Stihl BGA 86 User manual

BGA 86
2 - 21 Instruction Manual
21 - 44 Notice d’emploi

Contents
1 Introduction................................................. 2
2 Guide to Using this Manual.........................2
3 Main Parts...................................................2
4 Safety Symbols on the Products.................3
5 IMPORTANT SAFETY INSTRUCTIONS....3
6 Battery Safety............................................. 7
7 Maintenance, Repair and Storage.............. 9
8 General Warnings and Instructions.............9
9 Before Starting Work.................................10
10 Charging the Battery................................. 10
11 LED Diagnostics and Acoustic Signals..... 12
12 STIHL AR Backpack Battery.....................13
13 Assembling the Blower............................. 14
14 Inserting and Removing the Battery..........14
15 Switching the Blower On and Off.............. 15
16 Checking the Controls...............................16
17 During Operation.......................................16
18 After Finishing Work..................................17
19 Transporting the Blower and Battery........ 17
20 Storing the Blower and Battery................. 17
21 Cleaning....................................................18
22 Inspection and Maintenance..................... 19
23 Troubleshooting Guide..............................19
24 Specifications............................................20
25 Replacement Parts and Equipment.......... 21
26 Disposal.................................................... 21
27 Addresses................................................. 21
1 Introduction
Thank you for your purchase. The information
contained in this manual will help you receive
maximum performance and satisfaction from
your blower and, if followed, reduce the risk of
injury from its use.
SAVE THIS MANUAL!
Because a blower is a high-speed bat‐
tery-powered tool, special safety pre‐
cautions must be observed to reduce
the risk of personal injury.
Read this instruction manual thor‐
oughly before use and periodically
thereafter. Follow all safety precau‐
tions. Careless or improper use of the
blower can cause serious or fatal
injury.
Do not lend or rent the blower without this
instruction manual. Allow only persons who fully
understand the information in this manual to
operate the blower.
For further information, or if you do not under‐
stand any of the instructions in this manual,
please go to www.stihlusa.com (for Canada:
www.stihl.ca) or contact your authorized STIHL
servicing dealer.
2 Guide to Using this Manual
2.1 Signal Words
This manual contains safety information that
requires your special attention. Such information
is introduced with the following symbols and sig‐
nal words:
DANGER
■ Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
■ Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
NOTICE
■ Indicates a risk of property damage, including
damage to the machine or its individual com‐
ponents.
2.2 Symbols in Text
The following symbol is included to assist you
with the use of the manual:
Refers to a designated chapter or sub-chapter
in this instruction manual.
3 Main Parts
3.1 Blower and Battery
7
6
8
9
1
2
5
#
4
3
10 11
12
#
0000-GXX-9902-A0
1 Nozzle
Directs and concentrates the airstream.
2 Blower Tube
Directs the airstream.
3 Intake Screen
Covers the air intake opening and reduces
risk of contact with the blower fan.
4 Battery Compartment
Holds the battery.
5 Locking Lever
Secures the battery in the battery compart‐
ment.
English
2 0458-824-8221-B
© ANDREAS STIHL AG & Co. KG 2023
0458-824-8221-B. VA0.J23.
Printed on chlorine-free paper Paper is recyclable.
Original Instruction Manual
0000008994_008_GB

6 Control Handle
The blower's handle.
7 Ergo-Lever
Holds the retaining latch in the unlocked posi‐
tion.
8 Retaining Latch
Locks/unlocks the trigger switch.
9 Trigger Switch
Switches the motor on and off.
10 Battery
Supplies electrical power to the motor.
11 Battery LEDs
Indicate the battery's state of charge and dis‐
play error messages regarding potential mal‐
functions in the battery or power tool.
12 Push Button
Activates the battery‘s LEDs.
# Rating Plate
Contains electrical information and the pro‐
duct's serial number.
4 Safety Symbols on the
Products
4.1 Blower
The following safety symbols are found on the
blower.
To reduce the risk of injury, follow the
specified safety precautions.
Read and follow all safety precautions
in the instruction manual. Improper use
can lead to serious or fatal personal
injury or property damage.
To reduce the risk of eye injury, always
wear proper eye protection, 5.4.
To reduce the risk of personal injury
from blown objects, never direct the air
flow toward bystanders or pets,
5.6.4.
To reduce the risk of personal injury,
keep hair and loose-fitting clothing
away from the air intake, 5.4.
To reduce the risk of injury or property
damage from unintended activation,
remove the battery any time the blower
is not in use, 5.5.
5m (17 ft)
To reduce the risk of personal
injury from high velocity air flow
and blown objects, keep bystand‐
ers at least 17 ft. (5 m) away,
5.6.4.
4.2 Battery
The following safety symbols are found on the
AR series backpack battery and the AP series
battery:
To reduce the risk of injury, follow the
specified safety precautions.
Read and follow all safety precautions
in the battery's instruction manual and
the manual for the STIHL tool powered
by this battery. Improper use can lead
to serious or fatal personal injury or
property damage.
To reduce the risk of personal injury or
property damage from fire, explosion
or burns, including chemical burns, do
not disassemble, crush, drop, damage
or heat above 212 °F (100 °C). Never
expose to fire or incinerate, 6.1.
AR 1000, 2000, 3000 Backpack Batteries
To reduce the risk of personal injury or
property damage from a short circuit,
fire or explosion, keep dry. Protect
from rain, water, liquids and damp con‐
ditions. Never immerse in water or
other liquids, 6.1.
AR L Backpack Batteries
To reduce the risk of personal injury or
property damage from a short circuit,
fire or explosion, keep dry. Never
immerse in water or other liquids,
6.1.
AP Series Batteries
To reduce the risk of personal injury or
property damage from a short circuit,
fire or explosion, keep dry. Never
immerse in water or other liquids,
6.1.
Batteries sold separately.
5 IMPORTANT SAFETY
INSTRUCTIONS
5.1 Introduction
When using an electric blower, basic precautions
should always be followed, including the follow‐
ing:
READ ALL INSTRUCTIONS BEFORE USING
THE BLOWER!
SAVE THESE INSTRUCTIONS
4 Safety Symbols on the Products English
0458-824-8221-B 3

