Structured Cable Products 961 User manual

www.scpcat5e.com
HDMI EXTENDER OVER SINGLE COAXIAL CABLE
PART# 961
OPERATING INSTRUCTIONS

HDMI EXTENDER OVER SINGLE COAXIAL CABLE
PART# 961
23
www.scpcat5e.com
SCP’s 961- HDMI Extender over Single Coaxial Cable has been tested for conformity to safety regulations and
requirements, and has been certied for international use. However, like all electronic equipments, the 961
should be used with care. Please read and follow the safety instructions to protect yourself from possible injury
and to minimize the risk of damage to the unit.
•Followallinstructionsandwarningsmarkedonthisunit.
•Donotattempttoservicethisunityourself,exceptwhereexplainedinthismanual.
•Provideproperventilationandaircirculationanddonotusenearwater.
•Keepobjectsthatmightdamagethedeviceandassurethattheplacementofthisunitis
on a stable surface.
•Useonlythepoweradapterandpowercordsandconnectioncablesdesignedforthisunit.
•Donotuseliquidoraerosolcleanerstocleanthisunit.Alwaysunplugthepowertothedevice
before cleaning
Safety and Notice

HDMI EXTENDER OVER SINGLE COAXIAL CABLE PART# 961
23
www.scpcat5e.com
SCP’s 961- HDMI Extender over Single Coaxial boosts up your HDMI transmission range up to 60m (180ft) in
HDTV1080pformatthroughasinglecoaxialcable.The961iseasytoinstallandworkswithanycoaxialcable.
Thetransmissiondistancedependsuponthequalityandbandwidthoftheparticularcoaxialcableyouwillbe
using with SCP’s 961.
The 961 includes two units: transmitting (961-TX) and receiving (961-RX) units. The transmitting unit is used to
capturetheHDMIandHDCPinputsignalsandcarrythesignalsthroughonlycoaxialcable.Thereceivingunit
is responsible for auto equalizing the transmitted HDMI multimedia data. The transmission range between
thesendingandreceivingunitscanbeupto60m(180ft)underFullHD(1080p)with7.1channelaudio.
•HDMI®HighSpeed
•HDCPcompliant
•Singlecoaxialcable
•7.1-channelaudiosupported
•Extendsthetransmissionrangeupto60m(180ft)fromtheHDMIsources
underFullHDresolution1080p24-bitcolordepth.
•Videoresolutionssupport480i,576i,720p,1080i,and1080p
Introduction
Features

HDMI EXTENDER OVER SINGLE COAXIAL CABLE
PART# 961
45
www.scpcat5e.com
Installation
HDMI
SCP-961
TX
CoaxialCable
HDMI Cable
HDMI
HDMI Display
C
R
L
LS
LB
RS
RB
SCP-961
RX
1. Connect a HDMI source to the transmitting unit 961-TX.
2.ConnectaHDMIdisplayorprojectortothereceivingunit961-RX.
3.Connectacoaxialcablebetweenthetransmittingandreceivingunits.
4.Makesurethiscoaxialcableistightlyconnectedandnotloose.
5.Plugin5VDCpowersupplyunitstothelatch-lockingpowerjackonthebothtransmitting
and receiving units of SCP 961.
CoaxialCable
HDMI Cable
HDMI
Coaxial
HDMI

