Stirling STR-AEO65L User manual

N13275
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Model Number STR-AEO65L
Electric Oven
INSTRUCTION MANUAL

2AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Welcome
Congratulations on choosing to buy a STIRLING®product.
All products brought to you by STIRLING®are manufactured to the highest
standards of performance and safety and, as part of our philosophy of
customer service and satisfaction, are backed by our comprehensive 3 Year
in Home Warranty. We hope you will enjoy using your purchase for many years
to come.

3
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Contents
02 Welcome
04 Warranty Details
05 General Safety Instructions
08 Product Overview
10 Installation
16 Getting Started
17 Instructions
25 Cooking Guidelines
27 FAQs
29 Other Useful Information
35 Repair and Refurbished Goods or Parts Notice

4AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Electric Oven
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 36 months from the date of purchase. Defects that occur
within this warranty period, under normal use and care, will be repaired,
replaced or refunded at our discretion, solely at our option with no charge for
parts and labour. The benefits conferred by this warranty are in addition
to all rights and remedies in respect of the product that the consumer
has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
YEAR IN HOME
WARRANTY
3
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION

5
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
General Safety Instructions
Important installation advice
• This oven must be installed by a licensed electrician.
• Adjacent furniture: When having the oven installed, make sure that
the adjacent benchtop surfaces, laminates and adhesives are able
to withstand a minimum temperature of 100°C, and the front parts of
neighbouring units up to 70°C.
Certain types of vinyl or laminate kitchen furniture are particularly prone
to heat damage or discolouration at temperatures below the guidelines
given above. We assume no liability for any damage caused by the
appliances being installed in contravention of this temperature limit, or by
placing adjacent cabinet materials closer than 4mm near the appliance.
• Ventilation: Heat, steam and moisture will be created during use of the
oven. Take care to avoid injury and ensure that the room is adequately
ventilated. If the appliance is going to be used for prolonged periods
of time, additional ventilation may be required. If in doubt about your
ventilation requirements, consult your qualied installer.
• Cables: Do not allow electrical ttings or cables to come into contact
with areas on the oven that get hot.
• Curtains: Do not install the oven next to curtains or soft furnishings.
• Damaged cord: If the power cord is damaged, it must be replaced by the
manufacturer or a qualied service engineer in order to avoid a hazard.
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with
this type of product. The safety precautions enclosed herein reduce the risk
of fire, electric shock and injury when correctly adhered to. Keep the manual
in a safe place for future reference, along with the completed warranty card
and purchase receipt. If applicable, pass these instructions on to the next
owner of the appliance.
Always follow basic safety precautions and accident prevention
measures when using an electrical appliance, including the following:

6AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
General Safety Instructions (Cont.)
General usage conditions and restrictions
• Domestic use only: This oven is designed for indoor domestic use only. It
can be built into a standard kitchen cabinet or housing unit.
• Intended purpose: Only use this oven for its intended purpose, in its intended
environment and as described in this manual. Any other use may cause re,
electric shock or injury. This oven is not intended for commercial, industrial
or trade use.
• Follow instructions: Make sure to observe all rules and provisions in this
instruction manual. Do not allow anybody who is not familiar with the contents
of this manual to operate the oven.
• Use common sense: These instructions are not intended to cover every
possible condition and situation. As with any electrical household appliance,
common sense and caution are therefore always recommended when
installing, operating and maintaining the oven.
• Usage restriction: This oven is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of ex-
perience and knowledge, unless they have been given supervision or instruc-
tion concerning use of the appliance by a person responsible for their safety.
• Supervise children: Young children do not recognise the risks involved
when using electrical appliances. Make sure children younger than 8 years
of age are kept away from the oven during use. If it is necessary for younger
family members to be in the kitchen, ensure that they are kept under close
supervision at all times.
• Unattended: Never leave the oven unattended during use, as this is a re risk.
Oils and fats in roasting dishes may catch re due to overheating.
• No heater: Do not use the oven for heating a room or drying clothes.
• No timer: The appliance is not intended to be operated by means of an
external timer or separate remote control system.
• After use: Make sure to switch off the oven after use and before cleaning.
• Damage: Do not use the oven if any part has been damaged or does not
work properly. Only have it repaired by an authorised service centre.
Incorrect repair could expose you to the risk of electric shock, re or
injury. Prolonged use of the unit in such conditions could cause re or
electrocution. In case of damage, contact our after sales support centre
using the details at the bottom of this page.
• Liability: We assume no liability for any eventual damages caused by
misuse of the product or noncompliance with these instructions.

