STIEBEL ELTRON PSH 30 Si Instruction Manual

OPERATION AND INSTALLATION
OBSŁUGA I INSTALACJA
OBSLUHA A INSTALACE
ЭКСПЛУАТАЦИЯ И МОНТАЖ
ОБСЛУЖВАНЕ И ИНСТАЛИРАНЕ
HASZNÁLATI ÉS TELEPÍTÉSI ÚTMUTATÓ
Unvented (pressurized) wallmounted water heater | Ciśnieniowy, pojemnościowy
ogrzewacz wody | Tlakové elektrické zásobnÍky teplé vody| Накопительный
настенный водонагреватель эакрытого типа | Обемен бойлер за монтаж на стена,
работещ под налягане | Falra függeszthető melegvíz-tároló
» PSH 30 Si
» PSH 50 Si
» PSH 75 Si
» PSH 100 Si
» PSH 120 Si
» PSH 150 Si

2|PSH Si www.stiebel-eltron.com
P
lease read carefully
(EN)
WARNINGS: This device is not intended for use by persons (including children) with physical, sensory or mental disability, or by persons
lacking experience or knowledge, unless they have received from a person in charge of their safety adequate supervision or preliminary
instructions on how to use the device. Children should be supervised to ensure that they do not play with the appliance. This unit can be
used by children of not less than 8 years and people with reduced physical, sensory or mental capabilities or without experience or
knowledge if they are properly supervised or if the instructions for using the device safely have been given and if the risks are taking into
account. Children must not play with the device. Cleaning and maintenance must not be done by children without supervision.
1. CAUTION! Heavy item, handle with care:
1.1 Install the appliance in a room which is protected from frost. If the appliance is damaged because the safety device has been blocked, it is not
covered by guarantee,
1.2 Make sure that the wall on which the appliance is mounted can support the weight of the appliance when filled with water,
1.3 If the appliance is to be fitted in a room or location where the ambient temperature is higher than 35°C, provide sufficient ventilation,
1.4 When installed in a bathroom, do not install the appliance in volumes V0 and V1. If the water heater is to install above living space, fit a
retaining tank with drain to the sewer system. Place the water heater in a place with easy access,
1.5 If PER pipes are used, the installation of a thermostatic regulator on the output pipe of the device is strongly recommended. It will be set
according to the performance of the material used.
1.6 Installation of a vertical or horizontal wall mounted device: To allow the replacement of the heating element leave a free space of 300mm
between the tube ends and the wall or fixed furniture.
1.7 Switch off the power before removing the cover, to avoid any risk of injury or electric shock.
1.8 The installation must be equipped, upstream of the appliance, with a bipolar cut-out device (fuse, breaker switch) respecting local regulations
(30 mA earth-leakage breaker).
1.9 If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or the after sales service.
1.10 Mandatory installation of a safety device in a frost free location (or any other new device which limits the tank pressure) to 7 or 9 bar (0.7 or
0.9 MPa) according to the nominal pressure, with a size of ½ "or ¾" on the input of the water heater, respecting the local regulations (see table
p.1),
1.11 Operate regularly the discharge of safety device to prevent scaling and check that it is not blocked.
1.12 Hydraulic accessories should not be located between the safety valve and the cold water inlet. A pressure reducer (not supplied) is required
when the water supply pressure exceeds 5 bar (0,5 MPa) and will be fitted on the main supply.
1.13 Connect the safety device to an unpressurised outlet pipe in a frost free location, with a continuous slope to evacuate water during heating up
or draining the water heater.
1.14 The pipes used must support 10 bars (1 MPa) and 100 ° C.
1.15 To drain the device: Switch off the power and the supply of cold water, open the hot water faucets and manipulate the safety valve. To drain
under sink water heater disconnect the hydraulic connections and return the device.
1.16 The products described in this manual are subject to changes at any time to be in accordance with technology and standards. The
devices comply with electromagnetic directives 2004/108/EC and Low Voltage 2006/95/EC.
1.17 Do not dispose your water heater in the garbage, but hand it to a place assigned for this purpose (collection point) where it can be
recycled.