WARNING
■ To reduce the risk of fire, explosion, electric
shock or other personal injury, read and follow
the important safety instructions in this chap‐
ter. Additional important warnings and instruc‐
tions are provided in subsequent chapters of
this manual.
5.2 Intended Use
WARNING
■ This blower is designed for blowing leaves,
grass, and similar lightweight material from
yards, gardens, sidewalks, driveways, decks,
patios and comparable surfaces in the manner
and in the conditions described in this manual.
Use of the blower for operations different than
intended could result in serious injury or death.
►Blow leaves, grass, and similar lightweight
material only.
■ Improper use could result in personal injury or
property damage, including damage to the
blower.
►Use the blower and battery only as descri‐
bed in this manual.
► Never attempt to modify or override the
blower's controls or safety devices in any
way.
►Never use a blower that has been modified
or altered from its original design.
► Be sure to read and follow the warnings
and instructions for your battery and
charger before charging or starting work.
■This power tool may be powered by a STIHL
AP series battery. Alternatively, it may be pow‐
ered by a STIHL AR series backpack battery
in combination with an AP Adapter.
Batteries, chargers and other accessories are
sold separately.
5.3 Operator
WARNING
■Working with the blower can be strenuous.
The operator must be in good physical condi‐
tion and mental health. To reduce the risk of
personal injury:
►Check with your doctor before using the
blower if you have any health condition that
may be aggravated by strenuous work.
►Do not operate the blower while under the
influence of any substance (drug, alcohol or
medication, etc.) that might impair vision,
balance, dexterity or judgment.
►Be alert. Do not operate the blower when
you are tired. Take a break if you become
tired.
►Do not permit minors to use the blower.
■ According to STIHL's current knowledge, the
electric motor of this blower should not inter‐
fere with a pacemaker.
►However, persons with a pacemaker or
other implanted medical device should con‐
sult their physician and device manufac‐
turer before operating this blower.
5.4 Personal Protective Equipment
WARNING
■ To reduce the risk of personal injury:
► Always wear proper clothing and protective
apparel, including proper eye protection.
■ Loss of control and severe injuries may result
if hair, clothing or apparel are drawn into the
air intake or otherwise become entangled in
the components of the blower. To reduce the
risk of severe personal injury:
► Wear sturdy and snug-fitting clothing
that also allows complete freedom of
movement.
► Wear overalls or long pants made of
heavy material to help protect your
legs. Do not wear shorts.
►Wear a long-sleeve shirt or jacket.
► Avoid loose-fitting jackets, scarves,
neckties, flared or cuffed pants, jew‐
elry and any other apparel that could
be drawn into the air intake.
► Secure hair above shoulder level
before starting work.
■To reduce the risk of eye injury:
► Always wear goggles or close-fitting
protective glasses with adequate
side protection that are impact-rated
and marked as complying with
CSA Z94.
■Good footing is very important. To help main‐
tain a secure footing and reduce the risk of
injury while working:
► Wear substantial footwear with non-
slip soles. Do not wear sandals, flip-
flops, open-toed or similar footwear.
■ To help reduce the risk of personal injury
caused by loss of control during operation:
► STIHL recommends wearing heavy-
duty non‑slip work gloves made of
leather or another wear-resistant
material when handling the blower.
English 5 IMPORTANT SAFETY INSTRUCTIONS
4 0458-824-8221-B

5.5 Blower
WARNING
■To reduce the risk of electric shock:
► Do not immerse the blower in water or other
fluids.
► Store the blower indoors.
■ This battery-powered blower is intended only
for garden and landscape maintenance. Use
for other purposes may increase the risk of
personal injury and property damage.
►Read and follow the operating instructions
in this manual for approved applications,
17.
■To reduce the risk of personal injury to the
operator and bystanders:
► Always release the trigger switch
and remove the battery before
assembling, transporting, adjusting,
inspecting, cleaning, servicing, main‐
taining or storing the blower, and any
other time it is not in use.
■Although certain unauthorized attachments
may fit STIHL blowers, their use may be
extremely dangerous. Only attachments sup‐
plied by STIHL or expressly approved by
STIHL for use with this specific model are rec‐
ommended.
►Use only attachments supplied or expressly
approved by STIHL.
► Never modify this blower in any way.
► Never attempt to modify or override the
blower's controls or safety devices in any
way.
►Never use a blower that has been modified
or altered from its original design.
► Do not put any object into the openings of
the blower.
► Do not use the blower with any openings
blocked.
► Keep the blower free of dust, lint, hair and
anything that might reduce air flow.
■ If the blower is dropped or subjected to similar
heavy impacts:
► Check that it is undamaged, in good condi‐
tion and functioning properly before con‐
tinuing work.
►Check that the controls and safety devices
are working properly.
►Check the LEDs for error messages,
11.1.2.
► Check that the battery has not been dam‐
aged. Never use or charge a malfunction‐
ing, damaged, cracked, leaking or
deformed battery.
►Never work with a damaged or malfunction‐
ing blower or battery. In case of doubt, have
the blower and battery checked by your
authorized STIHL servicing dealer.
■If the blower or battery is damaged, not work‐
ing properly, has been left outdoors and
exposed to rain or damp conditions, or drop‐
ped into water or other liquid, its components
may no longer function properly and safety
devices may be inoperative. To reduce the risk
of personal injury and property damage:
►Take the blower and battery to your author‐
ized STIHL servicing dealer to be checked
before further operation.
■Genuine STIHL replacement parts are specifi‐
cally designed to match your blower and meet
safety and performance requirements. Use of
parts that are not authorized or approved by
STIHL may cause serious or fatal injury or
property damage.
►STIHL recommends that only identical
replacement parts be used.
5.6 Using the Blower
5.6.1 Before Operation
WARNING
■ Misuse or unauthorized use may result in per‐
sonal injury and property damage.
► Use the blower only as described in this
instruction manual.
■ Using a blower that is modified, damaged,
improperly adjusted or maintained, or not com‐
pletely and securely assembled can increase
the risk of serious personal injury.
►Never operate a blower that is modified,
damaged, improperly maintained or not
completely and securely assembled.
►Always check your blower for proper condi‐
tion and operation before starting work, par‐
ticularly the retaining latch, Ergo-Lever and
trigger switch.
►Ensure that the retaining latch, Ergo-Lever
and trigger switch move freely and spring
back into place when released. The trigger
switch must not engage until the retaining
latch is unlocked.
►Never attempt to modify or override the
controls or safety devices in any way.
► If your blower or any part is damaged or
does not function properly, take it to your
authorized STIHL servicing dealer. Do not
use the blower until the problem has been
corrected.
■Before inserting the battery:
5 IMPORTANT SAFETY INSTRUCTIONS English
0458-824-8221-B 5