7
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
General Safety Instructions (Cont.)
• Do not use when faulty: Do not use the oven in the event of a technical fault.
Any faults must be xed by an appropriately qualied and authorised person.
Contact our after sales support line for advice.
Oven-specific safety advice
• Oven door: Do not place heavy objects on the oven door. Do not lean on
the oven door when it is open, as this can damage the door hinges.
• Grill: Keep the oven door closed when using the grill function.
• Oven cavity: During cooking, never place pans or cookware directly onto
the bottom of your oven. Always place them on the shelves provided.
• Oven accessories: When removing the baking/drip tray or oven rack from
the hot oven, always use an oven mitt. If a temperature probe is included in
the scope of delivery, only use the supplied probe.
• Aluminium foil: Do not use aluminium foil to cover the grill pan or heat
items wrapped in aluminium foil under the grill. The high reectivity of the
foil could potentially damage the grill element. You should also never line the
base of your oven with aluminium foil.
• Lifting/moving: Do not attempt to lift or move the oven by using the oven
door or handle, as this may cause damage to the appliance or result in injury
to the person lifting the appliance.
• Cleaning: Clean the oven on a regular basis so oils and fats do not
accumulate and cause a re risk. Make sure the oven is switched off before
cleaning. Do not use harsh abrasive cleaners or metal scrapers to clean
the oven door glass as this can scratch the surface, which may result in the
oven glass shattering. Do not use steam cleaning equipment for cleaning any
part of the oven. When cleaning the oven, ensure that no part is immersed in
water or other liquid.
CAUTION: HOT SURFACE!
This symbol indicates that the heating elements and other acces-
sible parts inside the oven cavity become extremely hot during use
and can cause burns on contact. Do not touch hot surfaces! Take
care when handling the food you are cooking to avoid touching
hot parts inadvertently. Keep young children well away during use.
• Opening the door: Be careful when opening the oven door to avoid contact
with hot parts of the oven and steam.
• Danger of fire! Never leave items inside the oven cavity as this can be a re
hazard when the oven is switched on.

8AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Product Overview
Oven cavity
A 1x Oven rack
B 1x Baking/drip tray
C 1x Oven light
D 2x Side rack supports for ve shelf positions:
1 (lowest)
2 (medium low)
3 (middle)
4 (medium high)
5 (highest)
E Fan cover
Also included, but not pictured:
2x Screws and washers for installation
BA
DD
5
1
4
4
3
2
1
2
C
E
3
5

9
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Product Overview (Cont.)
Control panel
LED display
1
4 6
2 3
1 Function selector knob
2 LED display
3 Thermostat control knob
4 Power indicator light (will be on when a function is selected)
5 Oven operating light (will be on when the oven is heating)
6 Timer buttons (see page 17 for details)
A Time display (hr:min)
B Heating symbol
C Automatic mode symbol
D Minute minder symbol
C
B
5
D
NOTE: Due to continued product improvement, images and illustrations in this manual
may vary slightly from the product purchased. All images in this manual are for
reference purposes only. Parts are not necessarily pictured to scale.
A

10 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Installation
Unpacking the appliance
• This product has been packaged to protect it against transportation
damage. Unpack the appliance and remove all packaging materials from
around the oven and from inside the oven cavity.
• Keep all packaging materials until you have made sure your new oven is
undamaged and in good working order. The carton is recyclable. Whenever
possible, reuse the carton and recycle it when disposing of the packaging
materials.
• Plastic wrapping can be a suffocation hazard for babies and young
children, so ensure all packaging materials are out of their reach, and
dispose of them safely.
This oven must be correctly installed by an appropriately qualified
electrician in accordance with all applicable rules and regulations and
following the instructions in this manual.
Do not try to install the oven yourself; doing so will expose you to danger and
void the warranty. Improper installation, adjustment, alteration or service can
cause injury or damage. We decline any responsibility for injury or damage,
to persons or property, as a result of improper use or installation.
Important advice for the installer
• Before connecting the appliance, make sure that the supply voltage
marked on the Rating Plate corresponds with your mains supply voltage.
• WARNING: This appliance must be earthed.
• Means for disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules.
• The appliance should be connected to a circuit which incorporates an
isolating switch providing full disconnection from the power supply.

