Style selections 5120855 User manual

1
Serial Number Purchase Date
ATTACH YOUR RECEIPT HERE
ITEM #5120855
MODEL #LWSSSS
SHELF STORAGE
2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Top panel 1
B Stretcher 1
C Side panel left 1
D Side panel right 1
E Shoe shelf 4
F Bottom panel 1
G Back panel 1
H Wire stopper 4
A
C
G
E
E
E
E
F
D
H
B
STYLE SELECTIONS is a trademark or registered
trademark of LF, LLC. All rights reserved.
Call customer service at 1-877-888-8225,8 a.m. - 8 p.m., EST, Monday - Sunday.

43
HARDWARE CONTENTS (not shown actual size)
AA
EE
II JJ
BB
FF
KK
CC
GG
DD
HH
Cam lock
Qty. 8
M3.5 x 15 mm
Screw
Qty. 20
Metal plate
Qty. 1
Shelf pin
Qty. 16
Plastic cover
Qty. 4
Cap
Qty. 4
Floor Leveler
Qty. 4
Cam bolt
Qty. 8
Wood dowel
Qty. 16
M4 x 50 mm
Screw
Qty. 4
CAM LOCK SYSTEM OPERATION
1 2 3
1. Screw the Cam Bolt into the pre-drilled small holes on the panel. Connect both panels together;
making sure the Cam Bolt goes into the pre-drilled hole at the end of the panel with the Cam
Lock.
2. Insert the Cam Lock into the pre-drilled large hole in the panel. Make sure the arrow on the
Cam Lock is pointed towards the Cam Bolt.
3. Once the Cam Bolt is connected inside the Cam Lock, take a Phillips screwdriver (not included)
and tighten the Cam Lock clockwise.
LL
M3.5 x 19 mm
Screw
Qty. 4
Back Crosser
Qty. 1
M5 x 65 mm
Screw
Qty. 1
MM NN
Drywall Anchor
Qty. 1

65
PREPARATION
SAFETY INFORMATION
WARNING
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
1. Do not allow children to climb or play in or around this product.
2. Use this unit for its intended purpose only. Do not use shelves as step ladder.
3. To avoid damage, assemble the product on a sturdy, level and protective surface.
4. Make sure all bolts/screws are tightly fastened before the unit is used.
5. Check bolts/screws periodically and tighten them if necessary.
MAXIMUM LOAD: 30 lb.
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 50 minutes
Tools Required for Assembly (not included): Rubber Mallet, Phillips screwdriver.
THIS UNIT IS INTENDED FOR USE ONLY WITH THE MAXIMUM WEIGHTS INDICATED. USE
WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHTS INDICATED MAY RESULT IN
INSTABILITY CAUSING POSSIBLE INJURY. DISTRIBUTE WEIGHT EVENLY.
ASSEMBLY INSTRUCTIONS
1. Screw cam bolts (BB) all the way into the small
holes located on side panel left (C) and side panel right
(D) as shown gure. Insert the wood dowels (CC) into
the end holes as a guide, attach stretcher (B) to the
side panel left (C) and side panel right (D) by engaging
cam locks (AA).
2. Screw cam bolts (BB) all the way into the small holes
located on top panel (A). Insert the wood dowels (CC)
into the holes pre-drilled on top edge of assembled frame.
Position the top panel (A) onto the inserted dowels and
attach in place by engaging cam locks (AA) as shown
gure.
1
2
3
BB
CC
AA
AA
CC
BB
D
B
A
C
Hardware Used
Hardware Used
Cam lock
Cam lock
Cam bolt
Cam bolt
wood dowel
wood dowel
x 2
x 6
x 2
x 6
x 2
x 6
AA
AA
BB
BB
CC
CC
C
D
B
CC
DD
C
D
F
3. Insert the wood dowels (CC) into the holes pre-drilled
on bottom edge of assembled frame. Position the bottom
panel (F) onto the inserted dowels and attach in place by
engaging M4 x 50 mm screws (DD) as shown gure.
Hardware Used
Wood dowel
M4 x 50 mm
Screw
x 4
x 4
CC
DD