HDMI EXTENDER OVER SINGLE COAXIAL CABLE PART# 961
45
www.scpcat5e.com
Model Name CV-54G
CV-54S
Technical CV-54G[TX] CV-54G[RX]
CV-
54S[TX]
CV-54S[RX]
Role of usage Transmitter [TX] Receiver [RX]
Transmitter
[TX]
Receiver [RX]
HDMI compliance HDMI 1.3c
HDMI 1.2a
HDCP compliance
Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Single-link 165MHz [4.95Gbps]
Video support
480i / 480p / 720p / 1080i / 1080p60
Audio support
Surround sound (up to 7.1ch) or stereo digital audio
HDMI over Coax
transmission range
Full HD [1080p 24-bit color] Ð 60m [180ft]
HDMI equalization
Auto
Input TMDS signal
1.2 Volts [peak-to-peak]
Input DDC signal
5 Volts [peak-to-peak, TTL]
ESD protection [1] Human body Ñ ±19kV [air-
gap discharge] & ±12kV [contact discharge]
[2] Core chipset Ñ ±4kV
PCB stack-up 4-layer board [impedance control Ñ
differential 100Ω; single 50Ω]
6-layer board [impedance control Ñ differential
100Ω; single 50Ω]
Input 1x HDMI
1x BNC
Output 1x BNC
1x HDMI
IR remote control
N/A
HDMI connector
TypeA[19-pin female]
BNC connector 75Ω
interlocking socket
2.5mm connector 2.5mm earphone jack for IR receiver to
receive IR commands from IR remote
N/A
3.5mm connector 3.5mm earphone jack for IR blaster to
control HDMI source device
N/A
Mechanical CV-54G
CV-54S
Enclosure
Metal enclosure
Model [TX] Ð75x 75 x 30mm [3Ó x 3Ó x 1.2Ó ]
[RX] Ð 55 x 75 x 30mm [2.2Ó x 3Ó x 1.2Ó ]
[TX] Ð75x 75 x 30mm [3Ó x 3Ó x 1.2Ó ]
[RX] Ð 55 x 75 x 30mm [2.2Ó x 3Ó x 1.2Ó ]
Package
175 x 265 x 80mm [6.9Ó x10.4Ó x3.1Ó ]
Dimensions
(Lx W x H) Carton
450 x 370 x 300mm [1Õ6Ó x 1Õ3Ó x 1Õ]
Model [TX] Ð 215g [7.6oz] / [RX] Ð 160g [5.6oz]
[TX] Ð 215g [7.6oz] / [RX] Ð 160g [5.6oz]
Weight Package 950g [2.1 lbs]
1115g [2.5 lbs]
Fixedness
Interlocking power supply
Power supply
5V 4ADC
Power consumption 6
Watts [max]
Operation temperature 0~40¡
C [32~104¡F]
Storage temperature -
20~60¡C [-4~140¡F]
Relative humidity
20~90% RH [no condensation]
Package Contents
1x CV-54G [TX & RX]
2x 5V power supply unit
1x User manual
1x CV-54S [TX & RX]
2x 5V power supply unit
1x User manual
HDMI High Speed
Yes
480i/480p/ 720p/ 1080i/ 1080 p60
Surround Sound ( up to 7.1 channel)
or stereo digital audio
Full HD [1080p 24-bit color] - 60m (180ft)
[1] Human body — ±19kV [air-gap discharge]
& ±12kV [contact discharge]
[2] Core chipset — ±4kV
Auto
1.2 Volts [peak to peak]
5 Volts [peak to peak]
N/A
Type A [19-pin female]
75Ωinterlockingsocket
SCP 961
Metal Enclosure
175x265x80mm[6.9”x10.4”x3.1”]
Interlocking power supply
5V4ADC
6Watts[max]
0~40°C[32~104°F]
-20~60°C[-4~140°F]
20~90%RH[nocondensation]
450x370x300mm[1’6”x1’3”x1’]
MECHANICAL
Specications

HDMI EXTENDER OVER SINGLE COAXIAL CABLE
PART# 961
67
www.scpcat5e.com
Transmitter: 961-TX
2-pin DIP Switch: Please see below table for detail information
HDMI IN: Connect to a HDMI source device with a HDMI male-male cable here
+5V DC: Connecttoa5VDCpowersupplyunit
LED: Green light means video in Full-HD mode. Orange light means video in SD or HD mode.
COAX OUT: connecttotheahighstandardcoaxialcablehere
Input Panel
Output Panel


Panel Descriptions
PinNo. 1 2
OFF()Default EDID (1080p) 7.1ch PCM audio
ON()Default EDID (720p / 1080i) stereo PCM audio
PinNo.
1
2
OFF(

