STSLITE Q PAR 708 wash User manual

Q PAR 708 wash
User Manual
Ver1.0

1
Table of contents
INTRODUCTION ……………………………………………….…………………………..2
SAFETY INSTRUCTIONS…………………………………………………………………2
OPERATING DETERMINATIONS…………………………………………….…………..3
DESCRIPTION OF THE DEVICE…………………………………………………………4
INSTALLATION………………………………………………………………….…………..5
OPERATION……………………………………………………………………….………...6
Stand alone operation…………………………………………………………….…………6
Master slave operation…………………………………………………………….……..…6
DMX controlled operation………………………………………………………….…….…6
Addressing…………………………………………………………………………….…..…6
Control board………………………………………………………………………….…..…6
DMX protocol………………………………………………………………………….…..…7
TECHNICAL SPECIFICATIONS…………………………………………………….……7

2
Every person involved with installation. operation and maintenance of this fixture has to
- be qualified
- follow the instruction of this manual
- consider this manual to be part of the total product
- Keep this manual for the entire service life of the product
- pass this manual to every future owner or use of the product
INTRODUCTION
Thank you for choosing our fixture, if you follow up the instruction given in this manual we be sure that
you will enjoy this product for a long period of time
SAFETY INSTRUCTION
This device has left our premises in absolutely perfect condition .In order to maintain this condition and
to ensure a safe operation, it is absolutely necessary for the user to follow the safety instruction and
warning notes written in this user manual.
Important: Damages caused by the disregard of this user manual are not subject o warranty, the dealer
will not accept liability for any resulting defects of problem. If the device had been exposed to drastic
temperature fluctuation (e.g. after transportation),do not switch it on immediately. The arising
condensation water might damage your device. Leave the device switched off until it had reached room
temperature. Please make sure that there are no obvious transport damages, should you notice any
damages on the AC connection cable or on the casing, do not take the device into operation and
immediately consult your local dealer.
The device falls under protection-class. The power plug must only be plugged into a protection class I
CAUTION!
Be careful with your operations, With a dangerous voltage you can suffer a dangerous electric
shock when touching the wires.
CAUTION !
Keep this device away from rain and moisture
Unplug mains lead before opening the housing
For your own safety, please read this user manual carefully before you initially start-up

3
outlet. The voltage and frequency must exactly be the same as stated on the device. Wrong voltages or
power outlets can lead to the destruction of the device and mortal electrical shock.Always plug in the
power plug last. The power plug must always be inserted without force .Make sure that the plug is tightly
connected with the outlet.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution! Never touch them with wet hands .as this could lead
to mortal electrical shock. Never modify, bend, strain mechanically, put pressure on, pull or heat up the
power cord. Never operate next to sources of heat or cold. Disregard can lead to power cord damages,
fire or mortal electrical shock.The cable insert or the female part in the device must never be strained.
There must always be sufficient cable to the device. Otherwise, the cable may be damaged which may
lead to mortal electrical shock. Make sure that the power-cord is never crimped or damaged by sharp
edges. Check the device and the power-cord from time to time.If extension cords are used, make sure
that the core diameter is sufficient for the required power consumption of the device. All warnings
concerning the power cords are also valid for possible extension cords.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the
power-cord by the plug. Never pull out the plug by tugging the power-cord. Otherwise, the cable or plug
can be damaged leading to mortal electrical shock. If the power plug or the power switch is not
accessible, the device must be the disconnected via the mains. If the power plug or the device is dusty,
the device must be take out of operation, disconnected and then be cleaned with a dry cloth, Dust can
reduce the insulation which may lead to mortal electrical shock. More severe dirt in and at the device
should only be removed by a specialist.
There must never enter any liquid into power outlets, extension cords or any holes in the housing of the
device. If you suppose that also a minimal amount of liquid may have exerted the device it must
immediately be disconnected. This is also valid, if the device was exposed to high humidity. Also if the
device is still running, the device must be checking by a specialist if the liquid has reduced any
insulation. Reduced insulation can cause mortal electrical shock. There must never be any objects
entering into the device. This is especially valid for metal parts. If any metal parts like staples or coarse
metal chips enter into the device, the device must be taken out of operation and disconnected
immediately. Malfunction or short-circuits caused by metal parts my cause mortal injuries. Never look
directly into the light source, as sensitive persons may suffer an epileptic shock (especially meant for
epileptics)Keep away children and amateurs. Never leave this device running unattended.
OPERATING DETERMINATIONS
This device is designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects. Do not shake the device. Avoid brute force when
installing or operation the device. Never lift the fixture by holding it at the projector-head. As the
mechanics may be damaged.When choosing the installation-spot, please make sure that the device is
not exposed to extreme heat, moisture or dust. There should not be any cable lying around. Please
make sure that the fixture can not be touched or bumped. Your endanger your own and the safety of
others.
This device must never be operated or stockpiled in surroundings’ where splash water, rain, moisture or

4
fog may harm the device. Moisture or very high humidity can reduce the insulation and lead to mortal
electrical shocks. When using smoking machines, make sure that the device is never exposed to the
direct smoke jet and is installed in a distance of 0.5 meters between smoke machine and device. The
room must only be saturated with an amount of smoke that the visibility will always be more then 10
meters.
The ambient temperature must always be between -50C and + 450C. keep away from direct
insulation(particularly in cars)and heaters .The relative humidity must not exceed 50% with an ambient
temperature of 450C. This device must only be operated in an altitude between -20 and 2000m over NN.
Never use the device during thunderstorms. Over voltage could destroy the device. Always disconnect
the device during thunderstorms.The Symbol determines the minimum distance from lighted objects.
The minimum distance between light output and the illuminated surface must be more then this value.
The device must only be installed on a non-flammable surface, In order to safeguard sufficient
ventilation, leave 50 cm of free space around the device.
The housing must never touch surrounding surfaces or objects. Make sure that the area below the
installation place is blocked when rigging, dragging or servicing the fixture. For overhead use (mounting
height>100cm), always fix the fixture with an appropriate safety-rope. Fix the safety-rope at the correct
fixation points only. The safety-rope must never be fixed at the transport handles. Only operate the
fixture after having check that the housing is firmly closed and all screw are tightly fastened.
The maximum ambient temperature Ta=450C must never be exceeded. Operate the device only after
having become familiarized with its functions. Do not permit operation by persons not qualified for
operating the device. Most damages are the result of unprofessional operation. Please use the original
packaging if the device is to be transported. Please consider that unauthorized modifications on the
device are forbidden due to safety reasons! Never remove the serial barcode from the device as this
would make the guarantee void. If this device will be operated in any way different to the one described
in this manual, the product may suffer damages and the guarantee becomes void. Furthermore, any
other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
DESCRIPTION OF THE DEVICE
Features
> 7X8w Quad LED with RGBW colors
>Compact lightweight
>6 or 4 DMX channels in optional
>Strobe effect with 1-10 flashes per second
> Programmable color-change speed and strobe effect
>DMX-controlled operation or stand-alone operation with Master/Slave function
> Sound-controlled via built-in microphone
> Addressing via control panel with 4 digit led display
>Remote controller in optional can easy control fixture with basic function and effect
INSTALLATION
Rigging

