Stryker SYNK User manual

SYNK Wireless System
Transmitter: 0240-031-010
Display: 0240-031-000

Table of Contents
Warnings and Cautions ............................................................................................3
Warnings ��������������������������������������������������������������������������������������������������������������������������������3
Cautions����������������������������������������������������������������������������������������������������������������������������������4
About Your Device.....................................................................................................6
Intended Use and Indications for Use �������������������������������������������������������������������������7
Contraindications����������������������������������������������������������������������������������������������������������������7
System Features.........................................................................................................8
SYNK Wireless Transmitter Front Panel������������������������������������������������������������������������8
SYNK Wireless Transmitter Rear Panel �������������������������������������������������������������������������9
Setup and Interconnection ������������������������������������������������������������������������������������������ 10
Permanently Linking the Transmitter to an Auxiliary Display�������������������������� 15
Removing the the Permanent Link����������������������������������������������������������������������������15
Troubleshooting ..................................................................................................... 16
Cleaning and Maintenance................................................................................... 18
Cleaning the Display and Transmitter ����������������������������������������������������������������������18
Maintenance����������������������������������������������������������������������������������������������������������������������19
Technical Specications ........................................................................................ 20
Electromagnetic Compatibility............................................................................ 22
Symbol Denitions................................................................................................. 26

3
Warnings and Cautions
Please read this manual and follow its instructions carefully� The words warning, caution,
and note carry special meanings and should be carefully reviewed:
• Warning: Indicates measures to avoid potential serious injury to the user and the
patient and/or damage to this device�
• Caution: Indicates risks to the equipment� Failure to follow cautions may result in
product damage�
• Note: Provides special information to clarify instructions or present additional useful
information�
• An exclamation mark within a triangle is intended to alert the user to the
presence of important operating andmaintenance instructions in the manual�
• A lightning bolt within a triangle is intended to warn of the presence of
hazardous voltage� Refer all service to authorized personnel�
For all warnings and cautions related to the VisionPro SYNK 26" Wireless LED Display, refer to the
display user manual, P22286�
Warnings
To avoid potential serious injury to the user and the patient and/or damage to the system, please
note the following warnings:
• Read the operating manual thoroughly and be familiar with its contents prior to using the
system�
• Carefully unpack the system and check if any damage occurred during shipment�
• Test this system prior to a surgical procedure� This system was fully tested at the factory
before shipment�
• Do not place any heavy object on the power cord� Damage to the power cord can cause re
or electric shock�
• This system is not suitable for use in the presence of a ammable anesthetic mixture with air,
or with oxygen or nitrous oxide�
• Do not put any liquid or solid object into the display panel, or the transmitter console� If this
occurs, unplug the device and have it checked by qualied personnel before operating it any
further�
• Disconnect the transmitter from the electrical outlet when inspecting the fuses�
• To avoid electric shock, do not open the display and transmitter housing�
• Do not touch the device and a patient simultaneously, as there is a risk of electric shock�
• Install this system in an operating room that complies with all applicable IEC, CEC, and
NEC requirements for safety of electrical devices� Any installation or connection with other
devices shall be evaluated for electrical safety according to the IEC 60601-1�
• Do not modify this equipment without authorization of the manufacturer�
• Attempt no internal repairs or adjustments not specically detailed in this operating manual�
Refer any adjustments, modications, and/or repairs to Stryker Endoscopy or its authorized
representatives�
• Use appropriate caution to prevent contact with uids if the display or transmitter is being
used with a power supply in patient environments�

4
• Federal law (United States of America) restricts this device to sale by, or on the order of, a
physician�
• To avoid risk of electric shock, use only the hospital-grade power cord furnished with the
display and/or transmitter� Disconnect the display and/or transmitter from the power supply
to make connections or to inspect the equipment�
• To avoid the risk of electric shock, this equipment must only be connected to a supply mains
with protective earth�
Cautions
• Plug the AC adapter into a grounded power outlet�
• Connect the devices to a hospital grade receptacle to achieve grounding reliability�
• To connect to an international power supply, use an attachment plug appropriate for the
power outlet�
• Do not position the devices so that it is dicult to disconnect the power cords from the
supply mains�
• Power o the devices when they are not in use�
• Remove the power cord when transporting the transmitter�
• Unplug the display and transmitter if they are not to be used for an extended period of time�
• Never operate the devices immediately after transportation from a cold location to a warm
location�
• Pay close attention to the care and cleaning instructions in this manual� A deviation may
cause damage�
• Do not install the devices near sunlight, excessive dust, mechanical vibration, or shock�
• Keep the devices away from equipment that uses strong magnets (i�e�, large loudspeakers)�
• Do not touch the patient with signal input or output connectors� Equipment with SIP/SOP
connectors should either comply with IEC60601-1 harmonized national standard or the
combination should be evaluated for safety�
• Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the devices�
Note: This device has been tested and found to comply with the limit for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
device generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a particular
installation, which can be determined by turning the device o and on.

