STILLE imagiQ2 User manual

Stille imagiQ2
Service and technical manual
Surgical Perfection. For life.

Copyright © 2015 STILLE AB. All rights reserved.
The contents of this manual are the property of STILLE AB. Any reproduction in whole or in part is strictly prohi-
bited. Trade marks: True Free Float™, ISO ROLL™ and imagiQ2™ are trademarks owned by Stille AB.
At the time of printing, this manual correctly described the device and its functions. However, as modifications
may have been carried out since the production of this manual, the system package may contain one or more
amendments to the manual. This manual including any such amendments must be thoroughly read, before using
the device.
The English version of the User Manual and Service Manual is the original instructions. Manuals in other langu-
ages are a translation of the original instructions.
The following imagiQ2™ models are covered by this manual: 530-1700 imagiQ2 EU 230V, 530-1701 imagiQ2
GB 230V, 530-1702 imagiQ2 JP100V, 530-1703 imagiQ2 US 120V.
The imagiQ2 operating table is CE marked in conformity with the essential requirements, according to annex I,
and classified, according to annex IX, as Class I (rule 12) of the Medical Device Directive 93/42/EEC.
We declare the compliance of the medical device concerned with the Swedish Medical Devices Act (1993:584)
and the regulation LVFS 2003:11 of the Medical Products Agency. Hereby, the medical device complies with the
requirements of the Medical Device Directive 93/42/EEC, the amending Directive 2007/47/EC and the appli-
cable harmonized standards as well as the RoHS directive 2011/65/EU and the WEEE directive 2012/19/EU.
The device does also comply with the International standards, IEC 60601-1, IEC/EN 60601-2-46, UL 60601-
1. CAN/CSA C22.2 No 601.1-M90. Any modification to the device, not authorized by us, will invalidate this
declaration.
The original signed CE declaration of conformity is a separate document can be obtained upon request.
Classifications
CE Medicla device classification: Class 1
GMDN code: 36606
FDA Regulation Status: Class 1 Exempt 878.4960 (GDC)
FDA List No.: E130044
Warranty terms for imagiQ2™ vascular imaging table:
To be able to benefit the full warranty terms of the Stille imagiQ2, the installation report that comes enclosed
with the documetation must be filled in at installation and returned to [email protected]
Information regarding Stille Warranty Provisions can be found on Stilles website, http://www.stille.se.
If you do not find the installation report please do contact [e-mail] for a copy.
It is recommended that all repairs and modifications are carry out by authorized personnel.
Manufacturer:
Stille AB
Ekbacken 11
SE-644 30, Torshälla
Sweden

3
Stille imagiQ2™ Service manual Contents 3
n
CONTENTS
SAFETY INFORMATION 4-5
OVERVIEW of imagiQ2™ 6-13
Overview 6-7
Intended use 7
Detailed description 7
1:st time start up procedure 8
Daily control 8
Target group (Service) 9
Scope of the manual 9
Technical knowledge 9
Applied part 9
Technical lifetime 9
Table function priority 10
Periodic maintenance 11
Cleaning of the mattress 11
Removal of table top 12
Installation 13
Site planning 13
Transportation/ storage 13
Tools for service and repair 13
TECHNICAL 14-76
Position for service 14
LoTo 15-21
Replacement of:
Connection board 22
Inclinometer board 23
Main board 24
PSU 25
AC-inlet 26
Wheel cylinder 27
Lateral cylinder 28
Lift cylinder 29
Trend cylinder 30
Hydraulic pump 31
Solenoide valve 32
Brake- clamp valve 33
Bleed brakes- clamps 34
Internal fuses 35
Adjust the Pan handle 36
Lower the wheels 37
Trouble shooting guide 38-47
Drawings and schematics 48-67
Spare part service kit 68
Electrical and EMC 69-71
Service protocol 72-74
ISO/EN 62353 protocol 75
Specifications 76
Electricla standards 76
Notes 77-79

