Planet WNAP-1110 User manual

I

Copyright
Copyright 2014 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the
software. Further, this company reserves the right to revise this publication and to make changes from time to
time in the contents hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their
respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution:
To assure continued compliance, (example-use only shielded interface cables when connecting to computer or
peripheral devices) any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two conditions:
(1) This device may not cause harmful interference
(2) This Device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
II

Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to
avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna
shall not be less than 20 cm (8 inches) during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal
Equipment and the mutual recognition of their conformity (R&TTE).
The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal
Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However, special
attention must be paid to the dangers of electric shock and static electricity when working with electrical
equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to
ensure the safe use of the equipment.
National Restrictions
This device is intended for home and office use in all EU countries (and other countries following the EU
directive 1999/5/EC) without any limitation except for the countries mentioned below:
Country Restriction Reason/remark
Bulgaria None General authorization required for outdoor use and
public service
France
Outdoor use limited to 10
mW e.i.r.p. within the band
2454-2483.5 MHz
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
Italy None If used outside of own premises, general authorization is
required
Luxembourg None General authorization required for network and service
supply(not for spectrum)
Norway Implemented This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Russian
Federation
None Only for indoor applications
Note: Please don’t use the product outdoors in France
WEEE regulation
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
III

Revision
User’s Manual for PLANET 0ESV802.11n Wireless Range Extender
Model: WNAP-1110
Rev: 2.0 (February, 2014)
Part No. EM-WNAP-1110v2_v2.0 (2081-E10350-002)
IV

CONTENTS
Chapter 1. Product Introduction.........................................................................................................10
1.1 Package Contents...............................................................................................................10
1.2 Product Description.............................................................................................................10
1.3 Product Features................................................................................................................. 11
1.4 Product Specifications.........................................................................................................12
Chapter 2. Hardware Installation ........................................................................................................14
2.1 Hardware Description..........................................................................................................14
2.1.1 The Front Panel......................................................................................................14
2.1.2 The Rear Panel.......................................................................................................15
Chapter 3. Connecting the AP ............................................................................................................17
3.1 System Requirements.........................................................................................................17
3.2 Installing the AP ..................................................................................................................17
Chapter 4. Quick Installation Guide ...................................................................................................21
4.1 Manual Network Setup - TCP/IP Configuration ..................................................................21
4.1.1 Configuring the IP Address Manually .....................................................................21
4.2 Starting Setup in Web UI.....................................................................................................25
Chapter 5. Configuring the AP............................................................................................................29
5.1 Status ..................................................................................................................................29
5.2 Quick Setup.........................................................................................................................31
5.3 Operation Mode ..................................................................................................................31
5.3.1 Operation Mode – Access Point .............................................................................32
5.3.2 Operation Mode – Multi-SSID.................................................................................34
5.3.3 Operation Mode – Repeater (Range Extender) .....................................................38
5.3.4 Operation Mode – Bridge with AP ..........................................................................44
5.3.5 Operation Mode – Client.........................................................................................49
5.4 WPS ....................................................................................................................................52
5.5 Network ...............................................................................................................................56
5.5.1 LAN.........................................................................................................................56
5.6 Wireless...............................................................................................................................58
5.6.1 Wireless Settings....................................................................................................58
5.6.2 Wireless Security ....................................................................................................60
5.6.3 Wireless MAC Filtering ...........................................................................................65
5.6.4 Wireless Advanced .................................................................................................68
5.6.5 Antenna Alignment..................................................................................................69
V

5.6.6 Throughput Monitor ................................................................................................70
5.6.7 Wireless Statistics...................................................................................................71
5.7 DHCP ..................................................................................................................................72
5.7.1 DHCP Settings........................................................................................................72
5.7.2 DHCP Clients List ...................................................................................................74
5.7.3 Address Reservation ..............................................................................................75
5.8 System Tools.......................................................................................................................77
5.8.1 SNMP......................................................................................................................77
5.8.2 Time Settings..........................................................................................................79
5.8.3 Diagnostic ...............................................................................................................81
5.8.4 Ping Watch Dog......................................................................................................84
5.8.5 Firmware Upgrade..................................................................................................84
5.8.6 Factory Defaults......................................................................................................85
5.8.7 Backup & Restore...................................................................................................86
5.8.8 Reboot ....................................................................................................................87
5.8.9 Password ................................................................................................................87
5.8.10 System Log.............................................................................................................89
5.8.11 Statistics..................................................................................................................92
Chapter 6. Quick Connection to a Wireless Network.......................................................................94
6.1 Windows XP (Wireless Zero Configuration)........................................................................94
6.2 Windows 7 (WLAN AutoConfig) ..........................................................................................96
6.3 Mac OS X 10.x ....................................................................................................................99
6.4 iPhone / iPod Touch / iPad................................................................................................101
Appendix A: Planet Smart Discovery Utility ......................................................................................105
Appendix B: Factory Default Settings................................................................................................106
Appendix C: Troubleshooting .............................................................................................................107
Appendix D: Specifications.................................................................................................................109
Appendix E: Glossary .......................................................................................................................... 110
VI