5
The user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving unit.
• Increase the separation distance between the units.
• Connect the unit to an outlet on a circuit dierent from that to which the other unit(s)
are connected.
• Consult the manufacturer or eld service technician for help.
• To ensure electromagnetic compatibility, refer to the“Electromagnetic Compatibility” section
of this manual� The VisionPro SYNK 26”Wireless LED Display (REF 0240-031-000) and the
SYNK Wireless Transmitter (0240-031-010) must be installed and operated according to the
EMC information provided in this manual�
The warranty is void if any of these warnings or cautions are disregarded�
These products contains electrical waste or electronic equipment� They must not be disposed of
as unsorted municipal waste and must be collected separately�

6
About Your Device
The SYNK Wireless System consists of:
VisionPro SYNK 26”Wireless LED Display
REF: 0240-031-000
The VisionPro SYNK 26”LED Display is a wide screen LED surgical display that can support a
maximum resolution of WUXGA (1920x1200)� The display supports the following video inputs:
DVI, S-Video, and C-Video/SOG� Once the wireless functionality is enabled, the display supports a
wireless digital RGB video input� The display also supports a USB port and serial communication via
the RS232 port�
Note: For details and instructions on using the VisionPro SYNK 26" Wireless LED Display, refer
to the VisionPro User Manual (P22286). This manual provides instructions for using the display
and the transmitter together.
SYNK Wireless Transmitter
REF: 0240-031-010
The SYNK Wireless Transmitter allows the VisionPro SYNK 26”Wireless LED Display to receive a
high-denition video signal over a radio-frequency link� The transmitter also controls the viewing
mode, so the user can switch between picture-in-picture, picture-by-picture, and full screen
mode�

7
Intended Use and Indications for Use
The SYNK Wireless System is intended for video display during surgical procedures including
arthroscopy (orthopedic surgery), laparoscopy (general and gynecological surgery),
thoracoscopy, endoscopy (general, gastroenterological, and ENT surgery) and general surgery�
The system is a non-sterile reusable device not intended for use in the sterile eld� The system
is intended for use by qualied physicians having complete knowledge of these surgical
procedures�
Contraindications
There are no contraindications for these products�

8
System Features
This section outlines the features of the SYNK Wireless Transmitter� The features of the VisionPro
SYNK 26" Wireless LED Display are explained in the VisionPro User Manual (P22286)�
Note: The SYNK Wireless Transmitter can only transmit a wireless signal to the VisionPro SYNK
Wireless LED Display (0240-031-000). The wireless functionality of the transmitter is not
compatible with the Vision Pro 26" LED Display, or WiSE Display and Receiver.
SYNK Wireless Transmitter Front Panel
1 2 3 4 5 6
87
1. Full Screen mode
button
Shows one video feed on the display�
2. Picture-in-picture mode
button
Shows a second video feed in the corner of the display in a
smaller overlay�
3. Picture-by-picture
mode button
Shows two video feeds side-by-side�
4. Source Select button Toggles the video feeds shown in full screen, picture-by-
picture or picture-in-picture mode�
5. Token Slot Token insertion site used to establish a wireless connection�
6. Token LED Green - Wireless link is established
Amber - Initializing
Blinking Amber - Error, contact service representative
7. Token Initializes the wireless connection after insertion into the
transmitter and display�
8. Power switch (hard) Powers transmitter ON and OFF�

