Sukup Fastir Parts list manual

Manual L1413 © Sukup Manufacturing Co.
01/09/2019
Owner’s Instruction and Parts Manual
for Sukup Fastir and Fastir Plus Units
Sukup Manufacturing Co.
1555 255th Street, Box 677
Sheffield, Iowa, USA 50475-0677
Phone: [phone]
Fax: [phone]
Website: www.sukup.com
E-mail: [email protected]
DATE REVISIONS PAGES
01/09/2019 – Updated warranty ---------------------------------------------------------------------------------------------------- 4
01/09/2019 – Changed screw (Ref #11) from hex head to button head on stabilizer kit trolley ------------------- 20
01/09/2019 – Changed J0555 screw to B5952 bin bolt in track bolt sacks --------------------------------------------- 55

2
Table of Contents
Limited Warranty ................................................................................................................................... 4
I. General Safety Practices ........................................................................................................... 5
II. Placement of Fastir Safety Decals ............................................................................................ 7
Materials Required ................................................................................................................................ 8
Assembly & Installation ....................................................................................................................... 10
I. Installing Track......................................................................................................................... 10
II. Assembling & Installing Carriages ........................................................................................... 12
III. Installing Stabilizer Arm Kit ...................................................................................................... 19
IV. Installing Tilt Switches ............................................................................................................. 21
V. Installing Motors ...................................................................................................................... 21
VI. Installing Reversing Plates ...................................................................................................... 22
VII. Installing Center Hanger & Related Parts ............................................................................... 22
VIII. Installing & Adjusting Reversing Mechanism .......................................................................... 24
IX. Wiring Gearmotor on Center Hanger ...................................................................................... 25
X. Wiring Motors........................................................................................................................... 26
XI. Wiring Tilt Switches on Motors ................................................................................................ 26
XII. Installing Machine .................................................................................................................... 28
XIII. Installing Rotating Contact ....................................................................................................... 28
XIV. Installing Optional Spreader-Bar Kit ........................................................................................ 29
XV. Preparing Down Augers .......................................................................................................... 29
XVI. Installing Down Augers ............................................................................................................ 30
XVII. Final Steps ............................................................................................................................... 31
Fastir Operation Guidelines................................................................................................................. 32
I. Operation Procedures ............................................................................................................. 32
II. Restarting Fastir Machine ........................................................................................................ 32
III. Fastir Maintenance .................................................................................................................. 32
Fastir Troubleshooting Guide .............................................................................................................. 33
I. Checking Gearmotor ............................................................................................................... 33
II. Bench-Testing Gearmotor ....................................................................................................... 33
III. Checking Capacitor ................................................................................................................. 33
IV. Checking Reversing Mechanism ............................................................................................. 33
Principles of Grain Drying.................................................................................................................... 35
I. Basic Principles ....................................................................................................................... 35
II. Drying Guidelines to Prevent Bin Wall Spoilage ..................................................................... 39
III. Drying Precautions .................................................................................................................. 40
Managing Stored Grain ....................................................................................................................... 41
I. Basic Principles ....................................................................................................................... 41
II. Grain Storage .......................................................................................................................... 42
III. Aeration ................................................................................................................................... 45
IV. Addressing Grain Storage Problems ....................................................................................... 46
V. Bin System Upkeep ................................................................................................................. 47
Appendix A - Wiring Diagrams ............................................................................................................ 49
Fastir Parts Assembly Manual ............................................................................................................ 53