FIGURE
FIGURE 2-1 WNAP-1110 FRONT PANEL.................................................................................................14
FIGURE 2-2 WNAP-1110 REAR PANEL...................................................................................................15
FIGURE 3-1 ADJUST THE DIRECTION OF THE ANTENNA .............................................................................18
FIGURE 3-2 HARDWARE INSTALLATION OF THE WNAP-1110 WIRELESS AP..............................................19
FIGURE 3-3 HARDWARE INSTALLATION OF THE WNAP-1110 WIRELESS AP..............................................19
FIGURE 4-1 TCP/IP SETTING.................................................................................................................22
FIGURE 4-2 WINDOWS START MENU ......................................................................................................23
FIGURE 4-3 SUCCESSFUL RESULT OF PING COMMAND .............................................................................23
FIGURE 4-4 FAILED RESULT OF PING COMMAND ......................................................................................24
FIGURE 4-5 LOGIN THE AP.....................................................................................................................25
FIGURE 4-6 LOGIN WINDOW ..................................................................................................................25
FIGURE 4-7 WNAP-1110 QUICK SETUP .................................................................................................26
FIGURE 4-8 QUICK SETUP –OPERATION MODE ......................................................................................26
FIGURE 4-9 QUICK SETUP –WIRELESS ..................................................................................................27
FIGURE 4-10 QUICK SETUP –NETWORK ................................................................................................27
FIGURE 4-11 QUICK SETUP –FINISH ......................................................................................................28
FIGURE 4-12 BASIC WIRELESS INTERNET CONNECTION ..........................................................................28
FIGURE 5-1 MAIN MENU ........................................................................................................................29
FIGURE 5-2 STATUS ...............................................................................................................................30
FIGURE 5-3 OPERATION MODE...............................................................................................................31
FIGURE 5-4 WIRELESS –AP MODE ........................................................................................................33
FIGURE 5-5 TOPOLOGY –AP MODE .......................................................................................................33
FIGURE 5-6 OPERATION MODE –MULTI-SSID ........................................................................................34
FIGURE 5-7 TOPOLOGY –MULTI-SSID ...................................................................................................36
FIGURE 5-8 MULTI-SSID –ENABLE VLAN..............................................................................................36
FIGURE 5-9 MULTI-SSID –VLAN TOPOLOGY .........................................................................................38
FIGURE 5-10 OPERATION MODE -REPEATER (RANGE EXTENDER)...........................................................39
FIGURE 5-11 TOPOLOGY –UNIVERSAL REPEATER ..................................................................................39
FIGURE 5-12 REPEATER (RANGE EXTENDER)–UNIVERSAL REPEATER....................................................40
FIGURE 5-13 TOPOLOGY –WDS REPEATER...........................................................................................40
FIGURE 5-14 REPEATER (RANGE EXTENDER)–WDS REPEATER ............................................................41
FIGURE 5-15 REPEATER (RANGE EXTENDER)–SURVEY .........................................................................42
FIGURE 5-16 REPEATER (RANGE EXTENDER)–AP LIST .........................................................................43
FIGURE 5-17 REPEATER (RANGE EXTENDER)–FINISH SETTING..............................................................43
FIGURE 5-18 REPEATER (RANGE EXTENDER)–SECURITY ......................................................................44
FIGURE 5-19 REPEATER (RANGE EXTENDER)–STATUS ..........................................................................44
FIGURE 5-20 OPERATION MODE -BRIDGE WITH AP ................................................................................45
FIGURE 5-21 TOPOLOGY -BRIDGE WITH AP ...........................................................................................46
VII

