatic High-Speed Hand Dryers
Secadores de manos automáticos de alta velocidad sin contacto
Sèche-mains automatiques à haute vitesse sans contact
» Ultronic™-1 Plus
» Ultronic™-1 Premium
» Ultronic™-2 Plus
» Ultronic™-2 Premium
Certified to ANSI/UL Std. 50
Conforms to CAN/CSA Std. C22.2 No.113
Certificación con ANSI/UL Std. 50
Conforme a CAN/CSA Std. C22.2 No.113
Certifié à la norme ANSI/UL Std. 50
Conforme à la norme CAN/CSA Std. C22.2 No.113

2| Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
TABLE OF CONTENTS
SPECIAL INFORMATION
OPERATION
1. General information _________________________________________4
1.1 Safety instructions_______________________________________________ 4
1.2 Other symbols in this documentation _______________________ 5
1.3 Information on the appliance _________________________________ 5
1.4 Units of measurement __________________________________________ 5
2. Safety__________________________________________________________6
2.1 Intended use______________________________________________________ 6
2.2 General safety instructions ____________________________________ 6
2.3 Test mark__________________________________________________________ 7
3. Register your product _______________________________________7
4. Appliance description _______________________________________8
5. Operation _____________________________________________________8
6. Cleaning, care and maintenance ___________________________8
7. Troubleshooting ______________________________________________9
INSTALLATION
8. Safety________________________________________________________ 10
8.1 General safety instructions ___________________________________ 10
8.2 Instructions, standards and regulations ___________________ 10
9. Appliance description _____________________________________ 10
9.1 Standard delivery_______________________________________________ 10
10. Preparation _________________________________________________ 10
10.1 Installation site__________________________________________________ 10
10.2 Minimum clearances___________________________________________ 11
10.3 Guidelines for installation height____________________________ 11
11. Installation__________________________________________________ 12
11.1 Fitting the wall mounting bracket___________________________ 12
11.2 Electrical connection___________________________________________ 14
11.3 Opening the appliance_________________________________________15
11.4 Inserting the HEPA filter_______________________________________ 16
11.5 Activating/deactivating appliance functions ______________ 17
11.6 Fitting the casing cover________________________________________ 17
11.7 Installing the appliance________________________________________ 18
11.8 Appliance handover ____________________________________________ 18
12. Cleaning and maintenance ________________________________ 18
12.1 Cleaning __________________________________________________________ 19
12.2 Changing the HEPA filter ______________________________________ 19
13. Specification ________________________________________________ 20
13.1 Dimensions and connections_________________________________ 20
13.2 Data table ________________________________________________________ 21
WARRANTY
ENVIRONMENT AND RECYCLING
DRILLING TEMPLATE (IN THE CENTER SECTION OF THESE IN-
STRUCTIONS)

SPECIAL INFORMATION
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |3
SPECIAL INFORMATION
- Keep children under the age of3 away from
the appliance if constant supervision cannot
be guaranteed.
- Children from the age of 3 to 7 may switch
the appliance on and off, provided they are
supervised or have been instructed in the safe
operation of the appliance and understand
any risks that may result. This is subject to the
appliance having been installed as described.
Children from the age of 3 to 7 must not plug
the power cable into its socket or regulate the
appliance.
- The appliance may be used by children aged8
and older and persons with reduced physical,
sensory or mental capabilities or a lack of ex-
perience and know-how, provided that they
are supervised or they have been instructed
on how to use the appliance safely and have
understood the potential risks. Children must
never play with the appliance. Cleaning and
user maintenance must not be carried out by
children without supervision.
- Parts of the appliance can get very hot and
may cause burns. Particular caution is ad-
vised when children or vulnerable persons are
present.
- To prevent the appliance from overheating,
never cover it with anything.
- Never install the appliance directly below a
wall socket.

OPERATION
General information
4| Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
- In the case of a permanent connection, en-
sure the appliance can be separated from
the power supply by an isolator that discon-
nects all poles with at least 3mm contact
separation.
- The specified voltage must match the power
supply.
- The appliance must be connected to the
ground conductor.
- To prevent hazards, the power cable must
only be replaced (for example if damaged) by
a qualified contractor authorized by the man-
ufacturer, using an original spare part.
- Secure the appliance as described in chapter
"Installation/ Installation".
- This manual may also be downloaded at:
www.stiebel-eltron-usa.com/
installation-manuals
OPERATION
1. General information
The chapters "Special information" and "Operation" are intended
for appliance users and qualified contractors.
The chapter "Installation" is intended for qualified contractors.
Note Read these instructions carefully before using the appli-
ance and retain them for future reference.
Pass on these instructions to a new user if required.
1.1 Safety instructions
1.1.1 Structure of safety instructions
KEYWORD Type of risk Here, possible consequences are listed that may result
from failure to observe the safety instructions.
f Steps to prevent the risk are listed.