3
Thank you for turning to Sukup Manufacturing Co.
for your grain drying needs. In 1962, a young,
innovative farmer named Eugene Sukup bought his
first grain bin to dry and store shelled corn.
However, he soon encountered problems with the
process, such as crusting and hard spots. In
response, Eugene developed and patented an idea
for an automatic stirring machine—the idea from
which Sukup Manufacturing Co. was born.
Sukup stirring machines have come a long way
since they revolutionized in-bin drying, but they
remain the simplest, most dependable stirring
machines on the market. Additionally, the Fastir
stirring machine’s adaptable design and variety of
extras make it ideal for both large and small drying
operations.
Fastir stirring machines eliminate overdried grain,
increase airflow, and preserve grain quality.
Overdried grain resulting from typical heating
processes has been a constant problem
accompanying grain drying in bins, meaning lower
quality grain, wasted fuel, and wasted time.
Sukup’s goal has been to eliminate this problem by bringing the advantages of stirring to both low- and high-
temperature in-bin drying systems. As the machine mixes and loosens bottom layers of grain that are easily
overdried, grain may be heated to higher temperatures to achieve faster drying rates without any of the typical
effects of overdrying.
The Sukup Fastir provides a low-cost solution for on-farm drying of grain. If additional stirring capacity is desired
after installation, additional down augers may be economically added to machines at any time. In short, our
stirring machine is an excellent tool for adding greater flexibility to any bin drying or storage system, whether high
or low temperature.
We hope that you return to Sukup for all of your grain storage, drying, and handling needs. Along with the simply
dependable Fastir, Sukup is the leader in unloading equipment and fans and heaters. Sukup grain bins and
dryers have also taken the market by storm. From heaters to grain bins and everything in between, our family-
owned company is dedicated to providing customers with the best quality products and the best value for their
money.
This manual contains instructions for the installation, operation, and service of Sukup Fastir and Fastir Plus
units. Fastir and Fastir Plus units are largely the same except the Fastir Plus model has a stationary outside
carriage. This manual is written for both models, so carefully read and follow all instructions.
This document also contains an illustrated parts assembly manual (attached, page 53), which is broken down into
groups for each section of the unit and details all serviceable parts. Parts shown in exploded views of assemblies
are reference numbered and correspond to numbers in Ref # column of parts list following each illustration. Total
number of parts required per unit or assembly is shown opposite each part number.
When ordering parts, always give part number (in Comp # column) and part description shown alongside
reference number. Do not order parts by reference numbers. If part number cannot be found in manual, give clear
description of part and its location and function. Also, specify your machine type and size.
From left to right: Steve Sukup, Eugene Sukup, Charles Sukup
Sukup Manufacturing Co., Sheffield, IA, USA

Limited Warranty
4
LIMITED WARRANTY

General Safety
5
I. General Safety Practices
On safety decals, this symbol and the
signal words Danger, Warning, Caution
and Notice draw your attention to
important instructions regarding safety.
They indicate potential hazards and levels of intensity.
RED - DANGER indicates an
imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
ORANGE - WARNING
indicates a potentially
hazardous situation which, if not avoided, could result
in death or serious injury.
YELLOW - CAUTION
indicates a potentially
hazardous situation which, if not avoided, may result
in minor or moderate injury.
BLUE - NOTICE alerts you to
practices unrelated to personal
injury, such as messages related to property damage.
IMPORTANT: To prevent death or serious injury to
you or your family, it is essential that safety decals
are clearly visible, in good condition, and applied to
the appropriate equipment.
FOLLOW MACHINE SAFETY DECAL MESSAGES
Carefully read this manual and
all safety decals on your
equipment. Safety decals must
be kept in good condition.
Replace missing or damaged
safety decals free of charge by
contacting Sukup Manufacturing
Co. by mail at PO Box 677, Sheffield, Iowa 50475; by
phone at 641-892-4222; or by e-mail at
[email protected].
It is the responsibility of the owner/operator to know
what specific requirements, precautions, and work
hazards exist. It is also the responsibility of the
owner/operator to inform anyone operating or
working in the area of this equipment of hazards and
safety precautions that need to be taken to avoid
personal injury or death. Always keep children away
from bins and vehicles with flowing grain.
Make no unauthorized modifications to machine.
Modifications may endanger function and/or safety of
unit. Keep unit in good working condition. Keep shields
in place. Replace worn or missing shields free of
charge by contacting Sukup Manufacturing Co.
GRAIN BIN SAFETY
Owners/operators are responsible for developing
site-specific confined space entry procedures.
OSHA’s confined space entry procedures (29CFR
1910.146) can be found at www.osha.gov.
If you must enter bin for repair or maintenance:
 Use a safety harness, safety line and respirator
 Station another person outside of bin
 Avoid the center of the bin
 Wear appropriate personal protective equipment
 Keep clear of all augers and moving parts
DANGER! Never enter bin unless all power is
locked off and another person is present.
Rotating augers can dismember or kill!
Flowing grain may trap and suffocate. If you enter a
bin of flowing grain you can be completely
submerged in grain in about 8 seconds.
Failure to heed these warnings could result in death
or serious injury.
NEVER clean out bin with augers running!
When bin is nearly empty, sweep (floor) augers will
travel at an increasing speed; just turning around can
give augers enough time to trap you. Keep away from
sweep and sump augers to avoid entanglement.
Failure to heed this warning could result in death or
serious injury.
Read manual before installing or using product. Failure to follow instructions and safety precautions in
manual can result in death or serious injury. Keep manual in a safe location for future reference.