FIGURE 5-22 BRIDGE WITH AP –SURVEY ...............................................................................................47
FIGURE 5-23 BRIDGE WITH AP –AP LIST ...............................................................................................47
FIGURE 5-24 BRIDGE WITH AP –FINISH SETTING ...................................................................................48
FIGURE 5-25 BRIDGE WITH AP –STATUS ................................................................................................48
FIGURE 5-26 WIRELESS -CLIENT...........................................................................................................49
FIGURE 5-27 TOPOLOGY –CLIENT MODE ...............................................................................................50
FIGURE 5-28 CLIENT –SURVEY .............................................................................................................50
FIGURE 5-29 CLIENT –AP LIST..............................................................................................................51
FIGURE 5-30 CLIENT –FINISH SETTING ..................................................................................................51
FIGURE 5-31 CLIENT –STATUS ..............................................................................................................52
FIGURE 5-32 WPS................................................................................................................................52
FIGURE 5-33 HARDWARE WPS BUTTON.................................................................................................53
FIGURE 5-34 SOFTWARE WPS BUTTON .................................................................................................53
FIGURE 5-35 ADD A NEW DEVICE ............................................................................................................54
FIGURE 5-36 NEW DEVICE CONNECT SUCCESSFULLY...............................................................................55
FIGURE 5-37 THE NETWORK MENU ........................................................................................................56
FIGURE 5-38 LAN SETTINGS .................................................................................................................56
FIGURE 5-39 WIRELESS MENU ...............................................................................................................58
FIGURE 5-40 WIRELESS SETTINGS.........................................................................................................58
FIGURE 5-41 WIRELESS SECURITY ........................................................................................................60
FIGURE 5-42 WIRELESS SECURITY –WEP.............................................................................................61
FIGURE 5-43 WIRELESS SECURITY -WPA/WPA2 ENTERPRISE ...............................................................62
FIGURE 5-44 WIRELESS SECURITY -WPA/WPA2 PERSONAL..................................................................63
FIGURE 5-45 WIRELESS MAC ADDRESS FILTERING ................................................................................65
FIGURE 5-46 ADD OR MODIFY WIRELESS MAC ADDRESS FILTERING ENTRY ............................................66
FIGURE 5-47 WIRELESS MAC ADDRESS FILTERING ................................................................................67
FIGURE 5-48 WIRELESS ADVANCED .......................................................................................................68
FIGURE 5-49 ANTENNA ALIGNMENT........................................................................................................69
FIGURE 5-50 THROUGHPUT MONITOR ....................................................................................................70
FIGURE 5-51 THE AP ATTACHED WIRELESS STATIONS ..............................................................................71
FIGURE 5-52 THE DHCP MENU..............................................................................................................72
FIGURE 5-53 DHCP SETTINGS ..............................................................................................................73
FIGURE 5-54 DHCP CLIENTS LIST .........................................................................................................74
FIGURE 5-55 ADDRESS RESERVATION ....................................................................................................75
FIGURE 5-56 ADD AN ADDRESS RESERVATION ENTRY .............................................................................76
FIGURE 5-57 MODIFY AN ADDRESS RESERVATION ENTRY........................................................................76
FIGURE 5-58 THE SYSTEM TOOLS MENU ................................................................................................77
FIGURE 5-59 THE SYSTEM TOOLS MENU ................................................................................................78
FIGURE 5-60 TIME SETTINGS .................................................................................................................79
FIGURE 5-61 DIAGNOSTIC TOOLS...........................................................................................................81
VIII

