Streamax MDVRs User manual

ISTALLATON M-ALL MDVR-2012_Q2_Ver 1.0
1/27
Installation Manual
For
All Streamax MDVRs
Mobile Digital Video Recorder
Copyright 2012-2014, Streamax Video Technology Co., Ltd
All Rights Reser ed

ISTALLATON M-ALL MDVR-2012_Q2_Ver 1.0
2/27
Table of Content
NOTICE...................................................................................................................................................................................................2
Installation General Instruction...........................................................................................................................................................4
Part 1 MDVR De ice Installation.....................................................................................................................................................5
1 Pre-Installation Preparation.........................................................................................................................................................5
1.1 Technical Requirement.....................................................................................................................................................5
1.2 Installer and Super isor Qualification............................................................................................................................5
1.3 Pre-installation In estigation and Installation Plan Making........................................................................................5
1.4 Reference Installation Tool..............................................................................................................................................6
2 MDVR De ice Installation.............................................................................................................................................................7
2.1 The Hard Disk Installation...............................................................................................................................................8
2.2 Power Connection.............................................................................................................................................................8
2.2.1 Power Wire Requirement....................................................................................................................................8
2.2.2 The Power Connection........................................................................................................................................8
2.3 MDVR De ice installation.................................................................................................................................................9
2.4 How to Choose and Install Cameras............................................................................................................................11
2.5 Antenna (GPS/WIFI/3G) Connection...........................................................................................................................14
2.6 Monitor Installation........................................................................................................................................................15
2.7 How to connect the I/O Sensors..................................................................................................................................16
2.8 How to Connect Alarm System...................................................................................................................................17
2.9 How to Deal with the Connection for Cables and Wire.............................................................................................19
Part 2 The Whole System Testing after Installation..................................................................................................................19
1 MDVR De ice Testing................................................................................................................................................................. 20
1.1 Inspection before Power Connection...........................................................................................................................20
1.2 Trial Testing after the System Gets the Power...........................................................................................................20
1.3 Accessories Testing........................................................................................................................................................ 21
1.4 MDVR Recording and Network Testing........................................................................................................................21
1.4 1 MDVR Recording Testing.................................................................................................................................. 21
1.4.2 I/O Sensor Testing.............................................................................................................................................22
1.4.3 Vehicle Speed and Pulse Testing..................................................................................................................... 22
1.4.4 Wireless Network Testing................................................................................................................................. 23
1.4.5 Software Upgrade................................................................................................................................................24
1.4.6 Setup Machine Registration Information........................................................................................................25
1.4.7 Storage Format (HDD or SD Card)..................................................................................................................25
Appendix.............................................................................................................................................................................................. 26
Bus Application...........................................................................................................................................................................26
The Table for Bandwidth and Frame Rate..............................................................................................................................27

ISTALLATON M-ALL MDVR-2012_Q2_Ver 1.0
3/27
NOTICE
Before you install the MDVR system in the ehicle, please be familiar with this system and read this manual carefully.
Meanwhile the whole installation process must be guided by the professional persons.
1. MDVR is electronic recording and storage system which must be deli ered ery carefully.
2. Use only a regular 12- olt DC or 24- olt DC (3 ~ 5 Amps) certified power supply for installation in ehicles. The
MDVR can support wide power range from 8 ~36 DC. Please follow the installation and operating instructions
pro ided to ensure a steady and reliable installation. Handle all electric equipments and connections properly to a oid
injuries.
3. E en though the recorder unit may not be turned on, li e power exists in the mounting assembly and precautions
should be taken to a oid shock or short circuit.
4. The MDVR installation and maintenance should be implemented by the person who is trained professionally.
5. Choose the right place to install the recorder unit. The space must be big enough for entilation. No any other
subjects around are allowed.
6. Install the MDVR in a dry location shielded from direct contact with excessi e humidity and moisture, rain or other
sources of liquid spills. Do not install on a recessed surface where liquids may accumulate or under surfaces where
liquids may drip.
7. Do not handle the MDVR with wet hands, while standing in water, or while in contact with other sources of water or
moisture that could create a shock hazard.
8. Install the MDVR out of direct sunlight and away from direct sources of heat, dust, ibration and high magnetic field
9. MDVR and accessories installation must be insulated with ehicle to a oid loop interference
10. Do not attach any external de ice (not recommended) to the recorder unit without specified or appro ed by Vendor.
11. Attach the MDVR ground cable to the ehicle correctly to complete the power circuit.
12. Do not mount the unit to a surface subject to excessi e ibration.
13. Do not take out or change any module when the MDVR is power on.
14. Power supply must connect to the ehicle battery positi e and negati e polarity directly or UPS from ehicle. Any
other indirect power connection is forbidden. In order to make sure the de ice and ehicle work fine, please add a
fuse into the connection for protection.
15. Please do maintenance routine for MDVR and accessories to a oid any screw loose or bad ideo image.