9
SYNK Wireless Transmitter Rear Panel
Warning
• Only a Stryker representative can remove the video card from the expansion card
slot�
• Never touch the device and a patient simultaneously, as there is a risk of electric
shock�
BLANK
6 7 8
2 3 91 45
1. Expansion Card Slot The card slot can accomodate the following video
cards:
• DVI-I
• Composite
Contact your Stryker representative for more
information�
2. Digital Input Connects to a digital input source�
3. Digital Output Connects to primary display�
4. Audio Connectors Line-in and Mic-in connectors�
5. Remotes Connectors Remote 1 and 2 connectors�
6. RS232 Port Maintenance port�
7. AC Power Inlet Connects to separable power cord that can be used for
mains isolation�
8. Fuse Panel Contains two 1�6A/250V (slow blow, high breaking
capacity 1500A) fuses�
9. Equipotential Ground Plug For connection to an external protective earthing
system as described in the IEC 60601-1 Electrical Safety
standard�

10
Setup and Interconnection
Connecting AC power
Warning
Always use an approved hospital-grade power cord�
BLANK

11
Setting up the SYNK Wireless Transmitter
Warning
• When the transmitter is used with other equipment, leakage currents may be
additive� Ensure that all systems are installed according to the requirements of
IEC60601-1�
• Always set up the transmitter in a location that allows adequate ventilation�
Insucient ventilation may cause the transmitter to overheat and shut down�
1� Connect the DVI OUT 1 on the camera control unit to the DVI 1 IN on the SDC�
2� Connect the DVI 1 OUT on the SDC to the DIGITAL INPUT on the transmitter�
3� Connect the DIGITAL OUTPUT on the transmitter to the DVI on the primary display�
4� Connect the C-video input on the display to the C-video output on the printer�
5� Connect the C-video input on the printer to the C-video output on the camera�
6� Link an auxiliary display to the transmitter with the token� (Link the display and transmitter
each time the display or transmitter is powered on�)

12
IN OUT
4
1
25
3
6
Camera Control Unit
SDC
Transmitter
Auxiliary Display
Primary Display
Printer

13
Conguring the Wireless Settings for the SYNK Wireless Transmitter
The SYNK Wireless System uses a radio-frequency (RF) link to deliver high-denition video signals
in real time� Each system uses a portion of the RF spectrum commonly referred to as a“channel”
to broadcast its signal� Channels are commonly designated using the formula:
Channel Number = (Frequency in MHz – 5000) / 5�
The SYNK Wireless System can use any available 20 MHz channel in the 5�15-5�825 GHz spectrum�
The list of allowed channels is regulated and varies by region�
The 5�15-5�825 GHz spectrum is also used by 802�11a/n devices as well as 5�8 GHz cordless
phones� The SYNK Wireless System uses an automatic frequency selection (AFS) mechanism in
combination with a passive scanning capability to maintain compatibility with these devices�
Using AFS and passive scanning, the system will identify an unoccupied 20 MHz channel for use�
Each linked SYNK Wireless System requires one 20 MHz channel� Systems that are separated by a
large distance may use the same channel�
Note: The SYNK wireless system uses a proprietary transmission method, which cannot
connect to or be accessed by 802.11 devices
In order to make sure that there are enough free channels for each SYNK System, follow the steps
outlined below:
1� Contact your IT administrator to determine if 802�11a or 802�11n WiFi is in use at your facility�
If so, note which channels are in use in or near each SYNK System installation location�
2� Determine if any 5�8 GHz cordless phones are in use at your facility� If so, note their locations�
3� For each SYNK System installation location, ensure that there are two unused channels per
SYNK Transmitter installed� If a 5�8 GHz cordless phone is used in the vicinity, assume that
channels 149-165 are occupied�
Contact your Stryker sales representative for more details�

14
Linking the SYNK Wireless Transmitter to an Auxiliary Display
The SYNK Wireless Transmitter connects to the VisionPro SYNK 26”Wireless LED Display over a
radio-frequency link�
Cautions
• Equipment that employs RF communications may aect the normal function
of the transmitter� When choosing a location for the transmitter, consult the
“Electromagnetic Compatibility” section of this manual to ensure proper function�
• In accordance with patient privacy laws, do not transmit personal patient
information, such as EKG, EEG, patient name, or patient ID, over the wireless signal�
To link the display to the transmitter and thereby enable wireless communication, use the blue
SYNK Wireless Transmitter token�
1� Power on the transmitter and auxiliary display� The token LED shines amber as the devices
perform startup functions�
2� When the LED turns o, insert the blue token into the token slot on the transmitter� The
token LED shines amber as it writes the data�
Stryker Endoscopy
5900 Optical Court
San Jose, CA95138 USA
[phone]
Madein
USA
0240031010
0.63A/250V
RS232
AUDIO REMOTES
1
2
DIGITALINPUT
DIGITALOUTPUT
Place Serial Label
Here
EXPANSIONCARD
100-240~, 50-60 Hz, 630 mA
FCC ID: SSH-SYNKTX
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1)This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Stryker European Rep. - RA/QA Manager
ZAC Satolas Green Pusignan
Av.De Satolas Green
69881 MEYZIEU Cedex, France
BLANK
3� When the token LED is green, remove the token from the transmitter�
4� Within 2 minutes, insert the token into the token slot on the auxiliary display�
• The token LED on the display shines green�
• An audible tone sounds from the transmitter�
• The video feed appears on the auxillary display�

15
5� Remove the token from the token slot on the auxiliary display�
6� By repeating steps 4 and 5, you can link as many as two additional auxiliary displays�
Complete all linking within two minutes�
7� Store the token in the transmitter token slot when not in use�
Permanently Linking the Transmitter to an Auxiliary Display
A permanent link may be desirable in certain cases� Please contact your Stryker representative
in order to permanently link the display(s) with a specic transmitter, as deemed appropriate�
Once the display/transmitter set has been permanently linked, the set will automatically link
when powered on� Keep display/transmitter sets that are in permanent link mode in the same
operating room�
Removing the the Permanent Link
To return the display(s) and transmitter to default linking mode please follow the instructions
below using the token�
1� Power on the display(s) and transmitter�
2� Insert the token into the transmitter and remove when the token LED turns green�
3� Power cycle the transmitter�
4� Insert the token into each display, one at a time, and remove the token when the token LED
turns green�
5� Power cycle each display after removing the token�
Now the system can be linked as described in the default linking mode procedure�

16
Troubleshooting
Before returning your display or transmitter for service, consult the troubleshooting list below:
Problem Current Status Remedy
No picture Power LED on Using the OSD, adjust the brightness and
contrast to maximum, or reset them to their
default settings�
Make sure the video cable is connected to
the transmitter digital input or expansion
slot input�
Power LED o Make sure that the power switch at the front
and back of the display are set to ON�
Make sure that the AC power cord is
properly connected to the AC adapter and
outlet�
Make sure the power adapter is properly
connected to the display�
Power LED blinking Check if the video signal cable isproperly
connected at the back ofthe display�
Check if power is set to ON for the video
signal source�
Make sure the correct input is selected on
the display and the transmitter�
Token LED blinking amber Please contact Stryer representative�
Abnormal picture Oversized, undersized,
ormissing display; or
center shift�
Using the Screen Menu, adjust the Phase,
Frequency, Horizontal, and Vertical settings
with non-standard video signal timing�
Wait a few seconds after initial sync of video
signals, or power cycle the display�
OSD error message “Video format
notsupported”
Ensure that an acceptable video source is
connected� Refer to technical specications
for a list ofacceptable video formats�
Wireless link not
established within 2
minutes (with SYNK
Wireless Transmitter)�
“Wireless RGB
NoSignal”
Cycle the hard power switch at the rear of
the display� Cycle the hard power switch at
the front of the transmitter� Re-establish link�
Wireless link
established with some
but not all displays
(with SYNK Wireless
Transmitter)�
“Wireless RGB
NoSignal”
Cycle the hard power switch on the aected
display only� Re-insert token into display�

17
Problem Current Status Remedy
Wireless error
symbol appears on
the display�
Conditions are not
sucient for optimal
wireless performance�
Switch to a wired video input on the display,
or contact your Stryker representative�

18
Cleaning and Maintenance
Warning
To avoid electric shock and potentially fatal injury, unplug the transmitter from the
electrical outlet before cleaning�
Caution
• Do not spray cleaning liquid directly onto the devices as product damage may result�
Spray cleaning liquid on the cloth before wiping the devices�
• Do not immerse the devices in any liquid as product damage will result�
• Do not use corrosive cleaning solutions to clean the devices as product damage may
result�
• Do not sterilize the devices as product damage may result�
Cleaning the Display and Transmitter
Display
Note: For complete display cleaning instructions, refer to the VisionPro 26" LED Display
manual, P22286.
Transmitter
1� Apply a standard disinfectant or mild detergent to a dry, sterile cloth� Do not saturate the
cloth�
2� Wipe the device� Do not allow liquid to drip from the cloth or collect on the device�
