Streamax X7-E160 User manual

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
1 - 78
User Manual
For
X7-E1608 MDVR
Mobile Digital Video Recorder
Copyright 2013-2015, Streamax Technology Co., Ltd
All Rights Reserved

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
2 - 78
Notice
The information in this manual was current when published. The manufacturer reserves the right to
revise and improve its products. All specifications are therefore subject to change without any notice.
The purpose of this manual is to kindly aid the user for the operation for our MDVR. The user should
have a basic understanding of computer operation and basic knowledge of how to connect peripherals
and make some settings.
Copyright
Under copyright laws, the content of this manual may not be copied, photocopied, reproduced,
translated or reduced to any electronic medium or machine- readable form, in whole or in part, without
prior written consent of Streamax Technology Co., Ltd (Copyright 2013-2015)

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
3 - 78
Guarantee & Warnings
1) Electrical Apparatus Safety
All installation and operation should comply with local electrical safety norms.
2) Transportation
In the process of transportation, storage and installation, please avoid heavy stress, violent vibration,
impact and water splashing.
3) Installation
Install the equipment in accordance with the requirements, handle carefully. Do not heavily press the
equipment before the MDVR installation is finished.
4) Requirements on Engineers & Technicians
All the work of checking and maintenance should be done by qualified technicians and engineers.
We do not undertake any responsibility caused by unauthorized modifications.
5) Requirements on Environment
The equipment should be installed and stored in a cool and dry place, away from direct sunlight,
flammable or explosive substances, etc. Keep gaps not less than 3cm around the device to facilitate
ventilation for cooling.
6) Accessories
Make sure to use accessories from the manufacturer recommended in the attachment.
Insulate circuit ground and metal shell for all the peripherals.
Before installation, please open the package and ensure that all parts are included.
If there are any problems, please contact us as soon as possible.
Description
Term
Description
Term
Description
MDVR
Mobile Digital Video Recorder
LAN
LAN Network
FPS
Picture Frames Per Second
MPEG
Picture Format
GPS
Specially for Antenna of GPS System
TCP/IP
TCP/IP Protocol
HDD
Hard Disk for Recording
USB
USB Flash Interface
IR
Remote Control IR Receiver
DB44
A/V Input, Output.IO/ALARM Output
DB26
Alarm Input/RS232/RS485
UPS
Power to Switcher and MDVR

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
4 - 78
Contents
1．PRODUCT CHARACTERISTICS................................................................................................................... 6
1.1. OVERVIEW.........................................................................................................................................6
1.2. FEATURES......................................................................................................................................... 6
1.2.1. HARDWARE FEATURES:....................................................................................................... 6
1.2.2. SOFTWARE FEATURES:........................................................................................................ 6
1.3. SPECIFICATIONS............................................................................................................................. 8
1.4. EXTERNAL INTERFACE................................................................................................................. 9
1.5. SYSTEM DIAGRAM........................................................................................................................11
1.6. HARD DISK INSTALLATION INSTRUCTION............................................................................ 12
1.7. EXTERNAL WIRE DIAGRAM........................................................................................................12
1.7.1. DB44 CABLE (Analog A/V input/output)..............................................................................12
1.7.2. DB26 CABLE............................................................................................................................15
1.7.3. POWER CABLE.......................................................................................................................16
1.7.4. GPS AND GPRS ANTENNA..................................................................................................17
1.7.5. ALARM INPUT / OUTPUT..................................................................................................... 17
2．LOCAL MANAGEMENT................................................................................................................................. 18
2.1. LOGIN INTERFACE........................................................................................................................ 18
2.2. RECORD SEARCH:........................................................................................................................21
2.3. LOG SEARCH..................................................................................................................................24
2.4. SYSTEM STATUS........................................................................................................................... 26
2.5. BASIC SETUP..................................................................................................................................28
2.5.1. REGISTER INFOMATION (SETUP VEHICLE INFORMATION).....................................28
2.5.2. TIME SETUP............................................................................................................................ 30
2.5.3. START UP.................................................................................................................................32
2.5.4. USER SETUP...........................................................................................................................33
2.5.5. NETWORK................................................................................................................................34
2.5.6. APPLICATION..........................................................................................................................38
2.6. SURVEILLANCE..............................................................................................................................38
2.6.1. LIVE VIEW................................................................................................................................ 39
2.6.2. RECORD...................................................................................................................................40
2.6.3. IPC SETUP............................................................................................................................... 44
2.6.4. PTZ.............................................................................................................................................46
2.7. DATA COLLECTION........................................................................................................................46
2.7.1. GENERAL................................................................................................................................. 46
2.7.2. SNAP SETTING.......................................................................................................................48
2.7.3. ECO-DRIVING ....................................................................................................................... 50
2.8. ALARM.............................................................................................................................................. 51
2.8.1. BASE..........................................................................................................................................51
2.8.2. VIDEO........................................................................................................................................58
2.8.3. ADVANCE................................................................................................................................. 61
2.9. MAINTENANCE............................................................................................................................... 62
2.9.1. CONFIGURATION...................................................................................................................63