IX
FIGURE 5-62 DIAGNOSTIC RESULTS .......................................................................................................83
FIGURE 5-63 PING WATCH DOG.............................................................................................................84
FIGURE 5-64 FIRMWARE UPGRADE ........................................................................................................85
FIGURE 5-65 RESTORE FACTORY DEFAULT.............................................................................................86
FIGURE 5-66 BACKUP &RESTORE CONFIGURATION................................................................................86
FIGURE 5-67 REBOOT THE AP ...............................................................................................................87
FIGURE 5-68 PASSWORD .......................................................................................................................88
FIGURE 5-69 SYSTEM LOG ....................................................................................................................89
FIGURE 5-70 MAIL ACCOUNT SETTINGS..................................................................................................90
FIGURE 5-71 STATISTICS .......................................................................................................................92
FIGURE 6-1 WIRELESS ZERO CONFIGURATION........................................................................................94
FIGURE 6-2 VIEW AVAILABLE WIRELESS NETWORKS ...............................................................................94
FIGURE 6-3 CHOOSE A WIRELESS NETWORK ...........................................................................................95
FIGURE 6-4 ENTER THE ENCRYPTION KEY ...............................................................................................95
FIGURE 6-5 WIRELESS NETWORK CONNECTED.......................................................................................96
FIGURE 6-6 WLAN AUTOCONFIG...........................................................................................................96
FIGURE 6-7 WLAN AUTOCONFIG WINDOW .............................................................................................97
FIGURE 6-8 WLAN AUTOCONFIG –TYPE THE NETWORK SECURITY KEY ...................................................98
FIGURE 6-9 WLAN AUTOCONFIG –CONNECTING....................................................................................98
FIGURE 6-10 WLAN AUTOCONFIG –CONNECTED ..................................................................................99
FIGURE 6-11 THE AIRPORT NETWORK CONNECTION ICON.......................................................................99
FIGURE 6-12 THE AIRPORT NETWORK CONNECTION MENU ...................................................................100
FIGURE 6-13 THE AIRPORT NETWORK CONNECTION –ENTER PASSWORD..............................................100
FIGURE 6-14 THE AIRPORT NETWORK CONNECTION –CONNECTED.......................................................101
FIGURE 6-15 THE WI-FI SETTINGS IN IPHONE/IPOD TOUCH/IPAD...........................................................101
FIGURE 6-16 GENERAL SETTINGS ........................................................................................................102
FIGURE 6-17 GENERAL SETTINGS –NOT CONNECTED ..........................................................................102
FIGURE 6-18 GENERAL SETTINGS –WI-FI ON......................................................................................103
FIGURE 6-19 GENERAL SETTINGS –ENTER PASSWORD.........................................................................104
FIGURE 6-20 GENERAL SETTINGS –WI-FI NETWORK CONNECTED ........................................................104

User’s Manual of WNAP-1110
-10-
Chapter 1. Product Introduction
1.1 Package Contents
The following items should be contained in the package:
WNAP-1110 Wireless Range Extender
Power Adapter
Passive PoE Injector
4dBi Antenna x1
Quick Installation Guide
CD-ROM (User’s Manual included)
If there is any item missing or damaged, please contact the seller immediately.
1.2 Product Description
PLANET 802.11n Wireless Access Point (WNAP-1110) features 802.11n radio with 1T1R MIMO technology. It is
also backward compliant with 802.11b/g standard. Compared with simple Access Point, the WNAP-1110 offers
more powerful, flexible capability for wireless client to access Internet.
The WNAP-1110 provides multiple operation modes including AP (Multi-SSID), Client, Repeater, Universal
Repeater (Range Extender), and WDS Bridge (Point to Point and Point to Multiple Points) that can play different
roles in different situations. To secure the wireless communications, the WNAP-1110 supports 64/128/152-bit
WEP encryption, WiFi Protected Access (WPA/WPA2, WPA-PSK/WPA2-PSK). Furthermore, in order to simplify
the security settings, the WNAP-1110 supports WPS configuration with the PBC/PIN type. Your whole wireless
network can be secured within a few seconds.
Being an Access Point, the WNAP-1110 supports the VLAN function to allow multiple SSIDs (Four sets of SSID
and tagging VID) to access Internal VLAN topology via the VLAN Switch function. Moreover, WMM capability
can provide better service to selected traffic or application, which utilizes the network usage. In the wireless
security aspect, the WNAP-1110 supplies MAC address filtering which prevents possible hackers attack.
The WNAP-1110 provides a total solution for the Small Office and the SOHO users. With the MIMO 11n wireless
technology, it’s easy to combine the wireless devices with the existing wired network.

User’s Manual of WNAP-1110
-11-
1.3 Product Features
Standard Compliant Hardware Interface
150Mbps wireless transmission rate with MIMO technology
IEEE 802.11n, 802.11b/g standard compliant
1 x 10/100Base-TX Port with Passive PoE supported
Secure Network Connection
Advanced security: 64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES
encryption) and 802.1X Radius Authentication
Easy setup secure wireless connection by one-touch WPS (Wi-Fi Protected Setup) button
Supports MAC address filtering
Supports multiple SSIDs to allow users to access different networks through a single AP
Wireless Network Range Extender
Multiple wireless modes: AP, WDS, Repeater, Universal Repeater, Client
Supports WMM (Wi-Fi Multimedia), wireless QoS
Supports wireless roaming
Easy Installation & Management
Flexible deployment with passive PoE/PD supported
Web-based UI and Quick Setup Wizard for easy configuration
SNMP-based management interface