Prosz uwanie przeczyta
(PL)
UWAGA: To urzdzenie nie jest przeznaczone do uytku przez osoby (włcznie z dziemi) z niepełnosprawnoci fizyczn, sensoryczn
lub intelektualn ani przez osoby, które nie posiadaj dowiadczenia lub wiedzy, chyba e znajduj si pod odpowiednim nadzorem osoby
odpowiedzialnej za ich bezpieczestwo lub otrzymały wstpne instrukcje dotyczce korzystania z urzdzenia. Urzdzenie nie moe by
traktowane jako zabawka dla dzieci. Dzieci przynajmniej omioletnie oraz osoby o ograniczonej sprawnoci fizycznej, sensorycznej lub
intelektualnej lub bez dowiadczenia i wiedzy mog korzysta z urzdzenia, jeli znajduj si pod odpowiednim nadzorem lub jeli
udzielono im instrukcji dotyczcych bezpiecznego korzystania z urzdzenia, a wszelkie ryzyko zostało wzite pod uwag. Dzieciom nie
wolno bawi si urzdzeniem. Dzieci nie mog równie czyci ani konserwowa urzdzenia bez nadzoru.
1. OSTRONIE! Ciki przedmiot, zachowa ostrono:
1.1 Urzdzenie naley zainstalowa w pomieszczeniu, w którym zawsze panuj temperatury dodatnie. Gwarancja nie obejmuje uszkodze
spowodowanych zablokowaniem zabezpiecze,
1.2 Naley upewni si, e ciana, na której zamontowano urzdzenie, jest w stanie wytrzyma wag zbiornika napełnionego wod,
1.3 Jeli urzdzenie ma zosta zamontowane w pomieszczeniu lub miejscu, w którym temperatura otoczenia przekracza 35°C, naley zapewni
odpowiedni wentylacj,
1.4 W przypadku instalacji w łazience nie instalowa urzdzenia w przestrzeniach V0 i V1. Jeli ogrzewacz wody ma by zainstalowany powyej
czci mieszkalnej, zbiornik naley wyposay w instalacj odprowadzajc do systemu kanalizacyjnego. Umieci podgrzewacz wody w miejscu
o łatwym dostpie,
1.5 W przypadku uycia rur PEX, zdecydowanie zalecamy zainstalowanie regulatora termostatycznego na rurze wylotowej urzdzenia. Zostanie
on ustawiony zgodnie z efektywnoci wykorzystanego materiału.
1.6 Instalacja urzdzenia zamontowanego poziomo lub pionowo na cianie: aby umoliwi wymian elementu grzewczego naley pozostawi 300
mm wolnej przestrzeni pomidzy kocami rury a cian lub przymocowanymi na stałe meblami.
1.7 Przed zdjciem pokrywy odłczy zasilanie, aby unikn niebezpieczestwa obrae lub poraenia prdem.
1.8 Instalacja musi by wyposaona w dwubiegunowe urzdzenie odcinajce prd (bezpiecznik, przerywacz obwodu), zainstalowane przed
urzdzeniem, uwzgldniajce lokalne przepisy (przerywacz ziemnozwarciowy 30 mA).
1.9 Jeli przewód zasilajcy jest uszkodzony, naley go wymieni na specjalny przewód lub kabel dostpny u producenta lub w specjalistycznym
sklepie.
1.10 Urzdzenie zabezpieczajce (lub kade inne nowe urzdzenie ograniczajce cinienie zbiornika) musi by zamontowane w miejscu
chronionym przed mrozem. Wymagania: do 7 lub 9 barów (0.7 lub 0.9 MPa) zgodnie z cinieniem nominalnym, dla rozmiaru ½" lub ¾" na wlocie
ogrzewacza wody, uwzgldniajc miejscowe przepisy (patrz tabela s.1),
1.11 Regularnie otwiera spust urzdzenia zabezpieczajcego, aby zapobiec osadzaniu si kamienia i sprawdzi, czy nie został zablokowany.
1.12 Akcesoria hydrauliczne nie powinny by umieszczone pomidzy zaworem bezpieczestwa a wlotem zimnej wody. Jeeli cinienie wody
zasilajcej przekracza 5 barów (0,5 MPa) naley zastosowa reduktor cinienia (nie ma w komplecie), zamontowany na głównym dopływie.
1.13 Urzdzenie zabezpieczajce podłczy (w miejscu chronionym przed mrozem) do bezcinieniowej rury wylotowej o stałym spadku, aby
spuszcza wod w trakcie ogrzewania lub opróniania ogrzewacza wody.
1.14 Zastosowane rury musz wytrzymywa cinienie min. 10 barów (1 MPa) i temperatur 100° C.
1.15 W celu spuszczenia wody ze zbiornika: wyłczy zasilanie i odci dopływ zimnej wody, otworzy krany z ciepł wod i przestawi zawór
bezpieczestwa. Aby opróni ogrzewacz wody zamontowany pod umywalk odłczy przyłcza hydrauliczne i odda do oprónienia.
