Sun-Tech SunTech 247 User manual

Attaching the Wall Bracket
2.
Attaching the BP Module
4b.
Attaching the Wall Bracket Adaptor
3.
Attaching the Wall Basket
5.
Pieces & Parts
1.
Attaching the BP Module
4a.
BLOOD PRESSURE MODULE WALL MOUNT INSTALLATION GUIDE
part # 82-0064-00 Rev B.
7x 7x 7x3x
1x Wall Bracket 1x Wa l l
Bracket Adaptor
1x Wall Basket
Wa l l
BP
Module
Battery
Cover
BP
Module
Battery
Cover
Wa l l
Wa l l
Wa l l
Wa l l
BP
Module
Pull the
BP Module
down until
it snaps
into place.
Wa l l

Replacing an ADC Wall Aneroid
2.
a. Remove the screw at the bottom of the basket behind
the wall aneroid.
b. Remove the aneroid.
c. Remove the top two screws connecting the basket to the
wall.
d. Slide the basket up and towards you to remove it from
the wall.
Replacing a Medline Wall Aneroid
3.
Replacing a Welch Allyn Wall Aneroid
1.
BLOOD PRESSURE MODULE WALL MOUNT REPLACEMENT GUIDE
part # 82-0064-00 Rev B.
Applicable
Hole Pattern
a. Remove the screws at the top and the bottom of the wall
aneroid.
b. Remove the aneroid.
c. Remove the screws attaching the bracket to the wall.
a. Remove the screws at the top and the bottom of the wall
aneroid.
b. Remove the aneroid.
c. Remove the screws attaching the bracket to the wall.
Applicable
Hole Pattern
Applicable
Hole Pattern