ISTM-ALL MDVR-2012_Q2_Ver 1.0
4/27
Installation General Instruction
Before install the recorder system and accessories, the most important is to know the ehicle construction especially for
power. Please check following:
1) Which MDVR model and accessories will be installed?
2) In which part of the ehicle can install the MDVR? How big the size is?
3) Cables and installation tools (for example: electric drill, screw dri er, screws, multimeters etc…)
4) Manpower distribution
5) General concept for wiring
6) Draft the specific installation guide for specific ehicle
Roug Installation Steps as below:
Step 1: Preparation
Step 2: Installing Point Test
Step 3: Installing
Step 4: Testing
Step 5: Inspection
Step 6: Finish the installation
Step 7: Maintenance

ISTM-ALL MDVR-2012_Q2_Ver 1.0
5/27
Part 1 MDVR Device Installation
1 Pre-Installation Preparation
1.1 Tec nical Requirement
Be familiar with the MDVR de ice functions and application
Be familiar with the whole MDVR solution
Be familiar with the ehicle electrical circuit, ehicle structure and installation skills.
1.2 Installer and Supervisor Qualification
Supervisor Qualification and responsibility
1. He must be familiar with the installation requirements, the whole MDVR system (including MDVR
de ice and the relati e accessories and PC software).
2. Assign the task to the installers and guild them for the installation
3. Control the installation schedule, installation inspection to make sure that installation is correct and safe.
Installer Qualification:
1. He must be trained and qualified for installation
2. He must comply with safety rules and use the installation tools safely
3. He must be ery familiar with the ehicle working principle and the internal electronic equipment
1.3 Pre-installation Investigation and Installation Plan Making
Before installation, the installer must do the in estigation to know more for the installation en ironment including:
1. He must know the ehicle which will be installed MDVR in
2. The point for installation and how to protect the MDVR and accessories.
3. Camera and some other accessories installation
4. He should prepare the suitable cable (the material for the cable and the length for the cable) for MDVR
installation.
5. All the commonly-used materials should be listed to make sure the installation go fast
6. Some other that is helpful for installation

ISTM-ALL MDVR-2012_Q2_Ver 1.0
6/27
1.4 Reference Installation Tool
Item Name P oto Specification Function Remark
1Electric Drill
Drill the holes
2 Drill bit 12mm
To drill the hole in the
ehicle to get the
power cable out getting
the power for the
MDVR.
3 Drill bit 2.8mm
To drill the hole for
cameras, monitor
bracket etc…
4
Philli
ps
screwdri er
for screwing manually
5
digital
multimeter
for oltage testing and
short- circuit
6
power cable
and Extention
W
7wire stripper
for cable spliting and
connecting
8 Ribbon
9Thread
Forming
To fix the camera and
monitor bracket
10 Log Bolts
for fixing MDVR
machine and proection
box
11 Insulating
tape
for wrapping up the
wires

ISTM-ALL MDVR-2012_Q2_Ver 1.0
7/27
12 soldering iron for welding
13 Tin Bar
14 Diagonal
Pliers for cable connecting
15 Crimping
Pliers for cable connecting
16 Scissors for shrinkable tube cut
17
Heat Gun for shrinkable tube
encapsulation
18 Glass glue
gun
for hole sealing and
fixation.
2 MDVR Device Installation
The basic Installation principal is:
1. All parts installation complies to the principal: same type ehicle, same installation point
2. Keep the ehicle clean and safe
The MDVR installation is the most part. Please make sure that the MDVR unit is fully and carefully tested before
installation to guarantee the installation can be competed fast and easier and more con enient for post-installation
maintenance.
1) MDVR working environment
The installer must know that MDVR works in harsh en ironment e eryday and they ha e high requirements for
the en ironment and installer’s skill.
a) Anti- ibration: The MDVR de ice must be installed the place with week ibration (for example: behind the
dri er’s seat). Installing the MDVR on the rear of the ehicle with strong ibration or closing to the engine
is forbidden.
b) Ventilation: The MDVR de ice must be far away for the heating source in the ehicle. The installation point
should be entilated.
c) Waterproof and Moistureproof: The de ice must be away from water or some other liquid source. If