Safety Information
5
4Stille imagiQ2TM service manual Safety Information Stille imagiQ2TM service manual Safety Information
SAFETY INFORMATION
Always follow the manufacturer’s instructions!
Read carefully and always follow the instructions in the users manual before first using the imagiQ2™ operating
table. This manual has been written to ensure that you will handle the table in a safe and correct manner, use this
manual together with the users manual.
n The device is intended to be used by qualified surgical staff.
n Quick Stop/ Main switch: Move the switch downwards for immediate shut-off (see page 12).
n All movements are interrupted when the hand control is switched off (OFF), or when the Quick Shut-off
switch is turned off.
n All table top movements cease immediately if the button in question is released.
n Charge the batteries if the battery indicator is indicating low battery.
n Avoid discharging the batteries completely. Maximum battery life-time is achieved if charged regularly.
n The manual must always be stored within reach of the operating table.
n The main switch must be turned “ON” when charging the table.
n Follow the packaging / unpackaging procedure to avoid personal injuries, equipment damage or property
damage.
n This device, as all medical electric equipment in general, need special precautions regarding EMC and need to
be installed and put into service according to information in the user and service manual.
n During operation make sure to not touch external ports or conenctors and patient at the same time.
n Always use anti-static cushions to ensure that static electricity is discharged to the anti-static floor.
n The table is intended to be used on an anti-static floor.
n Always connect the table’s potential equalization connection point to protective earth.
n Never place surgical cloths/ sheets so that the grounding rails are totally covered. Surgical cloths/ sheets pre-
vent electric discharge to anti-static floors.
n Radio transmitting equipment, cellular phones etc. shall not be used in the close proximity of the imagiQ2™
table since this could influence the performance of the imagiQ2™ table.
n Particular precaution must be considered during use of strong emission sources such as High Frequency
surgical equipment and similar so that e. g. the HF-cables are not routed on or near the imagiQ2™ table. If in
doubt, contact qualified technician or your local representative.
n Do not subject the operating table to electromagnetic fields that exceed the applicable standards for radio
frequency equipment, such as diathermy apparatus, defibrillators and defibrillator monitors.
n The table is only to be used with medical equipment complying with EN 60601-1, EN 60601-1-2.
n The imagiQ2™ table complies with the EMC requirements according to IEC 60601-1-2.
n The device is not intended for use with flammable anaesthetic gases. A possible explosion hazard exists and
personal injury or equipment damage could occur.
n The device shall be cleaned / disinfected according to the user manual.
n Do not immerse the control unit device in water or any other liquid (see the care / maintenance section for
specific details).
n The operating table is disconnected from mains by disconnecting the AC-power cord from the table.
n Unplug the power connector from its power source before moving the table, cleaning or servicing. Failure to
do so could result in equipment damage.
n The table is more stable when parked. Always park the table when it’s not being transported.
n Only use accessories approved by STILLE AB.
n Always check that mounted accessories do not collide with the operating table or surrounding equipment
when movement is activated
n Remove any obstacles before lowering or tilting the operating table. It could tip over.
n The operating table base must always be stable and horizontally level.
n Centre the table top longitudinally over the column as far as possible before lowering the free end of the table
top.
n When adjusting or when panning the operating table, never put your fingers under the table top or cover. Risk
of injury.
n Secure the patient before changing the position of the operating table.
n The patient must not lie on conductive mattresses or on damp bedding when defibrillators, defibrillator moni-
toring screens or high frequency apparatus are being used. Nor should the patient come into contact with
metal parts or their accessories on the operating table. This could result in burns.
n Keep the patient under constant observation.
n Use only STILLE spare parts.