1.16 Konstrukcja produktów opisanych w niniejszej instrukcji moe w kadej chwili ulec zmianie, tak aby spełniały obowizujce normy i
wymagania technologiczne. Urzdzenia spełniaj wymogi dyrektyw dotyczcych kompatybilnoci elektromagnetycznej 2004/108/WE
oraz niskonapiciowej 2006/95/WE.
1.17 Nie utylizowa ogrzewacza wody poprzez wyrzucenie do mieci, lecz przekaza odpowiedniego punktu zbierania odpadów, gdzie
moe zosta poddany recyklingowi.

www.stiebel-eltron.com PSH Si|5
ENGLISH
Contents | Operation
General information
1. General information
The chapter Operation is intended for users and contractors.
The chapter Installation is intended for contractors.
Please read carefully. Read these instructions carefully and retain for future
reference. If the appliance is passed on to a third party
please hand these instructions to the new user.
1.1 Key
1.1.1 Symbols in these instructions:
In these instructions you will come across symbols and highlighted
sections that are defined as follows:
Risk of injury. Information concerning risk of injury.
Danger to life through electrocution.
Risk of scalding.
!
Please note. Information concerning an actual risk. Damage to the
appliance or environment may result. Material loss may
also result.
Please read carefully. Read the text next to these symbols carefully.
 Passages preceded by this symbol indicate procedures you
must follow; these are described step-by-step.
- Passages preceded by this symbol indicate lists.
1.1.2 Symbols on the appliance
Symbols are displayed on the appliance type plate. These are
defined as follows:
Disposal
Appliances with this label are unsuitable for general do-
mestic waste. Please dispose of these appliances sepa-
rately.
2. Safety
2.1 Correct use
The appliance is exclusively designed for heating domestic hot
water (DHW). This appliance is designed for domestic use. It can
be used safely by untrained persons. The appliance can also be
used in a non-domestic environment, e.g. in a small business, as
long as it is used in the same way.
Any other use beyond that described shall be deemed inappropri-
ate. It is not permissible to heat other liquids or materials.
OPERATION
OPERATION
1. General information �����������������������������������������5
1.1 Key������������������������������������������������������������������ 5
2. Safety����������������������������������������������������������5
2.1 Correct use�������������������������������������������������������� 5
2.2 Safety instructions����������������������������������������������� 6
2.3 CE designation ��������������������������������������������������� 6
3. Appliance description ���������������������������������������6
4. Operation �����������������������������������������������������6
4.1 Other relevant documents ������������������������������������ 6
4.2 Adjustment options ��������������������������������������������� 6
4.3 Recommended settings ���������������������������������������� 7
5. Cleaning, care and maintenance ���������������������������7
6. What to do if... ? ���������������������������������������������7
7. Safety����������������������������������������������������������8
7.1 Country-specific safety information�������������������������� 8
8. Appliance description ���������������������������������������8
8.1 Standard delivery������������������������������������������������ 8
INSTALLATION
9. Installation����������������������������������������������������8
9.1 Installation conditions ������������������������������������������ 8
10. Assembly������������������������������������������������������9
10.1 Appliance assembly ��������������������������������������������� 9
10.2 Installation of accessories������������������������������������� 10
11. Commissioning ��������������������������������������������� 10
11.1 Checks before commissioning�������������������������������� 10
11.2 Commissioning�������������������������������������������������� 10
11.3 Taking the appliance out of use������������������������������ 11
11.4 Restarting �������������������������������������������������������� 11
12. Appliance handover���������������������������������������� 11
13. Troubleshooting �������������������������������������������� 11
14. Maintenance ������������������������������������������������ 11
14.1 Maintenance work���������������������������������������������� 11
14.2 Wearing parts ��������������������������������������������������� 11
15. Specification ������������������������������������������������ 12
15.1 Diagram with dimensions������������������������������������� 12
15.2 Specification ����������������������������������������������������� 13
WARRANTY
ENVIRONMENT AND RECYCLING

Operation
Appliance description
6|PSH Si www.stiebel-eltron.com
Observation of these instructions is also part of the correct use
of this appliance.
2.2 Safety instructions
Observe the following safety information and instructions.
All steps up to the commissioning of this appliance must only be
carried out by qualified contractors.
The electrical installation and installation of the water connecti-
on must only be carried out by a qualified contractor or by our
customer service engineers.
The contractor is responsible for adherence to all currently appli-
cable regulations during installation and commissioning.
Operate this appliance only if it is fully installed and all safety
equipment is fitted.