OPERATION
General information
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |5
1.1.2 Symbols, type of risk
Symbol Type of risk
Injury
Electrocution
Burns
(burns, scalding)
1.1.3 Signal words
Keyword Meaning
DANGER Failure to observe this information will result in serious
injury or death.
WARNING Failure to observe this information may result in serious
injury or death.
CAUTION Failure to observe this information may result in non-seri-
ous or minor injury.
1.2 Other symbols in this documentation
Note General information is identified by the adjacent symbol.
f Read these texts carefully.
Symbol Meaning
Property damage
(appliance damage, consequential losses and environmen-
tal pollution)
Appliance disposal
f This symbol indicates that you have to do something. The ac-
tion you need to take is described step by step.
1.3 Information on the appliance
Symbol Meaning
Never cover the appliance
1.4 Units of measurement
Note All measurements are given in inches (mm) unless stated
otherwise.

OPERATION
Safety
6| Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
2. Safety
2.1 Intended use
The appliance is used to dry wet hands.
The appliance is intended for domestic use. The unit can be used
safely by untrained persons. The appliance can also be used in
non-domestic environments, e.g.in commercial and industrial
applications, as long as it is used in the same way.
Any other use beyond that described shall be deemed inappro-
priate. Observation of these instructions and of the instructions
for any accessories used is also part of the correct use of this
appliance.
2.2 General safety instructions
CAUTION Burns -Do not lean any objects against the appliance.
-Never place any flammable, combustible or insulat-
ing objects or materials on the appliance or in direct
proximity to it.
-Ensure that the air intake and discharge on the un-
derside of the appliance are never blocked.
WARNING Electrocution Never insert any object into appliance openings.
!WARNING Injury
-Keep children under the age of3 away from the
appliance if constant supervision cannot be guar-
anteed.
-Children from the age of 3 to 7 may switch the ap-
pliance on and off, provided they are supervised
or have been instructed in the safe operation of
the appliance and understand any risks that may
result. This is subject to the appliance having been
installed as described. Children from the age of 3 to
7 must not plug the power cable into its socket or
regulate the appliance.
-The appliance may be used by children aged8 and
older and persons with reduced physical, sensory
or mental capabilities or a lack of experience and
know-how, provided that they are supervised or
they have been instructed on how to use the appli-
ance safely and have understood the potential risks.
-Children must never play with the appliance. Clean-
ing and user maintenance must not be carried out
by children without supervision.
CAUTION Burns Parts of the appliance can get very hot and may cause
burns. Particular caution is advised when children or
vulnerable persons are present.

OPERATION
Register your product
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |7
CAUTION UV light exposure
The unit has a built-in antimicrobial UV-C lamp. Avoid
direct eye contact with the UV-C lamp.
WARNING Burns Never operate this appliance...
-if the distance from adjacent objects or other flam-
mable materials would be less than the minimum
permissible distance.
-in rooms where it is at risk of fire or explosion as a
result of chemicals, dust, gases or vapors. Ensure
the room is adequately ventilated before using the
appliance.
-in the direct proximity of pipes or receptacles that
carry or contain flammable or explosive materials.
-if an appliance component is damaged, the appli-
ance has fallen over or there is a fault.
WARNING Overheating
To prevent the appliance from overheating, never cover
it with anything.
2.3 Test mark
See type plate on the appliance. The type plate is located on the
back of the appliance.
3. Register your product
You must register this product within 90 days of purchase on our website in order to activate
the standard warranty or to be eligible for the extended
warranty. Go to our web site at: www.stiebel-eltron-usa.com
and click on Register Your Product.
Before beginning the registration process, we suggest that
you gather the necessary information which will be as follows:
Type, Example: Ultronic-1 Premium (from the label that is on
the back of the unit)
Number listed after “Nr.”
Place of Purchase
Purchase Date
First & Last Name
Email address
Physical Address
Phone Number
IF YOU HAVE ANY QUESTIONS CONCERNING THE REGISTRA-
TION PROCESS OR WARRANTY OPTIONS, PLEASE CONTACT
STIEBEL ELTRON USA DIRECTLY AT (800)-582-8423.