7 8
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
7. Insert the wire stopper (H) into the holes of the shoe
shelf (E).
The shelf can be used as regular shelf by removing the
wire stopper.
5. Insert oor levelers (GG) into the bottom of bottom
panel (F).
If you plan to use this unit as hutch (stand this on another
one), please skip step 5 & 6.
6. Insert the caps (HH) into the holes on top of the top
panel (A).
4. Expand the back panel (G) and lay it onto the back
edges of assembled frame making sure the margins
along all edges are equal. Attach the back panel in
place by using M3.5 x 15 mm screws (FF) through the
pre-drilled holes of back panel.
4 7
8
9
5
6
FF
GG
HH
E
H
F
A
Hardware Used
Hardware Used
Hardware Used
M3.5 x 15 mm Screw
Floor Leveler
Cap
x 20
x 4
x 4
GG
HH
FF
G
x 4
II
KK
E
E
E
E
8. Set the rear shelf pin (KK) to one hole higher than the
front shelf pin. Tilt and install adjustable shelves (E) in
place. Plug the plastic covers (II) onto the visible cams
locks to conceal the cams.
Hardware Used
Plastic cover
Shelf pin
x 4
x 16
II
KK
LL
CC
EE
9. This cabinet was designed with a feature that allows
stacking two units. Additional units sold separately. Insert
wood dowels (CC) into the holes on top of the base unit.
Place bottom of second unit onto the inserted dowels.
Secure units together by attaching the metal plates (EE)
at both ends with the M3.5 x 19 mm screws (LL) into the
predrilled holes.
NOTE: Remove caps (HH) before stacking two units
together.
Hardware Used
Metal plate
Metal plate
M3.5 x 19 mm Screw
x 1
x 4
x 4
EE
CC
LL

9 10
ASSEMBLY INSTRUCTIONS CARE AND MAINTENANCE
• Periodically check to make certain all components are properly positioned, free from damage
and rmly connected.
• Use a soft, clean cloth that will not scratch the surface when dusting.
• Never use water to clean the furniture as it may cause damage to the nish.
• Wipe clean using a damp cloth and a mild cleaner. Wipe dry with a clean cloth.
• In the event that the furniture is stained or otherwise damaged during use, it is recommended
you call a professional to repair the furniture.
• Keep furniture away from direct sunlight as it may damage the nish.
• It is best to keep the furniture in a climate-controlled environment. Extreme temperature and
humidity changes can cause fading, warping, shrinking and splitting of wood.
10. Adjust oor levelers to level the unit against the wall
where desired. Using stretcher (B) as a template, mark
one mounting holes location on the wall. Drill one pilot
holes into the wall where previously marked. Make sure
that the drilled holes can t for the wall anchors (sold
separately) properly. Press the anchors into the holes
and gently tap with a hammer until ush in the holes. If
the mounting hole coincides with a wooden stud, there is
no need wall anchor. Align stretcher (B) and back cross-
ers (MM) over the drywall anchors (NN) and secure with
M5 x 65 mm screw (JJ). Tighten securely with phillips
screwdriver.
NOTE: Must install for both base and stacker.
10
Hardware Used
BJJ
NN MM
Drywall Anchor x 1
x 1
NN
Back Crosser
x 1
JJ
MM
M5 x 65 mm
Screw
LIMITED LIFETIME WARRANTY
This product is warranted to the original purchaser. If there is a failure in this unit due to defects in
materials or workmanship, the manufacturer will repair or replace this item at our discretion without
charge. Warranty is void if product has been assembled incorrectly, misused, abused by
overloading, altered in any way or damaged due to accident. This warranty is not transferable and
does not cover chipping, aking, scratches, rust, dents, or other damages to the surfaces of this
product. Responsibility of the manufacturer is limited to repair or replacement of this product. The
manufacturer is not responsible for consequential, incidental, or other damages or losses resulting
from product failure.
This warranty is in lieu of all other expressed warranties. Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation may not apply to you.
This warranty gives you specic legal rights and you may have other rights which vary from state
to state.
Wall
PART DESCRIPTION PART #
A Top panel 00LWSSSS-A
B Stretcher 00LWSSSS-B
C Side panel left 00LWSSSS-C
D Side panel right 00LWSSSS-D
E Shoe shelf 00LWSSSS-E
F Bottom panel 00LWSSSS-F
G Back panel 00LWSSSS-G
H Wire stopper 00LWSSSS-H
AA Cam lock 00LWSSSS-AA
BB Cam bolt 00LWSSSS-BB
CC Wood dowel 00LWSSSS-CC
DD M4 x 50 mm Screw 00LWSSSS-DD
EE Metal plate 00LWSSSS-EE
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-888-8225,8 a.m. - 8 p.m., EST,
Monday - Sunday.

11
Printed in Vietnam
Date: 2022-10-05
Rev. 0001-A
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-888-8225,8 a.m. - 8 p.m., EST,
Monday - Sunday.
AA BB
FF
CC
GG
DD
EE HH
II JJ
MM
KK
NN
A
C
G
E
E
E
E
F
D
H
B
LL
PART DESCRIPTION PART #
FF M3.5 x 15 mm Screw 00LWSSSS-FF
GG Floor Leveler 00LWSSSS-GG
HH Cap 00LWSSSS-HH
II Plastic cover 00LWSSSS-II
JJ M5 x 65 mm Screw 00LWSSSS-JJ
KK Shelf pin 00LWSSSS-KK
LL M3.5 x 19 mm Screw 00LWSSSS-LL
MM Back Crosser 00LWSSSS-MM
NN Drywall Anchor 00LWSSSS-NN
CH Complete hardware 00LWSSSS-CH
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-888-8225,8 a.m. - 8 p.m., EST,
Monday - Sunday.
12