General Safety
6
Refer to OSHA
1910.132
(Personal Prot.
Equip.)
Refer to OSHA 1910.132
(Personal Prot. Equip.)
I. General Safety Practices (continued)
To avoid electrocution, all
equipment must be properly
wired and grounded according
to electrical codes. Have unit
wired by qualified electrician.
Have an electrician install a main
power disconnect switch capable
of being locked only in OFF position. Mark disconnect
clearly as to
equipment it
operates.
Always lock out
main power
disconnect switch
whenever
equipment is not
in use.
WARNING: When servicing equipment,
never enter bin unless all power is locked out
and another person is present. Always LOCK OUT
all power and always check with voltage meter
before servicing. To avoid personal injury, frequently
inspect all mechanical and electrical components.
Repair and/or replace worn parts. Be sure all
electrical wires are in good condition.
Failure to do so could result in death or serious injury.
Owners/operators are responsible for developing
site-specific Lockout/Tagout procedures based on
equipment at their work site. See OSHA’s typical
minimal lockout procedures (29CFR 1910.147 App
A) at www.osha.gov.
WARNING: KEEP CLEAR OF ALL
MOVING PARTS.
Keep people (ESPECIALLY YOUTH) away from
equipment, particularly during operation.
Keep away from all moving parts. Keep all shields in
place. SHUT OFF AND LOCK OUT all power before
servicing.
Failure to follow precautions above could result in
death or serious injury.
CAUTION: Metal edges are sharp. To avoid
injury, wear protective clothing and handle
equipment and parts with care.
Failure to do so may result in minor or moderate injury.
WARNING! If a ladder is to be placed
against crosstube for installation or
maintenance, securely wire outside drive end of
crosstube to track to avoid movement of unit. (Be
sure to remove wire when work is completed.)
Failure to do so could result in death or serious
injury.
WARNING!
Metal is
slippery when wet.
To avoid falls, never
carry items while
climbing on bin.
Maintain secure
hand and foothold if
climbing on bin.
Failure to do so
could result in death or serious injury.
PERSONAL PROTECTIVE EQUIPMENT
Owners/Operators are
responsible for developing
site-specific personal
protective equipment
standards. OSHA’s
personal protective
equipment standards
(29CFR 1910.132) can be
found at www.osha.gov.
EMERGENCIES – KNOW WHAT TO DO
Have emergency numbers and written directions to
work site readily available in case of emergency. An
area for emergency phone numbers to be recorded
is provided below and at end of this manual.
Ambulance • Fire • Police: 9-1-1
Bin rescue team: _______________________
Emergency medical squad: ______________
Address of work site: ___________________
Directions to work site:__________________

General Safety
7
II. Placement of Fastir Safety Decals
Yearly and prior to equipment use, ensure that all
decals and shields are in legible condition and in
place according to these drawings. Replace missing
or damaged safety decals or shields free of charge
by contacting Sukup Manufacturing Co. by mail at
Box 677, Sheffield, Iowa 50475; by phone at 641-
892-4222; or by e-mail at [e-mail].
Figure 1 - Placement of Safety Decals on Carriages
Decals #1, #2, and #5 are factory-mounted. If their
replacement is necessary, follow steps below.
1 Before replacing Decals #1, #2, and #5:
1.1 Disconnect electricity.
1.2 Wire end of crosstube to track.
1.3 Ensure hairpin clips are through holes in
motor mount.
2 Ensure areas of placement for decals are free
from grease, oil and dirt.
3 Mount decals without standing under machine.
Decal #2-L0271
Decal #1-L0284
Decal #5-L0260
Figure 2 - Placement of Safety Decals on Outside of Bin
Decals #3 and #4 must be mounted on-site:
1 Ensure areas of placement for decals are free
from grease, oil, and dirt.
2 During machine installation, mount decal #3 on
bin sheet near door handle and at all other entry
points or by ladder going up to roof so everyone
entering bin will see it. See above.
2.1 Note: If suggested areas of placement for
decals are not clearly visible, place safety
decals in a more suitable area. Never cover
up any existing safety decals.
3 Mount decal #4 on bin sheet near door handle.
See above.
Decal #3-L0258A
Decal #4-L0281