OPERATION
Appliance description
8| Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
4. Appliance description
The appliance works without contact. If you hold your hands in
the IR sensor detection range, the appliance fan is automatically
enabled.
The appliance dries hands by removing the moisture with a con-
centrated jet of air. A switchable heating element increases your
comfort during hand drying.
When you move your hands away from the IR sensor detection
range, the appliance stops automatically.
Additional hygiene is provided by the HEPA filter and the air clean-
ing function with UV-C light and ion generator. The appliance
reliably removes dust, pollen, bacteria and viruses from the in-
door air.
In silent mode, the appliance operates more quietly with a reduced
fan speed.
The switchable heating element, air cleaning function and silent
mode can be activated and deactivated by a qualified contrac-
tor (see chapter "Installation/ Activating/deactivating appliance
functions").
5. Operation
f Shake your wet hands over the washbasin before drying to
reduce the drying time.
f Hold your hands under the air outlet.
f Move your hands slowly back and forth in the airflow.
The blue LED on the underside of the appliance flashes during
operation. When you move your hands away from the IR sensor
detection range, the appliance stops automatically.
When used without interruption, the appliance stops automatically
after approx. 50seconds to avoid constant operation.
When the air cleaning function is activated, it switches on auto-
matically during operation.
LED indicator on the front of the appliance
Operating mode LED indicator
Standby mode Steady white light
Operation Fast blinking light, white
Operation with air cleaning function Slow blinking light, white
6. Cleaning, care and maintenance
!
Property damage
Ensure that no moisture can enter the appliance.
!
Property damage
Unsuitable cleaning agents may damage the appliance
casing.
f Never use abrasive or corrosive cleaning agents.

OPERATION
Troubleshooting
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |9
f Wipe the appliance casing regularly with a soft, damp cloth.
f Clean the air intake area on the underside of the appliance
regularly with a brush.
7. Troubleshooting
Problem Cause Solution
The appliance does
not start.
There is no power.
Check whether a circuit
breaker has tripped in the
main breaker panel.
Check that the appliance is
installed correctly on the
wall mounting bracket.
Covering the IR sensor
can impair the function of
the appliance. When used
without interruption, the ap-
pliance stops automatically
after approx.50seconds to
avoid constant operation.
Check whether any objects
etc. are interfering with the
IR sensor detection range.
After removing the interfer-
ence factors, the appliance
operates normally.
The LED on the
front of the appli-
ance flashes red.
At least 60,000applications
with the built-in HEPA filter
have been reached. The
filter must be replaced.
The appliance can still
be operated without the
filter function. After ap-
prox.75,000applications,
the appliance can no longer
be operated until the filter is
replaced.
Ask a qualified contractor to
replace the HEPA filter.
Problem Cause Solution
The blue LED on
the underside
of the appliance
flashes.
The PCB or fan motor is
faulty.
Contact a qualified con-
tractor.
If you cannot solve the problem, contact your qualified contractor.
To facilitate and speed up your inquiry, please provide the serial
number from the type plate (000000-0000-000000).

INSTALLATION
Safety
10 | Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
INSTALLATION
8. Safety
Only a qualified contractor should carry out installation, commis-
sioning, maintenance and repair of the appliance.
8.1 General safety instructions
We guarantee trouble-free functional and operational reliability
only if original accessories and spare parts intended for the ap-
pliance are used.
8.2 Instructions, standards and regulations
Note Observe all applicable national and regional regulations
and instructions.
9. Appliance description
9.1 Standard delivery
The following are delivered with the appliance:
- Wall mounting bracket (fitted on the appliance)
- HEPA filter
- Torx key
- Spare screw
- 3 screws and 3 rawl plugs to secure the wall mounting
bracket
- Cable cover with 2 screws
- Drilling template (in the center section of these instructions)
10. Preparation
10.1 Installation site
!
Property damage
The appliance is exclusively designed for indoor instal-
lation. The appliance can be damaged if it is exposed to
the elements.
Note The appliance must be installed flush against a wall with
sufficient load bearing capacity.
f Mount the appliance only on a vertical wall.