ISTM-ALL MDVR-2012_Q2_Ver 1.0
8/27
necessary the external protection de ice is recommended (lock box or installation bracket)
d) Dustproof: The de ice must be installed on the point with little dust
e) Installation points size: horizontal installing for MDVR de ice is recommend as it is easier for installation
and maintenance. The installation point size must be big enough and the MDVR de ice cannot be
surrounded with other subjects are it is not good for entilation.
f) Electric: The MDVR de ice must be far away from electromagnetism en ironment to a oid the strong
interference.
g) Wiring: The cables should be hidden to keep the ehicle clean
2) MDVR Protection
If the MDVR has to be installed in the harsh en ironment (with much dust and high moisture or easily to be
damaged humanly), The lock box or installation bracket pro ided by manufacturer are recommended.
3) Installation
a) The MDVR must be installed horizontally (especially for the hard disk unit must be installed by this way)
b) The MDVR and accessories must be fix firmly to a oid strong ibration
c) The IR recei er and the LED should (on the front panel of the MDVR) be toward to the direction with easy
operation
2.1 T e Hard Disk Installation
Each MDVR is shipped with the hard disk installation manual. Please read it ery carefully. The wrong installation will
shorten the life of the hard disk.
2.2 Power Connection
2.2.1 Power Wire Requirement
Power wire material: according to the MDVR de ice maximum load, power cable should be 1.5mm-2.5mm
diameter BVV cable or with protection tube to ensure the wires are not frazzled and damaged easily.
2.2.2 T e Power Connection
The power supply is the basic and critical for MDVR de ice working. The connection and wiring is ery rigid for
installation.
1) The MDVR power must be pro ided by the battery of the ehicle. It must be connected with the positi e and
negati e polarity of the battery directly (Below left diagram). Or the power connects the ehicle power control
box (Below right diagram). Any other ways for connection are forbidden as this will cause the unstable power
supply and affect MDVR working.

ISTM-ALL MDVR-2012_Q2_Ver 1.0
9/27
2) The power extension should be a little bit longer to lea e some space for mo ement during the ehicle is running.
The external protection tube (fire resistant PVC bellow) are recommended. The diameter for the cable is
required to be from 1.5mm to 2.5mm. E en for the bigger power consumption MDVR de ice or 12V ehicle with
the long distance wiring requires that the cable diameter should be 2.0mm copper material inside.
3) The power cable wiring should be ertical with the other cable wiring to a oid the equidirectional interference.
4) Security setting: safety de ice (like fuse) must be added between the de ice and battery.
2.3 MDVR Device installation
The installation diagram
Positi e
polarityNegati e polarity
Fuse
Ve icle Battery
De ice to control the ignition of ehicle
MDVR power input negati e polarity
MDVR power input positi e polarity(red)
Mobile DVR
The lock for remo able hard disk
case (lock it before booting up
the MDVR)
The ACC
signal cable
(yellow).
The oltage
is ≥7.5V
1. The MDVR cannot be installed on the ehicle floor directly. MDVR housing must be insulated with the
body of the ehicle. External protection cap or box is necessary for waterproof and dustproof.
2. Horizontal installation is recommended by manufacturer
3. The LED light on the MDVR front panel should be outward for each checking the MDVR working status and
recei ing the IR signal.
OR

ISTM-ALL MDVR-2012_Q2_Ver 1.0
10/27
4. Some tips for installation:
（1）12V natural gas anti-interference isolation
When install the MDVR in 12V natural gas ehicles, the MDVR de ice must be insulated with the body of the
ehicle. Get power for the MDVR from ehicle battery directly and make sure to install the power protector and
security de ice between the MDVR de ice and battery.
（2）Pay attention to the polarity of electric power switch control (polarity test method: disconnect control
switch, take a wire from battery negati e polarity, test it with digital multimeter. Connect this wire by
black pen on the multimeter, then connect ehicle body with red pen. If the circuit is working, this means that
ehicle power switch control is positi e. If not, it is negati e. If the ehicle switch is negati e, it is
necessary to deal with the insulation between MDVR de ice and the accessories.
（3）It is ery necessary for 12V battery-powered ehicles to deal with the insulation between the MDVR de ice and
the accessories of MDVR.
5. ACC cable requirements
（1）ACC wire working principle
Actual wire: red is positi e, black is negati e, yellow is ignition signal.
The MDVR de ice does not work if yellow ignition signal wire is connected ground or nothing. Make sure ACC
oltage is higher than 7.5V (Please test the oltage before connection) before booting up the MDVR
system for ensuring normal operation.
（2）When the recording model for MDVR is timing recording, please make sure connect the yellow ignition signal
wire with battery positi e polarity.
（3）Switch power le el alue
Ignition
signal
≤6V Ignition OFF
≥7.5V Ignition ON
6. All the wires connected to the rear panel of the MDVR should be wrapped together. The high frequency signal
cables should be shield by protected de ice. The connection should be strong and firm. All lines cannot be