Materials Required
8
MATERIALS REQUIRED
Before beginning to install this product, ensure that all required components are present by checking the Shipping
List section below. Also, compare carton contents against labels on cartons and ensure crosstube supplied is
correct size for bin.
Shipping List
Table 1 - Major Parts List
Fastir
Fastir Plus
Description
Qty - Single
Qty - Double
Qty - Triple
Qty - Triple
Qty - Quad
Qty - Quint
Fastir Crosstube
1
1
1
1
1
1
Hanger Pipe
1
1
1
1
1
1
Top Hanger
1
1
1
1
1
1
Outside Cord Hanger
1
1
1
1
1
1
Tie Bar(s)
-
2
4
2
4
6
Track
1
1
1
1
1
1
Down Auger
1
2
3
3
4
5
Hardware Ctn #1
1
1
1
1
1
1
Hardware Ctn #2
1
1
1
1
1
1
Hardware Ctn #3
-
-
-
1
1
1
Stationary Auger Kit
-
-
-
1
1
1
Stabilizer Arm Kit (Standard with
units ordered after 2007)
1
1
1
1
1
1
Table 2 - Fastir/Fastir Plus Basic Hardware Carton Part Numbers
Hardware Carton #
Comp #
Single
Double
Triple
Quad
Quint (Fastir Plus)
4-1/2”
5-1/2”
4-1/2”
5-1/2”
4-1/2”
5-1/2”
4-1/2”
5-1/2”
4-1/2”
5-1/2”
1
A8490
-
A8491
A84912
A8492
A84922
A8493
A84933
-
A84935
2
Varies by bin diameter and motor phase and voltage
3*
* For Fastir Plus units only
A3424
A34242
A3424
A34242
A3424
A34242
Table 3 - Fastir/Fastir Plus Basic Hardware Carton #1 Contents
Description
Comp #
Qty
4-1/2” Crosstube
5-1/2” Crosstube
Single
Double
Triple
Quad
Quint
Safety Decal Pkg.
A3399
A3399
1
1
1
1
1
Motor Mount
A5209
A5209
1
2
3
4
5
Cast Junction Elec. Box
A5612
A5612
1
1
1
1
1
Flinger
A5616
A5616
1
2
3
4
5
Cord Support Strap
A6121
A6121
1
1
1
1*
1*
Parts Sack Single
A6806
A6806
1
-
-
-
-
Parts Sack Double
A6807
A6807
-
1
-
-
-
Parts Sack Triple
A6808
A6808
-
-
1
1
1
Offset (Center) Hanger
A7504
A7504
1
1
1
1
1
Hanger
A7509
A7509
2
2
2
2
2
Rev. Carriage Plate
A80342
A8060
4
4
4
4
4
Primary Carriage
A8500
-
1
-
-
-
-
Primary Carriage
A8501
A6130
-
1
1
1
1
Satellite Carriage
A8502
A6135
-
1
2
3
4
Shield
A8508
A6120
1
2
3
4
5
Flange Bearing “1”
J0003
J0003
2
4
6
8
10
Belt
J0179
J0195
1
2
3
4
5
Pulley, 9”, Sng, A Groove
J0355
J0355
1
2
3
4
5
Prevent Voiding Warranty
L0249
L0249
1
1
1
1
1
Imp. Grain Level Warning
L0304
L0304
1
1
1
1
1
Sukup Logo
L03171
L03171
-
1
1
1
1
Manual
L1413
L1413
-
1
1
1
1
Wire Ties, Bundle
L9999
L9999
1
2
3
4
5
*Includes 2 with Fastir Plus

Materials Required
9
Table 4 - Fastir/Fastir Plus Hardware Carton #2 Contents
Description
Comp #
Qty
Single
Double
Triple
Quad
Quint
Gearmotor, Hvy Duty (*Gearmotor, Extra Hvy Duty - A5299)
A5319
1
1
1
1
1
Rotating Contact
Varies
1
1
1
1
1
Pillow Block Bearing 1” (*Pillow Blk Bearing 1-1/4” - A5651)
A5649
1
1
1
1
1
Junction Switch Box
A8140
1
1
1
1
1
Tilt Switch
Varies
1
2
3
4
Bolt Sack, Track
Varies
1
1
1
1
1
Tie Bar 18” hole- to-hole (*Tie Bar 27” hole-to-hole - A59021)
A5897
-
-
2
2
2
*Used on 40’ Diameter & Larger Machines
Table 5 - Fastir Plus Only Hardware Carton #3 Contents
Description
Comp #
Qty
4-1/2”
Crosstube
5-1/2”
Crosstube
Safety Decal Package
A3399
A3399
1
Parts Sack Stationary Auger Kit
A3426
A3426
1
Motor Mount
A5209
A5209
1
Outside Stationary Carriage
A5250
A6140
1
Shield
A8508
A6120
1
Stationary Carriage Plate
A5245
A6115
2
Flinger
A5616
A5616
1
Bolt Sack, Supplemental
A6854
A6854
1
Bearing, 1” Flange
J0003
J0003
2
Belt
J0179
J0195
1
Pulley, 9” Single A Groove
J0355
J0355
1
Prevent Voiding Warranty Sticker
L0249
L0249
1
Warning, Keep Away Moving Parts
L0284
L0284
1
Important, Grain Level Sticker
L0304
L0304
1
Sukup Logo
L03171
L03171
1
Manual
L1413
L1413
1
Wire Ties, Bundle
L9999
L9999
1
Tools Required
 Wrenches: 5/16”, 7/16”, 1/2”, 9/16”, 3/4”, 10 mm wrench or adjustable (Crescent) wrench
 Hex (Allen) Wrenches: 1/4", 5/32”
 Regular-head Screwdriver
 Phillips-head Screwdriver
 Wire Stripper
 Punch
 Hammer