► Check the electrical contacts in the battery
compartment for corrosion or other foreign
matter. Keep clean.
►Never insert or use a malfunctioning, dam‐
aged, cracked, leaking or deformed battery.
► Read and follow the instructions on switch‐
ing on the blower, 15.1.
■ To help reduce the risk of serious personal
injury from unintentional starting:
► Be sure the retaining latch is in the locked
position and the trigger switch is in the off
position before inserting the battery.
►Never carry the blower with your finger on
the trigger switch.
► Release the trigger switch before removing
the battery.
► Remove the battery before assem‐
bling, transporting, adjusting,
inspecting, cleaning, servicing, main‐
taining or storing the blower, and any
other time it is not in use.
►Never leave the blower unattended when
the battery is inserted.
► Never store the battery in the blower.
5.6.2 Holding and Controlling the Blower
0000-GXX-4495-A0
WARNING
■To maintain a firm grip and properly control
your blower:
► Keep the handle clean and dry at all times.
Keep it free of moisture, pitch, oil, grease
and resin.
■To reduce the risk of serious or fatal injuries to
the operator or bystanders from loss of con‐
trol:
►Always hold the blower firmly with one hand
when you are working.
► Wrap your fingers tightly around the handle,
keeping the handle cradled between your
thumb and forefinger (see illustration).
■To reduce the risk of serious or fatal injuries to
the operator or bystanders from loss of con‐
trol, keep proper footing and balance at all
times:
►Never work on a ladder, roof, in a tree or
while standing on any other insecure sup‐
port.
►Take special care in overgrown or wet ter‐
rain and always watch for hidden obstacles
such as tree stumps, roots, rocks, holes
and ditches to avoid stumbling.
►Be extremely cautious when working on
slopes or uneven ground.
► Use extra care when working on stairs.
► For better footing, always clear away fallen
branches, scrub, cuttings and other mate‐
rial, objects or vegetation that can increase
the danger of slipping, tripping or falling.
►Never operate the blower above shoulder
height.
► Do not overreach. Keep proper footing and
balance at all times.
5.6.3 Working Conditions
WARNING
■ Operate your blower only under good visibility
during favorable daylight conditions.
► Postpone the work if the weather is windy,
foggy, rainy or inclement.
■ Your blower is a one-person machine.
► Bystanders, especially children, and ani‐
mals should not be allowed in the area
where it is in use.
►Switch off the blower immediately if you are
approached.
■ To reduce the risk of injury to bystanders and
unauthorized users:
► Never leave the blower unattended when
the battery is inserted.
► Switch off the blower and remove the bat‐
tery during work breaks and any other time
the blower is not in use.
■Operating the blower in certain dry, dusty con‐
ditions may cause static electricity to build up
in the blower tube, nozzle and housing. This
static electricity may discharge suddenly with
a spark. To reduce the risk of personal injury
following static discharge:
►Never operate the blower in a location
where combustible gases, liquids, vapors,
dusts or other combustible materials and
substances are present.
■Sparks generated from operation of the blower
may be capable of igniting combustible gases,
liquids, vapors, dusts or other combustible
materials and substances. To reduce the risk
of fire and explosion:
English 5 IMPORTANT SAFETY INSTRUCTIONS
6 0458-824-8221-B

► Never operate the blower in a location
where combustible gases, liquids, vapors,
dusts or other combustible materials and
substances are present.
►Read and follow recommendations issued
by government authorities (e.g., CCOHS)
for identifying and avoiding the hazards of
combustible gases, liquids, vapors, dusts or
other combustible materials and substan‐
ces.
■Use of this blower can generate dust and
other substances containing chemicals known
to cause respiratory problems, cancer, birth
defects and other reproductive harm.
►Consult governmental agencies such as
ECCC, CCOHS and PHAC and other
authoritative sources on hazardous materi‐
als if you are unfamiliar with the risks asso‐
ciated with the particular substances with
which you are working.
■Inhalation of certain dusts, especially organic
dusts such as mold or pollen, can cause sus‐
ceptible persons to have an allergic or asth‐
matic reaction. Substantial or repeated inhala‐
tion of dust or other airborne contaminants,
especially those with a smaller particle size,
may cause respiratory or other illnesses.
►Control dust at the source where possible.
► To the extent possible, operate the blower
so that the wind or operating process
directs any dust, mist or other particulate
matter raised by the blower away from the
operator.
►When respirable dust or other particulate
matter cannot be kept at or near back‐
ground levels, always wear a respirator that
is approved by PHAC and rated for work‐
site-specific conditions. Follow the recom‐
mendations of governmental authorities
(e.g., CCOHS/PHAC) and occupational and
trade associations.
■ If the surrounding ground is coated with a
chemical substance, such as pesticide or her‐
bicide:
►Read and follow the instructions and warn‐
ings that accompanied the substance coat‐
ing the vegetation or surrounding ground.
5.6.4 Operating Instructions
WARNING
■In the event of an emergency:
► Switch off the motor immediately and
remove the battery.
■ The blower fan between the air intake and out‐
put opening rotates whenever the motor is
running. To reduce the risk of injury from con‐
tact with the blower fan:
► Never operate the blower with a missing,
cracked or worn intake screen or housing.
► Never operate the blower without a properly
mounted blower tube and nozzle.
► Keep hair, loose clothing, fingers and all
parts of the body away from openings and
moving parts of the blower.
■The air flow from the blower can propel small
objects at high speed. To reduce the risk of
eye or other serious personal injuries to
bystanders from blown objects:
5m (17 ft)
► Keep bystanders and pets at
least 17 ft. (5 m) away when
the blower is running.
► Never direct the air flow toward
bystanders or pets.
► Do not allow the blower to be used as a toy.
► Switch off the blower immediately if you are
approached.
■ A missing, cracked or worn intake screen or
housing may result in an increased risk of
injury from thrown objects.
►Never operate a blower that has a missing,
cracked or worn intake screen or housing.
■ Inserting any foreign object into the air intake
or nozzle may result in property damage,
including damage to the blower itself, and seri‐
ous injury to the operator or bystanders as a
result of the object or broken parts being
blown at high speed.
►Never insert any objects into the nozzle or
air intake of the blower.
► Immediately switch off the blower if it starts
to vibrate abnormally.
■ Using the blower to spread herbicides, pesti‐
cides, fertilizers or other chemical substances
can be dangerous and may cause serious or
fatal injury to persons and damage to the envi‐
ronment.
►Never use the blower to disperse or spread
chemicals of any kind.
6 Battery Safety
6.1 Warnings and Instructions
WARNING
■Read and follow the safety precautions on the
battery and all warnings and instructions that
accompany it.
6 Battery Safety English
0458-824-8221-B 7

