User's Manual of mLabs®Smart
1 Introduction
1.1 Intended Use
The mLabs®Smart is designed to be used with mLabs®Test Cartridges manufactured by
Micropoint Biotechnologies Co., Ltd., hereinafter referred to as “Micropoint”, to perform tests
in clinical laboratories by using immunofl uorescence technique.
1.2 Product Contents
The mLabs®Smart, shown in Figure 1-1, consists of a motherboard module, a built-in printer, a
touchscreen, a test module, a cartridge tray, an incubation track, cartridge-push components, a
power module, an IC card reading module, a barcode scanning module, and a shell.
Figure1-1 mLabs®Smart
1.3 List of Accessories
The following accessories are provided with this device:
1* Power cord
1* Calibration cartridge
1* Waste box
1* Printer paper roll
1* Pipette
For other accessories, please see the Packing List.
1.4 Technical Speci cations
Display screen 264mm(10.4 in.) LCD
Keyboard Touchscreen
I/O USB*1 Ethernet*1
Printer Built-in 50 mm (2 in.) DIA thermal printer
Wireless(reserved) WiFi
OS window7
Language English, Deutsch, Espanol, Francais, Italiano,
Portugues
Memory 4G
Dimension 550*355*260 (L×W×H)

User's Manual of mLabs®Smart
2
Weight 14KG
Power AC100-240V
Operating environment Temperature:10℃-35℃
Humidity: 5%-90%RH
Warranty period 2 years
1.5 Contraindications, Precautions, Cautions and Warnings
This meter has no contraindications and is for in vitro diagnostic use only. Before using please
carefully read and strictly adhere to the following cautions and warnings.
Warnings on Electrical Safety
zDo not plug the power cord into any power socket other than one of AC 110/220V.
Failure to do so may result in re or electric shock.
zUse only the provided power cord to ensure proper grounding. Failure to do so
may result in re or electric shock.
zDo not damage the insulation sheath of the power cord. Do not pull on the power
cord or hang heavy objects on the cord. Failure to do so may result in circuit-breaking
or short-circuiting, which may then cause electric shock or re.
zBefore connecting a peripheral meter, disconnect the power. Failure to do so may
result in electric shock or malfunction.
zThis meter should be kept at least 30cm away from the wall to facilitate the
connection or heat dissipation.
zOnly Micropoint-authorized service personnel are allowed to disassemble the
inside modules and components of the meter.
zIf there is an abnormal smell or smoke, immediately turn off the power and
unplug the power plug from the power socket to prevent re, personal injury or
death. Contact your Micropoint distributor or agent as soon as possible to perform an
inspection and servicing.
zDo not spill test samples or reagents on the meter, since chemical liquids and
metallic objects may result in short-circuiting or re.
Warnings on Biological Risk
zUsed cartridges and other consumables should be disposed of as medical waste or
infectious waste.
zWhile performing maintenance and inspections, always wear protective gloves
and use the specied tools. Wash your hands with disinfectant after nishing such
operation. Fail to do so may cause infection in the skin exposed to the blood.
zAlways take care and wear protective gloves while handling samples. Fail to do so
may result in infection. If the sample gets into eyes or wounds, immediately wash it
off with plenty of clean water and see the doctor.
zUsed cartridges should be discarded into a designated medical waste container.