11
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Installation (Cont.)
Specifications
Oven chamber capacity 65L
Dimensions See Fig. 1, above
Weight 31kg
Shelf positions 5
Oven door Triple glazed, removable
Oven light bulb 25W, 300°C, screw type pigmy
Accessories 1 x Baking/drip tray, 1 x Oven rack
Set of side racks (already assembled)
Oven functions 5
Oven temperature range 50 – 250°C
Timer 24 hour, digital
Rated voltage / frequency 220-240V AC / 50Hz
Total rated mains power 2300W
Dimensions
Height 595mm
Width of Face 595mm
Width of Back 540mm
Depth of Face 20mm
Depth of Back 555mm
Fig. 1
540mm
555mm 20mm
595mm
595mm

12 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Space requirements
Installation (Cont.)
Installing the oven into the kitchen cabinet
Fig. 2

13
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Installation (Cont.)
Fig. 3: Minimum ventilation and cut-out requirements for the installation of the
appliance into a tall housing unit
Fig. 3
Storage
Remove rear
panel from
this section
Storage

14 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Installation (Cont.)
Positioning the appliance
• Ensure that the aperture that you will be fitting the oven into is of the size
given in Fig. 2 and Fig. 3 on the previous pages.
• The oven must be fitted into an oven housing with the ventilation cut-outs
shown in Fig. 4 below.
• Ensure that the rear panel of the furniture housing unit has been removed.
• Kitchen cabinets must be set level and fixed. A gap of 5mm is required
between the appliance and the front panels of surrounding cabinets.
• If there is a drawer underneath the oven, a shelf must be installed between
the oven and drawer.
Fig. 4: Ventilation and cut-out requirements for the installation of the
appliance into a standard kitchen unit
Fig. 4
35mm spacing
between wall and rear
of support shelf and
of cabinet base

15
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Installation (Cont.)
• Insert the two screws and washers (supplied) through the slots at the sides
of the unit (Fig. 5) to affix the oven cabinet into the housing unit. Ensure
that the oven has been securely fixed into the housing unit.
IMPORTANT!
• Do not use the oven door or handle to lift or move the oven.
• Carry the appliance with at least one two persons.
• Use the slots or wire handles located at both sides to move the
appliance.
Fig. 5

16 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Before first use
• Read: The best way to familiarise yourself with all the parts and operating
principles of your new electric oven is to read this manual. Pay particular
attention to the safety instructions on pages 5–7. Refer to pages 8–9 for a
picture and list of all parts and buttons.
• Initial use: After the appliance has been properly installed, and before rst
use, you should burn off any dust, oil or other remnants that may have
been left from the manufacturing process or transport.
First, set the oven to manual operation mode (see opposite for
instructions). Then set the oven function to the “Intensive Bake” setting
(see page 21) and the thermostat to a 250°C.
Leave the oven on for 30–40 minutes. We recommend you leave the
room during this burning off process. However, any smoke and odour
development during this initial use is normal and completely harmless;
ensure good ventilation.
• Clean: After the oven cavity has cooled, wipe the interior oven surfaces
with a soft cloth dampened with warm water and a little mild detergent. Do
not use abrasive cleaners.
• Wash: Remove and wash the oven rack and baking/drip tray with warm
water and a little washing-up liquid. Dry and return to the oven. Leave the
oven door open until it is completely dry.
CAUTION!
Take care to avoid burns, the oven becomes very hot during use.
Getting Started

17
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Using the oven programmer/timer
Manual operation mode
Your new electric oven has a digital timer with an easy to read LED display
and six control buttons for easy operation (Fig. 6).
When your appliance is connected to the mains supply for the rst time,
the numbers on the LED display will ash. Before you can select a cooking
function or temperature, you must set the oven into manual operation mode.
• Press the MANUAL button to select manual operation mode.
Using the PLUS / MINUS buttons
• Press briey for minute-to-minute progression.
• Press and hold to move quickly through the digits.
Setting the clock
After setting your oven for manual operation, you should also set the time of day.
• First press the MANUAL button, then use the MINUS and PLUS buttons
to adjust the time that appears in the display. When the correct time is
displayed, release the MINUS and PLUS buttons. After a few seconds the
time will x in the display and you will be able to use your oven.
Instructions
A C E
B D F
Fig. 6
Timer buttons
A MINUTE MINDER button
B DURATION button
C END COOK button
D MANUAL button
E MINUS button
F PLUS button

