Sunbeam MIXMASTER 2366 User manual

Instruction Manual
DELUXE MIXMASTER ® MIXER
Manuel d’Instructions
BATTEUR DE LUXE MIXMASTER ®
Manual de Instrucciones
BATIDORA MIXMASTER ® DE LUJO
Manual de Instruções
BATEDEIRA DE LUXO MIXMASTER ®
MODELS/MODELOS
MODÈLES/MODELOS
2366,2367,2368 &2369
MODELS/MODELOS
MODÈLES/MODELOS
2366,2367,2368 &2369

2
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. READ ALL INSTRUCTIONS BEFORE USING THE MIXER.
2. To protect against risk of electrical shock, do not put Mixer
in water or other liquid. This may cause personal injury
or damage to the product.
3. Close supervision is necessary when Mixer is used by or near
children or incapacitated persons.
4. Unplug from outlet while not in use, before putting on or
taking off parts and before cleaning.
5. Avoid contacting moving parts. Keep hands, hair, clothing,
as well as spatulas and other utensils away from beaters
during operation to reduce the risk of injury to persons and/or
damage to the Mixer.
6. Do not operate Mixer with a damaged cord or plug or after
the appliance malfunctions, or is dropped or damaged in any
manner. Return appliance to the nearest Sunbeam Appliance
authorized service center for examination, repair or electrical
or mechanical adjustment.
7. The use of attachments not recommended or sold by Sunbeam
may cause fire, electrical shock or injury.
8. Do not use outdoors or for commercial purposes.
9. Do not let cord hang over edge of table or counter or touch
hot surfaces, including the stove.
10. Remove beaters from Mixer before washing.
IMPORTANT SAFEGUARDS

3
11. Do not place Mixer or bowls on or near a hot gas or
electric burner, or in a heated oven.
12. Do not use Mixer for other than intended use.
13. Do not leave Mixer unattended while it is operating.
THIS UNIT IS FOR HOUSEHOLD USE ONLY
When your Mixmaster®Mixer is first used, you may experience
an odor and possibly a slight wisp of smoke from your mixer motor.
This is caused by the heat curing of the insulation which protects the
motor and is normal. After the first few uses, this effect will disappear.
FOR PRODUCTS PURCHASED IN U.S & CANADA ONLY:
To reduce the risk of electrical shock, this appliance has a polarized
plug (one blade is wider than the
other). As a safety feature, this plug
will fit in a polarized plug only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician.
DO NOT ATTEMPT TO DEFEAT THIS
SAFETY FEATURE.
SAVE THESE INSTRUCTIONS

4
1. Beater Ejector
2. Large Mixing Bowl
3. Small Mixing Bowl
4. Bowl-Fit Beaters
5. Turntable
6. Dough Hooks*
7. Stand
8. Headlock
9. Mixer-Release Trigger
10. Burst of Power®
11. Speed Control Dial
12. Turntable Locator Switch
*Some models do not have
Dough Hooks.
FEATURES
Thank you for choosing the Sunbeam®
Mixmaster®Mixer. For generations we have
been helping cooks prepare moist cakes,
light and fluffy meringue and chewy cookies.
You can even make bread dough with your
Sunbeam®Mixmaster®Mixer.
The Sunbeam®Mixmaster®Mixer offers
a choice of 12 different mixing speeds.
The bowl-fit beaters and bowls have been
designed to mix ingredients thoroughly
and evenly.
No problem ejecting the beaters either – just
push the ejector button beside the handle.
You’ll love being able to make so many
things with your mixer!
1
2
3
4
5
12 6
7
8
9
11
10

5
ASSEMBLING THE STAND MIXER
Before assembling the mixer, be
sure the speed control dial is in the
OFF position and the electric cord
is unplugged.
ATTACHING THE TURNTABLE
Place the revolving turntable into
the base of the stand by pressing the
turntable into the center hole of the
adjustment slot until it snaps into place.
ADJUSTING THE TURNTABLE
The turntable must be adjusted
depending upon which bowl size is
being used (see “Adding the Mixing
Bowl”). To adjust, press down on the
turntable locator switch and slide switch
to the proper icon.
Attaching and Removing the Mixer Head
To attach the mixing head, press in on
the mixer-release trigger, located at the
rear of the stand.
Place the mixer head on the stand so
that the metal pivot on the bottom of
the mixer head goes into the latched
opening on the top of the stand.
As you release pressure from the
mixer-release trigger, the top of the
latch should clamp around the
metal pivot. Once the mixing head
is lowered into position, it will lock
into place.
To raise the mixing head, press the
head lock button downward while
pulling up on the handle of the mixing
head. Once unlocked, the mixing head
can be removed by pressing the mixer
release trigger.
Be sure the mixer head is securely
in position before using.
NOTE: This mixer is NOT intended
for use away from the stand.
ADDING THE MIXING BOWL
Move the turntable locator switch to the
proper setting - the large bowl icon if
you are using the large bowl; the small
bowl icon if you are using the small
bowl. Place the desired mixing bowl
onto the turntable.
Mixing bowls should NEVER be used in
a conventional oven, microwave oven,
on top of the range or on any other
heated surface.
If mixing bowls are scratched
or chipped, do not use mixer. Mixer
bowl should not be used to blend in
hot liquids.
Mixer-Release
Trigger
Latched Opening
Ball Bearing
Extension
Mixer
Head
Mixer-Release
Trigger
Metal
Pivot
Stand