Risk of scalding. The hot water at the tap can reach a temperature of up
to 65°C (PSH 30-50 Si) / 62 °C (PSH75-150Si). There is a
risk of scalding at outlet temperatures in excess of 43 °C.
Small children should be kept away from the taps.
Risk of injury! The appliance may be used by children aged 8 and up
and persons with reduced physical, sensory or mental
capabilities or a lack of experience provided that they
are supervised or they have been instructed on how to
use the appliance safely and have understood the result-
ing risks. Children must never play with the appliance.
Children must never clean the appliance or perform user
maintenance unless they are supervised.
2.3 CE designation
The CE designation shows that the appliance meets all essential
requirements according to the:
- Electromagnetic Compatibility Directive
- Low Voltage Directive
The type plate is located at the bottom of the appliance.
3. Appliance description
The wall mounted DHW cylinder constantly maintains the DHW at
the pre-selected temperature. The water is heated by the electrical
heating element.
The appliance is preset at the factory to 65 °C (PSH 30-50 Si)/ 62
°C (PSH 75-150 Si). For appliances of type PSH 75-150 Si, The
temperature setting should only be made by a contractor.
The expansion water that collects as the water is heated up is
drained off via the safety valve. The inner cylinder of the DHW
cylinder is protected against corrosion by an enamel coating in
conjunction with the integral protective magnesium anode.
4. Operation
4.1 Other relevant documents
For operation, also observe the operating instructions of the re-
levant accessories and any appliance documentation.
4.2 Adjustment options
4.2.1 Temperature adjustment PSH 30-50 Si
26�02�20�0026
1
1 temperature selector (only for PSH 30-50 Si)
By turning the temperature selector, you can select the tempera-
ture of the water in the DHW cylinder. Turn it clockwise to raise
the temperature, and anti-clockwise to lower the temperature.
As soon as the temperature of the water in the DHW cylinder drops
below the set value, the heating element automatically switches
on. The ON/OFF indicator illuminates until reheating is complete
and the set temperature has been reached again.
4.2.2 Temperature adjustment PSH 75-150 Si
26�02�20�0030
1
1 temperature selector
The temperature set at the factory can be changed by a contrac-
tor. To do this, the temperature controller inside the appliance

Operation
Cleaning, care and maintenance
www.stiebel-eltron.com PSH Si|7
ENGLISH
must be turned to the required position (position 5 corresponds
to approximately 62 °C).
4.3 Recommended settings
4.3.1 Water temperature
The water temperature is continuously variable, and can be set
subject to your requirements. The setting range extends from
approx. 5 °C to approx. 65°C (PSH 75-150 Si: 5 °C to 62 °C).
For low water consumption or very hard water, we recom-
mend setting the cylinder to a low temperature, as water above
approx. 55 °C deposits the limescale contained in it.
4.3.2 Holiday and absence
During a prolonged period of absence, such as a holiday, you
should set the appliance to frost protection or disconnect it from
the power supply, in order to save energy. To do so, observe the
details in the frost protection chapter.
4.3.3 Sporadic use
For only sporadic use, such as in a weekend home, you should set
the appliance to frost protection or disconnect it from the power
supply when you are not there. For reasons of hygiene and health,
you should heat up the content of the cylinder once to above 60 °C
before initial usage.
4.3.4 Frost protection
In the frost protection setting, the cylinder is protected against
frost, but the safety valve and water lines in the apartment or
house are not. If the appliance are disconnected from the power
supply, the cylinder is not protected against frost. In such cases,
if there is a risk of frost, the cylinder must be drained.
 Close the cold water inlet.
 Open a DHW draw-off point.
 Open the drain valve or the drain valve on the safety valve,
and fully drain the cylinder.
Risk of scalding. Hot water may emerge during draining.
5. Cleaning, care and maintenance
A damp cloth is sufficient for cleaning the casing. Do not use
abrasive or corrosive cleaning agents.
 Check the tap regularly. Remove limescale deposits at the tap
outlets using commercially available descaling agents.
 Regularly activate the safety valve to prevent it from becom-
ing blocked by limescale deposits.
 Check the safety valve is functioning correctly by pulling out
or turning the rotary selector. When you do so, water will
escape from the safety valve!
The drip water outlet of the safety valve must always remain open
to atmosphere, and must never become narrower or blocked.
Route the drip water outlet to a drain free from the risk of frost,
with a constant slope to ensure the unrestricted flow of the water
to the drain.
!Have a contractor regularly check the appliance and
safety valve.
Danger to life through electrocution! Maintenance work, such as checking the electrical
safety, must only be carried out by a qualified contractor.