Assembly & Installation
10
ASSEMBLY & INSTALLATION
I. Installing Track
For part numbers and descriptions of parts
referenced in this section, see parts assembly
manual, page 53.
Track is most easily installed while first ring of bin is
being assembled on the ground. Track of correct
size must be installed as a unit in bin. Track brackets
and curvature vary according to bin diameter.
The process for installing track on some Sukup bin
sheets differs slightly from that used with bin sheets
produced by other companies. Section A describes
the process used with Sukup track-punched bin
sheets. Section B describes the process used with
Sukup bin sheets not punched for track and for non-
Sukup bin sheets.
With bin sheets produced by other companies, the
existing holes in top bin sheets may be used for
mounting track in many cases (Section B). However,
in some cases, no holes will match and all holes
must be drilled in bin sheet to mount track. Section
C describes this process.
Figure 3 - Head-On View of Track Bracket Placement
A. Installing Track on Sukup Bin Sheets
Punched for Track
A1 For Sukup bins smaller than 30’, insert 5/16” x 1-
1/4” bolts in top hole of every other pair of bolt
holes for track around top of bin (approximately
18” spacing). For Sukup bins 30’ and larger,
place bolts in top hole of every pair of bolt holes
(approximately 9” spacing) except those at bin
wall seam. Figure 3, Figure 4.
A2 Mount 1 length of track with bolts through top
holes on track brackets. Figure 3, Figure 4.
A2.1 Note: On bins 30’ and larger with a double-
bracketed track, a gap has been left to
prevent interference between seam bolts
and track brackets. Install first section of
track with seam in place of missing bracket.
Figure 3.
A3 Insert 5/16” x 1” bolts through bottom holes on
track brackets.
A4 Place 5/16” nuts onto bolts through track
bracket. Do not tighten at this time. Figure 4.
Figure 4 - Side View of Track Mounted on Sukup Bin
Sheet Punched for Track
A5 Mount remaining track sections using steps A2-
A4, joining track sections together with 3/8” x 1”
bolt and 3/8” lockwasher and nut. Tighten using
9/16” wrench. Figure 5.
A5.1 Note: Ensure these bolts are pointing to
outside (toward bin sidewall) to avoid
obstructing machine movement.
Figure 5 - Top View of Track Splice
A6 Tighten 5/16” nuts on bolts through track bracket
using 1/2” wrench.
A7 Ensure entire length of track and bin wall is free
of any obstructions that could hinder movement
of machine through bin.
B. Installing Track on Sukup Bin Sheets Not
Punched for Track and on Bin Sheets from
Other Companies
B1 For bins smaller than 30’, insert 5/16” x 1-1/4”
bolts in single ring of bolt holes around top of bin
(approximately 18” spacing). For bins 30’ and
larger, place bolts in every bolt hole
(approximately 9” spacing) except those at bin
wall seam. Figure 3.
B2 Tighten 5/16” spacer nuts onto these bolts.
Figure 6.
B3 Mount first segment of track over bolts and screw
on a second 5/16” nut. Figure 3, Figure 6.

