STYLEX Verve Installation instructions

safety glasses
5/32 alan wrench
1. Turn the chair on its back to reveal
the aluminum 4 blade swivel base.
Start by using a 5/32 allen key to re-
move the 1/4-20 Shoulder head cap
screw. When the screw is removed
pull up the base to seperate it from
the spigot (gure A1).
3. Finally, seperate the arms and spigot
from the carraige useing the 5/32
allen key (gure C1).
2. After removing the base from the
chair, use the same allen key to
unscrew the screws holding the
aluminum carriage onto the shell.
(gure B1).
www.stylexseating.com 800.257.5742 Disassembly Verve 08/18/16
- Seat Shell
- Material:
Polypropylene, foam
upholstery
Tools Required
Disassembly and Recycling Document
Disassembly Time: 5min / No Special Training Required
Breakdown Steps
Model: Verve with 4 Blade base
*Refer to P.2 for model variations
- 4 Blade Base
- Material: Aluminum
- Phillips button-head (¼ 20 bolt)
- Material: Steel
x1
x4
x4
P. 1
- Carriage
- Material: aluminum, steel
- Washers
- Material: Steel x4
- Socked Head shoulder Screw
- Material: Steel
- Washer
- Material: Steel
- Casters
- Material: Steel, Nylon
A1
B1
C1

Chair Variations
Disassembly and Recycling Document
Disassembly Time: 5min / No Special Training Required
Model: Verve
P. 2
Verve
All Verve chairs have various options for upholstery and base
options:
- Fully upholstered liner with 4 blade base (gure A1).
- Fully upholstered with 5 blade base (gure A2).
- Shell with seat and sled frame (gure A3).
Disassembly for all of these versions is fairly similar
to the original. Please use P1 as a disassembly
reference for all of these variations.
All bases can be recycled
