Assembly
Instructions
Canopy Bed
Single
Instructions 31
Fixings Q

Enby Canopy 3ft Single- LONG
Description Required
Part CL - Left Handside Corner Post 2
Part CR - Right Handside Corner Post 2
Part 1- Long Side rail 2
Part CHR - Canopy High Rail 1
Part 4K- Quattro/Enby side top siderail facia 2
Part BS - Pack of 3ft base slats 1
Part 13- 3ft Blue Headboard Facia 2
Part RSA - Right handsideArch 2
Part LSA - Left handside Arch 2
FIXING KIT & INSTRUCTIONS 1
CL CR CL
CR
1
4K
CHR
LSA RSA LSA
RSA

Clean out the Pre-drilled Holes
You have brought a solid pine product. During the drilling
process there may be sawdust still in the holes.
BEFORE you start assembly clear these holes with one of the
bolts. Push the bolt through each hole, this will dislodge any
sawdust or debris that could interfere with fixing the bed.
TOP TIPS - TOP TIPS
Read before you start assembly
NO YES
Locating the Dowel Rods
To keep the bed from rattling all the dowel holes
have been slightly mis-drilled by a couple of mm.
When you push parts together the dowels will
straighten and pull together to ensure a tight fit.
Whenever you locate a dowel on the hole NEVER
push it all the way in, leave it so it is loose and can
be aligned with the second locating hole.
Push them all the way in and they will not line
GLUE SACHET INCLUDED
We have included a sachet of glue.
THIS IS NOT TO BE USED with the dowel rods.
Open the sachet and empty into a plastic container.
Whenever you connect a confirmat bolt (D) or a
connector bolt (B) into a barrel bolt (c) dip the end of the
bolt in the wood glue and screw in as normal. This will act
as a lock tight and prevent the bolt from working loose.
Applying a Finish to the Beds
The bed can be used in a natural form. However if you are
applying a stain or finish we advise that you build the bed first.
When you are happy with your purchase then put a sheet
under the product and apply your stain/paint to the
manufacturers recommendations.
NOTE: we are unable to accept the return, under any
circumstance once a finish has been applied. By painting the
bed you have deemed to accept the quality.
Corner Posts -
Make sure the WHITE Mark is facing
upwards when laid on the floor
Headboard Facias-
These are colour coded
Please position as follows:
RED - At the top
WHITE - In the middle
BLUE - At the bottom
WHITE
BLUERED

How to identify your parts and fixings
All our products have four attachment methods. These are colour coded, at the end of
each part you will find a marker pen marking either RED, WHITE or BLUE (two types)
RED MARKING/FIXINGS
The part will have a red marker pen marking on the end.
Hole / Bolt configuration:
One large dowel hole - Place for large dowel
One small hole - Place for large 90cm confirmation bolt
D
Areas this method is used:
Top front and back guard rails and top headboard facia
WHITE MARKING/FIXINGS
The part will have a white chalk marking on the
end.
Hole / Bolt configuration:
TWO large dowel holes - Place for large dowel
Areas this method is used:
Bottom front and back guard rails and centre
headboard facia
SIDE RAIL MARKING/FIXINGS
The part will have a blue marker pen marking on
the end.
Hole / Bolt configuration:
TWO large dowel holes - Place for large dowel
One small centre hole - Place for large 90mm
connector bolt C
Facing access hole - Place for barrel bolt B
BLUE MARKING/FIXINGS -
The part will have a blue marker pen marking on
the end.
Hole / Bolt configuration:
TWO large dowel holes - Place for large dowel
One small centre hole - Place for large 90mm
connector bolt D

To ALL customers - If you have a missing or damaged bolt you can order these FREE
of CHARGE using the following method,
please note we will require your order number or delivery address
Email: [email protected]
Website: www.strictlyhelpdesk.co.uk
All fixings are sent out via next day Royal Mail Post
Fixings List

Assemble The Headboard
CL CR
13
LSA RSA
White Chalk
Markings
facing upwards
Lets build the headboard
Start by place part CL to your left, CR to your right. You must
ensure the white chalk makings are facing upwards. The locate
the part 13 to the bottom. Using Bolts A and D attach the blue
bottom facia. Now attach the two arches, LSA to your left, RSA
to your right. Again using fixings A and D attach. When you
place the arch on top of each corner post please apply a sachet
of GLUE to bond. Now repeat to make both the ends.
Attach the siderails and top facia
Now with a second person stand each end up and attach the
siderails and part 4K. Using bolts A, B and C attach to each
corner post. Please ensure the white chalk markings are facing
inwards. TIP- Make sure you clean out the access holes in the
siderail incase sawdust is still present.
Attach the top Centre Rail
Now locate and fix the top centre rail CHR using parts A & D

You will have twelve extra wide base slats. Push
the first slat tight with the footboard corner posts,
then using the base slat spacer block evenly
space out the remaining base slats. DO NOT
SCREW IN PLACE YET.
Now push the slats flush to the left hand side rail
and screw in (do not screw the right hand side
yet). Now go to the right hand side and start with
the slat near the centre. Push the side rail in so
the slat is flush, then fix using the screw. This
aligns the side rail. Now fix the remaining base
slats.
Attach base slats
CUSTOMER CARE
We have checked all parts to ensure they are free of damage. However timber is a
natural, living product. Occasionally timber can still be adjusting to humidity, for this
reason a crack or stretch mark may appear after the product has been packaged.
Strictly Beds and Bunks however have a
FREE PARTS REQUEST
Should you need to order a part please go to our FREE help desk
go to www.strictlyhelpdesk.co.uk.
Assistance: [email protected]
All parts are sent FREE of charge using next working day carrier.
IMPORTANT SAFETY NOTICE
This bed is not designed to be a
climbing frame. Please instruct/teach
the user not to hang off or balance from
the top centre rail.
