Sun Yeh Electrical OME Series User manual

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
OME Series
Explosion-Proof
Quarter-Turn
Electric Valve Actuator
Operation Manual
SY07-C001A-EN

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
Contents
1General Information..................................................................................................................................1
1.1 Safety Instructions.......................................................................................................................... 1
1.2 Installation Notices......................................................................................................................... 1
1.3 Working Conditions........................................................................................................................ 3
1.4 Standards ........................................................................................................................................ 3
1.5 Inspection, Storage, Transport........................................................................................................ 5
2Product Overview......................................................................................................................................6
2.1 Features........................................................................................................................................... 7
3Product Mechanical Data ..........................................................................................................................7
3.1 Parts Identification.......................................................................................................................... 7
3.2 Technical Information .................................................................................................................... 8
3.3 Mounting Base Details................................................................................................................... 8
3.4 Actuator Selection .......................................................................................................................... 9
3.5 Sizing.............................................................................................................................................. 9
3.6 Duty Cycle.................................................................................................................................... 10
3.7 Flamepath Joint ............................................................................................................................ 11
3.8 Nameplate Details ........................................................................................................................ 12
4Mounting And Setup ...............................................................................................................................13
4.1 Handwheel Installation................................................................................................................. 13
4.2 Value Mounting Instructions ........................................................................................................ 14
4.3 Wiring Instructions....................................................................................................................... 15
4.4 Actuator Setup.............................................................................................................................. 16
4.5 Adjustment Steps.......................................................................................................................... 16
5Modulating Control Board Adjustment...................................................................................................21
5.1 Modulating Control Board Surface.............................................................................................. 21
5.2 Procedure...................................................................................................................................... 21
5.3 Dip Switch Setting (SW1)............................................................................................................ 22
5.4 Sensitivity Switch Setting (SW2)................................................................................................. 25
5.5 Settings for OPEN and CLOSE.................................................................................................... 25
6Troubleshooting.......................................................................................................................................30
7Warranty..................................................................................................................................................32

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
1
1General Information
Failure to follow safety instructions may cause serious injury, equipment damage, or voided
warranty.
1.1 Safety Instructions
Installation, maintenance and repair works must be performed by trained personnel.
The handling shall follow the safety and warning instruction contained in this manual.
The user should read and follow instructions contained in this operation manual included with
the product. Failure to do this may result in damages and void warranty. Sun Yeh will not be
liable for damages due to operator negligence or misuse.
Local health and safety legislation shall be complied with.
In a few cases, the surface temperature may exceed 60°C (140 ℉). Please check the surface
temperature before operation, using an appropriate thermometer and wearing protective gloves
before operation.
1.2 Installation Notices
All setting of opening the cover must be made in the safe place, prevent the spark from
making the possibility of explosion.
Operating by handwheel: Do not use excessive force when operating the handwheel as this
can damage the actuator or valve.
1.2.1 General
DO NOT install in ambient temperatures that exceed 70 °C (158 °F).
DO NOT, under any circumstances, remove the cover of the actuator while in a hazardous
location when the power is still live inside the actuator. This could cause ignition of a
hazardous atmosphere.
DO NOT, under any circumstances, use an explosion-proof electric actuator in a hazardous
location that does not meet the specification which the actuator was designed for.
Mount, test, and calibrate actuators in non-hazardous location.
When removing the actuator, care must be taken not to scratch, scar or deform the flame
path of the cover or base of the actuator. That will negate the protection rating of the
enclosure in a hazardous location.
The explosion proof electric actuator is shipped with mating surfces of the cover and base.
When assembling them, pay attention to the mating number (QA code) to assure the
protection rating in a hazardous location.

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
2
Please read operation manual and wiring diagram carefully before installation.
Verify that supply voltage is in accordance with the data on nameplate to prevent short
circuit or electrical/electronic parts damage caused by incorrect power input.
Turn power off before wiring or maintenance.
There are grounding devices both inside and outside of the actuator and the ground wires
should be connected properly.
The metal plugs in conduit entries are for transit only. For long term protection fit suitable
flameproof cable gland and power cable should be with a minimum withstand
temperature105 °C (221°F). Please refer to 1.2.3 (P.3).
To avoid functional failure caused by static, do not touch any components on the PCB with
metal tools or bare hands.
Do not parallel wire multiple actuators together without using an extra relay.
Use proper techniques when installing conduit and properly seal the connection. Do not
mount the actuator with conduit entries in upright position to prevent condensation from
entering the unit.
Actuator should be installed in an upright or horizontal position. Do not mount upside
down or below a horizontal position.
Periodically inspect actuator enclosure to prevent dust from accumulating.
Perform below inspections prior to installation. Not allowed to adopt if any item is
unqualified.
Check the marking and certificate number to see if it conforms to the indicated
application.
All the parts of the housing are assembled in the right manner and fastened.
USE FASTENERS WITH YIELD STRESS ≥ 700MPa.
All the explosion-proof parts should be made without cracks or functional defects.
1.2.2 CSA Certification Considerations
KEEP COVER TIGHT WHILE CIRCUITS ARE ALIVE.
AFTER DE-ENERGIZING, DELAY 10 MINUTES BEFORE
OPENING THE COVER.
SEAL REQUIRED WITHIN 18 INCHES (450 mm) OF ENCLOSURE (for Divisions
only).
SEAL REQUIRED WITHIN 2 INCHES (50 mm) OF ENCLOSURE (for Zones only).