Assembly & Installation
11
B3.1 Note: On bins 30’ and larger with a
double-bracketed track, a gap has been
left to prevent interference between
vertical seam on sidewall sheets and track
brackets. Install first section of track with
bin wall seam in place of missing bracket.
Figure 3.
Figure 6 - Side View of Track Mounted on Sukup Bin
Sheets Not Punched for Track and Sheets from Other
Companies
B4 Mount remaining track sections using steps B2-
B3, joining track sections together with 3/8” x 1”
bolt and 3/8” lockwasher and nut. Tighten using
9/16” wrench. Figure 5.
B4.1 Note: Ensure these bolts are pointing to
outside (toward bin sidewall) to avoid
obstructing machine movement.
B5 After all track sections are in place, drill second,
lower bolt holes through bin sheets using track
brackets as pattern. Figure 6.
B5.1 Note: Drill through middle bracket holes
only when dealing with 4.0” cor. sidewall
sheet.
B5.2 Note: Drill through bottom bracket holes
only when dealing with 2.66” cor. sidewall
sheet.
B6 Insert 5/16” bolt no longer than 1” into newly
drilled holes. If needed, insert a longer bolt
pointed to outside to avoid obstructing machine
movement and screw on 5/16” nuts. Tighten
using 1/2” wrench.
B6.1 Note: Leave unused track bracket holes
empty. Figure 6.
B7 Tighten 5/16” nuts on top bolts through track
brackets using 1/2” wrench.
B8 Ensure entire length of track and bin wall is free
of any obstructions that could hinder movement
of machine through bin.
C. Installing Track When Holes for Track
Brackets Must Be Drilled
C1 Place first segment of track in bin.
C2 Drill holes in top bin sheet to match holes on
each bracket:
C2.1 When drilling 4.0” Cor. sidewall sheets,
use top and bottom track bracket holes as
guide as shown in Figure 4.
C2.2 When drilling 2.66” Cor. sidewall sheet,
use bracket holes as guide to drill through
corrugation hills on sheet.
C3 Insert 5/16” x 1-1/4” bolt through top bolt holes.
Figure 6.
C4 Mount first segment of track over bolts and
screw on 5/16” nuts. Figure 6.
C5 Insert 5/16” x 1” bolts in lower holes of track
bracket and add 5/16” nuts. Tighten using 1/2”
wrench. Figure 6.
C5.1 Note: Leave unused track bracket holes
empty. Figure 6.
C6 Mount remaining track sections using steps C2-
C5, joining track sections together with 3/8” x 1”
bolts and 3/8” lockwashers and nuts. Tighten
using 9/16” wrench. Figure 5.
C6.1 Note: Ensure these bolts are pointing to
outside (toward bin sidewall) to avoid
obstructing machine movement.
C6.2 Note: Because of the large variation in
diameter from bin to bin, it may be
necessary to use a splice to join the last
section of track. These splice sections are
available at no charge by contacting
Sukup Manufacturing Co. by mail at Box
677, Sheffield, Iowa 50475; by phone at
641-892-4222; or by e-mail at
[email protected].
C6.3 If splice is required, bolt splice sections in
place and tighten.
C7 Ensure entire length of track and bin wall is free
of any obstructions that could hinder movement
of machine through bin.

Assembly & Installation
12
II. Assembling & Installing Carriages
For part numbers and descriptions of parts
referenced in this section, see parts assembly
manual, page 53.
1 Carry crosstube and hardware into bin.
2 Place outside crosstube end with drive wheel
next to bin sidewall and inside end with shaft in
center of bin.
For Fastir Plus units, begin here and continue
following instructions:
3 Bolt stationary carriage plate onto drive wheel
end of crosstube with hub pointing outward
using 3/8” x 1-3/4” bolts and 3/8” washers and
nuts. Figure 7, Figure 13.
Figure 7 - Placement of Stationary Outside Carriage on
Fastir Plus Unit
4 Slide stationary outside carriage onto crosstube
beside plate with reversing mechanism tab
pointing toward drive wheel. Figure 7, Figure 13.
For multiple-carriage regular Fastir units, begin
here and continue following instructions:
5 Slide satellite carriage(s) onto crosstube from
inside, shaft end with reversing mechanism tab
pointing toward drive wheel, as shown in Figure 7.
For single-carriage Fastir units, begin here:
6 Slide primary carriage about 1 foot onto
crosstube from inside, shaft end. Knurled
bearing should be on top and slot for down
auger on front of crosstube as shown in Figure
7, Figure 8.
7 Ensure 1/16” gaps (approximately the thickness
of a credit card) exist between crosstube and
bearing blocks. Figure 8.
Note: If necessary, adjustments may be made
using 3/4” wrench on bottom carriage
bolts. Do not overtighten carriages.
Figure 8 - Side View of Primary and Satellite Carriages
8 Ensure correct spacing between carriages exists
by comparing hole-to-hole length on installed tie
bar with tie bar specifications in drawings and
tables on pages 15-18.
Figure 9 - Back and Top View of Fastir Tie Bar Installation
9 Bolt tie bar(s) between carriages on sides
without down auger slots as shown. Use 5/16” x
1” bolts pointing out and 5/16” lockwashers and
nuts and tighten using 1/2” wrench. Figure 9,
Figure 12, Figure 13.
9.1 Note: Single-carriage units do not require tie
bars.
9A On all Fastir sizes, install additional tie bar on
back inside of carriage near top as shown.
Figure 10. (For 4 ½” crosstube, use lower holes
shown in drawing inset. 5 ½” crosstube has only
one set of holes.) Figure 10.
9B Install additional tie bar(s) between
moving carriages in same manner. Figure 10.

