ST-290PC User Manual
1. ST-290PC Main Features
1. Record checking and removing
2. Key Lock function
3. Battery saving mode
4. Counting function
5. Compatible with both battery/power adaptor
6. USB connection with PC
2. ST-290PC Key Advantages
Convenient operation with Light weight
Automatic Hourly Data updating
Record Removing function
1.15 Inch Blue LCD screen makes it easy on the eyes
Cache Memory Capacity up to 500pcs messages (Recorded Every hour)
Counting distance spans from 0.8M to 4M
Adjustable LCD background light turns on/off when only people access
Lower battery indicator on LCD screen
Two languages for operation (English/ Chinese)
Signal Indicator gives warning for weak signal
Extended battery life with power supply
Key Lock function eliminates improper operation
Counting Data available on the LCD interface
3. Operation Guide
1. Record checking and removing
1）Record Query
Press , then press or to select”Record Query”, Press and enter in
“Record Query”
Press or to check counting number in certain day
Press , then press or to check counting number of certain period in
certain day
2）Record Removing
Press , then press or to select “Record Query”, press or to select
“Record Removing”;
Press and removing record
Remarks: Press <Exit> to come back to the main screen.
2. Key Lock Function
This is designed to eliminate improper operation by unauthorized person
Press and then press , the key board is locked and screen shows “System
locked”
Low-cost people counter

2
Press and then press , key board is unlocked，and screen resume to main
interface
Remarks: Press <Exit> to come back to the main screen.
3. Clock
1）Set Up Time
Press , then press or , and select”time setting” then press to enter
in”time setting”;
Press or to select”Current time”, press to enter in”current time”;
Press or set up”Year”, press to confirm;
Press or set up”Month”, press to confirm;
Press or set up”Day”, press to confirm;
Press or set up”Minute”, press to confirm;
Press or set up”Second”, press to confirm.
Remarks: Press <Exit> to come back to the main screen.
2）Auto On/Off
Set up clock to turn on/off counting device
Press ,then press or ,and select“time setting”， press to enter in “time
setting”;
Press or ,and select “Timer setting”, Press to confirm；
Press or to set “Power On Timer”, press to confirm；
Press or to set “Power off Timer”, press to confirm。
Remarks: Press <Exit> to come back to the main screen.
4. System Setting
1）Battery Saving Mode
Press , then press or ,select “system setting”, press to confirm．
Press or ,select “battery saving mode”, press to confirm．
Press or ,select “on/off”, press to confirm．
Remarks: Press <Exit> to come back to the main screen.
2）Sensitivity Setting（Detection distance and accuracy）
Press ,then press or ，select “system setting”, press to confirm;
Press or , select “Sensitivity Setting”, press to confirm;
Press or ,select “high／medium／low”, press to confirm.
Remarks:
Suggested to select high sensitivity for high volume to raise power sensitivity
Suggested to select low sensitivity for low volume to extend battery life
The red LED on receiver flashes, when transmitter is placed away from
receiver far than accurate distance. It is suggested to move both part closer to
solve this problem.
Language Setting
Low-cost people counter

3
3）Language Setting
Press , then press or , select “system setting”, press to confirm;
Press or , select “language setting”, press to confirm;
Press or , select”Chinese” or”English”, Press to confirm.
Remarks: Press <Exit> to come back to the main screen.
4、Notice
（1）Optimal Detection Height: 0.5m ≤The position of transmitter and receiver
≤1.5m ，receiver and transmitter is placed at same height with opposite
direction.
（2） Optimal Detection Distance：Max Distance is 4M，Min Distance ≥0.8m
(Transmitter and receiver should be placed at same height with distance ≤3
mm）
（3）LED indicator flashes every second when voltage ≤2.3V or transmitter and
receiver don’t have connection signal.
（4）In order to save battery, display screen uses low brightness with faster
refresh frequency
5、Installation of battery and power adaptor
1）Installation of Battery
1）Put two 1.5V SIZE AA batteries into each set of the people counter's back
battery housing
2）The Red LED indicator flashes every 6 second when battery in normal
status, and flashes every 1 second in low battery status
3）The clock setting is needed after replacing battery.
4）The clock setting will be saved after replacing battery when connecting with
computer via USB Cable,
5）The Alkaline Battery is recommended. Rechargeable Battery might lead to
installation difficulties due to the differences size and measurement.
2）Installation of Power Adaptor
Plug the cable head into transmitter hole and work（same for receiver）
Remarks: 1. Power Adaptor can be used together with battery
2. This people counter could equip with either Chinese
Standard adaptor or Euro Standard adaptor or American
Standard adaptor according to customer requirement.
6、PC Connection
1. PCTools installation
Step 1, place installation CD in CD-ROM, and double click “PEOPLE
Low-cost people counter

4
COUNTER” folder
Step 2
Double Click“data output” file
（As showed in left graph）
Step 3
Click“Next Step”Button
（As showed in left graph）
Step 4
Click“Next Step”Button
（As showed in left graph）
Step 5
Click “Next Step” Button
（As showed in left graph）
Low-cost people counter

5
2. USB Connection Setting
Place installation CD in CD-ROM, and plug the bigger USB cable head into
computer USB port and finish connection. “New hardware is available” will
showed on screen.（As showed in bellow graphs）
Step 6
Click “Close” to finish installation
（As showed in left graph）
Step 1,
Choose “Auto Run” to begin
installation，click “Next Step”.
（As showed in left graph）
Step 2,
Click “Close” to finish drive
installation
（As showed in left graph）
Step 3,
Double Click PCTools on the
desktop
（As showed in left graph）
Low-cost people counter

6
3. Download Data to Computer
1. Click “Menu” on the tool bar
2. Click “Save” as showed bellow
3.Input name in the folder bar, like “ST-290PC”，and click “save”
4. Double click the folder “ST-290PC” on the desktop
Remarks：1、Data can be read only on computer which can’t be removed
on computer
2、Data in certain period of certain day can be read or
Step 4,
Click “Activate” Button on the
tool bar
（As showed in left graph）
Step 5,
Click input program on the tool
bar
（As showed in left graph）
Step 6
Click “D” or “W”, or “M” to check records
in different period of day
“D” means the records in whole day
“W” means the records in whole week；
“M” means the records in whole month
Low-cost people counter

7
removed directly on people counter
3、Further system updating might not be listed in user manual.
7、Package Contents
ST-290PC Transmitter （1）
ST-290PC Receiver （1）
USB Cable （1）
CD-ROM （1）
Power Adaptor （2）
Fastening Adhesive Tape （2）
Mounting Hooks(Concave) （2）
Mounting Hooks(Convex) （2）
M3X15 Screws （4）
Low-cost people counter