INSTALLATION
Preparation
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |11
Installation in bathrooms
WARNING Electrocution Only install the appliance outside safety zone2.
24” (600
mm
)
24”
(600
mm
)
89”
118”
(3000
mm
)
(2250
mm
)
1
2
30
26_07_31_0167
Electrical safety zones in the bathroom
10.2 Minimum clearances
ǪÝ
(10)
9ǬÝ
(250)
òÝ

D0000109429
f Maintain the minimum clearances to adjacent object surfaces
to ensure trouble-free operation.
10.3 Guidelines for installation height
Note The height indicates the distance between the top drill
holes and the floor.

INSTALLATION
Installation
12 | Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
Categories of people Height
Adult man 55˝ (1400 mm)
Adult woman 53¾˝ (1365 mm)
Children 5-8 years old 40½˝ (1028 mm)
Children 8-11 years old 44½˝ (1128 mm)
Children 11-14 years old 47½˝ (1208 mm)
Wheelchair users 45¼˝ (1150 mm)
11. Installation
11.1 Fitting the wall mounting bracket
The appliance is intended for wall mounting using the wall mount-
ing bracket supplied.
f Place the appliance on a soft underlay to prevent damage to
the surface.
1. 2.
3.
D0000109479
f Undo the locking screw on the underside of the appliance
using the Torx key included in the standard delivery.
f Pull the wall mounting bracket downwards.
f Remove the wall mounting bracket from the appliance.

INSTALLATION
Installation
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |13
Note
f When positioning the wall mounting bracket, ob-
serve the position and length of the power cable.
Note f Use the relevant standard values as a guide for the
installation height (see chapter "Preparations/ Stan-
dard values for the installation height").
!
Property damage
If you hit electrical cables when drilling, the circuit break-
er will trip and the cable will be damaged. If you hit pipes
when drilling, there is a risk of water damage.
f Make sure that you do not damage any electrical ca-
bles or pipes when drilling.
D0000109678
f Mark out the 3drilling positions with reference to the drilling
template (in the center section of these instructions) or the
wall mounting bracket.
f Drill the holes and insert the provided rawl plugs.

INSTALLATION
Installation
14 | Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
11.2 Electrical connection
WARNING Electrocution
Carry out all electrical connection and installation work
in accordance with national and regional regulations.
WARNING Electrocution
In the case of a permanent connection, ensure the ap-
pliance can be separated from the power supply by an
isolator that disconnects all poles with at least 3mm
contact separation.
WARNING Electrocution
Ensure that the appliance is connected to the ground
conductor.
!Property damage
Observe the type plate. The specified voltage must match
the mains power supply.
!Property damage
fWhen making the connection to a standard safety
socket (in the case of a power cable with mains
plug), ensure that the socket is freely accessible after
the appliance has been installed.
The power supply can be connected directly to the appliance or
via a power cable with mains plug.
6
NL
D0000109480
12
1 Cable entry
2 Cable duct
Note
fMake sure the length of the power cable is sufficient
to pass correctly through the wall mounting bracket
to the terminal.
fRoute the power cable from the back through the cable
grommet of the wall mounting bracket.

INSTALLATION
Installation
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |15
fConnect the power cable to the mains terminal according to
the markings.
fLay the power cable in the cable duct.
D0000109482
1
2
1 Cable exit
2 Strain relief fittings
fIf the power cable is routed through the cable exit, route the
connecting cable through the 3integral strain reliefs on the
back of the wall mounting bracket.
D0000109481
fSecure the wall mounting bracket to the wall with the provid-
ed screws.
fSecure the cable cover to the wall mounting bracket.
11.3 Opening the appliance
Remove the casing cover to insert the HEPA filter or to set the
appliance functions.
If you want to start the appliance directly, you can continue the
installation by following the chapter “Installing the appliance”.
D0000109486
Ultronic™Plus Ultronic™Premium
5 Phillips screws 5 Phillips screws - 4 casing, 1 ground
fUse a suitable screwdriver to unscrew the Phillips screws on
the back of the appliance.

INSTALLATION
Installation
16 | Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
D0000109688
Ultronic™Plus
D0000109487
Ultronic™Premium
f Remove the casing cover from the appliance.
11.4 Inserting the HEPA filter
D0000109489
f To unlock the filter casing, turn it in the direction indicated
on the filter casing (OPEN) and remove the filter casing.
D0000109691
f Insert the filter into the filter casing.