ISTM-ALL MDVR-2012_Q2_Ver 1.0
11/27
stretched. Protection solution are need for cable cut parts.
7. To fix the MDVR de ice well
2.4 How to C oose and Install Cameras
1) Camera Selection
There are 5 features should be considered for ehicle camera.
（1）The monitored space for camera (Angle)
（2）The size for the monitored objects
（3）Focus
（4）CCD size
（5）Camera is required to ha e a good IC reset circuit to a oid the black screen during recording.
Except the abo e 5 features, there are some others requirements for camera working en ironment.
（1）The camera should be small and not hea y.
（2）Should support anti- ibration
（3）Infrared light is required to monitor during the night or in some places with week light.
（4）Waterproof and moistureproof
2) Camera Installation Regulation
（1）The camera should be far away from heat source and electromagnetic interference in the ehicle.
（2）The installation point should be safe a oiding camera damaged humanly.
（3）How many cameras should be installed is depends on the ehicle size. Please make sure the camera
（4）Angle is big enough to co er all parts of the ehicle (excluding some special application).
（5）The camera should be fixed well to a oid any human mo ing effecting the monitoring image.
（6）The camera should be installed in the point with good luminance. Otherwise the infrared light working
too long time will affect the camera life.
3) Camera Installation Diagram
Usually required by bus operator or bus company, there are 4 cameras should be installed for one bus. These
cameras are used to monitor dri er, coin box, rear door, road and e ery parts in the ehicles. The infrared color
camera is recommended.
（1）Front camera: To monitor the dri er. The dri er must dri e correctly and safely to a oid the accident.
（2）The wide angle camera is recommended. If the angle is big enough, it can monitor the dri er and the
road forward together.
（3）Camera for coin box: To check whether some passengers get on the bus without paying
（4）Rear door camera: To check whether some passengers get on the bus without paying (as there is no coin
box in some buses)
（5）Rear camera: To monitor the whole ehicle inside for passenger beha ior for example: thie ery, fight)

ISTM-ALL MDVR-2012_Q2_Ver 1.0
12/27
Deri er’s
seat
MDVR
Rear
Door
Front
Door
1
2
4 3
Dri er’s
seat
MDVR
Rear
Door
Front
Door
1
2
4 3
4) T e Installation P otos for Reference
Mainly the installation point for camera is really depends on different ehicle and different application. Here please
see some photos for reference.

ISTM-ALL MDVR-2012_Q2_Ver 1.0
13/27
For police car, taxi or some other ehicles, the camera installation point will be different. Here are some photos for
reference.
The
rear
camera
For taxi
installation
Install 2 cameras on the roof of the
police car
The PTZ for
police car
application

ISTM-ALL MDVR-2012_Q2_Ver 1.0
14/27
2.5 Antenna (GPS/WIFI/3G) Connection
For the products with WIFI, GPS, 3G functions, the antenna will be shipped with the MDVR together to customers.
Here are some tips for antenna connection and fixation:
（1）The antenna is recommended to be installed on ehicle roof (drill the hole on the roof) to get the good
signal.
（2）The external protection cap is recommended for antenna to a oid human damage.
（3）Each antenna cannot interfere mutually.
（4）If the antenna cannot be installed outside of the ehicle (As some bus companies or bus operators do not
agree to drill a hole on the ehicle roof. In this situation, the antenna should be fixed inside of the
ehicle to guarantee the good signal.
1) How to Connect WIFI Antenna
Currently there main WIFI system includes:
（1）802.11b: Speed is 11M. Frequency is 2.4G HZ. This signal distance for this system is from 200 to
400 meters.
（2）802.11a: Speed is 54M. Frequency is 5G HZ
（3）802.11g: Speed is 54M and 11M optional. This system is compatible with 802.11b and 802.11a. The
frequency is 2.4GHZ, But when this system is compatible with 802.11a, the frequency is 5GHZ.
2) T e P otos for Reference
3) How to Connect GPS Antenna
GPS should be installed on the roof of ehicles for good reception of satellite signals. If drilling the hole on the ehicle
roof is forbidden, then please try to get the GPS cable outside of the ehicle (please put the cable hidden)). The GPS
antenna bottom is magnetic and can be stick to the metal on the roof of the ehicle. It must be fixed by glass cement
and the antenna black side must be upward.
4) How to Connect 3G Antenna
Attach the antenna to the ehicle window or plastic shell, but not the metal as it will affect the communication signal.
3G Antenna WIFI Antenna External GPS Built-in GPS Antenna
The WIFI
antenna near
dash mounted
panel in bus