Safety Information
5
4Stille imagiQ2TM service manual Safety Information Stille imagiQ2TM service manual Safety Information
n Ensure that hands, feet and equipment are clear of the frame assemblies when changing positions of the table.
n Use precaution as the imagiQ2™ table can be activated by another operator.
n Particular precaution must be taken during use of the foot control to avoid unwanted movements.
n Not intended to be used in an oxygen rich environment.
n Do not subject the operating table to electromagnetic fields that exceed the applicable standards for radio
frequency equipment, such as diathermy apparatus, defibrillators and defibrillator monitors.
n All service shall be performed without any patient placed on the table. In case of emergency service and repair
shall be performed without any connections between the technician and the patient or the operator.
n For moving safely over a threshold 15 mm or higher, it´s required to be two persons.
n Before moving over a threshold always makes sure that the table top is centre.
n The battery shall only be changed by service personnel.
n Replenishment of oil into the hydraulic system shall only be done by service personnel.
n Addition to the Service Manual: Never overfill the hydraulic system when refilling oil.
n Do not place or position imagiQ2 so that it is difficult to disconnect the table from the supply mains socket.
n Do not touch the patient and accessible contacts of connectors simultaneously.
n The table shall be centered and turned OFF on the hand control before and during transport.
n Extra precaution must be taken during service when a guard is open and someone is activating a movement.
Risk of injury.
n A clicking sound shall be heard when attaching the head rest to be sure that its attached safely.
n Preventive maintenance of the table shall always be performed according to the Service Manual.
n Always check that the accessories are securely attached to the table before use.
n Always check accessories before use. Damaged or worn accessories shall never be used as they can cause
injury.
n Do not operate the device if the protective covers are removed, risk for personal injury.
n Skin contact with hydraulic fluid may cause skin irritation, clean and wash with soap and water.
n If another mattress is used than the original mattress, a grounding connection must be established.
n When the AC cable is connected to the device, the batteries are charging if the main switch is ON, if the bat-
teries are completely discharged it may take some time before the device can be restarted.
n Isolation from the supply mains is made by disconnecting the AC power cable from the equipment.
n Enclosure protection of the foot control is IP68.
No specific warnings specified in the service manual according to use of other accessories, transducers and
cable other than those specified by Stille.
n Precautions has to be taken to equipment and surrounding equipment in relation to specific EMC requirements
see tables for EMC specifications.
n Testing against IEC/EN 62353 shall be performed by Qualified personnel according to the requirements in the
standard.
n Use of accessories, cables and spare parts other than those sold by Stille as replacement for internal compo-
nents, may result in increased emissions or decreased immunity of the operating table imagiQ2.
n Warning: imagiQ2™ should not be used adjacent to or stacked with other equipment. If adjacent or stacked use
is necessary, imagiQ2™ should be observed to verify normal operation in the configuration in which it will be
used.
n WARNING: if the table is beeping continously every 30 second, table is in failstate, all safetyfunctions are
turned OFF, do not transport patients on the table park the table during procedures.
n WARNING: Risk for pinch/squees damage when installing/ removing the detachable table top.
n WARNING: To avoid the risk of electric shock, this equipment must only be connected to a supply main with
protective earth.
n WARNING: Using other cables and accessories than the specified, can possibly increase the emission and
decrease the immunity in regards of EMC requirement.
n WARNING: To avoid risk of electric shock, this equipment must only be connected to a supply mains
with protective earth.
n WARNING: No modification of this equipment is allowed.
n Do not position the imagiQ2™ operation table so that it is difficult to operate the disconnection device.
n Means for isolating imagiQ2™ operation table from mains supply, trough disconnecting the power cord from
the ME equipment.
n It is recommended that at least 2 persons are transporting the imagiQ2™ operation table.
n If in doubt, consult the supplier or person responsible for operating room equipment.

6Stille imagiQ2TM service manual Overview
Overview
OVERVIEW of the imagiQ2™ TABLE
2
3
5
4
7
6
8
9
10
7.4 7.57.37.27.1
1
7.6