6
ATTACHING THE BEATERS
Be sure the speed control dial is in the
OFF position and unplug electric cord
from the electrical outlet.
Lift mixer head up and back to pull it
out of the way of the bowl.
NOTE: It is important that the beaters
go into the correct sockets. Otherwise
the mixer will not give you the proper
mixing action. Do not risk ruining a
recipe or damaging your mixer. Read
the following instructions carefully.
One of the beaters is conical in shape
and has a nylon button on the bottom.
It goes into the socket on the side of
the mixer nearest the side of the bowl.
The other beater is square-shaped and
goes into the socket nearest the center
of the bowl. See beater symbols located
on the bottom of the mixer head.
Insert the beaters, one at a time,
using a combination pressing and
twisting motion, until the beaters
snap into position.
If a beater should not properly snap
into place, pull it out of the socket
and rotate it one quarter turn.
Reinsert the beater into the socket
until it snaps into position.
Attaching the Dough Hooks
(Some Models Only)
Set the speed dial in the OFF position
and unplug the electric cord from the
electrical outlet.
Lift mixer head up and back to tilt it out
of the way of the bowl, while holding in
an upright position.
NOTE: The dough hooks must go into
the correct sockets. The mixer will
operate with the dough hooks in the
wrong position. However, you will not
get proper kneading action and you
could risk ruining a recipe or damaging
your mixer. Read the following
instructions carefully.
Nylon
Button
Square
Beater
Conical-Shaped
Beater
Side of
Bowl
Conical
Beater Square
Beater

7
The dough hook with the small washer
and foot goes into the socket on the
side of the mixer nearest the side of
the bowl. The other dough hook with
the large washer goes into the socket
nearest the center of the bowl. See the
dough hook symbols located on the
bottom of the mixer head.
BEATER-BOWL DRIVE ADJUSTMENT
Automatic bowl rotation is factory set.
Occasionally, a simple adjustment
may be necessary when the bowl
fails to rotate.
To make this adjustment, tilt the mixer
head back. Hold the mixer head in an
upright position and locate the
adjustment screw on the underside
of the mixer head. Loosen the locking
nut and turn the adjustment screw on
the underside of the mixer head.
Loosen the locking nut and turn the
adjustment screw clockwise, to lower
the mixer head; or counter clockwise,
to raise the mixer head. Retighten the
locking nut. The beater with the nylon
button should lightly touch the bottom
of the mixing bowl.
OPERATING INSTRUCTIONS
ABOUT THE SPEED CONTROL DIAL
The speed control dial is used
for turning the mixer ON and OFF
and for selecting its 12 mixing speeds.
Rotate the speed control dial in a
clockwise
direction to increase mixing
speed; and in a counter-clockwise
direction to decrease mixing speed.
As you rotate the speed control dial,
notice that a numbered speed
is aligned with the indicator on top
of the mixer head. This numbered
speed indicates the speed at which
the mixer is operating.
Rotate the speed control dial until
the indicator is opposite the numbered
speed you wish to use.
BURST OF POWER®
Press down on button or top handle to
automatically increase the beater speed
by 150 RPM for an immediate boost
of power.
HEAD LOCK
The head lock feature locks the mixing
head in the down position for added
control while mixing and locks it in the
up position for added convenience while
cleaning. To unlock, press down the
button on the side of the stand. To lock,
lower mixing head until it automatically
locks in place.
Speed
Indicator
Mixing
Guide
Speed Control
Dial
Adjustment
Screw Locking
Nut

