STYLEX Metrum Installation instructions

- Legs
- Material: Aluminum
Wood Leg optional
safety glasses
phillips screwdriver
3/8 wrench with extension
7/16 wrench (for arms)
1. Turn the chair on its side (or back if a
large unit) to reveal the metal legs.
Locate the 4 legs.
3. Using a phillips head screw driver or
drill, remove all screws from the frame,
releasing the legs from the seat wood
(figure B1).
4. Finally, release the back from the seat.
3. To remove the back frame from the
seat, locate the hex bolts towards the
back of the seat. Using a 3/8 wrench,
uncrew each of the bolts.
www.stylexseating.com 800.257.5742 Disassembly Metrum 00 12/17/18
C1
B1
A1
D1
-Washer
-Hex Washer Bolt
(1/4 20)
Material: Steel
Tools Required
Disassembly and Recycling Document
Disassembly Time:10min / No Special Training Required
Breakdown Steps
Model: Metrum one seater
*Refer to P.2 for model variations
x4
- Seat cushion
- Material:
Foam, plywood, upholstery
P.1
- Back cushion
- Material:
Foam, plywood, upholstery
-Phillips round head
(1/4 20)
Material: Steel x4
x6Per seat
x6Per seat

1 Seater
2 Seater
Settee
3 Seater
Corner
Chaise
High Back 1 Seater
High Back 2 Seater
High Back 3 Seater
High Back 1 Corner
www.stylexseating.com 800.257.5742 Disassembly Metrum 00 12/17/18
Chair Variations
Disassembly and Recycling Document
Disassembly Time:10min / No Special Training Required
Model: Metrum
P.2
Standard, bookshelf, cantilever, privacy,
mid-arm. All arms are bolted to the frame
using either a hex bolt or threaded studs
welded to the arm and held down with a
nut. The following example is using hex
bolts.
1. Turn the chair on its back to have better
access to the hex bolts holding the arm
to the chair frame.
3. There are 3 bolts holding the arm to the
seat (figure A1, B1) and 2 bolts holding
the arm to the back. (figure B2).
3. After locating the bolts, use a 3/8
wrench to remove them. For cantilever
arm or mid arms, use a 7/16 wrench
to remove the nut. (Note: Mid-arm is
removed the same way you would a
normal arm, except it is not attached to
the back, only the seat.)
C1
B1
A1
Arm Removal
B2
Dissesembly for other Metrum units is
similar to the single seater disassembly
on P1. Refer to P1 for instructions.