7
Stille imagiQ2TM service manual Overview
Overview
Intended use
imagiQ2TM is intended to be used by trained medi-
cal personnel’s for positioning and supporting of
patients before, during and after human surgery in
operating rooms. It can be used for general open
surgery but is suitable for minimally invasive vascular
surgery e.g. endovascular and cardiovascular sur-
gery.
Because the table top is made of translucent car-
bon-fiber it has a high degree of transparency of
X-rays. The table is designed to fit well together
with a C-arm for fluoroscopic procedures.
The table is not suitable for infants.
Intended medical indication:
Minimal invasive surgery
Intended patient population:
Max. 225 / 300 kg - 496 / 661 Lbs patient
weight (depending on model)
Intended part of the body interacted with the
device:
Skin tissue
Not intended for use during brain surgery
Intended user profile:
Trained medical personnel’s
Intended conditions of use
To be used in operating theatres/rooms
Temperature +10°C to +40°C (50°F to 104°F)
Humidity 30% - 75%.
Atmospheric pressure 700hPa - 1060hPa
Cleaned and disinfected before use
Operating principle
A battery operated mobile surgical operating
table intended to support and positioning
patients during surgical and examination proce
dures.
Least favorable working condition
The table is used during max. operation conditions,
off center and unparked with max. safe work load
placed on the table and the column all the way up.
Essential performance
Essential performance according to EN 60 601-
2-46: Essential performance of the imagiQ2 table
is the Trendelenburg function. The function can be
activated by the use of the hand control and can
manually be achieved as an emergency function in
cases of power failure.
Detailed description
1. The table top is made of translucent carbon fibre
composite. Accessory rails run along 2/3 of the
table top. Static electricity is discharged from
the bottom of the mattress via the grounding
rails on the upper surface of the table top.
2. The mattress is made of what is known as ”Slow
Recovery” material, to minimise pressure sores
on patients during long operations.
3. The pan handle is a manoeuvring function allow-
ing panning of the table top. The handle normally
remains in a locked position on the accessory rail
Two pan handles can be used simultaneously
to maneuver the True Free Float™.
4. Connections. The column contains connections
for the pan handle and hand controls and a RED
connector for special imagiQ2 accessories.
5. Hand control manages the hydraulic movements
of the table. Normally, the hand control is sus
pended on the table top accessory rail.
6. Safety control cover holds the emergency
operation control and safety hand control.
7. Connection panel located on the back of the
base, which is the main interface for connectors
for mains supply, main fuse and connector for
foot control (optional).
7. 1 LAN
7.2 Foot control
7.3 USB port
7.4 Quick-Stop / Main switch: automatic fuse,
which also serves as an quick shut-off device.
7.5 Potential equalization connector (on back
side of the base).
7.6 Applians inlet, NOTE The main switch
must be turned “ON” when charging the table.
8. Retractable wheels, park the operating table.
9. Side protective covers, protect the inside of the
table.
10. Connector, hand control. Extension cable for
connecting hand control at opposite end of
table.

8Stille imagiQ2TM service manual Overview
Overview
Start-Up procedure
Follow the procedure described below before the
Stille imagiQ2TM operation table is used for the first
time:
n Before the table is used for the first time:
- charge the batteries until they are fully charged,
(the main switch must be “ON” when charging
the table.)
- Fill out the installation report.
- Fill out the testprotocol ISO -EN 62353
1) Read the User Manual
2) Test run all functions on the hand control as
described:
3) Column, Run column from lowest position to
highest position and up again.
4) ISO ROLL™/Lateral tilt right, Run tabletop from
zero position to maximum right inclination, and
then zero the table.
5) ISO ROLL™/Lateral tilt left, Run tabletop from
zero position to maximum left inclination, and
then zero the table.
6) Longitudinal tilt (Trendelenburg), Run tabletop
from zero position to maximum head down, and
then zero the table.
7) Reversed longitudinal tilt (anti-Trendelenburg),
Run tabletop from zero position to maximum
head up and then zero the table.
8) Quick-trend (Trendelenburg), Run tabletop
from zero position to maximum head down and
then zero the table.
9) Zero position. Lateral tilt, Run tabletop from
maximum left inclination to maximum right
inclination and back. Make sure that the table
stops both times it passes zero position.
10) Longitudinal tilt (Trendelenburg) Run tabletop
from maximum head down to maximum head
up and back. Make sure that the table stops
both times it passes zero position.
11) True Free Float™ / Panning. Pan functions,
place table in 0-position and test run both
axis. Check that motion works effortlessly and
smooth (manoeuvre with one hand only).
12) All above mentioned steps shall be controlled
on the Safety Hand Control as well.
Daily control before procedures
n The operator should have knowledge how to
operate the device, be aware of warnings and
signals described in the user manual and the
user manual should always be available.
n The operator should perform a function Check
accordingt to 2-11.
n Test the device for proper function and inspect
cables for cuts and other damage. If in doubt,
replace the relevant parts.