ISTM-ALL MDVR-2012_Q2_Ver 1.0
15/27
5) General Connection Instruction
（1）Choose right place for antenna for GPS/WIFI/3G installation. Generally the antenna are recommended to be
installed in front part of ehicle roof (please drill one hole on the ehicle roof and installed the antenna
outdoor) and fix them. Make sure put them in open air without any blocking.
（2）Use a waterproof rubber stopper or glass cement or some other reliable ways to seal the hole for stretching
the antenna out to ensure the tightness of roof.
（3）An extra cap is needed for external antenna. Exposing parts should be waterproof and fire treatment.
（4）Place antenna in tri-angle shape with 120 angle, 10cm distance between center point.
（5）Fix antenna base with neutral silicone for fixing and waterproof.
（6）On the cable of the antenna, there is one SMA connector, please connect it with the module firmly.
If drilling hole is not allowed by bus company or bus operator, then please install the antenna just inside of the ehicle
6) Installation Tips:
（1）The WIFI antenna must be fixed by the glass cerement and the WIFI antenna bottom plane must be
parallel with the ehicle roof. Standing or side installation are not allowed.
（2）GPS antenna should be installed in open air on top of ehicle, The bottom plane must be parallel with the
ehicle roof and fixed by glass cerement. Stand or side installation are not allowed. The black side must
be upwards.
（3）EVDO (CDMA2000)/HSDPA (WCDMA) antenna, stickled on glass or plastic shell but not metal as this will
affect the network signal.
2.6 Monitor Installation
Monitor Installation depends on different requirement. It is recommended to install where is easy to by iewed by dri er

ISTM-ALL MDVR-2012_Q2_Ver 1.0
16/27
and can a oid sight reflection such as around rear- iew mirror.
2.7 How to connect t e I/O Sensors
The MDVR de ice can support 8 sensor inputs and 2 or 4 outputs (depends on different models. Some of the models can
support 2 outputs only).The inputs are used to detect the dri ing beha ior like panic button for emergency alarm, braking,
turning left or right, open or close the door, re erse etc…
In MDVR GUI, you can setup different sensor inputs as following. You can define any or the sensor inputs to be different
function. For example, if you define sensor 1 is for panic button please connect panic button with sensor 1 signal on the
alarm box (the photo is below). Please just make sure you connect the sensor correctly with the alarm box.
1) How to connect t e signal for open/close t e door
Signal for opening
the
d
oor
Signal for closing
the door
Defined Sensor Input
Defined Sensor Input
+12V/24V

ISTM-ALL MDVR-2012_Q2_Ver 1.0
17/27
2) How to connect t e signal for braking
When the dri er stamps the brake ane, the MDVR de ice can detect the high power le el. Otherwise it is low power le el.
To connect the sensor
signal of the ehicle
by alarm box
Braking light
12V/24V
Brake Vane
Alarm outputs are power le el output. For powerful equipments, external replay is necessary. The following diagram is for
how to wire the photoelectric alarm from alarm outputting.
24V/12V
Alarm output
2.8 How to Connect Alarm System
Alarm system (we say panic button as well) is one of the MDVR I/O sensor input function. This function is used to deal with
some emergency. For example if some accidents happens, the dri er or the passengers can press the button to trigger the
alarm ideo to centre ser er by 3G network.
The alarm system is ery typical for bus application. There are 2 different panic button used for bus. One is for dri er and
another is for passenger.
1) Driver alarm system installation
Generally the alarm system for dri er is installed close to him for easy operation. The signal from MDVR to front part
dri er panic button connected with 3*0.2 wires.
The installation steps are as bellow:
（1）Drill a hole with 65mm length, 35mm width beside the seat of the dri er (This size of the hole is depends
on the size of the panic button)
（2）Connect panic wire with connectors behind panic button.
（3）Fix button with thread foaming.