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
5 - 78
2.9.2. DATA EXPORT.........................................................................................................................63
2.9.3. UPGRADE................................................................................................................................ 64
2.9.4. STORAGE.................................................................................................................................65
2.9.5. DEFAULT.................................................................................................................................. 66
3．WEB MANAGEMENT..................................................................................................................................... 66
3.1 LOGIN INTERFACE.........................................................................................................................66
3.2 MAIN INTERFACE...........................................................................................................................67
3.3 PLAYBACK....................................................................................................................................... 68
3.4 MAINTENANCE............................................................................................................................... 70
3.4.1. BASIC INFORMATION........................................................................................................... 71
3.4.2. DEVICE MODULE...................................................................................................................71
3.4.3. STORAGE DEVICE................................................................................................................ 72
3.4.4. VERSION INFORMATION..................................................................................................... 73
3.5 CONFIGURATION...........................................................................................................................73
4．STORAGE CAPACITY CALCULATION.......................................................................................................75
5．FAQ.................................................................................................................................................................... 76

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
6 - 78
1．PRODUCT CHARACTERISTICS
1.1. OVERVIEW
X7-E1608 is a cost effective and function-extensive device specially designed for Mobile Video
surveillance and intelligent dispatch. It adopts high speed processor and built-in operating system,
combining with H. 264 video compression / decompression technology, 4G/3G network technology, GPS
locating technology and WIFI technology. It can realize 720P high definition, WD1, WHD1, WCIF, D1,
CIF, HD1, CIF video recording and vehicle driving information recording, as well as remote video upload.
With center software it also achieves alarm linkage central monitoring, vehicle intelligent dispatching
management and playback analysis based on central database. It is powerful with strong anti-vibration,
totally metal appearance design, flexible installation, easy maintenance and high reliability.
1.2. FEATURES
1.2.1. HARDWARE FEATURES:
1) All the modules are connected with exquisite connectors, supporting quick disconnection, which is
safe and easy to maintain;
2) Supports DC8~36V wide voltage output. There are protection for over voltage, under voltage, short
circuit and over current;
3) Supports dual 2.5" SATA hard disks of large-capacity;
4) Built-in mechanical anti-vibration technology;
5) Adopts rich interfaces: 2xDB44, 1xserial ports (DB26), 1xCP4 aviation interface, 1xUSB, 1xfan
connector, 2x RJ45, 1xpower aviation interface and 1x3Pin debugging serial port;
6) Convenient operation: CP4 touch panel, remote control, mouse, keyboard, PTZ controller are
optional. It can even equips with a special extension cable for remote control;
7) Built-in wireless module: Built-in GPS module, 4G/3G
(FDD-LTE/TDD-LTE/EVDO/TD-SCDMA/WCDMA);
8) Aviation interface: It adopts professional aviation interface with waterproof and anti-vibration ability.
1.2.2. SOFTWARE FEATURES:
1) 24-hour single-file recording mode. Time line mode playback, makes the operation more
convenient;

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
7 - 78
2) Supports dual streams for main/sub stream recordings and mirror recording;
3) Built-in H.264 codec, user can manually configure the video coding attributes
4) A series of synchronous operation: Information record, recording playback, file backup, network
transmission, etc.;
5) Supports multiple languages;
6) Adapts dynamic coding technology to adjust the dynamic change of 4G/3G network bandwidth and
ensure the fluency of monitoring video;
7) Multi-information display: vehicle number, time/date information, channel information, alarm
information, GPS information, speed information, etc. User can set video recording overlay and
information record;
8) Supports Multi-recording modes: vehicle switch recording, timing switch recording, manual
recording, alarm recording, and latent shutdown recording, etc.; supports continuous recording and
loop recording; supports power protection to ensure that the last video data is not lost;
9) Local recording: 720P/WD1/WHD1/WCIF/D1/HD1/CIF resolution optional;
10) Driving record: provides statistics on speed, turning, brake, reverse, opening door, etc.;
11) Network function: supports break point uploading continually, which can realize the remote video
surveillance, video download, remote alarming and network timing of the equipment, network
setting and remote upgrade, etc.;
12) High-speed backup: supports high-speed backup through USB2.0, as well as built-in and external
SD cards;
13) Device upgrade: upgrade all items that can be upgraded at one time;
14) Alarm linkage: supports linkage switch value output, image display, etc.;
15) Storage format: formats device hard disk and external USB devices and SD cards.

