Strictly Beds & Bunks Double/Kingsize Bed User manual

QUATTRO
FOUR POSTER
Double/Kingsize Bed
Box K
Instructions 25
Assembly
Instructions

13
Packing Note: Box 1 of 2
Quattro Double Four Poster
Description Required
Part Q1 Quattro Corner Post 1
Part Q2 Quattro Corner Post 1
Part Q3 Quattro Corner Post 1
Part Q4 Quattro Corner Post 1
Part 1 - LONG Side Rail 2
Part 16- LONG Centre Rail 1
Part 25- Siderail Support Legs 2
Part 26- Centre Leg 1
Part 9- 4G Shaker headboard Insert 2
Part 13- Blue headboard facia 1
Part 4K- Quattro side top side rail facia (4k) 2
Part 4H- Quattro Top Headboard (4H) 2
Part 12- Long Shaker Inserts 10
FIXING KIT & INSTRUCTIONS 25K 1
(extra Pack of Dowels) Packed By:
Box 2 - Base Slats

We need to build the headboard
You have four corners posts, each marked at the bottom.
Select Q1 (right) & Q2 (left), ensure the white chalk mark is
at the top and facing you. Lay them down as shown and
attach the headboard insert you completed on the previous
step. DO NOT attach the top detail yet.
You need TWO people for this
Attach each side rail as shown. Use Dowel/connector &
barrel bolts to secure. DO NOT TIGHTEN YET
Now we need to build the footboard.
You have four corners posts, each marked at the bottom.
Select Q3 (left) & Q4 (right). Have the white chalk mark at
the top facing you as lay them down as shown. (Remember
you are turning this around later so Q3 will become your
right) Attach part 4A. DO NOT attach the top detail yet.
Attaching the top fineals.
You will have two parts 4H for the top head and foot boards.
Attach these using confirmat bolts.
You will find two part 4K, again attach using connector
Place dowel rods in all the
headboard inserts as described
above. Then push fit them
together with the two headboard
facias. This now completed the
headboard facia.
First we need to create the headboard insert.
Grab parts 4G. The have lines of access holes for the shaker inserts.
Both are universal. Grab the shaker inserts and put in the dowel rods,
then insert into parts 4G.

Now we need to attach the side rails.
The side rails are universal, left or right. Firstly ensure there is no sawdust or
debris in the access holes. Using a bolt push through to clear. Now insert the
dowel rods at all ends, do not push all the way in.
With the help of a second person start from the right side and attach to the head
and footboard to the side rails. Place the barrel bolt within the round access hole
on the side rail. Now dip bolt B into the glue and push through to connect to the
barrel bolt.
This side rail is designed not too move so the fixing is tight.
Now attach the centre rail
You will find two metal brackets, these are fixed to the bottom facia on
the head and foot board. With a tape measure mark the centre of the
headboard facia. Using the small screws attach to the bottom of the facia
board. Then insert the centre rail.
Now attach Siderails, centre leg and centre rail
The centre leg is located under the centre rail, in
the centre. Simply measure to the centre of the
bed and locate under the centre rail. Using two
black screws attach from the side.
It is IMPORTANT that this is positioned correctly
and remains in place while the bed is being used.
This part is manufactured using recycled timber
as the component is out of sight.

We have supplied optional Side rail support legs.
These strengthen the bed further to make the model for
heavy duty use. This leg is optional but is recommended.
Measure a half way point on the side rail. Place the
support leg under the side rail from the outside. Using two
black screws attach from the inside of the side rail. Note
there is no access hole as the screws are self threading
Section 3 - Attach base slats
The centre leg will hover slightly off the
floor, when the bed is in use it will move
down and support the bed. This is to
protect the leg if the bed moves.
If you have ordered a guest bed or drawer option simply do not attach the from side rail support leg.
We Now need to attach the base slats.
You will have twelve extra wide base slats. Push
the first slat tight with the footboard corner posts,
then using the base slat spacer block evenly
space out the remaining base slats. DO NOT
SCREW IN PLACE YET.
Now push the slats flush to the left hand side rail
and screw in (do not screw the right hand side
yet). Now go to the right hand side and start with
the slat near the centre. Push the side rail in so
the slat is flush, then fix using the screw. This
aligns the side rail. Now fix the remaining base
slats.
CUSTOMER CARE
We have checked all parts to ensure they are free of damage. However timber is a
natural, living product. Occasionally timber can still be adjusting to humidity, for this
reason a crack or stretch mark may appear after the product has been packaged.
Strictly Beds and Bunks however have a
FREE PARTS REQUEST
Should you need to order a part please go to our FREE help desk go to
www.strictlyhelpdesk.co.uk.
Assistance: [email protected]
All parts are sent FREE of charge using next working day carrier.