To safeguard a long service life, we recommend having a cont-
ractor inspect the protective magnesium anode installed in the
appliance after the first year of service. The contractor should
determine further maintenance intervals. Annual maintenance
intervals could be necessary in areas with particularly hard water.
6. What to do if... ?
Fault Troubleshooting checks
No hot water Has the power supply (fuse or MCB) been inter-
rupted? If so, reset the fuse or MCB and wait until
the cylinder has heated up again. Notify your con-
tractor if the fuse/MCB blows/trips again after you
have reset it.
No hot water Is the temperature set high enough? Set the tem-
perature slightly higher.
No hot water Is the ON/OFF indicator illuminated? When the ON/
OFF indicator illuminates, the appliance heats the
cylinder content. This can be necessary, for example
because a large volume of water was previously
drawn. Wait until the ON/OFF indicator extinguishes
again.
No hot water Is the ON/OFF indicator illuminated? If the ON/OFF
indicator is not illuminated and all other causes
have been checked, this can indicate that the high
limit safety cut-out has responded. Notify your local
contractor.
Too little hot water Is the temperature set correctly? If all other possible
sources of the fault have been eliminated, the ap-
pliance may have been sized too small. In this con-
nection, also observe the maximum DHW draw-off
volume, as specified in the "Specification" chapter.
Low DHW outlet volume Are the draw-off points scaled up? Limescale on the
draw-off points reduces the output volume. Descale
and clean the outlet points. If this does not remedy
the fault, inform your local contractor.
The safety valve is drip-
ping
This is normal during heat-up. If the safety valve
continues to drip after heat-up is complete, inform
your local contractor.

8|PSH Si www.stiebel-eltron.com
Installation
Safety
7. Safety
Use only original spare parts.
7.1 Country-specific safety information
Observe the country-specific instructions and regulations regar-
ding the water and power connection.
8. Appliance description
1
2
3
4, 5
6
7
8
9
C26�02�20�0008
1 Plastic top cap
2 Wall mounting brackets (on PSH 30 - 50 Si on top only)
3 Sheet steel casing, white paint finish
4 Cold water connection nozzle (blue)
5 Hot water connection nozzle (red)
6 Plastic bottom cap
7 Electric housing with electrical connection
8 Temperature selector (only PSH 30-50 Si)
9 ON/OFF indicator
The appliance is equipped with an enamelled steel cylinder, a
flanged immersion heater with a copper tubular heating element
and a protective anode.
- The appliance can supply several draw-off points.
- The water is heated in a pressurised inner cylinder.
- A protective magnesium anode protects the enamelled inner
cylinder against corrosion.
- The thermal insulation is made of environmentally friendly
and recyclable polyurethane foam.
8.1 Standard delivery
- Wall mounted cylinder with mounting bracket
- These operating and installation instructions
INSTALLATION
9. Installation
9.1 Installation conditions
The appliance is intended for installation in a room free from the
risk of frost, near the main draw-off point. Installation outside a
building is not permissible.
Observe the following specifications and information:
- The room must be free from the risk of frost, for example a
bathroom or utility room.
- The wall on which the appliance will be mounted must be
vertical and load-bearing. Take into account the weight of the
appliance when filled with water.
- There should be a suitable drain near the appliance to drain
off the expansion water.
- The power supply, cold water and DHW lines must be suit-
able for the installation of the appliance.

www.stiebel-eltron.com PSH Si | 9
ENGLISH
Installation
Assembly
10. Assembly
10.1 Appliance assembly
10.1.1 Appliance installation
When installing the appliance, select securing materials to suit
the stability of the wall.
For the position of the screws required for the installation, see the
diagram in chapter „Specification“.
!
When drilling, note that supply cables/water lines and ducts may run in the wall.
 Observe the dry weight of the appliance. Subject to the size
of the appliance, two people may be needed to hook it onto
the wall.
 Align the cylinder vertically.
26�02�20�0003
 Tighten all screws/nuts.
10.1.2 Water connection
!A safety valve must be fitted at the cold water inlet
of the unit.
When making the water connection, observe these instructions
and country-specific standards and regulations.
!
If the water pressure is higher than 0.5 MPa (5 bar), install a pressure reducer in the cold water inlet.
The water connection must be made as a sealed unvented system
(pressurised) to supply several draw-off points. Thoroughly flush
out the cold water line before connection to the cylinder, so that
no contamination gets into the cylinder or safety valve.
 Install the cylinder according to the following diagram.