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
8 - 78
1.3. SPECIFICATIONS
Items
Technical Index
Product Series
X7-E1608
Function Overview
Preview, Recording, Playback, Network, Locating
System
OS
Linux 3.0.8
Control Mode
CP4, Easy Check, Network, Mouse(3G/4G/WIFI)
Video
Input
16 channels WD1+8 channels IPC(720P)
Output
3 channels
Total Resource
(16 x 25)FPS WD1 @ PAL/(16 x 30)FPS WD1@NTSC
+(8 x 30)FPS 720P
Video Signal Standard
Electrical level:1Vpp Impedance:75Ω
NTSC/PAL Optional
Audio
Input
24 channels(8 channels IPC)
Output
3 channels
Audio Signal Standard
Electrical level:2Vpp Input impedance:4.7kΩ
Display
Display Split
1/4/9
OSD
Locating, alarm, vehicle number, speed and date/time
Operation Interface
Graphical User Interface
Recording
Video/Audio
Compression
Video: H.264
Audio: ADPCM, G.711U, G.711A
Image Resolution
Analog:
PAL:WD1(928X576), WHD1(928X288),
WCIF(464X288), D1(704X576), HD1(704x288),
CIF(352x288);
NTSC:WD1(928X480), WHD1(928X240),
WCIF(464X240), D1(704x480), HD1(704x240),
CIF(352x240);
Digital: 720P(1280X720)
Image Quality
8 levels adjustable
Recording Mode
Boots up/manual/schedule/Alarm event recording(sensor
trigger, speed, external acceleration sensor, alarm
button)
Pre-recording
0-60 minutes
Post-recording
0-30 minutes
Mirror Recording
Yes
Playback
Playback Channel
4 channels by local playback
Search Mode
Date/time, channel, event
Network
Ethernet
RJ45x2 (10/100/1000Mbps)
WIFI
802.11b/g/n
3G/4G
EVDO/WCDMA/TDD-LTE/FDD-LTE

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
9 - 78
Locating
GPS
Location tracking, speed detection and time sync
Storage
Hard disk
2.5" SATA hard disk x 2
Interface
USB
USB 2.0 x 2 (1 at front panel, 1 at rear panel)
SD
SD x 1
SIM
SIM slot x 1
Serial ports
RS232 x 2, RS485 x 2
Sensor
8 inputs, 2 outputs
Speed
1 channel pulse speed detection
Interface
Control panel (CP4)(Optional)
Intercommunication
I MIC interface
Power
Input
DC8-36V, ACC
Output
5V@1000mA, 12V@1000mA
Max Power
Consumption
162W
Standby Power
Consumption
≈0W
Physical
Characteristics
Dimension(L x W x H)
324.6 x 238 x 116 mm
Weight
4.2 kg
Environment
Operating
Temperature
-40℃- +70℃(With heater) or -10℃- +70℃
Operating Relative
Humidity
8%-90%（No Condense）
1.4. EXTERNAL INTERFACE
Dimension (Unit: mm)

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
10 - 78
Front Panel
Serial No.
Description
1
Hard disk module
2
USB interface
3
LED status
4
Slots of SD card and SIM card
Rear Panel
Serial
No.
Print
Description
1
Power
DC 8-36 V Power Input
2
Serial
The Interfaces of Serial Port, Switch
and pulse
3
Panel
Control panel (CP4)
4
A/V 1~2
Analog audio/video input&output

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
11 - 78
5
LAN 1~2
RJ45(1000M)
6
GPS Antenna Interface
7
3G/4G Antenna Interface
8
WIFI Antenna Interface
9
USB
USB 2.0 Interface
10
Fan
Fan Interface
1.5. SYSTEM DIAGRAM

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
12 - 78
1.6. HARD DISK INSTALLATION INSTRUCTION
1.7. EXTERNAL WIRE DIAGRAM
1.7.1. DB44 CABLE (Analog A/V input/output)

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
13 - 78

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
14 - 78
Sectional view
Definition and interface of DB44
DB44
Definition of DB44
Interface
Name
Description
Audio/Video
Input
VIN1~VIN8
The port is Aviation Male. There are 4 audio/video inputs of a
4-channel MDVR, while there are 8 audio/video inputs of a
8-channel MDVR, Pin1 with 12V power output, pin2 with GND, pin3
with audio input, pin4 with video input.
Audio/Video
Output
AV OUT
The port is Aviation Female, audio/video output, pin1 with 12V
power output, pin2 with GND, pin3 with audio input, pin4 with video
input.