9
Stille imagiQ2TM service manual Overview
Overview
Target group
This service manual is intended for use by medical technicians with a general knowledge of
operating tables. It is not intended for use by clinical personnel.
Scope of the manual
The manual describes all checkpoints for maintenance of the table as well as other instructions
for servicing the imagiQ2 . information is provided in the form of block-, hydraulic-, electro-
nics diagrams and exploded views with associated lists of spare parts. Fault tracing is descri-
bed in a separate chapter.
Technical knowledge required of maintenance personnel
imagiQ2 is designed to give problem-free service for many years, provided that preventive
maintenance is performed at the specified intervals and in accordance with the instructions
given in this manual. To be able to perform installation and repair and maintenance correctly,
the personnel are required to have general technical training for work with medical devices, it
is beneficial to have knowledge of hydraulic systems (particularly attention to preventing the
entry of dirt or particles into the hydraulic system) and suitable knowledge of medical devices
with respect to operating tables. Knowledge of the operation of the table is also required and
can be gained by reading the user manual. Effective maintenance ensures functional reliability
and extends the service life of the table. Contact Stille AB in the event of any uncertainty or if
relevant training is required.
Technical Lifetime
This product has a technical lifetime, which by Stille AB is considered to be 10 years. At the
time of delivery the product fulfils the existing regulations and standards but as all other
electro-mechanical products, the Stille imagiQ2 table is subjected to age and wear, and even
though the product undergoes regular and prescribed service, Stille AB can not guarantee the
product’s safety after the expiry of the technical lifetime. Stille AB recommends that the pro-
duct is taken out of service after latest 10 years. By Stille AB provided spare parts and service
after the expiry of the specified technical lifetime does not mean an extension of Stille AB’s
liabilities. Note: Maximum life time for the batteries (if well maintained and charged regularly)
is 3 years. The technical lifetime for the mattress is 3 years.

10
Stille imagiQ2TM service manual Overview
Overview
Table function priority
All movements of the table-top cease immediately if the operating button or pedal has been
released. All operations including those of the floor lock cylinders can be interrupted by either
pressing the main ”OFF” button or by disconnecting the voltage with the emergency power
switch.
If several commands are given simultaneously from the same control unit, all movements
cease. (With the exception of fast lowering of the head end (“Quick-Trend”) in combination
with head end down). It is only possible to connect one hand control to the table. Pressing the
”OFF” button however, always takes precedence over all other commands. All hydraulically
assisted movements can be activated by the hand control but only one hydraulically assisted
movement can be activated at one time. Certain table-top movements can be activated by
foot control. Column end up/down and fast lowering of the head end is executed indepen-
dently of if the table is parked or not, and have priority over parking/unparking commands.
Should a parking/ unparking sequence be in progress when one of these controls is activated,
the parking/ unparking sequence is temporarily interrupted. Column up/down movements are
executed independently of the parking status but a parking/ unparking sequence in progress
takes precedence. The lateral tilt command or a return to zero position command is only pos-
sible when the table is parked and an acknowledgement has been received from the position
switches for the parking circuit. An attempt to activate these movements when the table is
unparked will result in an automatic parking of the table. The table can only be unparked when
the table is in safe position, or if the weight of the load on the table is less than the unregula-
ted transport weight (100kg). If the table is loaded with a higher weight load than allowed a
fixed sound signal gives indication that the table is overloaded, the sound signal can be reset
by lowering the weight load.
Safe position
The table is in safe position when parked. for safe position when unparked with load the table
needs to be adjusted, the safe position is, table top centered side to side and centered bet-
ween the blue arrows on the side, it might be needed to lower the column to achieve safe
position.
WARNING: Do not activate lateral tilting or return to zero position during transport of the
table. Make a habit of switching off the table before any transport is begun.
The return to zero sequence is activated by pressing the zero button and holding it depres-
sed until any lateral or longitudinal tilting movement has ceased. If the zero button is released,
all movements cease immediately. The return to zero sequence restarts from the beginning
when the button is pressed again. Lateral and longitudinal tilt movements are provided with
automatic stop functions at the zero position. Movement ceases when the table has reached
these positions. The movement is reactivated by releasing and depressing the button/pedal.
This simplifies individual resetting of lateral and longitudinal tilting. There is no automatic
stop at zero position function with fast lowering of the head end. The optional guide wheel is
activated simultaneously when the table is unparked. The guide wheel is retracted hydraulically
and is lowered by a return spring. When parking, the guide wheel is retracted automatically to
avoid obstructing other equipment.

