Sun Heat PHTRGH/SS-34 User manual

1
Owner’s Manual
OUTDOOR
PATIO HEATER
MODEL# PHTRGH/SS-34
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call you gas supplier or fire department.
WARNING
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING: For Outdoor Use Only
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent, car or home.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this
equipment.
R
R R
C US
ANS Z83.26-2014 •CSA 2.37-2014 Gas-Fired Outdoor Infrared Patio Heaters

PACKAGE CONTENTS
2
PART
DESCRIPTION
QUANTITY
L
Lower Support (Short)
3
M
Block Belt
1
N
Gas Hose & Regulator
1
O
Wheel Assembly
2
P
Bottom plate
1
Q
Front Panel
1
A Reflector
B Mesh
C Glass Tube Fixer
D Ceramic Fiber
E Top Plate
F Glass Tube
G Upper Support (Long)
H Protective Guard
I Side Panel
J Black Silicone Ring
K Control Box Assembly
L Lower Support (Short)
M Block Belt
N Gas Hose & Regulator
O Wheel Assembly
P Bottom plate
Q Front Panel
PART
DESCRIPTION
QUANTITY
A
Reflector
1
B
Mesh
1
C
Glass Tube Fixer
1
D
Ceramic Fiber
1
E
Top Plate
1
F
Glass Tube
1
G
Upper Support (Long)
3
H
Protective Guard
3
I
Side Panel
2
J
Black Silicone Ring
1
K
Control Box Assembly
1

3
HARDWARE CONTENTS (shown actual size)
DANGER
CARBON MONOXIDE HAZARD
This appliance produces
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent, car or home.
AA BB
Wing nut
Qty.3
Small Flat
Washer
Qty.6
CC DD
Stud
Qty.3
M5 x 12 mm Screw
Qty.31
EE
M6 x 12 mm Bolt
Qty.8
FF
FixingBracket
Qty.3
GG
HH
Knob
Qty.1
M4 x 10 mm
Screw
Qty.1
II
Chain
Qty.1
JJ KK LL MM
Long Stem Lighter
Qty.1 Wrench
Qty.1
PhillipsScrewdriver
Qty.1
AA Battery (1.5 V)
Qty.1
SAFETYINFORMATION
This manual contains important information about the assembly, operation and maintenance of
this patio heater. General safety information is presented in these first few pages and is also
located throughout the manual. Keep this manual for future reference and to educate new users
of this product. This manual should be read in conjunction with the labeling on the product. Safety
precautions are essential when any mechanical or propane fueled equipment is involved. These
precautions are necessary when using, storing, and servicing this patio heater. Using this equipment
with the respect and caution demanded will reduce the possibilities of personal injury or property
damage. The following symbols shown below are used extensively throughout this manual. Always
follow these precautions, as they are essential when using any mechanical or fueled equipment.
DANGER
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
DANGER
Failure to comply with the precautions and instructions
provided with this heater can result in death, serious
bodily injury and property loss or damage from
hazards of fire, explosion, burn, asphyxiation, and/or
carbon monoxide poisoning. Only persons who can
understand and follow the instructions should use or
service this heater.