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
15 - 78
1.7.2. DB26 CABLE

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
16 - 78
Definition and interface of DB26
DB26
Definition of DB26
Port
Interface
Description
RS485
RS232-1
1: 232TX, 2:232RX, 3:5V，4:GND
RS232-2
1: 232TX, 2: 232RX, 3: 5V，4: GND
RS485-3
1: 485A, 2: 485B, 3: 5V，4: GND
RS485-4
1: 485A, 2: 485B, 3: 5V，4: GND
Alarm input
SENSOR1~8
8 alarm input，2V is low level，5V~30V is high level
Speed sensor
SPEED+ SPEED-
To connect with speed pulse
1.7.3. POWER CABLE
Below is a power cable, one end is 4PIN white connector which can be insert into the back panel
of MDVR. Red cable and black cable can be connected with the battery of vehicle; red cable is “+”, black
is “–”, yellow is ignition. MDVR will start to work automatically when you turn on the engine, it switches
off when you turn off the engine. The yellow cable should be connected with the key which is related with
the dash board.
Attention：
1) Make sure the voltage is 12V to 36 V before you connect the MDVR to the battery, otherwise, the
MDVR will be damaged by the power which is higher than 36V.
2) Pay attention to the insulation of the wires to avoid short circuit.
3) Yellow cable much be connected with the engine, otherwise, the MDVR will not support the feature
for shut-down delay, which will result in video loss.

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
17 - 78
Power cable
1.7.4. GPS AND GPRS ANTENNA
GPS Antenna
GPRS Antenna
1.7.5. ALARM INPUT / OUTPUT
MDVR has 8 alarm input and 2 alarm output. Alarm input works to inspect the electrical level, it can
detect different signals of the vehicle, like braking, turning direction, etc. Please see the diagram below
to simulate the working mode. When you press the brake, the MDVR will detect the high level pulse,
otherwise, it detects the low level pulse.
+24V
Alarm output is level output with 200mA drive capability. If user wants to drive a device of large
power, an external relay is needed.
Following is the diagram of alarm output::
Brake Board
Brake Light
Connect input line
of sensor X11

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
18 - 78
24V
2．LOCAL MANAGEMENT
N9M supports 3 kinds of local setting methods:
1) Connect monitor to mobile DVR and make sure it can play real time output image. Then connect
mouse to USB interface at the front panel to have MDVR parameter setting.
2) Connect the touch panel CP4 to mobile DVR to have MDVR parameter setting. (RS232 serial port is
needed when they are model X1 and M1, while model X3, X5 and X7 can connect to the panel
interface directly.)
3) Model X5 supports MDVR parameter setting via remote controller.
2.1. LOGIN INTERFACE
When operate the device, user needs to have permission certified.
1) Press the remote control 【LOGIN / LOCK】or【SETUP】, the login screen will pop up.
2) Right click the mouse, the shortcut menu will pop up, left click login picture, login screen will pop up.
3) Left click on the login button to login and right click to log out.
X11Alarm
output

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
19 - 78
Login Notice:
1) Software is automatically assigned by user name and password, it can be divided into user and
administrator privileges.
2) Password options cannot be closed, but it can be set to null; when it is empty, user do not need to
enter the password to login。
Login interface Introduction:
User name：
1) Select users from the drop-down box. There are admin and user as defaults.
2) Currently, it can show two users and one admin.
Password：
1) User can enter the operation interface if entering the right password;
2) User must enter the right password again if entering the wrong ones;
3) Click cancel to exit the login interface;
Language：
1) It supports language switch. "language" (Lang) means the current interface adopts Chinese;
2) It will automatically switch once selecting the language.
3) Currently, it supports Chinese and English;
4) After switching languages, it will not restore language option when user restores the factory
Settings;
Default password and permission table is as follows:
Default Password
Related User
Related Authority
admin
admin
All Authorities
User
user
Search and playback
The password input Instruction:
1) User can set password with remote controller (only applicable to model X5), mouse or touch panel
CP4. Move cursor to password, click Enter and enter the right number.

User Manual for X7-E1608
For more information, please visit our website www.en.streamax.com
20 - 78
2) Move the cursor to the number position, press 【Enter 】or left click mouse button to select the
corresponding number.
3) Move the cursor to 【123】, press 【Enter】or mouse to choose input type, such as numbers, letters,
or special characters.
4) 【ab】means lower case letters,【123】means numbers,【AB】means capital letters; the highlighted
place of background refers to the current cursor position.
5) Move Cursor to , Press【Enter】or left click mouse to move between the contents that have
entered.
6) Move Cursor to , Press 【Enter】or left click mouse to delete the previous input contents.
7) Move Cursor to , Press 【Enter】or the left click mouse to exit the keypad, the entered
contents will be written to the edit box.
8) Move Cursor to【Esc】position, Press【Enter】or the left click mouse to exit the keypad, the entered
contents will not be written to the edit box.