INSTALLATION
Installation
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |17
1.
2.
D0000109492
fReplace the filter casing on the motor. Align the point on the
filter casing with the upper groove on the motor cover.
fTurn the filter casing in the direction indicated on the filter
casing (CLOSE) until you hear it click into place.
11.5 Activating/deactivating appliance functions
CAUTION UV light exposure
The unit has a built-in antimicrobial UV-C lamp. Avoid
direct eye contact with the UV-C lamp.
ON
Heat
S-Mode
On On
Q-Mode
On
ON
ON
ON
On
S-Mode He
On
at
On
Q-Mode
ON
ON
D0000109488
123
1Aircleaningfunction
2 Heating function
3 Silent mode
Function Factory
setting
Air cleaning function with UV-C light and ion generator OFF
Heating function with switchable heating element ON
Silent mode with reduced fan speed OFF
fSwitch the required functions on or off using the DIP switch.
11.6 Fitting the casing cover
fPlace the casing cover on the back panel of the appliance.
fCheck that the casing cover is seated correctly on the
appliance.
fTighten the Philips screws on the back of the appliance.

INSTALLATION
Cleaning and maintenance
18 | Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
WARNING Electrocution Do not forget to screw on the grounding connection
screw. The grounding connection screw is located on
the rear of the unit in the upper right-hand corner.
11.7 Installing the appliance
1.
2.
3.
D0000109483
f Position the appliance centrally over the wall mounting
bracket so the metal retainer on the back of the appliance is
above the fixture of the wall mounting bracket.
f Press the appliance against the wall and slowly push the ap-
pliance down as far as it will go.
f On the underside of the appliance, fasten the locking screw
into the wall mounting bracket using the provided Torx key.
f Switch on the power supply or insert the mains plug on the
power cable, if fitted, into the standard safety socket.
The LED on the front of the appliance flashes red three times, then
lights up white. The unit is ready for operation.
f Check the appliance function.
11.8 Appliance handover
f Explain the functions of the appliance to the user.
f Draw special attention to the safety instructions.
f Hand over these operating and installation instructions to the
user.
12. Cleaning and maintenance
WARNING Electrocution Before any work on the appliance, disconnect all poles
from the power supply.
f Before starting any cleaning and maintenance work, remove
the appliance from the wall mounting bracket.

INSTALLATION
Cleaning and maintenance
ENGLISH
www.stiebel-eltron-usa.com Ultronic™Plus & Premium Hand Dryers |19
1.
2.
D0000109485
f Undo the locking screw on the underside of the appliance
using the provided Torx key.
f Lift the appliance off the wall mounting bracket.
f Make sure that the LED on the front of the appliance is off
before you open the appliance.
12.1 Cleaning
The interior of the appliance must be cleaned regularly to remove
dust deposits.
f Open the appliance (see chapter "Installation/ Opening the
appliance").
f Remove the dust from inside the appliance.
f Fit the casing cover (see chapter "Installation/ Fitting the
casing cover").
f Hang the appliance on the wall mounting bracket (see chap-
ter "Installation/ Installing the appliance").
12.2 Changing the HEPA filter
Note A built-in filter must be replaced after 60,000applica-
tions. The appliance can still be operated, but without
the effectiveness of a HEPA filter. After approx. 75,000ap-
plications, the LED on the front of the appliance flashes
red. The appliance cannot be operated again until a new
filter is inserted.
The HEPA filter is available as a spare part, item no. 205638.
f Open the appliance (see chapter "Installation/ Opening the
appliance").
f Replace the filter (see chapter "Installation/ Installing the
HEPA filter").
f Fit the casing cover (see chapter "Installation/ Fitting the
casing cover").
f Hang the appliance on the wall mounting bracket (see chap-
ter "Installation/ Installing the appliance").

INSTALLATION
ZĤ¼êÐ|ŒêĒĉ
20 | Ultronic™Plus & Premium Hand Dryers www.stiebel-eltron-usa.com
13. Specification
13.1 Dimensions and connections
315/16Ý
(100)
3ǩÝ
(80)
3ǬÝ
(98)
b01
b02
1011/16Ý
(272)
12
3
/
16
Ý
(309)
53/16Ý
(132)
D0000109430
Ultronic™Plus & Premium
b01 Entry electrical cables
b02 Grounding connection screw