18 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Setting the cooking duration
This function will allow you to set a countdown time similar to the minute
minder function. However, the oven will no longer continue to heat once the
countdown period has elapsed.
• Use the thermostat control knob to set the temperature you require. The
heating symbol will appear on the display.
• Use the function selector knob to select the required cooking mode. You
have to set the mode rst before you can set the duration for the required
cooking time.
• Press the DURATION button and the display will show “00:00”. Then use
the MINUS / PLUS buttons to set the period of time you want the oven to
remain on for.
• Once your set countdown period appears on the display, let go of the
MINUS / PLUS buttons. The countdown will start immediately and the word
AUTO will appear on the timer display. If required, use the MINUS or PLUS
buttons to adjust the countdown time.
• An alarm will sound when the countdown time has elapsed and the oven
will switch off. The word AUTO will ash and the heating symbol will
disappear. Press the DURATION button to silence the alarm.
Instructions (Cont.)
Setting the minute minder
You are able to set the minute minder at any time, regardless of whether an
oven function has been selected. You can set a period of time using the minute
minder function and an alarm will sound when that period of time has elapsed.
• First press the MINUTE MINDER button, the display will show “00:00”.
Then use the MINUS / PLUS buttons to set the countdown period for the
minute minder.
• Once your set countdown time appears on the display, let go of the MINUS
and PLUS buttons. The minute minder symbol will appear on the timer
display. (To adjust the set time, use the MINUS / PLUS buttons.)
• An alarm will sound when the countdown time has elapsed. Press the
MINUTE MINDER button to silence the alarm.
IMPORTANT!
The oven will continue heating once the alarm has been silenced.
To switch off the oven if you have finished cooking,
you must turn the oven function selector and thermostat control knobs to “0”.

19
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
IMPORTANT!
If you do not turn the thermostat control and oven function knobs to “0”, the appliance
will continue to operate as soon as you press the MANUAL button.
Instructions (Cont.)
• Once the duration function has been used, you will need to return the oven
to manual operation mode. To do this, press the MANUAL button, the word
AUTO will disappear from the display.
Setting the cooking end time
This function is similar to the cooking duration function. However, instead
of setting the period of time that you wish the oven to remain on before
switching off, you select the point of time (the time of day) at which you want
the oven to switch off.
• Use the thermostat control knob to set the temperature you require. The
heating symbol will appear on the display.
• Use the function selector knob to select the required cooking mode.
• Press the END COOK button and then use the PLUS button to set the time
of day that you want the oven to stop heating and switch off. The timer will
calculate how long the cooking time will be, based on the time of day you
have selected, and show it on the display. (To adjust a set time, if required,
use the MINUS / PLUS buttons.)
• Once the display has reached the time of day at which you want the oven
to stop heating, let go of the MINUS / PLUS buttons. The countdown will
start immediately and the word AUTO will appear on the timer display.
• At the time of day that you have programmed the oven to stop heating, the
oven will switch off and an alarm will sound. The word AUTO will ash and
the heating symbol will disappear. Press the END COOK button to silence
the alarm.
• Once the end cook function has been used, you will need to return the
oven to manual operation mode. To do this, press the MANUAL button, the
word AUTO will disappear from the display.
IMPORTANT!
If you do not turn the thermostat control and oven function knobs to “0”, the appliance
will continue to operate as soon as you press the MANUAL button.

20 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-AEO65L PRODUCT CODE: 56485 06/2017
Setting the cooking start and end time
The oven start and end timer allows you to set a time in the future at which
the oven will switch on and switch off. This is a convenient feature you can
use when at home to help you program the oven for a later start.
Instructions (Cont.)
IMPORTANT!
If you do not turn the thermostat control and oven function knobs to “0”, the appliance
will continue to operate as soon as you press the MANUAL button.
WARNING!
• For your personal safety and to avoid any potential fire risk, do not program the
timer and then leave the oven unattended.
• For food safety reasons, do not leave easily spoilt foods in the oven for too long
when using the timer.
• When baking, we do not recommend programming the oven for a delayed start as
the cake mixture may dry out and the raising agents may lose their effectiveness.
• Use the thermostat control knob to set the temperature that you require.
The heating symbol will appear on the display.
• Use the function selector knob to select the required cooking mode.
• Press the DURATION button and the display will show “00:00”. Use the
MINUS / PLUS buttons to set the period of time you want to cook for. The
word AUTO will appear on the timer display.
• Immediately press the END COOK button and then use the PLUS button
to set the time of day at which you want the oven to switch off. The oven
will calculate at what time it needs to switch on, so that your food will
cook for the length of time selected. It will automatically switch on once it
reaches the previously set time of day.
• When the time of day reaches the end of the set cooking time, the oven
will switch off and an alarm will sound. The word AUTO will ash and the
heating symbol will disappear. Press the END COOK or DURATION button
to silence the alarm.
• Once the start and end time function has been used you will need to return
the oven to manual operation mode. To do this, press the MANUAL button,
the word AUTO will disappear from the display.