26�02�20�0004
9
1
87 6 4 3 25
1 Safety valve, 0.6 MPa (6 bar)
2 Pressure reducing valve (recommended for water pressure
above 0.5 MPa (5 bar))
3 Non-return valve
4 Straight-through shut-off valve (butterfly)
5 Cold water supply
6 Drain valve
7 Connection insulator made of gunmetal or plastic for cold
water and DHW
8 DHW supply
9 Draw-off points
Note for copper pipes: Never fit connections made of copper direc-
tly to the appliance. We recommend gunmetal or plastic adaptors
as connection insulators for the pipe connections.
 Set the flow rate on the straight-through shut-off valve to a
maximum of 18 l/min.
10.1.3 Safety valve
During heating, the DHW in the cylinder expands and causes po-
sitive pressure in the DHW cylinder. The safety valve protects the
cylinder against excessively high pressure.
!
Risk of damage Install the cylinder with a type-tested diaphragm ex-
pansion valve, to be integrated in the cold water line.
Observe the documentation supplied with the safety
valve, particularly the safety and operating instructions.
 Regularly activate the safety valve to prevent it from becom-
ing blocked by limescale deposits.
!The drip water outlet of the safety valve must al-
ways remain open to atmosphere, and must never
become narrower. The drain must be free from the risk of
frost and have a steady slope.
 Check the safety valve functions correctly.
 Show the user the safety valve and its operating instructions,
and explain its significance.

10|PSH Si www.stiebel-eltron.com
Installation
Commissioning
10.1.4 Plastic pipework
The wall mounted cylinder is suitable for connection to pla-
stic pipework. Should faults develop, temperatures up to 95°C
(max. 0.6 MPa) can occur. Any plastic pipework used must be sui-
table for such conditions.
10.1.5 Power connection
When making the electrical connection, observe these instructions
as well as the standards and regulations applicable in the country
of installation.
In the Federal Republic of Germany, these are the „Regulations
for installing HV systems with rated voltages up to 1000 V“, the
regulations of the local power supply utility, and VDE 0100.
An isolator that disconnects all poles of the power cable with at
least 3 mm contact separation must be installed on site. Fuses or
switches can be used for this, for example.
The wall mounted cylinder is only designed for permanent connec-
tion to the power supply.
Only PSH 30-50 Si: The wall mounted cylinder is supplied with
a flexible connecting cable prepared with wire ferrules, of
approx. 0.95 m in length.
If the cable is of insufficient length, unclamp from the appliance
and remove. Use a suitable installation cable (3 x 1.5 mm2).
When routing the new connecting cable, ensure that it is water-
proof as it passes through the existing cable entry, and is correctly
routed and connected inside the appliance.
PSH 30 Si
PSH 50 Si
1
3
45
6
2
26�02�20�0005
1 Power supply
2 Earth conductor
3 High limit safety cut-out/ temperature controller combination
4 Tubular heating element plug-in connection
5 Lamp „Heating“ (ON/OFF indicator)
6 Temperature selector
PSH 75 Si - 150 Si
1
3
4
2
5
26�02�20�0006
1 Mains connection
2 Protective earth connection
3 High limit safety cut-out/thermostat combination
4 Plug connection-tubular heating element
5 Lamp „Heating“ (ON/OFF indicator)
10.2 Installation of accessories
Install accessories according to the documentation supplied with
them.
11. Commissioning
The contractor must carry out and monitor commissioning and
the initial heat-up. Subject to appliance size and set temperature,
this can take several hours.
11.1 Checks before commissioning
 Check that the cylinder is mounted vertically.
 Ensure that the power supply is disconnected.
 Check whether the water connection is correct and was made
with the safety valve.
 Ensure that the temperature selector is turned as far to the
left as possible.
11.2 Commissioning
 Open the cold water inlet.
 Open a DHW draw-off point.
 Fill the cylinder until no more air escapes from the draw-off
point, only water.
 Close the draw-off point again.
 Switch the mains power ON.
 Turn the temperature selector clockwise as far as it will go.
Monitor the initial heat-up of the cylinder. The ON/OFF indi-
cator illuminates during heat-up. Wait until it extinguishes
again.
 Check the system and all components for leaks.
 Check the safety valve and drip water outlet.
 Set the temperature selector to a DHW temperature that will
suit the occupants.

www.stiebel-eltron.com PSH Si|11
ENGLISH
Installation
Appliance handover
11.3 Taking the appliance out of use
If you ever want to take the appliance out of use, carry out the
following steps:
 Isolate the appliance from the power supply.
 Close the cold water inlet.
 Drain the appliance.
The appliance can only be drained via the safety valve or via a
drain valve.