■ Use of unauthorized batteries can damage the
power tool and result in fire, explosion and
personal injury and property damage.
►Use only genuine STIHL AR or AP series
batteries with this power tool.
■ Use of STIHL AR or AP series batteries for
any purpose other than powering STIHL prod‐
ucts could be extremely dangerous.
►Use STIHL AR and AP series batteries only
to power compatible STIHL products.
■ Use of unauthorized chargers can damage the
battery and result in fire, explosion and per‐
sonal injury and property damage.
►Charge STIHL AP series batteries only with
genuine STIHL AL 101, AL 301, AL 301-4
or AL 500 series chargers.
►Charge STIHL AR series backpack batter‐
ies only with genuine STIHL AL 301,
AL 301-4 or AL 500 series chargers.
■The battery contains safety features and devi‐
ces which, if damaged, may allow the battery
to generate heat, rupture, leak, ignite or
explode.
► Never heat the battery above 212 °F
(100 °C).
► Never incinerate or place the battery
on or near fires, stoves or other high-
temperature locations.
►Never use or charge a malfunctioning, dam‐
aged, cracked, leaking or deformed battery.
► Never open, disassemble, crush, drop, sub‐
ject to heavy impact or otherwise damage
the battery.
►Never expose the battery to microwaves or
high pressures.
► Never insert objects into the battery's cool‐
ing slots.
■ Extreme temperatures may cause the battery
to generate heat, rupture, leak, ignite or
explode, resulting in severe or fatal personal
injury and property damage.
►Never charge, use or store the battery out‐
side the specified ambient temperature lim‐
its, 24.2.
■To reduce the risk of personal injury and prop‐
erty damage in the event the battery emits
smoke, has an unusual smell or feels unusu‐
ally hot while using, charging or storing:
►Immediately discontinue using or charging
the battery. Contact the authorities in the
event of fire or explosion.
■To reduce the risk of a short circuit, which
could lead to electric shock, fire and explosion:
► Keep STIHL AR 1000, 2000, 3000
backpack batteries dry. Protect from
rain, water and other liquids. Attach
the rain cover to the battery before
starting work in rain or in very damp
conditions.
► If a STIHL AP or AR L battery has
been exposed to rain during work,
remove it from the product and allow
it to dry indoors. Make sure it is com‐
pletely dry before charging or using.
► Never immerse any STIHL battery in
water or other liquids.
►Never bridge the battery terminals with
wires or other metallic objects.
► Keep a battery that is not in use away from
small metal objects capable of conducting
electricity (e.g., paper clips, nails, coins,
keys).
►Store the battery indoors in a dry room.
► Never store the battery in damp or corro‐
sive environments or in conditions that
could lead to corrosion of its metal compo‐
nents.
►Never store the battery in the power tool.
► When storing the battery, maintain a charge
of 40 % to 60 % for STIHL AP series batter‐
ies and a charge of 30 % to 45 % for STIHL
AR series batteries (2 green LEDs).
►If storing the battery in the charger, discon‐
nect the charger from the outlet.
► Protect the battery from exposure to corro‐
sive agents such as garden chemicals and
de-icing salts.
►Protect the battery from exposure to con‐
ductive liquids such as salt water.
► Do not attempt to repair, open or disassem‐
ble the battery. There are no user-servicea‐
ble parts inside.
■Leaking battery fluid is potentially harmful and
can cause skin and eye irritation, chemical
burns and other serious personal injury.
►Avoid contact with skin and eyes.
► Use an inert absorbent such as sand on
spilled battery fluid.
► In the event of accidental contact, immedi‐
ately rinse the contact area thoroughly with
mild soap and water.
►If fluid gets into your eye(s): do not rub.
Rinse water over the open eye(s) for at
least 15 minutes and seek medical atten‐
tion.
■A battery fire can be dangerous. To reduce the
risk of severe personal injury and property
damage in the event of fire:
English 6 Battery Safety
8 0458-824-8221-B

► Evacuate the area. Fire can spread rapidly.
Stay clear of any vapors generated and
maintain a safe distance.
►Contact the fire department.
► Although water can be used to put out a
battery fire, use of a multi-purpose dry
chemical fire extinguisher is preferable.
►Consult the fire department regarding
proper disposal of a burned battery.
7 Maintenance, Repair and
Storage
7.1 Warnings and Instructions
WARNING
■ There are no user-authorized repairs for the
battery or blower. To reduce the risk of fire,
electric shock or other personal injury and
property damage:
►Users may carry out only the cleaning and
maintenance operations described in this
manual.
►Strictly follow the cleaning and maintenance
instructions in the appropriate sections of
this instruction manual.
►STIHL recommends that all repair work be
performed by authorized STIHL servicing
dealers.
■Unintentional starting may result in personal
injury or property damage.
► Remove the battery before inspect‐
ing the blower or carrying out any
cleaning, maintenance or repair
work, before storing, and any other
time the blower is not in use.
■Use of parts that are not authorized or
approved by STIHL may cause serious or fatal
injury or property damage.
►STIHL recommends that only identical
STIHL replacement parts be used for repair
or maintenance.
■To reduce the risk of short circuit and fire:
► Keep the battery guides free of foreign mat‐
ter. Clean as necessary with a dry cloth or
soft, dry brush.
■Improper storage can result in unauthorized
use, damage to the blower and battery and an
increased risk of fire, electric shock and other
personal injury or property damage.
►Remove the battery from the blower before
storing.
► Never store the blower with the battery
inserted.
► When storing the battery, maintain a charge
of 40 % to 60 % for STIHL AP series batter‐
ies and a charge of 30 % to 45 % for STIHL
AR series batteries (2 green LEDs).
► If storing the battery in the charger, discon‐
nect the charger from the outlet.
► Store the blower and battery indoors in a
dry, secure place that cannot be accessed
by children or other unauthorized users.
►Never store the battery in the blower or in a
container with small metal objects capable
of conducting electricity (e.g., paper clips,
nails, coins, keys).
■Dropping the battery could result in personal
injury or property damage. To prevent the bat‐
tery from falling during removal:
►Use care when ejecting the battery.
8 General Warnings and
Instructions
8.1 General Safety Warnings and
Instructions for Battery-Pow‐
ered Products
This section contains the general safety warn‐
ings and instructions for battery-powered prod‐
ucts contained in UL 2595 / CSA C22.2 No. 0.23.
WARNING
■Read all safety warnings and instructions.
■ Failure to follow the warnings and instructions
may result in electric shock, fire, explosion
and/or serious injury or property damage.
■Prevent unintentional starting. Ensure the trig‐
ger switch is in the off-position before inserting
the battery, picking up or carrying the blower.
Carrying the blower with your finger on the
trigger switch or inserting the battery with the
trigger switch engaged increases the likeli‐
hood of unintended starting and possible acci‐
dents.
■ Remove the battery from the blower before
making any adjustments, changing accesso‐
ries, or storing. Such preventive safety meas‐
ures reduce the risk of starting the blower
accidentally.
■Recharge only with the charger specified by
STIHL. A charger that is suitable for one type
of battery may create a risk of fire when used
with another battery.
■Use the blower only with the specifically desig‐
nated batteries. Use of any other battery may
create a risk of fire or explosion and personal
injury or property damage.
■When the battery is not in use, keep it away
from other metal objects, like paper clips,
7 Maintenance, Repair and Storage English
0458-824-8221-B 9

coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi‐
nals together may cause burns or a fire.
■Under abusive conditions, liquid may be ejec‐
ted from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irri‐
tation, chemical burns or respiratory illness
from inhalation.
■Do not use a battery or blower that is dam‐
aged or modified. Damaged or modified bat‐
teries may exhibit unpredictable behavior
resulting in fire, explosion and risk of injury or
property damage.
■Do not expose a battery or the blower to fire or
excessive temperature. Exposure to fire or
temperatures above 212 °F (100 °C) may
cause fire and explosion.
■Follow all charging instructions and do not
charge the battery outside of the ambient tem‐
perature range specified. Charging improperly
or outside the specified range may damage
the battery and increase the risk of fire.
■Have servicing performed by a qualified repair
person using only identical replacement parts.
■ Do not modify or attempt to repair the blower
or the battery pack. Follow the instructions for
use and care.
9 Before Starting Work
9.1 Preparing the Blower for Oper‐
ation
Before starting work:
►Fully charge the battery, 10.
►Mount the nozzle, 13.1.
► Check the controls for proper function and
condition, 16.
10 Charging the Battery
10.1 Setting up the Charger
WARNING
■ Read and follow the safety precautions on the
battery and charger and all warnings and
instructions that accompany those products.
To reduce the risk of short circuit, which could
lead to electric shock, fire and explosion,
make sure the charger and its components are
dry and not damaged. Read and follow the
warnings and instructions in your charger's
manual. For optimum performance, observe
the recommended ambient temperature
ranges, 24.3.
WARNING
■ A typical household electric circuit is between
15 and 20 amps. A single STIHL AL 500
charger draws approximately 4.8 amps. A sin‐
gle AL 301 or AL 301-4 charger draws approx‐
imately 4.4 amps and an AL 101 approxi‐
mately 1.3 amps. To reduce the risk of fire
from overloading an electrical circuit:
►Ensure the electrical system is rated to
withstand the expected electrical draw
before charging your battery.
►Charge multiple batteries one at a time or
on separate circuits, unless you know your
circuit can handle the total expected draw
from multiple chargers.
WARNING
■ Since the charger heats up during the charg‐
ing process, do not operate the charger on a
combustible surface or in a location where
combustible gases, liquids, vapors, dusts or
other materials and substances are present.
To set up the charger:
3
2
4
1
1
2
3
4
0000082682_005
English 9 Before Starting Work
10 0458-824-8221-B

► Insert the plug (3) into a properly installed
electrical outlet (4) matching the voltage and
electrical frequency stated on the charger's
rating plate.
The charger runs a self-test immediately after it
is plugged in. The charger LED (1) will glow
green for about 1 second, then it will glow red
briefly before going out. Once the LED goes out,
the self-test is complete and the charger is ready
to charge the battery.
► Position the power supply cord (2) so that it
will not be stepped on, tripped over, come in
contact with sharp objects or moving parts or
otherwise be subjected to damage or stress.
10.2 Charging
WARNING
■ STIHL batteries contain safety features and
devices which, if damaged, may allow the bat‐
tery to generate heat, rupture, leak, ignite or
explode. Never charge a malfunctioning, dam‐
aged, cracked, leaking or deformed battery, or
use a charger that has been damaged. Never
insert a wet battery or battery adapter. Never
use a wet charger. Follow all product-specific
warnings and instructions accompanying your
battery and charger.
A battery is not fully charged when it ships from
the factory. STIHL recommends that you fully
charge the battery before using it the first time.
Read and follow the warnings and instructions in
your charger's manual. For optimum perform‐
ance, observe the recommended ambient tem‐
perature ranges, 24.3.
The battery heats up during operation of the
power tool. If a hot battery is connected to the
charger, it may be necessary for it to cool down
before charging starts. The charging process
begins only after the battery has cooled down
sufficiently.
Charging time depends on a number of factors,
including battery condition and the ambient tem‐
perature. For a complete list of approximate
charging times, see www.stihl.com/charging-
times.
To charge an AR battery:
3
1
3
45
4
5
2
0000081894_003
► Push the plug of the connecting cord (1) into
the socket (2) of the AP Adapter (3) until it
stops.
► Push the AP Adapter into the charger (5) until
it stops.
The LED (4) on the charger glows green when
the battery is charging.
The LEDs on the AR battery glow green and
show the state of charge.
When the LEDs on the battery turn off, the
charging process is complete and the charger
will shut itself off. The AP Adapter can be
removed from the charger.
► Disconnect the power supply cord from the
electrical outlet when the charger is not in use
for extended periods of time.
► Charge STIHL AR backpack batteries only
with genuine STIHL AL 301, AL 301-4 or AL
500 series chargers.
To charge an AP battery:
2
3
4
1
0000083481_002
► Push the battery (2) into the charger (3) until it
stops.
The LED on the charger glows green when the
battery is charging.
The LEDs (1) on the AP battery glow green
and show the state of charge.
When the LEDs on the battery go out, the
charging process is complete and the charger
will shut itself off. The AP battery can be
removed from the charger.
► Disconnect the power supply cord from the
electrical outlet when the charger is not in use
for extended periods of time.
► Charge STIHL AP series batteries only with
genuine STIHL AL 101, AL 301, AL 301-4 or
AL 500 series chargers.
10 Charging the Battery English
0458-824-8221-B 11

11 LED Diagnostics and
Acoustic Signals
11.1 STIHL AP Battery
11.1.1 Battery Status
Four LEDs show the status of the battery. These
LEDs can glow or flash green or red.
If one LED glows red continuously: the
battery is either too hot or too cold.
Allow the battery to warm up or cool
down gradually at an ambient tempera‐
ture of about 50 °F to 68 °F (10 °C to
20 °C).
If all 4 LEDs flash red: the battery has
a malfunction and must be replaced.
Do not attempt to charge, use or store
the battery.
11.1.2 Power Tool Status
The same LEDs on the battery will indicate the
status of the power tool.
If three LEDs glow red continuously: the power
tool motor is too hot. Allow the motor to cool
down.
If three LEDs flash red when you activate the
trigger switch: the power tool has an electrical
malfunction. Do not operate the power tool. Have
it checked by an authorized STIHL servicing
dealer before use or storage.
For troubleshooting information, 23.
11.1.3 Charge Status
The LEDs on the battery also show the battery's
state of charge.
To determine the battery's state of charge:
0000079877_002
20-40%
40-60%
60-80%
80-100%
0-20%
1
► Press the button (1) on the battery.
The LEDs on the battery will glow or flash
green for about 5 seconds and indicate the
state of charge (see illustration).
For example:
If four green LEDs glow continuously: full charge.
If one green LED is flashing: less than 20 %
charge.
11.2 STIHL AR Backpack Battery
11.2.1 Battery Status
Six LEDs and an acoustic signal indicate the sta‐
tus of the battery.
1
2
3.......
0000-GXX-3229-A1
1 A short beep
The acoustic signal works as it should.
2 Four or six (AR L) long beeps
The battery's charge is low. Recharge the
battery.
3 Rapid succession of short beeps
There is a malfunction in the battery. The sig‐
nal stops automatically after a few seconds.
Do not attempt to charge, use or store the
battery. Replace the battery.
These LEDs can glow or flash green or red.
If one LED glows red continuously: the
battery is either too hot or too cold.
Allow the battery to warm up or cool
down gradually at an ambient tempera‐
ture of about 50 °F to 68 °F (10 °C to
20 °C).
If the four right side LEDs flash red and
a rapid succession of several short
beeps is emitted: the battery has a
malfunction and must be replaced. Do
not attempt to charge, use or store the
battery.
► Be aware that your ability to hear the acoustic
signal may be reduced when wearing hearing
protection.
11.2.2 Power Tool Status
When the battery is connected to the power tool,
the same LEDs on the battery will indicate the
status of the power tool.
If three LEDs glow red continuously: the power
tool motor is too hot. Allow the motor to cool
down.
If three LEDs flash red when you activate the
trigger switch: the power tool has an electrical
English 11 LED Diagnostics and Acoustic Signals
12 0458-824-8221-B