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
3
1.2.3 Cable Glands
Please select the relatively explosion-proof cable connector according to the
product specifications.
ATEX / IECEx / TS Certification：
The actuator is delivered with two conduit entries plugged by metal plugs. Use cable
glands with ATEX / IECEx / TS certification and in accordance with the technical
characteristics required by Ex db IIB Gb, Ex tb IIIC Db. The electrical supply cable
must be suitable for power rating and with a minimum withstand temperature 105 °C
(221 °F).
CNEx Certification：
The actuator is delivered with two conduit entries plugged by metal plugs. Use cable
glands with CNEx certification and in accordance with the technical characteristics
required by CNEx Ex db IIB Gb, Ex tD A21 IP68. The electrical supply cable must be
suitable for power rating and with a minimum withstand temperature 105 °C (221 °F).
CSACertification：
The actuator is delivered with two conduit entries plugged by metal plugs. Use cable
glands with CSA certification. The electrical supply cable must be suitable for power
rating and with a minimum withstand temperature 105 °C (221 °F).
1.3 Working Conditions
ATEX / IECEx / CNEx / TS Certification：
Atmospheric pressure：80 - 110 kPa.
Ambient temperature：- 30 °C to + 70 °C (- 22 °F to + 158 °F).
Relative humidity：Not more than 95 % (+ 25 °C / 77 °F).
The actuator can operate normally within tolerated variation of ± 10% of rated supply.
voltage or ± 1% of rated frequency.
CSACertification：
Atmospheric pressure：80 - 106 kPa.
Ambient temperature：-30 °C to +70 °C (-22 °F to +158 °F).
Air with normal oxygen content：21 % (Volume).

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
4
1.4 Standards
ATEX European Hazardous Area：EN60079-0, EN60079-1, EN60079-31
Directive
Group
Ambient Temperature
ATEX II 2 GD
Ex db IIB T4 Gb
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
ATEX II 2 GD
Ex tb IIIC T130 °C Db
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
IECEx International Hazardous Area：IEC 60079-0, IEC 60079-1, IEC60079-31
Group
Ambient Temperature
Ex db IIB T4 Gb
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
Ex tb IIIC T130 °C Db
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
North American Hazardous Area：
Zone System：
CAN/CSA-C22.2 No. 0-10, CAN/CSA-C22.2 No. 60079-0, CAN/CSA-C22.2 No. 60079-1,
CAN/CSA-C22.2 No. 60079-31, UL 60079-0, UL 60079-1, UL 60079-31
National
Conformity
Class
Zone
Protection
Method
Groups
T-Code
Ambient Temperature
AEx / Ex
I
1
db
IIB, IIA
T4
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
AEx / Ex
II
21
tb
IIIC, IIIB, IIIA
T130°C
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
Division System：
CAN/CSA-C22.2 No. 0-10, CSA C22.2 No. 30-M1986, CSAC22.2 No. 25-17,
FM 3600, FM 3615, FM 3616
Class
Division
Groups
T-Code
Ambient Temperature
I
1
C,D
T4
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
II
1
E,F,G
T130°C
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
CNEx Certification：GB3836.1, GB3836.2, GB12476.1, GB12476.5
Group
Ambient Temperature
Ex db IIB T4 Gb
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
Ex tD A21 IP68 T130°C
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
TS Certification：CNS3376-0, CNS3376-1, IEC60079-31
Group
Ambient Temperature
Ex db IIB T4 Gb
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )
Ex tb IIIC T130°C Db
- 30 °C to + 70 °C ( - 22 °F to + 158 °F )