User’s Manual of WNAP-1110
-12-
1.4 Product Specifications
Product WNAP-1110
150Mbps 802.11n Wireless Range Extender
Hardware Specifications
Interface PoE LAN Port: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
※Passive PoE/PD Port
PoE Passive PoE (Up to 30 meters)
Antenna Detachable 4dBi antenna x1
WPS Button Press the WPS button on the front panel of the device.
Button Reset Button Press for about 5 seconds to reset the device to factory default.
LED Indicators PWR/SYS/LAN/WLAN/WPS LED
Material Plastic
Dimensions (W x D x H) 174 x 110 x 23 mm
Weight 250g
Power Requirements 9V DC, 0.85A or Passive PoE
Power Consumption 2W (max.)
Wireless interface Specifications
Standard Compliance with IEEE 802.11b/g/n
Frequency Band 2.4~2.4835GHz
Extended Frequency DSSS
Modulation Type DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/ QPSK/ 16-QAM/ 64-QAM)
Data Transmission Rates
IEEE 802.11n: up to 150Mbps(Dynamic)
IEEE 802.11g: 54/48/36/24/18/12/9/6Mbps (Dynamic)
IEEE 802.11b: 11/5.5/2/1Mbps (Dynamic)
Frequency Band
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
Channel Width 20 or 40MHz
Transmission Distance Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
Max. RF Power
(Intentional Radiator)
IEEE 802.11b: 18dBm
IEEE 802.11g: 15dBm
IEEE 802.11n: 15dBm
Receive Sensitivity
130M: -70dBm@10% PER
108M: -72dBm@10% PER
54M: -74dBm@10% PER
11M: -86dBm@8% PER
6M: -91dBm@10% PER
1M: -91dBm@8% PER
Wireless Management Features
Wireless Modes AP (Multi-SSID)

User’s Manual of WNAP-1110
-13-
WDS
Repeater (WDS+AP)
Universal Repeater (AP+Client)
Client
Encryption Security
WEP (64/128/152-bit)
WPA-PSK (TKIP) / WPA2-PSK (AES)
WPA (TKIP) / WPA2 (AES)
802.1x Authentication
Enable/Disable SSID Broadcast
Wireless Security Wireless LAN ACL (Access Control List) MAC filtering
AP Isolation: Enable it to isolate each connected wireless client to let them cannot access
mutually.
Wireless Advanced
Supports 802.11e WMM (Wi-Fi Multimedia)
Max. Supported Clients Wired: 32
Wireless: 20
Web-based (HTTP) management interface
Supports SNMP v1/v2
Supports Planet Smart Discovery
Supports Scheduling Reboot
System Management
System Log

User’s Manual of WNAP-1110
-14-
Chapter 2. Hardware Installation
Please follow the instructions below to build the wireless network connection between WNAP-1110 and your computers.
2.1 Hardware Description
2.1.1 The Front Panel
The front panel provides a simple interface monitoring the AP. Figure 2-1 shows the front panel of WNAP-1110.
Front Panel
Figure 2-1 WNAP-1110 Front Panel
LED definition
Object Color State Description
On Device power on
PWR Green
Off Device power off
On Device is initialising
Flash The device is working properly
SYSTEM Green
Off The device has a system error
On There is a device linked to the corresponding port but no activity
Flash Packets are transmitting or receiving
LAN Green
Off LAN port is not connected
Wireless LED
WPS LED
WPS ButtonPower LED
System LED
LAN LED
WPS
WNAP-1110
LAN WLANSYSPWR WPS WPS

User’s Manual of WNAP-1110
-15-
Flash The Wireless function is enabled
WLAN Green
Off The Wireless function is disabled
On A wireless device has been successfully added to the network by
WPS function.
Slow Flash A wireless device is connecting to the network by WPS function.
This process will last in the first 2 minutes.
WPS Green
Quick Flash A wireless device failed to be added to the network by WPS
function.
2.1.2 The Rear Panel
The rear panel of the WNAP-1110 consists of buttons, connection port, and power connector. Figure 2-2 shows
the hardware interface of WNAP-1110.
Rear Panel
Figure 2-2 WNAP-1110 Rear Panel
Button definition
Object Description
WPS Press the button for less than 3 seconds for WPS configuration.
Power ON/OFF Press the button to power on the device.
Reset Press and hold the button for about 5 seconds to the factory default setting.
4dBi Antenna
10/100Mbps LAN Port
Reset Button
(Press and hold the Reset button for
about 5 seconds for factory default)
Power ON/OFF Button
Power Connector
9V DC Input
POWER ON/OFF LAN
Reset