 Fully open the DHW valves on all draw-off points.
 Open safety valve or drain valve.
Risk of scalding. Hot water may emerge during draining.
11.4 Restarting
 Open the cold water inlet.
 Open a DHW draw-off point.
 Fill the cylinder until no more air escapes from the draw-off
point, only water.
 Close the draw-off point again.
 Switch the mains power ON.
12. Appliance handover
Explain to the user how the appliance works, and hand over these
operating instructions.
13. Troubleshooting
In addition to the test steps in the „What to do if...?“ chapter,
check the following:
Fault Remedy
Too little DHW Is the immersion heater scaled up? Descale it if
required.
Little or no DHW Check the controller and heating elements, and
replace if required.
No hot water. The high
limit safety cut-out has
responded because of
overheating.
Investigate the cause of the fault. If there does not
seem to be a cause, you can reset the high limit
safety cut-out. To do so, press the reset button with
a screwdriver, as shown below. If there are no pro-
blems with the heating element, but the high limit
safety cut-out continues to respond, replace the
controller/limiter combination.
No hot water. The high
limit safety cut-out has
responded because the
temperature has drop-
ped below -15°C.
Press the high limit safety cut-out reset button.
No hot water. The flan-
ged immersion heater
is faulty.
Replace the flanged immersion heater.
26�02�20�0031
1
1 High limit safety cut-out reset button
14. Maintenance
14.1 Maintenance work
 Check the safety valve and drip water outlet line.
 Check the protective magnesium anode and replace if
required.
 Remove loose scale deposits from the cylinder.
 If necessary, descale the inner cylinder with commercially
available descaling agents.
Do not descale the appliance until you have removed the flanged
immersion heater. Never treat the cylinder surface with descaling
agents.
 Check the electrical connection, particularly the earth
connection.
14.2 Wearing parts
Replace the protective magnesium anode if it has dissolved. Use
only original spare parts.

12|PSH Si www.stiebel-eltron.com
Installation
Specication
15. Specification
15.1 Diagram with dimensions
PSH 30-50 Si:
c01
c06
i13
b01
345
338
100
a10
81
184
D0000028848
PSH 30 Si PSH 50 Si PSH 75 Si PSH 100 Si PSH 120 Si PSH 150 Si
a10 Appliance Height mm 623 918 737 908 1046 1241
b01 Entry electrical cables
c01 Cold water inlet Male thread G 1/2 A G 1/2 A G 1/2 A G 1/2 A G 1/2 A G 1/2 A
c06 DHW outlet Male thread G 1/2 A G 1/2 A G 1/2 A G 1/2 A G 1/2 A G 1/2 A
i13 Wall mounting bracket Height mm 463 750
i14 Wall mounting bracket I Height mm 748 748 1048
Clearance mm 570
i15 Wall mounting bracket II Height mm 250 250
PSH 75-150 Si:
c01
c06
i15
i14
505
520
a10
230 165
b01
D0000028881

www.stiebel-eltron.com PSH Si|13
ENGLISH
15.2 Specification
PSH 30 Si PSH 50 Si PSH 75 Si PSH 100 Si PSH 120 Si PSH 150 Si
074478 074479 236650 074481 074482 074483
Electrical details
Connected load with ~ 230 V kW 2 2 2,2 2,2 2,2 2,2
Rated voltage V230 230 230 230 230 230
Phases 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE
Frequency Hz 50/- 50/- 50/- 50/- 50/- 50/-
Single circuit operating mode X X X X X X
Hydraulic data
Rated capacity l30 50 75 100 120 150
Energy data
Standby energy consumption/24 h at 65 °C kWh 0,76 1,13 1,05 1,25 1,35 1,65
Energy efficiency class C C C C C C
Dimensions
Width mm 338 338 505 505 505 505
Height mm 623 918 737 908 1046 1241
Depth mm 345 345 520 520 520 520
Diameter mm 338 338 505 505 505 505
Weights
Weight (wet) kg 44 67 106 131 154 190
Weight (dry) kg 14 17 26 31 34 40
Application limits
Available temperature range °C 5-65 5-65 5-62 5-62 5-62 5-62
Max. permissible pressure MPa 0,6 0,6 0,6 0,6 0,6 0,6
Min./max. conductivity, drinking water μS/cm 100-1500 100-1500 100-1500 100-1500 100-1500 100-1500
Versions
Sealed unvented type X X X X X X
IP-Rating IP25 IP25 IP25 IP25 IP25 IP25
Colour white/grey white/grey white/grey white/grey white/grey white/grey
Guarantee
The guarantee conditions of our German companies do not
apply to appliances acquired outside of Germany. In countries
where our subsidiaries sell our products a guarantee can only
be issued by those subsidiaries. Such guarantee is only grant-
ed if the subsidiary has issued its own terms of guarantee. No
other guarantee will be granted.