)
Default EDID (1080p)
7.1ch PCM audio
ON()
Default EDID (720p / 1080i)
stereo PCM audio
PinNo.
1
2
OFF(

)
Default EDID (1080p)
7.1ch PCM audio
ON()
Default EDID (720p / 1080i)
stereo PCM audio
DIP Switch
1.Factorydefault:1. Factorydefault:OFF-OFF[]

HDMI EXTENDER OVER SINGLE COAXIAL CABLE PART# 961
67
www.scpcat5e.com
Receiver: 961-RX
Input Panel
Output Panel
COAX IN: Connecttoahighstandardcoaxialcablehere
HDMI OUT: Connect to a HDMI display with a HDMI male-male cable here
+5V DC T: Connecttoa5VDCPowerSupplyUnit
LED: Orange light meas in mormal operation mode



HDMI EXTENDER OVER SINGLE COAXIAL CABLE
PART# 961
89
www.scpcat5e.com

Pin 1 TMDS Data2+ Pin 8 TMDS Data0 Shield Pin 15 SCL
Pin 2 TMDS Data2 Shield Pin 9 TMDS Data0Ð Pin 16 SDA
Pin 3 TMDS Data2Ð Pin 10 TMDS Clock+ Pin 17 DDC/CEC Ground
Pin 4 TMDS Data1+ Pin 11 TMDS Clock Shield Pin 18 +5 V Power
Pin 5 TMDS Data1 Shield Pin 12 TMDS ClockÐ Pin 19 Hot Plug Detect
Pin 6 TMDS Data1Ð Pin 13 CEC
Pin 7 TMDS Data0+ Pin 14 Reserved (N.C. on device)
1. Since SC is sensitive to the HDMI source’s input jitters, the input HDMI signals with larger jitters will
shorten the transmission distance hugely, especially for full HD 1080p!
2.ThelabtestingresultshowsthatBelden1694AcoaxialcablescantransmitHDMIHighSpeed1.3a
signals up to 60m (180ft).
3. If your HDMI display has multiple HDMI inputs, it is found that the rst HDMI input [HDMI input #1]
generally can produce better transmission performance among all HDMI inputs.
HDMI Pin Denition

HDMI EXTENDER OVER SINGLE COAXIAL CABLE PART# 961
89
www.scpcat5e.com
Structured Cable Productswarrantsthe961HDMIExtenderoverSingleCoaxialCabletobefreefromde-
fects in the material and workmanship for 1 year from the date of purchase from Structured Cable Products
or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,
Structured Cable Products, at its option, repair or replace the unit, provided that the unit has not been sub-
jected to accident, disaster, abuse or any unauthorized modications including static discharge and power
surge. This warranty is oered by Structured Cable Products for its buyer with direct transaction only.
Unit that fails under conditions other than those covered will be repaired at the current price of parts and
labor in eect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment to
the buyer. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss or
damage in transit. Under no circumstances will a unit be accepted without a return authorization number.
Thewarrantyisinlieuofallotherwarrantiesexpressedorimplied,includingwithoutlimitations,anyotherim-
pliedwarrantyortnessormerchantabilityforanyparticularpurpose,allofwhichareexpresslydisclaimed.
Proof of sale may be required in order to claim warranty. Cables are limited to a 30 day warranty and cable
must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, Structured
Cable Products assumes no responsibility for any inaccuracies that may be contained in this manual.
Structured Cable Products will NOT be liable for direct, indirect, incidental, special, or consequential
damages resulting from any defect or omission in this manual, even if advised of the possibility of such
damages. Also, the technical information contained herein regarding SCPs’961 features and specications
is subject to change without further notice.
Limited Warranty
Thank you for your purchase.
STRUCTURED CABLE PRODUCTS
6228 Hiatus Road
Tamarac FL 33321 - USA
Tel: [phone] Fax: [phone]
Email: [email protected]om • http://www.scpcat5e.com