ISTM-ALL MDVR-2012_Q2_Ver 1.0
18/27
2) T e P otos for Reference
3) Alarm System for Passengers
Signal wire of this alarm button is 4*0.2 wires. The wiring diagram as picture below:
Generally the alarm system for passenger are installed near by the passenger and the wiring should go with
Any
sensor
inputs
(Supposed
sensor
Any
sensor
inputs
(Supposed
sensor
4)
F
o
r
high
le el
power
input
Fuse
Fuse
The
connectors
on
the
back
of
the
button
Pin 2: Power Positi e polarity………Red
Pin 4: Power negati e polarity……..Black
Pin1: Alarm input…………………..Green
Pin3: Alarm output…………………White

ISTM-ALL MDVR-2012_Q2_Ver 1.0
19/27
the air-conditioner. Different ehicle has different internal en ironment. E ery ehicle should ha e the suitable
installation method. Here introduce the installation steps for the ehicle with air-conditioner:
（1）Drill the hole close the channel for air conditioner
（2）Pull the wire through air conditioner channel and take it out from the hotel and connect with alarm
Box
（3）Fix the button with thread forming between 2 windows in the ehicle
2.9 How to Deal wit t e Connection for Cables and Wire
1) Cold Pressing Connection
（1）There are 3 different standards for wire connector: CHS-Φ3、5、8. according to the actual demand.
（2）All the cut cables must be connected by the wire connector
（3）Please use the wire stripper (model: HS-I01/0.5~10mm) for connection.
（4）The cold pressing process is striping the cable co er (10mm~15mm), connecting all the copper wire
together, cutting off the raw edge and put them into the suitable wire connector and then pressing connect
by the wire stripper.
（5）After the compression, please wrap the cables together by ribbon.
2) Welding
（1）If the wire of ideo cable or complex cable is too thin to be cold pressed, please try to weld.
（2）The power cable or others cables can not be cold pressed, please try to weld too. Wire wrap connection is
not allowed.
（3）After the welding, binding the cable with the ribbon.
（4）
Part 2 T e W ole System Testing after Installation
1 MDVR Device Testing
1.1 Inspection before Power Connection
After all the equipments are installed, please follow the steps to check before power supply for MDVR:

ISTM-ALL MDVR-2012_Q2_Ver 1.0
20/27
1) Wiring Inspection
（1）Cable wiring should be cross- ertical strokes, orderly to keep the ehicle clean and safe
（2）Wiring for power cable, extension cable, ground wire and digital wire should be in orderly.
（3）Keep 90 degree angle if cables cross is necessary.
（4）Suitable ribbon should be used in binding with consistent method and equal spacing; redundant ribbon
should be cut off and not harm for hand.
（5）Ribbon should be not too tight to injury the cable. The cable should not touch the sharp objects, rubber
protector is necessary for the holes
（6）All cable should be with Cabling Rack, no jump wiring is allowed.
2) MDVR Device inspection
（1）Check the MDVR de ice is fixed well or not. Try to mo e the MDVR and check whether it is loose.
（2）Check the de ice power connection is correct or not. Connect the MDVR ground cable with ehicle directly is
not allowed.
（3）Check whether the hard disk or SD card installation is correct or not?
（4）Inspect all connection cables and connectors.
3) Electrical Equipment Inspection
After the inspection for MDVR machine, please confirm the each connector as following:
（1）Checking the oltage for power connector is from 8V to36 , higher or lower oltage will bring damage for the
MDVR machine.
（2）Checking all kinds of antennas are well connected as photo showed.
（3）Check ideo outputting connector.
（4）Check the camera, no short-circuit and electrical ground phenomenon.
4) System Inspection and testing
（1）Check the cable connection is strong and firm.
（2）Check the connection of power and whether the fuse can work fine.
1.2 Trial Testing after t e System Gets t e Power
（1）After all the checking in item 1.1, please try to connect the power for the system.
（2）After the MDVR gets power, please check the LED lights on the front panel of the MDVR.
（3）Does the relati e LED is flashing or not. Does some LED shows error information.
（4）Check the image from the monitor
（5）Check the MDVR output oltage is normal or not (12V,5A)
（6）Check the firmware ersion, communication module and GPS module if the signal is strong or not.
（7）HDD format. After formatting, the MDVR system will reboot up. After that, please check the REC LED on the
front panel of the MDVR to ensure that MDVR can record. Then please enter the MDVR GUI for configuration
（8）T e last step is for Ignition test. Checking whether the machine will restart or not . If the MDVR will reboot up
continuously, please re-check the cables connection and load capacity of the system.