Additional Tie Bar Installation Assembly & Installation
13
INSTALLING ADDITIONAL TIE BAR
Figure 10 - Additional Tie Bar Installation
4 ½″ CROSSTUBE
FASTIR UPPER TIE-BAR

Assembly & Installation
14
Figure 11 - Primary and Satellite Carriage Assemblies, Exploded Views
WARNING!
To prevent death
or serious injury
be sure that
hairpin clips are
inserted in motor
mount so motor
will not fall
unexpectedly.

Assembly & Installation
15
Fastir Assembly
Figure 12 - Tie Bar and Carriage Placement for Fastir Units
BACK VIEW
TOP VIEW
BACK VIEW
BACK VIEW
BACK VIEW
TOP VIEW
TOP VIEW
TOP VIEW

Assembly & Installation
16
Fastir
Table 6 - Hole-to-Hole Lengths (Measured from Hole Centers) for Tie Bars and Reversing Rods
Double Auger
Triple Auger
Bin
Diameter
Reversing Rod
Hole-to-Hole*
Tie Bar Hole-to-Hole**
Reversing Rod Hole-
to-Hole*
Tie Bar Hole-to-Hole**
(A)
(B)
(A)
(B)
(C)
Comp #
Length
(”)
Comp #
Length
(”)
Comp #
Length
(“)
Comp #
Length
(”)
Comp #
Length
(”)
18’-18’7”
A8514
46
A59051
37
A85231
59.5
A5901
24
A5897
18
21’-21’8”
A8523
55.5
A59071
46
A85152
68.5
A5904
33
A5897
18
24’-24’9”
A85143
61.5
A59081
52
A85261
77
A59061
41
A5897
18
27’-27’10”
A8526
70.5
A59110
61
A8522
88
A59081
52
A5897
18
30’-31’
A8527
83.5
A81151
74
A8518
96.5
A59110
61
A5897
18
33’-34’
A85282
90.5
A59124
81
A8529
102
A59116
66
A5897
18
36’-37’1”
A8529
102
A59141
93
A85302
112.75
A59121
77
A5897
18
42’-42’8”
A8532
118.5
A5916
109
A8533
137.5
A59141
93
A59021
27
48’
-
-
-
-
A85333
153.75
A5916
109
A59021
27
49’3”
-
-
-
-
A85333
153.75
A5916
109
A59021
27
Quadruple Auger
Bin
Diameter
Reversing Rod Hole-to-
Hole*
Tie Bar Hole-to-Hole**
(A)
(B)
(C)
(D)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length (”)
27’-27’10”
A8529
102
A59032
29
A59032
29
A5897
18
30’-31’
A8532
118.5
A59051
37
A59051
37
A5897
18
33’-34’
A85321
127
A59061
41
A59061
41
A5897
18
36’-37’1”
A85324
136
A59071
46
A59071
46
A5897
18
42’-42’8”
A8537
165
A5910
56
A5910
56
A59021
27
48’
A85381X
196.5
A5912
71
A5912
71
A59021
27
*Hole-to-hole measurement is with adjustable spade bolt; cut length of reversing rod 1-1/2” shorter than hole-to-
hole measurement.
**Cut length of tie bar 1-1/2” longer than hole-to-hole measurement.

Assembly & Installation
17
Fastir Plus Assembly
Figure 13 - Tie Bar and Carriage Placement for Fastir Plus Units
TOP VIEW
TOP VIEW
TOP VIEW
BACK VIEW
BACK VIEW
BACK VIEW
PLACE STATIONARY AUGER
GUIDE PLATE AGAINST THE WELD
OUTSIDE REVERSING PLATE

Assembly & Installation
18
Fastir Plus
Table 7 - Hole-to-Hole Lengths (Measured from Hole Centers) for Tie Bars and Reversing Rods
Triple Auger (1 Stationary)
Quadruple Auger (1 Stationary)
Bin
Diameter
Reversing Rod Hole-
to-Hole*
Tie Bar Hole-to-Hole**
Reversing Rod Hole-
to-Hole*
Tie Bar Hole-to-Hole**
(A)
(B)
(A)
(B)
(C)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length
(”)
18’-18’7”
A85140
36.5
A59021
27
-
-
-
-
-
-
21’-21’8”
A8514
46
A59051
37
-
-
-
-
-
-
24’-24’9”
A8523
55.5
A59071
46
A85153
68.75
A5904
33
A5897
18
27’-27’10”
A8515
66
A5910
56
A85261
77
A59061
41
A5897
18
30’-31’
A85260
75.5
A59116
66
A8522
88
A59081
52
A5897
18
33’-34’
A85383
80.5
A5912
71
A8519
97
A59110
61
A5897
18
36’-37’1”
A85282
90.5
A59124
81
A85300
106.75
A5912
71
A5897
18
42’
-
-
-
-
A85322
130.75
A59131
86
A59021
27
Quintuple Auger (1 Stationary)
Reversing Rod Hole-to-Hole*
Tie Bar Hole-to-Hole**
(A)
(B)
(C)
(D)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length (”)
Comp #
Length (”)
42’-42’-8”
A85361
157
A59081
52
A59081
52
A59021
27
48’
A8539
185
A59116
66
A59116
66
A59021
27
49’3”
A85382
185
A59116
66
A59116
66
A59021
27
*Hole-to-hole measurement is with adjustable spade bolt; cut length of reversing rod 1-1/2” shorter than hole-to-
hole measurement.
**Cut length of tie bar 1-1/2” longer than hole-to-hole measurement.