11
Stille imagiQ2TM service manual Overview
Overview
Periodical preventive maintenance (PM)
The imagiQ2 requires a maintenance period of 1time every year or 2000 hours of service
whichever comes first according to the service schedule in this manual.
(2000 hours equals to 8 hours of service 5 days / week for 1 year)
If the service is not correctly documented the warranty is void.
Stille AB can not guarantee the product’s safety if Periodical preventive maintenance (PM) has
been neglected.
Cleaning and care of the polyurethane coated mattress
General Guidance
Attention must be paid to the properties of any other materials, (eg washing agents and
washing instructions).
Some surface wrinkling may result from cleaning procedures. This has no adverse effect on
the fabric’s properties.
Do not use washing machines
Abrasive cleaning agents should not be used.
Washing and Disinfection
Superficial dirt on the coating may be removed by wiping with a soft cloth moistened with
water containing a neutral detergent. More persistent contamination may be treated by wiping
with alcohols or turpentine substitute, followed by hot water and detergent.
Routine cleaning and disinfection may be carried out on the coating with hand hot water
and a neutral detergent or with a sodium hypochlorite solution (0.1% or 1000 parts per mil-
lion available chlorine).
The material is compatible with the 10,000ppm available chlorine in solution required for
the decontamination of blood spills. After the 2 minute required dwell, excess solution must be
removed and the surface thoroughly rinsed and dried prior to reuse or storage.
Proprietary disinfectants may be used provided manufacturer’s instructions are followed.
All cleaning agents, and disinfectants, must be thoroughly rinsed off and the item dried
before storage. Failure to do this may result in the accumulation of reagent that could damage
the polyurethane coating, react with the bed frame, or negate the biocompatibility results of
the fabric.
Drying
It is essential that articles be thoroughly dried after all cleaning procedures and before
storage.
Drying may be effected at temperatures up to 130 °C (266°F).
Storage
Store in a cool, dry area. Avoid excessive pressure and contact with non-colourfast materi-
als

12
Stille imagiQ2TM service manual Technical
Technical
Removint the table top
It is recommended to be 2 persons, remove any accessoreis on the table top.
- Remove the lock pins.
- While one person holds the table top in the back handles the other person lifts the table top
in the front, it may be needed to apply some force.
- When the front is lifted, slide the table top backward until the back is released.

13
Stille imagiQ2TM service manual Overview
Overview
Installation of the imagiQ2
Complete the installation report imagiQ2
Document number 0260-6PF002 and submitt
to Q[email protected]
Planning reference data
Transport data:
Length =2400 mm / 7,8 ft
Width= 875 mm / 2,9 ft
Height = 1168 mm / 3,8 ft
Gross weight 450 kg / 992 Lbs
Net weight 265 kg / 584 Lbs
Transport of Dangerous Goods by Air – Limi-
ted to class/UN 3164 –ADR, 1.3/IMDG 1.3/
IATA-DGR 1.5
Electrical data:
Mains voltage 100 - 230 V AC,
50 / 60 Hz
Rated power Max 504 VA
Fuse rating
T6,3 H, 250V SB
Output power 400W
Environmental data:
Operating conditions
Temperature: +10°C to +40°C (50°F
to104°F)
Humidity: 30% - 75%.
Atmospheric pressure 700hPa - 1060hPa
Storage conditions /Transportation
requirements
Temperature -40°C to +70°C (-40°F
to158°F)
Humidity 10% - 80%rh. incl. condensation.
Atmospheric pressure 700hPa - 1060hPa.
Tools for installation, service and repairs
Knife or scissor
Screw drivers
Small = 2 mm blade width
Medium = 5 mm blade width
Large = 10 mm blade width
Screwdriver for cross head screws
Small = PH 0
Medium = PH 2
To r x
TX 10
Allen keys
1,5 mm 5 mm
2 mm 6 mm
2,5 mm 8 mm
3 mm 10 mm
4 mm
Combination wrenches
6 mm 13 mm
7 mm 14 mm
8 mm 15mm
10 mm 17 mm
11 mm 19 mm
12 mm
Other tools
Multimeter
Torque wrenche
A digital angle-measuring level (recommen-
ded least resolution = 0,1°) analog can also
be used
Hammer
Locking ring pliers (opening)
Other working materials:
Cable straps, 3 mm and 5 mm width.
Thread-locking fluid (Loctite 242 or equal)
Thread-seale (Scantech flange and thread
seale, 4000T, or Loctite Thread Sealant
542 Fine Threads)
AFA grease, Part number 507-K9038
Hydraulic Oil, part number 507-K90385

