STM HRAP1215 User manual

STM AUSTRALIA
1/615 WARRIGAL RD
ASHWOODVIC 3147
AUSTRALIA
T 1300131 531
F 1300308 508
E [e-mail]
W WWW.STM.NET.AU
HRAP1215
Automatic Air Hose Reel
Working Pressure 30 bar/435 PSI
Inlet/Outlet Connection M½”G
Hose I.D. ½”
Hose Length 15M
TO PREVENT SERIOUS INJURY, PLEASE READ THIS MANUAL CAREFULLY BEFORE USING!
SAFETY & MAINTENANCE
SIZE DETAIL
1. Ensure that only the qualified hose can install/service this hose reel, and children or unskilled people must not use it.
2. Check for any form of damage before each use. Do not use when damaged.
3. Most parts of product are made of plastic, Please don't press it heavily, in order to avoid spoiling the parts.
4. Don't loose the hose quickly when you get it back
5. Please keep hose clean.
6. Do not use the reel in damp or wet conditions. Keep the work area clean. Avoid put in sundries in hose reel
• Technopolymer casing
• Easy for repairing
• Provided with hose ratchet stop device, easily
removable if constant transaction is required
• New Germany flexible hose, Polyurethane hose
⚠
High Quality Germany Flexible Hose
Polyurethane Mesh Hose
523mm
228mm
100mm
245mm
20mm
316mm 245mm

STM AUSTRALIA
1/615 WARRIGAL RD
ASHWOODVIC 3147
AUSTRALIA
T 1300131 531
F 1300308 508
E [e-mail]
W WWW.STM.NET.AU
Just to open two sides cover
HRAP1215 Automatic Air Hose Reel
SPECIFICATION
PARTS LIST
1. Mounting: It can be fixed on the wall and ceiling.
2. Complete with 180 degree pivot bracket.
3.Easy for repairing, just open the side cover to
change the parts.
Lock (No rotation): Rotation:
When the screws fixed, the
bracket can't rotate
Loosen the screws and push
out the lock, Bracket allows
for 180° of rotation
7
6
5
27
28
29
30
123489
10 11 12 13 14 15 16
18 19 20 21 22 24
25 23 26
17
3 Flange bolts M6x12
4 Ratchet
1 Self-tapping screws ST4X16
2 Side cover
6 D=5 Retainer
5 Pawl spring
9 M5x10 Bolt
10 Bearing 61802
7 Ratchet pawl
8 Side cover
12 Self-tapping screws ST3x12
13 Side drum cover
11 Spring fixing seat
14 Spring
15 Plastic drum
18 Shaft
19 Guide roller
16 Long hose assembly
17 Hose stop assembly
21 Bearing 61804
20 Side drum cover
24 Lead hose assembly
25 Retainer
22 Side cover
23 Valve assembly
27 Handle
28 Swing lock seat
26 Side cover
29 Supporting shaft
30 Swinging locking seat fixing bolt
1
13
1
1
1
4
1
1
1
12
1
1
1
1
1
2
1
Item No. Parts List Qty
1
1
1
1
1
1
1
1
2
1
2
2
Item No. Parts List Qty