malfunction. Do not operate the power tool. Have
it checked by an authorized STIHL servicing
dealer before use or storage.
For troubleshooting information, 23.
11.2.3 Charge Status
The LEDs and acoustic signals on the battery
also indicate the battery's state of charge.
To determine the battery's state of charge:
0000-GXX-2673-A0
100 % 0 %
► Press the button (1) on the backpack battery.
A single short beep will be emitted. The LEDs on
the battery will glow or flash green for about
5 seconds and indicate the state of charge (see
illustration).
For example:
If six green LEDs glow continuously: full charge.
If one green LED is flashing and four long beeps
are emitted: less than 20 % charge.
12 STIHL AR Backpack Bat‐
tery
12.1 Positioning the Connecting
Cord
WARNING
■ To reduce the risk of injury from tripping on the
connecting cord or losing control of the power
tool, always secure the connecting cord with
the hook and eye fasteners as described
below. Always position and secure the con‐
necting cord so that it will not interfere with the
proper working technique as described in the
instruction manual for the power tool you are
using, or your ability to maintain control of the
power tool.
WARNING
■ Manage the cord to prevent it from contacting
the cutting/working attachment or catching on
objects, which could cause you to lose bal‐
ance or control of the power tool, resulting in
serious personal injury and property damage.
The connecting cord can be secured in different
positions and adjusted to suit the height and
reach of the operator.
1
2
2
2
2
A B
0000-GXX-9303-A0
The connecting cord can run through the
guide (1) on the shoulder strap (Illustration A), or
along the back plate (Illustration B). Secure the
connecting cord to the harness with the hook
and eye fasteners (2). Always secure the con‐
necting cord using the guide or hook and eye
fasteners on the side of the body on which the
power tool is held and controlled. Do not allow
the connecting cord to swing across your body or
hang at your side.
0000-GXX-9304-A0
CD
The length of the connecting cord can be adjus‐
ted by making a loop around the top (Illustra‐
tion C) or on the side (Illustration D) of the back‐
pack battery with the hook and eye fasteners.
12.2 Putting on the Harness
WARNING
■ The operator must be able to remove the
backpack battery quickly in the event of an
emergency. In an emergency, open and
remove the waist belt and chest strap quickly
before dropping the battery to the ground.
12 STIHL AR Backpack Battery English
0458-824-8221-B 13

To ensure a proper fit:
1
0000-GXX-7803-A0
► Put the backpack battery on your back.
► Fasten and adjust the waist belt (2) so that it
rests comfortably but securely on your hips.
► Fasten the chest strap (1) and adjust it so that
it fits comfortably but securely across your
chest.
3
4
0000-GXX-A276-A0
► Adjust the harness straps so that the back
padding fits snugly and securely against your
back.
► Always wear the battery harness over both
shoulders.
► Thread the end of the waist belt through the
loops (3) and (4).
► To remove the harness, open the quick-
release fasteners on the waist belt and chest
strap and loosen the harness straps by lifting
the sliding adjusters.
To help reduce the risk of injury in the event of
an emergency, practice quickly opening the fas‐
teners on the waist belt and chest strap, loosen‐
ing the shoulder straps and removing the battery.
NOTICE
■ To avoid damage, ease the battery to the
ground when practicing. Do not allow the bat‐
tery to drop to the ground and do not throw it.
13 Assembling the Blower
13.1 Mounting and Adjusting the
Nozzle
WARNING
■ Make sure the battery is removed before start‐
ing assembly. Never operate your blower with‐
out a properly mounted blower tube and noz‐
zle, 5.6.4. Use only attachments supplied
or expressly approved by STIHL, 5.5.
The nozzle can be mounted to the blower tube in
three positions to suit the height and reach of the
user. The positions are marked on the blower
tube.
To mount the nozzle:
2
0000-GXX-0625-A0
4
3
1
► Align the nozzle mounting lugs (3) with the
groove on the nozzle (2) and push the noz‐
zle (1) onto the blower tube (4).
► Rotate the nozzle in the direction of the arrow
until it stops.
The nozzle should lock in position.
► To remove the nozzle, reverse the sequence
of steps above.
14 Inserting and Removing
the Battery
14.1 Inserting the Battery
WARNING
■ Never use a malfunctioning, damaged,
cracked, leaking or deformed battery, 6.
Never charge, use or store the battery outside
the specified ambient temperature limits,
24.2.
WARNING
■ To reduce the risk of unintended activation,
never store the battery in the blower, 20.2.
To insert the battery:
English 13 Assembling the Blower
14 0458-824-8221-B

2
1
0000095424_002
► Insert the battery (1) into the battery compart‐
ment (2) until it stops.
The battery is properly inserted when you hear
an audible click and the battery is flush with
the top of the housing. In this position, there is
electrical contact between the battery and the
blower.
Since a new battery is not fully charged, STIHL
recommends that you fully charge the battery
before using it the first time, 10.
14.2 Removing the Battery
WARNING
■ To reduce the risk of severe personal injury
from unintended activation, always remove the
battery before assembling, transporting,
adjusting, cleaning, servicing, maintaining or
storing the blower, and any other time it is not
in use.
WARNING
■ Use care when ejecting the battery to prevent
it from falling and causing personal injury or
property damage.
To remove the battery:
► Release the trigger switch.
► Position your hand behind the battery.
0000095425_002
1
2
► Compress the locking levers (1) to eject the
battery (2) from the battery compartment.
NOTICE
■ Avoid exposing the battery to excessive heat
or prolonged periods of direct sunlight. Use or
storage outside the recommended ambient
temperature range can reduce the perform‐
ance of the battery.
15 Switching the Blower On
and Off
15.1 Switching On
WARNING
■ Never operate your blower if it is modified,
damaged, improperly adjusted or maintained,
not completely and securely assembled or not
functioning properly, 5.5. To reduce the risk
of personal injury, always wear proper clothing
and protective apparel, including proper eye
protection, when operating your blower,
5.4.
Before switching on:
► Make sure you have a secure and firm footing.
► Stand upright.
► Always hold and operate the blower with one
hand firmly on the control handle.
To switch the blower on:
1
3
2
0000-GXX-9903-A0
► Unlock the retaining latch (1) by pushing it for‐
ward with your thumb. Hold it in this unlocked
position.
► While holding the retaining latch, squeeze the
trigger switch (2) with your index finger.
The blower will activate.
The motor will not switch on unless the retaining
latch is pushed forward and the trigger switch is
pressed at the same time. Once the trigger
switch is activated, you may release the retaining
latch. Holding the Ergo-Lever (3) down keeps the
trigger switch unlocked.
The further the trigger switch is depressed, the
stronger the blowing force.
15 Switching the Blower On and Off English
0458-824-8221-B 15