14
Stille imagiQ2TM service manual Technical
Technical
Position the table for service and repair.
To position the table for service (and preventive maintenance) time ~20 minutes.
1) Make sure the table is fully charged(reccomendation)
2) Move the table column to the highest position
3) Park the table
4) Remove the emgergency cover
5) Remove the lower coumn cover
6) Remove the front cover( be careful with the cables when the column covers is slid out
7) remove the front plate connection plate
8) Remove the lateral side plates
9) Remove the table top
10) remove the top cover
11) Depending on the service or repair additional dismantling can be necessary, see separate
instruction.

15
Stille imagiQ2TM service manual Technical
Technical
LoTo procedure Stille imagiQ2
LoTo = ”Lock out Tag out, the procedure to make the device safe
by removing stored energy.
Important information
is instruction is intended to be a support instruction to meet the requirements from OSHA 29
CFR 1910.147(c)(4) Energy Control Procedure. For the safe operation of this product, the users
and service manual must be followed. If the users manual is unavailable contact your service
organization, distributor or Stille AB directly on www.stille.se.
Take care for personal protections, reccomendation to wear protective eyeweare, and golves
when working with hydraulic system.
LOTO procedure Stille imagiQ2
(OSHA 29 CFR 1910.147(c)(4) Energy Control Procedure)
is procedure meets the basic LOTO requirements established by OSHA. It is designed to
insure that each employee involved in servicing this equipment has exclusive control over the
equipment. It is the obligation of each employee to follow this procedure and understand that
failing to do so can cause serious injury or death.
Field Service Engineers are recommended to have complete a LOTO Authorized and initial
LOTO Verication training to execute Lockout/Tagout on this system.
All non-authorized (non- service engineers) individuals are considered “aected” individuals.
e requires LOTO is described in respective repair instruction, if there are no specic repair
instruction perform both hydraulic and electric LOTO
Each individual LOTO can be performed separately or together with the others if needed, depen-
ding on the required operation.
If hydraulic LOTO is going to be performed, always start with the hydraulic LOTO then perform
the electric LOTO.

16
Stille imagiQ2TM service manual Technical
Technical
HYDRAULIC ENERGY CONTROL PROCEDURES
NOTE! if hydraulic LOTO shall be performed always start with the hydraulic LOTO.
NOTE! this chapter handles the hydraulic energy source, for electrical energy see chapter 1.
(OSHA 29 CFR 1910.147(d) Application of Control)
HYDRAULIC ENERGY:
Manual clamp
lock circuit release
Manual trend valve
Placed under the
back cover
Hydraulic pump unit 24VDC motor cable

17
Stille imagiQ2TM service manual Technical
Technical
1. Notify all aected individuals of a shutdown.*
2. Position Table for service, elevate the li column all the way to the top
3. Connect 1779-2AD001-01 Column support bracket LoTo to the side plate, make sure the
nut is securely tigthened, Do note that the tool 1779-2AD001-01 Column support bracket LoTo
is delivered together with the table as a standard part.
4. Lower the li column carefully until it is about 0 - 2 mm above the column.
5. Open the manual clamp lock and trend circuit release valve, open 0,5-1 turn.
6. Disconnect the 24V DC motor cable, orange / black - yellow/ blue.
7. Open the manual trend valve and press down the table top
8. Press and hold each of the keys related to the function that is aected, toggle between le
and right key, this is to release any built in pressure in the system.
Note it is important that you have supported the aected function before you press the key.
Other wice the function might sink by its own weight, all the way until it reaches the end posi-
tion.
9. Hydraulic power is now locked out.
10. It might be necessary to do an Electrical power LOTO according to the procedure for
“electrical energy” .
*In the event service will continue into another day, and/or the machine will cause a hazard if
reenergized aer the authorized employee leaves the location, leave the A/C cord cover installed
with a “transition” lock and yellow tag attached. (OSHA 29 CFR 1910.147(f)(4) Shi/Personnel
Changes)
*If more than one authorized employee is going to conduct service on the same system, at the
same time, multiple locking devices must be employed an each authorized employee must adhere
the entire LOTO procedure. (OSHA 29 CFR 1910.147(f)(3) Group Lockout/Tagout)
3