Assembly & Installation
19
III. Installing Stabilizer Arm Kit
(Stabilizer arm kit is standard with Fastir units ordered after 2007.)
Figure 14 - Stabilizer Arm Assembly on Quad Unit
10 Installation of stabilizer arm requires that
brackets be attached to all carriages (primary,
satellite, and, if present, stationary outside
carriages). All three types of carriages use the
same brackets, which are supplied by Sukup
Manufacturing Co.
11 Bolt center support to center hanger using 2 3/8”
holes in center hanger. Ensure bottom of center
support is flush with bottom of center hanger
assembly. Word “TOP” is etched on center
support (A4530) to aid in positioning.
12 Attach stabilizer arm brackets to primary and
satellite carriages on opposite sides of auger.
13 Adjust U-bolts on stabilizer tube so they are
loose enough to allow primary and satellite
carriages to slide freely.
14 Assemble trolley assembly as described on
page 20 and shown in Figure 15.

Assembly & Installation
20
Stabilizer Kit Trolley Pivot Assembly
Figure 15 - Assembly of Stabilizer Kit Pivot Assembly, Exploded View
Table 8 - Stabilizer Kit Trolley Pivot Assembly Parts List
Ref #
Description
Qty
Comp #
1
Bracket, Plate, Trolley – 4 ½", UHMW
Bracket, Plate, Trolley – 5 ½", UHMW
1
1
A4517
A45171
2
Trolley Bracket Cover
1
A4518
3
Wheel, Trolley, w/ Bushings
2
A6048
3A
Bushing, 1/2” x 3/4” x 3/4”
J0073
3B
Bushing, 1/2” x 3/4” x 1/2”
J0072
4
Flatwasher, 1/2”
6
J1125
5
Lockwasher, 3/8”, PLT
4
J1205
6
Screw, 1/2”-13, 2.5”, GR5, BHCS
5
J07463
7
Screw, 3/8”-16, 1.25”, PLT
4
J0616
8
Nut, Hex, 3/8”-16, PLT
4
J1020
9
Nut, Hex, Lock, 1/2” - 13
5
J1042
10
Roller, Trolley, w/ Bushings
2
A6049
10A
Bushing, 1/2” x 3/4” x 1”
J0074
10B
Bushing, 1/2” x 3/4” x 1/2”
J0072
11
Screw, 1/2”-13, 2.5”, GR5, BHCS
3
J07463
12
Bracket, Bar, Pivot Trolley
1
A45161
13
Shaft, Connect, Pivot Trolley
1
A45131-01
14
Bracket, Weldment, Pivot Trolley
1
A45122
15 If your trolley comes pre-assembled, skip to
Step 20.
16 Add a 1/2” flatwasher to each 1/2” x 2-1/2” bolt
and slide a top trolley pulley onto each, adding
second 1/2” flatwasher on outside of pulleys.
Figure 15.
17 Insert 1/2” x 2-1/2” bolt through roller assembly.
Figure 15.
18 Add 1/2” locknut to each bolt. Figure 15.
19 Insert 1/2” x 2-1/2” bolt through hole on
connecting shaft and slide up through center
extended hole on weldment bracket. Add 1/2”
locknut. Figure 15.
20 Insert 3/8” x 1-1/4” bolts through 2 holes trolley
bracket cover, bracket plate, and bracket bar,
adding 3/8” lockwashers and nuts. Figure 15.
21 Bolt bracket bar to weldment bracket using 2 3/8”
x 1-1/4” bolts pointing down through assembly.
Add 3/8” lockwasher and nut. Figure 15.
21.1 Note: Bracket plate fits over crosstube.
22 Tighten all hardware. Ensure roller turns freely.