If you releases the trigger switch and Ergo-Lever,
you have to unlock the tool again with the retain‐
ing latch.
15.2 Switching Off
WARNING
■ To reduce the risk of personal injury from unin‐
tended activation or unauthorized use, switch
off the motor and remove the battery before
transporting or putting the blower down.
To switch the blower off:
► Release the trigger switch and Ergo-Lever so
that the trigger switch springs back to the
locked position. In the locked position, activa‐
tion of the trigger switch is once again blocked
by the retaining latch.
16 Checking the Controls
16.1 Testing the Controls
Before starting work, confirm that the retaining
latch (1), Ergo-Lever (2) and the trigger
switch (3) are undamaged and functioning prop‐
erly.
3
2
1
0000-GXX-2383-A1
Retaining Latch (1), Ergo-Lever (2) and Trigger
Switch (3)
WARNING
■ To help reduce the risk of injury from blown
objects, always wear proper eye protection
while testing the controls. Keep bystanders at
least 17 ft. (5 m) away.
To test the controls:
► Remove the battery.
► Attempt to depress the trigger switch.
If the trigger switch can be depressed without
first unlocking the retaining latch, take the
blower to an authorized STIHL servicing
dealer to be repaired before use.
► Press down on the Ergo-Lever. Make sure it
moves freely and springs back into place
when released.
► Unlock the retaining latch by pushing it for‐
ward and depressing the Ergo-Lever. When
you release the retaining latch, it should
remain unlocked as long as you hold the Ergo-
Lever.
► Insert the battery.
► Hold the blower firmly with one hand on the
control handle. While pushing the retaining
latch forward, squeeze the trigger switch with
your index finger.
The blower should switch on. If it does not,
take the blower to an authorized STIHL servic‐
ing dealer to be repaired before use.
► Release the trigger switch.
The blower should switch off.
If the blower does not switch off after you
release the trigger switch, remove the battery
and take the blower to an authorized STIHL
servicing dealer to be repaired before use.
17 During Operation
17.1 Using the Blower
WARNING
■ Always wear proper clothing and protective
apparel, including proper eye protection,
5.4. Never direct the air flow toward bystand‐
ers. Keep bystanders at least 17 ft. (5 m) away
from the work area, 5.6.4. Work carefully
and maintain proper control of the blower.
The blower is designed for single-handed opera‐
tion with either the right or left hand.
0000-GXX-4496-A0
► Hold the unit firmly with your hand, keeping
the handle cradled between your thumb and
fingers.
► Direct the air flow at the edges of the pile of
material to be blown.
NOTICE
■ Never direct the air flow toward objects such
as vehicles or windows.
For optimum performance, observe the recom‐
mended ambient temperature ranges, 24.3.
English 16 Checking the Controls
16 0458-824-8221-B

Observe all applicable laws, regulations, stand‐
ards and ordinances.
18 After Finishing Work
18.1 Preparing for Transportation or
Storage
WARNING
■ To reduce the risk of personal injury from unin‐
tended activation or unauthorized use, switch
off the motor and remove the battery before
transporting the blower or putting it down.
To prepare the blower for transportation or stor‐
age:
►Switch off the blower, 15.2.
►Remove the battery, 14.2.
► If the battery or blower became damp or wet
during operation, allow them to dry separately
and completely before charging or storing,
24.3.
19 Transporting the Blower
and Battery
19.1 Blower
When transporting the blower:
0000-GXX-2382-A0
► When transporting the blower by hand, carry it
by the control handle.
► When transporting the blower in a vehicle,
secure and position the blower to prevent turn‐
over, impact and damage.
19.2 Battery
WARNING
■ To reduce the risk of a short circuit, which
could lead to electric shock, fire and explosion,
never transport the battery with small metal
objects capable of conducting electricity (e.g.,
paper clips, nails, coins, keys), 6.
When transporting the battery:
► Secure the battery in a container against
impact or damage. Never transport the battery
with small metal objects capable of conducting
electricity (e.g., paper clips, nails, coins, keys).
► If you are transporting the battery in a vehicle,
secure it and its container to prevent turnover,
impact and damage.
STIHL batteries comply with the requirements
set forth in UN-Manual of Tests and Criteria, Part
III, Subsection 38.3.
Commercial air, vessel and ground transporta‐
tion of lithium ion cells and batteries is regulated.
The battery is classified as a UN 3480, Class 9,
packaging group II product. Shipping it, either as
a complete tool or the battery, requires compli‐
ance with all applicable shipping regulations.
Check with the ground, vessel, air cargo or pas‐
senger airline to determine if transport is prohibi‐
ted or subject to restrictions or exemptions prior
to shipping or travel.
Normally, no further conditions have to be met by
the user in order to transport STIHL batteries by
road to the power tool's operating site. Check
and comply with any special regulations that may
apply to your situation.
For further information please go to www.stihl.ca.
20 Storing the Blower and
Battery
20.1 Blower
WARNING
■ Store the blower indoors in a dry, secure place
that is inaccessible to children and other unau‐
thorized users. Never store the battery in the
blower. Improper storage can result in unau‐
thorized use and damage to the blower.
When storing the blower:
►Clean the blower, 21.
► Secure and position the blower to prevent
turnover, impact and damage.
► Store the blower indoors in a dry and secure
location, out of the reach of children and other
unauthorized persons.
18 After Finishing Work English
0458-824-8221-B 17