18
Stille imagiQ2TM service manual Technical
Technical
TESTING AND POSITIONING DURING SERVICE
(OSHA 29 CFR 1910.147(f)(1) Testing/Positioning)
HYDRAULIC ENERGY:
In the event that lockout/tagout devices must be temporarily removed from the energy isolating
devices, for testing or positioning purposes, the following sequence shall be followed:
1. Clear the table of tools and materials excluding the 1779-2AD001-01 Column support
bracket LoTo.
2. Ensure that all employees/individuals in area are safely positioned or removed.
3. Close all of the valves.
4. Activate the system by reconnecting the 24VDC and turn on the main switch and the
table pressing On on the hand control, remove 1779-2AD001-01 Column support bracket LoTo
and proceed with testing or positioning.
5. De-energize table again aer testing or positioning.
RESTORE POWER AFTER SERVICE:
(OSHA 29 CFR 1910.147(e) Release of Lockout/Tagout)
1. Re-inspect work area for hazards.
2. Close all the valve.
3. Activate the system by reconnecting the 24VDC and turn on the main switch and the
table pressing On on the hand control, remove 1779-2AD001-01 Column support bracket LoTo
and proceed with testing or positioning.
4. Reinstall table covers.
5. Turn on main switch.
6. Notify all aected personnel that power being restored.
7. Energize the table.
8. Verify proper system operation.
9. Inform customer that system is ready to be returned to service.

19
Stille imagiQ2TM service manual Technical
Technical
ELECTICAL ENERGY CONTROL PROCEDURES
NOTE! if hydraulic LOTO shall be performed always start with the hydraulic LOTO.
NOTE! this chapter handles the electrical energy source, for hydraulic energy see chapter 2.
(OSHA 29 CFR 1910.147(d) Application of Control)
ELECTRICAL ENERGY:
Battery connector
Covers and
protective plates
Battery pack
Foot control
USB AC-power inlet
LAN
Battery power
24VDC Motor cable
Main switch

20
Stille imagiQ2TM service manual Technical
Technical
ENERGY CONTROL PROCEDURES
(OSHA 29 CFR 1910.147(d) Application of Control)
ELECTRICAL ENERGY:
1. Notify all aected individuals of a shutdown.*
2. Position Table for service
3. Turn OFF main switch
4. Remove A/C plug from wall power and from table.
5. Apply the red lock and tag to the AC plug.
6. Turn ON Main switch to verify primary power isolation.
7. Remove covers and protective plates
8. In the Table base verify zero volts A/C at AC-connector
9. Disconnect the red/black battery connector
10. Verify isolation by pressing ON on the hand control, nothing shall happend.
11. Turn OFF main switch
11. Electrical power is now locked out.
12. It might be necessary to do an hydraulic power LOTO according to the procedure for
”hydraulic energy”.
*In the event service will continue into another day, and/or the machine will cause a hazard if
reenergized aer the authorized employee leaves the location, leave the A/C cord cover installed
with a “transition” lock and yellow tag attached. (OSHA 29 CFR 1910.147(f)(4) Shi/Personnel
Changes)
*If more than one employee is going to conduct service on the same system, at the same time,
multiple locking devices must be employed an each authorized employee must adhere the entire
LOTO procedure. (OSHA 29 CFR 1910.147(f)(3) Group Lockout/Tagout)
TESTING AND POSITIONING DURING SERVICE
(OSHA 29 CFR 1910.147(f)(1) Testing/Positioning)
In the event that lockout/tagout devices must be temporarily removed from the energy isolating
devices, for testing or positioning purposes, the following sequence shall be followed:
1. Clear the table of tools and materials.
2. Ensure that all employees/individuals in area are safely positioned or removed.
3. Remove energy control measures.
4. Energize system and proceed with testing or positioning.
5. De-energize table again aer testing or positioning.
RESTORE POWER AFTER SERVICE:
(OSHA 29 CFR 1910.147(e) Release of Lockout/Tagout)
1. Re-inspect work area for hazards.
2. Reconnect the red/black battery connector
3. Reinstall table covers.
4. Turn on main switch.
5. Notify all aected personnel that power being restored.
6. Remove red lock and tag
7. Energize the table.
8. Verify proper system operation.
9. Inform customer that system is ready to be returned to service.
