STYLEX F4 Installation instructions

Safety Glasses
5/32 Allen Wrench
3/16 Allen Wrench
5/64 Allen Wrench
#2 Phillips Screwdriver
Mallet
1. Flip the chair over and remove the
8 screws holding the seat in place.
Slide the seat forward and pull up to
remove the seat. (Figure A1)
2. Unscrew the 2 screws at the botton
of the back and pull the seat back up
to remove. (Figure B1)
www.stylexseating.com 800.257.5742 Disassembly F4 09/21/17
- Seat Back
- Material: Glass Filled Nylon,
Mesh Upholstery
Tools Required
Disassembly and Recycling Document
Disassembly Time: 10 min / No Special Training Required
Breakdown Steps
Model: F4
P. 1
- Seat
- Material: Polypropolyne, foam
A1
A1
x8
- Socket Head Shoulder Screw
- Material: Steel
C1
- Carriage
- Material: Aluminum
x28
- Socket Head Shoulder Screw
- Material: Steel
3. Unscrew 2 screws per arm to remove
the arm pads. (Figure C1)
C1C1
x6
- Spring
- Material: Steel
B1

4. Flip the chair over and remove the
casters from the base. (Figure D1)
www.stylexseating.com 800.257.5742 Disassembly F4 09/21/17
-Cylinder
- Material: Aluminum, Steel
Disassembly and Recycling Document
Disassembly Time: 10 min / No Special Training Required
Model: F4
P. 2
A1
A1
D1
- 5 Blade Base
- Material: Aluminum
x5
- Casters
- Material: Steel, Nylon