8
NOTE: Due to variations in ingredient temperatures and quantities,
the Mixing Guide speeds are only suggested. If necessary,
adjust speeds as needed to achieve desired results.
MIXING GUIDE
The speed control guide on your mixer has been designed to help you take the
guess work out of preparing foods.
Use the chart below to determine the best setting to use when preparing your
favorite recipes.
SPEED MIXING
SETTING GUIDE EXAMPLE
1 Fold-Kneaded Use when mixing dry ingredients or when folding
two portions of a recipe together, such as a beaten
egg white into a batter or when directions call for
LOW speed. Use for kneading bread.
2 Stir Use when stirring liquid ingredients or when gentle action
is needed to moisten dry ingredients.
3 Blend Use when quick breads require a brisk action,
just enough to blend ingredients but not enough
to develop a smooth batter.
4 Mix Use when mixing dry ingredients and liquid ingredients
together alternately in a recipe.
5 Combine Use when recipe calls for combining ingredients together.
6 Cake Mixes Use when preparing packaged cake mixes or when
directions call for MEDIUM speed.
7 Cream Use when creaming sugar and butter together.
8 Whip Use to whip potatoes or to develop a smooth batter.
9 Whip/Cream Use to whip whipping cream or to develop a light,
fluffy texture.
10 Desserts Use to beat air into whipped desserts.
11 Frostings Use when preparing light, fluffy frostings and candies.
12 Egg Whites Use when aerating eggs and egg whites.
Use when directions call for HIGH speed.

9
CARING FOR YOUR MIXER
Ejecting the Beaters or Dough Hooks
After you’ve finished mixing, turn the
speed control dial to OFF and unplug
the electric cord from the electrical
outlet. Push the ejector button located
near the handle to remove beaters or
dough hooks.
Scrape excess batter off the beaters
using a rubber or plastic spatula. Do not
strike beaters on the rim of the bowl.
CLEANING YOUR MIXER
To clean the mixer, wipe the mixer head,
stand and turntable with a damp cloth,
then dry. DO NOT IMMERSE THE
MIXER HEAD OR STAND IN WATER.
Avoid the use of abrasive cleaners, as
they may mar the finish of the mixer.
Wash the beaters and bowls in hot,
soapy water after each use. Rinse
thoroughly and dry. Beaters and
bowls may also be washed in an
automatic dishwasher.
STORING YOUR MIXER
Store the mixer in a dry location,
such as on a counter top or table top,
or in a closet or cupboard.
Place the small mixing bowl inside
the large mixing bowl with the beaters
inserted into the proper sockets.
Place the dough hooks in the
small mixing bowl. Store the bowls
on the turntable. The beaters will help
hold the bowls in position. Wind the
electric cord into a coil, secure it
with a twist fastener.
MAINTENANCE
The motor of your stand mixer has
been carefully lubricated at the
factory and does not require any
additional lubricant.
Other than the recommended cleaning,
no further user maintenance should
be necessary.
Return the mixer to the nearest
Sunbeam Service Center for servicing
or repairs.

10
MIXING AND BAKING SUGGESTIONS
• Ingredients should be added to the
mixing bowl as they are specified in
the recipe. When combining dry
and wet ingredients, you may wish
to moisten ingredients on Speed 1
or 2, then turn to the desired
mixing speed.
• Use the mixing speed that is
recommended in the recipe. When
using a recipe that is not in this book,
use the handy mixing guide on the
speed control dial of the mixer to help
you find the correct speed to use.
• If times are specified in the recipe,
use them! BE CAREFUL NOT TO
OVERMIX. Overmixing can cause the
mixture to become very tough.
• Should an object, such as a spatula,
fall into the bowl while the mixer is
operating, turn the mixer OFF
immediately. Then, remove the object.
• Remove beaters and place in sink
for easy clean-up.
• When preparing your favorite
recipe, DO NOT exceed 3-1/2 cups
of flour grain in a recipe.
BREADS
SPECIAL INSTRUCTIONS FOR
MAKING KNEADED BREADS
When making kneaded breads,
your mixer will require more care
than when making ordinary mixtures,
such as cake batter and cookie dough.
The elasticity of the bread dough
and the shape of the dough hooks
may cause your mixer to do some
unusual things.
The bowl may tend to rock back and
forth. We suggest that you guide the
bowl with one hand to help control
the rocking action. AVOID GETTING
YOUR HANDS TOO NEAR THE
DOUGH HOOKS!
The kneading action may cause the
mixer to slide on a slippery work
surface. Be sure the work surface
and rubber feet on the bottom
of the mixer are clean and dry.
CAUTION: Do not use the mixer too
near the edge of a table or counter top,
where it could fall off.
DO NOT LEAVE YOUR MIXER
UNATTENDED WHEN USING THE
DOUGH HOOKS.