We shall not provide any guarantee for appliances acquired in
countries where we have no subsidiary to sell our products.
This will not aect warranties issued by any importers.
Environment and recycling
We would ask you to help protect the environment. After use,
dispose of the various materials in accordance with national
regulations.
Installation | Warranty | Environment and recycling
Specication



Deutschland
STIEBEL ELTRON GmbH & Co. KG
Dr.-Stiebel-Straße 33 | 37603 Holzminden
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.de
Verkauf Tel. [phone] | Fax [phone] | info-[email protected]
Kundendienst Tel. [phone] | Fax [phone] | kund[email protected]
Ersatzteilverkauf Tel. [phone] | Fax [phone] | [e-mail]
Irrtum und technische Änderungen vorbehalten! | Subject to errors and technical changes! | Sous réserve
d‘erreurs et de modifications techniques! | Onder voorbehoud van ver
g
issin
g
en en technische wi
j
zi
g
in
g
en! |
Salvo error o modificación técnica! | Excepto erro ou alteração técnica | Zastrzeżone zmian
y
techniczne i
ewentualne błędy | Omyly a technické změny jsou vyhrazeny! | A muszaki változtatások és tévedések
j
o
g
át
fenntartjuk! | Отсутствие ошибок не гарантируется. Возможны технические изменения. | Ch
y
b
y
a
technické zmeny sú vyhradené! Stand 9147
Australia
STIEBEL ELTRON Australia Pty. Ltd.
6 Prohasky Street | Port Melbourne VIC 3207
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel.com.au
Austria
STIEBEL ELTRON Ges.m.b.H.
Gewerbegebiet Neubau-Nord
Margaritenstraße 4 A | 4063 Hörsching
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.at
Belgium
STIEBEL ELTRON bvba/sprl
't Hofveld 6 - D1 | 1702 Groot-Bijgaarden
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.be
China
STIEBEL ELTRON (Guangzhou) Electric
Appliance Co., Ltd.
Rm 102, F1, Yingbin-Yihao Mansion, No. 1
Yingbin Road
Panyu District | 511431 Guangzhou
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebeleltron.cn
Czech Republic
STIEBEL ELTRON spol. s r.o.
K Hájům 946 | 155 00 Praha 5 - Stodůlky
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.cz
Finland
STIEBEL ELTRON OY
Kapinakuja 1 | 04600 Mäntsälä
Tel. [phone]
[email protected]
www.stiebel-eltron.fi
France
STIEBEL ELTRON SAS
7-9, rue des Selliers
B.P 85107 | 57073 Metz-Cédex 3
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.fr
Hungary
STIEBEL ELTRON Kft.
Gyár u. 2 | 2040 Budaörs
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.hu
Japan
NIHON STIEBEL Co. Ltd.
Kowa Kawasaki Nishiguchi Building 8F
66-2 Horikawa-Cho
Saiwai-Ku | 212-0013 Kawasaki
Tel. [phone] | Fax [phone]
[email protected]
www.nihonstiebel.co.jp
Netherlands
STIEBEL ELTRON Nederland B.V.
Daviottenweg 36 | 5222 BH 's-Hertogenbosch
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.nl
Poland
STIEBEL ELTRON Polska Sp. z O.O.
ul. Działkowa 2 | 02-234 Warszawa
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.pl
Russia
STIEBEL ELTRON LLC RUSSIA
Urzhumskaya street 4,
building 2 | 129343 Moscow
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.ru
Slovakia
TATRAMAT - ohrievače vody s.r.o.
Hlavná 1 | 058 01 Poprad
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.sk
Switzerland
STIEBEL ELTRON AG
Industrie West
Gass 8 | 5242 Lupfig
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.ch
Thailand
STIEBEL ELTRON Asia Ltd.
469 Moo 2 Tambol Klong-Jik
Amphur Bangpa-In | 13160 Ayutthaya
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebeleltronasia.com
United Kingdom and Ireland
STIEBEL ELTRON UK Ltd.
Unit 12 Stadium Court
Stadium Road | CH62 3RP Bromborough
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.co.uk
United States of America
STIEBEL ELTRON, Inc.
17 West Street | 01088 West Hatfield MA
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron-usa.com
A 171471-39594-9161 B 289191-39594-9161
4<AMHCMM=hbehbe>