20.2 Battery
WARNING
■ To reduce the risk of a short circuit, which
could lead to electric shock, fire and explosion,
never store the battery with small metal
objects capable of conducting electricity (e.g.,
paper clips, nails, coins, keys), 6. If the bat‐
tery is damp or wet, allow it to dry thoroughly
before storing, 6.
WARNING
■ Extreme temperatures can damage the battery
and may also cause the battery to generate
heat, rupture, leak, ignite or explode, resulting
in severe or fatal personal injury or property
damage. Never charge, use or store the bat‐
tery outside the specified ambient temperature
limits, 24.2.
To properly store the battery:
► Remove the battery from the blower.
► When storing the battery, maintain a charge of
40 % to 60 % for STIHL AP series batteries
and a charge of 30 % to 45 % for STIHL AR
series batteries (2 green LEDs).
► If storing the battery in the charger, disconnect
the charger from the outlet.
► Make sure the battery is dry and store it
indoors in a dry and secure location.
► Keep it out of the reach of children and other
unauthorized persons.
► Protect the battery against dampness and cor‐
rosive agents such as garden chemicals and
de-icing salts.
► Protect the battery from exposure to conduc‐
tive liquids such as salt water.
► For maximum battery life, store the battery at
an ambient temperature between 50 °F and
68 °F (10 °C and 20 °C) with a charge
between 40 % and 60 % for STIHL AP series
batteries and a charge of 30 % to 45 % for
STIHL AR series batteries (2 green LEDs).
► Do not leave spare batteries unused. Use
them in rotation.
NOTICE
■ A battery that is not stored properly may expe‐
rience deep discharge, which can result in per‐
manent damage. To avoid deep discharge:
►Remove the battery from the blower after
finishing work.
► For maximum battery life, store the battery
with a charge between 40 % and 60 % for
STIHL AP series batteries and a charge of
30 % to 45 % for STIHL AR series batteries
(2 green LEDs).
►If storing the battery in the charger, discon‐
nect the charger from the outlet.
► For maximum battery life, store the battery
at an ambient temperature between 50 °F
and 68 °F (10 °C and 20 °C).
21 Cleaning
21.1 Cleaning the Blower and Bat‐
tery
WARNING
■ To reduce the risk of personal injury from unin‐
tended activation, remove the battery before
carrying out any cleaning work, 5.5. Users
of this blower should carry out only the clean‐
ing described in this manual.
To clean the blower and battery:
► Clean a dirty intake screen carefully with a soft
brush whenever required.
► Clean the blower's polymer components with a
slightly dampened cloth. Do not use deter‐
gents or solvents. They may damage the poly‐
mer components.
► Do not use a pressure washer to clean the
blower or otherwise spray it with water or other
liquids.
► Keep the battery housing and guides free from
foreign matter and clean as necessary with a
soft brush or soft, dry cloth.
English 21 Cleaning
18 0458-824-8221-B

22 Inspection and Mainte‐
nance
22.1 Blower
WARNING
■ To reduce the risk of personal injury from unin‐
tended activation, remove the battery before
inspecting the blower or carrying out any
maintenance, 5.5. Carry out only the main‐
tenance operations described in this manual.
There are no user-authorized repairs. STIHL
recommends that repair work be performed by
authorized STIHL servicing dealers.
To properly maintain the blower:
► Inspect the intake screen of the blower and
replace if damaged.
► Have worn, missing or damaged safety labels
replaced by an authorized STIHL servicing
dealer.
23 Troubleshooting Guide
23.1 Blower and Battery
Always remove the battery before carrying out any inspection, cleaning or maintenance.
Condition LEDs on
Battery Cause Remedy
Blower does not
start when
switched on.
No electrical
contact between
blower and bat‐
tery.
►Remove the battery, 14.2.
► Visually check the electrical contacts in the bat‐
tery compartment and on the battery.
►Reinsert the battery, 14.1.
1 LED
flashes
green.
STIHL AR
Series: four
long beeps
are emitted
(AR L - six
beeps).
Battery has low
charge. ►Charge the battery, 10.
1 LED glows
red. Battery too hot / too cold. ► Allow the battery to warm up or cool down grad‐ ually at ambient temperatures of about 50 °F to
68 °F (10 °C to 20 °C).
4 LEDs flash
red.
STIHL
AR Series:
Additionally,
a rapid suc‐
cession of
short beeps
is emitted.
Malfunction in
battery. ►Remove the battery and reinsert it, 14.
►Switch on the blower, 15.1.
► If the LEDs continue to flash, do not attempt to
use.
The battery has a malfunction and must be
replaced.
3 LEDs glow
red. Blower too hot. ► Allow the blower to cool down.
3 LEDs flash
red. Malfunction in blower. ►Remove the battery and reinsert it, 14
►Switch on the blower, 15.1.
► If the LEDs still flash, do not attempt to use.
The blower has a malfunction and must be
checked by a servicing dealer.
Blower cuts out
during operation. 1 LED glows red. Battery too hot / too cold. ►Remove the battery, 14.2.
► Allow the blower and battery to cool down grad‐
ually at ambient temperatures of about 50 °F to
68 °F (10 °C to 20 °C).
3 LEDs glow
red. Blower too hot.
22 Inspection and Maintenance English
0458-824-8221-B 19

Condition LEDs on
Battery Cause Remedy
Run-time is too
short. Battery not fully charged. ►Charge the battery, 10.
Useful life of bat‐
tery has been
reached or
exceeded.
► Have the battery checked by an authorized
STIHL servicing dealer.
Battery is not
being charged
even though LED
on charger glows
green.
1 LED glows
red. Battery too hot / too cold. ► Allow the battery to warm up or cool down grad‐ ually at ambient temperatures of about 50 °F to
68 °F (10 °C to 20 °C).
► Read and follow the warnings and instructions in
your charger's manual. For optimum perform‐
ance, observe the recommended ambient tem‐
perature ranges, 24.3.
24 Specifications
24.1 STIHL BGA 86
Intended for household use.
–Approved battery types:
–STIHL AP series
–STIHL AR series
–Maximum air velocity: 154 mph (69 m/s)
–Weight without battery: 6.2 lbs. (2.8 kg)
For technical information regarding the STIHL
AP and AR / AR L series batteries, see the prod‐
uct information accompanying your battery.
For technical information regarding the STIHL AL
101, 301, 301-4 and 500 series chargers, see
the product information accompanying your
charger.
Batteries, chargers and other accessories sold
separately. Contact your authorized STIHL serv‐
icing dealer for pricing and availability.
24.2 Ambient Temperature Limits
WARNING
■ Extreme temperatures can damage the battery
and may also cause it to generate heat, rup‐
ture, leak, ignite or explode, resulting in severe
or fatal personal injury or property damage.
Never charge, use or store the battery outside
the ambient temperature limits specified
below.
►Do not charge the battery below - 4 °F (-
20 °C) or above 122 °F (50 °C).
► Do not use the blower or battery below
‑ 4 °F (- 20 °C) or above 122 °F (50 °C).
► Do not store the blower or battery below -
4 °F (- 20 °C) or above 158 °F (70 °C).
24.3 Ambient Temperature Recom‐
mendations
For optimum performance, observe the following
ambient temperature ranges for the blower and
battery:
–Charging: 41 °F to 104 °F (5 °C to 40 °C)
–Use: 14 °F to 104 °F (- 10 °C to 40 °C)
–Storage: - 4 °F to 122 °F (- 20 °C to 50 °C)
Charging, using or storing the battery outside the
recommended ambient temperature ranges may
reduce performance.
If the battery became damp or wet during opera‐
tion, allow it to dry at least 48 hours at tempera‐
tures between 59 °F (15 °C) and 122 °F (50 °C)
and relative humidity below 70 % before charg‐
ing or storing. Higher humidity can extend the
drying time.
24.4 Symbols on the Blower and
Battery
Symbol Explanation
V Volt
Hz Hertz
A Ampere
Ah Ampere hour
W Watt
Wh Watt hour
AC Alternating current
IP20 Ingress protection rating: resistant to
dust or ingress of objects over 12 mm
in size
Push and hold the retaining latch in
this direction to unlock
Direct current
Number of cells and stored energy accord‐
ing to cell manufacturer's specification.
Usable energy will be less.
English 24 Specifications
20 0458-824-8221-B