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
5
1.5 Inspection, Storage, Transport
1.5.1 Receiving / Inspection
Carefully inspect the package for any damages resulting from shipping and report all
damages to the freight carrier and seller.
After unpacking the product and information packet, please keep the cartons and any
packing materials in case of product return or replacement. Verify that the items listed in
packing slip or in bill of lading are the same as what were ordered. If there is any
discrepancy, please contact the seller.
Verify that the technical data on nameplate is in accordance with what was ordered.
1.5.2 Storage
The actuator should be stored in a dry area with relative humidity of less than 90 %（20 ± 5
°C）and at temperature between -20 °C to + 40 °C (-4 °F to + 104 °F).
The product shall be stored with suitable protection from corrosive substance that can
damage the metal and insulating parts.
The metal plugs for temporary protection should not be removed until the actuator is ready
to be cabled. Use suitable flameproof cable glands to ensure IP rated protection when
installing. Please refer to 1.2.3 (P.3).
1.5.3 Transport
Attach ropes or hooks for the purpose of lifting by hoist only to housing and not to
handwheel.
Actuators packaged in cartons can stand up to land, sea, or air transportation.
Packaged actuators shall avoid of violent impact and strong vibrations and be protected
from rain or snow.
1.5.4 Lubrication
The gear train has been sufficiently lubricated at the factory. No additional lubrication is
required.

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
6
2Product Overview
OME series explosion-proof quarter-turn electric actuators offer torque ranges from 35Nm to
1,500Nm ( 310 in.lb to 13,280 in.lb ). Product design is based on a self-locking worm drive principal,
which provides for a smooth running, dependable, robust drive system. All models are ISO 5211 compliant,
have a visual position indicator on top of actuator cover and manual override except OME-A. The manual
operation is non-clutch design that can be operated without any lever, clutch or brake upon power outage.
ATEX / IECEx / CNEx / TS Explosion-proof instructions：
OME series Explosion-proof Quarter-turn Electric Valve Actuator (referred as "actuator") is a
control device for valves and can be used in the places, where is classified as Zone 1 or Zone 2,
contained GroupⅡA and GroupⅡB gases, Zone 21 or Zone 22, contained the combustible dust
atmosphere or the mixture circumstance with the explosive gas atmospheres and the combustible
dust atmospheres. Temperature group T1-T4.
Certificate Number：
Sira17ATEX1243X
IECEx SIR17.0062X
CNEx17.2492X
(ITIR) 2018 No.07-00013
CSA explosion-proof instructions：
Division System where is classified as North American Division 1 or Division 2 of hazardous
location, contains Group C and Group D gases and temperature group T1 - T4; or contains one
or several flammable dusts with minimum flaming point over 130 °C; or include both above
flammable gases and dusts.
Zone System where is classified as North American Zone 1 or Zone 2 of hazardous location,
contains Group ⅡA and Group ⅡB gases and temperature group T1 - T4; or in Zone 21 or
Zone 22, contained one or several flammable dusts with the minimum flaming point over 130
°C; or include both above flammable gases and dusts.
Certificate Number：
70156877

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
7
2.1 Features
Enclosure conforms to IP68 (7 m / 72 hrs).
High alloy-steel gear trains with elf-locking prevent back-drive.
Clutch-less manual override.
ISO 5211 mounting flange.
Mechanical end stops.
Flatted position indicator.
Built-in motor thermal protection.
3Product Mechanical Data
3.1 Parts Identification
Actuator Top Cover
Top Cover Screw
Position Indicator
Casting End Cap
Handwheel
Nameplate
Mechanical End Stops
Conduit Entries Flamepath Joint

Explosion-Proof Quarter-Turn Valve Actuator【OME Series】Sun Yeh Ele. Ind. Co., Ltd. | 2019.07
8
3.2 Technical Information
Model
Torque
Weight
Moto Power
Manual Override
Mounting Flange
Nm
inlb
kg
lb
Watt
ISO 5211
OME-1
35
310
2
4
10
Lever
F03 / F05
OME-AM
50
445
3
7
10
F07
OME-A
50
445
3
7
10
N/A
F07
OME-2
90
800
18
40
40
Handwheel
F07
OME-3
150
1330
18
40
40
F07
OME-4
400
3540
32
71
80
F10
OME-5
500
4430
32
71
80
F10
OME-6
650
5755
32
71
80
F10
OME-7
1000
8855
46
101
120
F12 or F14
OME-8
1500
13280
46
101
120
F12 or F14
3.3 Mounting Base Details
Model
Mounting Flange
Shaft (A)
Depth of Shaft (B)
ISO 5211
mm
inch
mm
inch
OME-1
F03 / F05
14
0.551
17
0.669
OME-A
F07
17
0.669
20
0.787
OME-AM
F07
17
0.669
20
0.787
OME-2 to OME-3
F07
22
0.866
30
1.181
OME-4 to OME-6
F10
36
1.417
48
1.889
OME-7 to OME-8
F12 or F14
36
1.417
50
1.968