4
SAFETYINFORMATION
DANGER DANGER
•EXPLOSION - FIRE HAZARD
•Keep solid combustibles, such as building materials,
paper or cardboard, a safe distance away from the
heater as recommended by the instructions.
•Provide adequate clearances around air openings
into the combustion chamber.
•Never use the heater in spaces which do or may
contain volatile or airborne combustibles, or products
such as gasoline, solvents, paint thinner, dust particles
or unknown chemicals.
•During operation, this product can be a source of
ignition. Keep heater area clear and free from
combustible materials, gasoline, paint thinner, cleaning
solvents and other flammable vapors and liquids. Do
not use heater in areas with high dust content.
Minimum heater clearances from combustible
materials: 36" (91 cm) from the sides & 24" (61 cm)
from the top.
DANGER
•EXPLOSION - FIRE HAZARD
•Never store propane near high heat, open flames,
pilot lights, direct sunlight, other ignition sources or
where temperatures exceed 120 degrees F (49°C).
•Propane vapors are heavier than air and can
accumulate in low places. If you smell gas, leave the
area immediately.
•Never install or remove propane cylinder while heater
is lit, near flame, pilot light, and other ignition sources or
while heater is hot to touch.
•This heater is red hot during use and can ignite
flammables too close to the burner. Keep flammables
at least 36" (91 cm) from sides & 24" (61 cm) from top.
Keep gasoline and other flammable liquids and vapors
well away from heater.
•Store the propane cylinder outdoors in a well ventilated
space out of reach of children. Never store the propane
cylinder in an enclosed area (house, garage, etc.). If
heater is to be stored indoors, disconnect the propane
cylinder for outdoor storage.
•CARBON MONOXIDE HAZARD
•This heater is a combustion appliance. All
combustion appliances produce carbon monoxide
(CO) during the combustion process. This product is
designed to produce extremely minute, non-hazardous
amounts of CO if used and maintained in accordance
with all warnings and instructions. Do not block air
flow into or out of the heater.
•Carbon Monoxide (CO) poisoning produces flu-like
symptoms, watery eyes, headaches, dizziness, fatigue
and possibly death. You can't see it and you can't
smell it. It's an invisible killer. If these symptoms are
present during operation of this product, get fresh air
immediately!
•For outdoor use only.
•Never use inside house, or other unventilated or
enclosed areas.
•This heater consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid endangering
your life.
CAUTION
SERVICE SAFETY
•Keep all connections and fittings clean. Make sure
propane cylinder valve outlet is clean.
•During set up, check all connections and fittings for
leaks using soapy water. Never use a flame.
•Use as a heating appliance only. Never alter in any
way or use with any device.
CAUTION
CAUTION indicates an imminently hazardous situation
which, if not avoided, may result in minor or moderate
personal injury, or property damage.
CAUTION
An appliance may be installed with shelter no more
inclusive than:
(a) With walls on all sides, but with no overhead cover.
(b) Within a partial enclosure which includes an overhead
cover and no more than two side walls. These side walls
may be parallel, as in a breezeway, or at right angles to
each other.
(c) Within partial enclosure which includes an overhead
cover and three side walls, as long as 30 percent or
more of the horizontal periphery of the enclosure is
permanently open.

5
SAFETYINFORMATION
WARNING WARNING
California Proposition 65
Combustion by-products produced when using
this product contain chemicals known to the State
of California to cause cancer, birth defects, and
other reproductive harm.
WARNING
BURN HAZARD
•Never leave heater unattended when hot or in use.
•Keep out of reach of children.
WARNING
•This product is fueled by propane gas. Propane gas
is invisible, odorless, and flammable. An odorant is
normally added to help detect leaks and can be
described as a “rotten egg” smell. The odorant can
fade over time so leaking gas is not always detectable
by smell alone.
•Propane gas is heavier than air and leaking propane
will settle to the lowest level possible. It can ignite by
ignition sources including matches, lighters, sparks or
open flames of any kind many feet away from the
original leak. Use only propane cylinders set up for
vapor withdrawal.
•Store or use propane gas in compliance with local
ordinances and codes or with ANS/NFPA 58. Turn off
propane when not in use.
Certain materials or items, when stored under the
heater, will be subjected to radiant heat and could be
seriously damaged.
WARNING
WARNING
We cannot foresee every use which may be made of
our heaters.
Check with your local fire safety authority if you have
questions about heater use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local
authorities can advise you about these.
In Canada, installation must conform to local codes. If no
local codes exist, follow the current National standards of
CANADA CAN/CGA-B 149.2.
•Alert children and adults to the hazards of high surface
temperatures. Stay away from these surfaces to avoid
burning skin or igniting clothing.
•Carefully supervise young children when in the vicinity
of the heater.
•Do not hang clothing or any other flammable materials
from the heater, or place on or near the heater.
•Replace any guard or protective device removed for
servicing the appliance prior to placing back in service.
•Installation and repair should be done by a qualified
service person. The heater should be inspected before
use and annually by a qualified service person. More
frequent cleaning may be required as necessary. It is
imperative that the control compartment, burners, and
circulating air passageway of the appliance be kept
clean.
WARNING
PREPARATION
WARNING: This product contains small batteries.
Swallowed small batteries can cause CHOCKING
HAZARD. Seek immediate medical attention if batteries
are swallowed or inhaled. Keep children away from the
small batteries.
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Estimated AssemblyTime: 90 minutes
Tools Required for Assembly (not included):
Phillips screwdriver w/ medium blade. Leak Detection Solution.