User’s Manual of WNAP-1110
-16-
H/W Interface definition
Object Description
Antenna Detachable 4dBi Antenna with RP-SMA (male) connector.
LAN (Passive PoE) 10/100Mbps RJ-45 port, Auto MDI/ MDI-X & Passive PoE supported
Connect LAN port to the PoE injector to power on the device.
LAN 10/100Mbps RJ-45 port, Auto MDI/ MDI-X
Connect this port to the LAN port of the Router or Ethernet Switch.
Power Connector Connect this port to the 9V DC power adapter to power on the device.
The WNAP-1110 supports only 9VDC power adapter or passive POE injector (RJ45 pin
4, 5: +; pin 7, 8: -). It cannot work with IEEE 802.3af PSE for its power source.
At the same time, either 9V DC adapter from the DC-jack or passive PoE injector from
the UTP LAN port can be connected to the device at one time. Use of two power sources
will damage the device permanently.
!

User’s Manual of WNAP-1110
-17-
Chapter 3. Connecting the AP
3.1 System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet connection)
One DSL/Cable Modem that has an RJ-45 connector (not necessary if the AP is connected directly to
the Ethernet.)
PCs with a working Ethernet adapter and an Ethernet cable with RJ-45 connectors
Subscribers can utilize Windows 98/ME, NT4.0, 2000/XP, Windows Vista / Win 7, MAC OS 9 or later,
Linux, UNIX or other platforms compatible with TCP/IP protocols
The above PC is installed with a Web browser
It is recommended to use Internet Explore 7.0 or above to access the AP.
3.2 Installing the AP
Before installing the AP, make sure your PC is connected to the Internet through the broadband service
successfully at this moment. If there is any problem, please contact your local ISP. After that, please install the
AP according to the following steps. Don't forget to pull out the power plug and keep your hands dry.
Step 1. Power off your PC, Cable/DSL Modem, and the AP.
Step 2. Locate an optimum location for the AP. The best place is usually at the center of your wireless
network.
Step 3. Adjust the direction of the antenna. Normally, upright is a good direction.

User’s Manual of WNAP-1110
-18-
Figure 3-1 Adjust the direction of the antenna
Step 4. Connect the Power Source to the WNAP-1110. Only choose one of the following methods for the
suitability of AP’s location; otherwise, it will cause damage to the WNAP-1110.
Method A -- Hard to find the power socket
(1) Connect the Ethernet cable to the LAN port of the PC, and plug the other end of the Ethernet cable into the
LAN port of the PoE injector.
(2) Use another Ethernet cable (8-wire patch cable) to connect the LAN port of the WNAP-1110 and the PoE
port of the PoE Injector.
※The 8-wire patch cable should not exceed 30 meters in length.
(3) Connect the power adapter to the DC port of the PoE injector, and plug the other end of the power adapter
into an electrical outlet.
Method B -- Power Socket nearby
(1) Connect the Ethernet cable to the LAN port of the PC, and plug the other end of the Ethernet cable into the
LAN port of the WNAP-1110.
(2) Connect the power adapter into the POWER port of the WNAP-1110 in the rear panel, and plug the other
end of the power adapter into an electrical outlet.

User’s Manual of WNAP-1110
-19-
Method A – Hard to find the power socket
Figure 3-2 Hardware Installation of the WNAP-1110 Wireless AP
Check connection before powering on. Wrong connection may cause device
malfunction, say, your PC or other Ethernet device.
Method B – Power Socket nearby
Figure 3-3 Hardware Installation of the WNAP-1110 Wireless AP
PC
PoE Injector
POWER PoE LAN
POWER ON/OFF LAN
Reset
POWER PoE LAN
Power
3
1
2
PC
POWER ON/OFF LAN
Reset
Power
1
2

User’s Manual of WNAP-1110
-20-
Then power on the AP.
Step 6. Power on your PC and Cable/DSL Modem.
Step 5. Connect the power adapter to the power socket on the AP, and the other end into an electrical outlet.