5
The installation of the projector has to be built and constructed in a way that it can hold 10 times the
weight for 1 hour without any harming deformation.
IMPORTANT!OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including calculating
working load limits, installation material being used, and periodic safety inspection of all installation
material and the projector. If you lack these qualifications, do not attempt the installation yourself, but
instead use a professional structural rigger. Improper installation can result in bodily injury and or
damage to property. The projector had to be installed out of the reach of people
DANGER OF FIRE! When installing the device, make sure there is no highly-inflammable
material(decoration articles, etc.)within a distance of min.0.5m.
DMX 512 connection/ connection between fixture
The wires must not come into contact with each other, otherwise the fixture will not work at all or
properly. Please note the starting address depends upon which controller is being used. Only use a
DMX cable and 3-pin XLR-plugs and connectors in order to connect the controller with the fixture or one
fixture to another
Connection with the mains.
The earth has to be connected. The device must only be connected with an electric installation carried
out in compliance with IEC standards.
OPERATION
After you connected the effect to the mains, The fixture starts running
Stand Alone operation
In the stand alone mode, the fixture can be use without controller
Master/slave-operation
The master/slave-operation enables that several devices can be synchronized and controlled by one
master-device
DMX controlled operation
You can control the projectors individually via your DMX-controller

6
Addressing
The control board allows you to assign the DMX starting address,
Note;it’s necessary to insert the XLR termination plug (with 120ohm) in the last device in the link in order
to ensure proper transmission on the DMX data link.
CONTRO L B O ARD
The control board offer several features :you can simple set the starting address, run the
pre-programmed program or make a reset
he main menu is accessed by pressing the Mode/Esc-button, Browse through the submenu by pressing
Up or Down .Press the Enter-button in order to select the desired menu. You can change the selection
by pressing Up or Down, Confirm every selection by pressing the Enter-button. You can leave every
mode by pressing the Mode/Esc-button .The functions provided are described in the following setting.
MENU MAP
The device has two operation modes, It can be operated in Stand Alone or in DMX controlled
STAND ALONE MODE
Cfor setting solid color,
Pfor internal programs
Sfor sound control/sensitivity
DMX MODE
4ch or 6ch to select ( 6ch in default )
Setting Solid colors
Press the mode button on select the solid color mode, when display shown C, you can select the
desired solid color via the UP or Down buttons (see following graphic).
C01
C02
C03
C04
C05
C06
C07
C08
C09
C10
C11
C12
C13
C14
C15
Red
Green
Blue
White
Medium
yellow
Rose
pink
Steel
blue
Frost
white
Dark
pink
Light
green
Dark
blue
Light
Orange
Pink
carnation
Blue
mist
Pure
white
Internal Programs, sound control.
Press the MODE button to select the internal program mode, when the display shown P, you can select
the desired internal program, with or without sound control. Via the UP or DOWN buttons (see following
graphic)
P01 Endless loop in 7 colors, change every 3 seconds
P02 Endless loop in 7 colors, fade every 3 seconds
P03 Endless loop in 3 colors, change every 3 seconds
P04 Endless loop in 3 colors, fade every 3 seconds

7
P05 Endless loop in 7 colors, via sound control
P06 Endless loop in 3 colors, via sound control
P07 Endless loop in 15 colors, change every 3 seconds
P08 Endless loop in 15 colors, fade every 3 seconds
P09 Endless loop in 15 colors, via sound control
Sound control/ sensitivity
Press the mode button until the display show S, you can select the desired sensitivity via the UP or
DOWN buttons, S S00-S100 (S50 default)
DMX-pr otoc o l
4 DMX channel mode
channel
value
function
1
0-255
Red
Red (0%-100%)
2
0-255
Green
Green (0%--100%)
3
0-255
Blue
Blue (0%--100%)
4
0-255
White
White (0%-100%)
6 DMX channel mode
channel
value
function
1
0-255
Red
Red (0%-100%)
2
0-255
Green
Green (0%--100%)
3
0-255
Blue
Blue (0%--100%)
4
0-255
White
White (0%-100%)
5
0-255
Dimmer
Dimmer (0%-100%)
6
0
001-005
006-010
011-255
Sound and Strobe
No function
Sound control (15 colors)
No function
Strobe with increasing speed
TECHNICIAL SPECIFICATIONS
Model
Q Par 708 wash

8
Voltage
110V- 250V / 50-60Hz
Power consumption:
65W
LED
7pcsX8w RGBW 4 in 1 with 25degree beam angle
Gross Weight
1.3Kgs
Dimensions
245(H) x 245(W) x 150(L) mm
