Sunbeam HTD8216C User manual

Infrared Body Thermometer
Instruction Manual
Model : HTD8216C
Software version: V10

- 3 -
INDEX
Foreword
Safety Information
Overview
Operation
Troubleshooting
Cleaning, Care and Storage
Replacing the Battery
Disposal
Warranty
EMC Declaration
Body temperature
3
4
10
16
21
22
23
23
24
24
30
FOREWORD
The Infrared Body Thermometer Operating Instructions intend
to provide the necessary information for proper operation of the
HTD8216C Thermometer model.
Only Body Mode was reviewed and certied.
General knowledge of Infrared Thermometer and an understanding of
the features and functions of the HTD8216C Thermometer model are
prerequisites for proper use.
The Infrared Body Thermometer is a medical device, and can be used
repeatedly. The device shelf life is 5 years.
Do not operate HTD8216C Thermometer without completely reading
and understanding these instructions.
PLEASE READ THE MANUAL FIRST BEFORE USING
IT. IF THE USAGE IS NOT FULLY UNDERSTOOD,
PLEASE STOP USING THE THERMOMETER.
NOTICE
PURCHASE OR POSSESSION OF THIS DEVICE DOES NOT
CARRY ANY EXPRESS OR IMPLIED LICENSE TO USE WITH
REPLACEMENT PARTS WHICH WOULD, ALONE OR IN
COMBINATION WITH THIS DEVICE, FALL WITHIN THE
SCOPE OF ONE OF THE RELATING PATENTS.

- 4 - - 5 -
SAFETY INFORMATIONSAFETY INFORMATION
THIS DEVICE MAY ONLY BE USED FOR THE
PURPOSES DESCRIBED IN THESE INSTRUCTIONS.
THE MANUFACTURER CANNOT BE HELD LIABLE FOR
DAMAGE CAUSED BY INCORRECT APPLICATION.
THE INFRARED BODY THERMOMETER IS DESIGNED
TO MINIMIZE THE POSSIBILITY OF HAZARDS FROM
ERRORS IN THE SOFTWARE PROGRAM BY FOLLOWING
SOUND AND LIGHT ENGINEERING DESIGN PROCESSES,
RISK ANALYSIS AND SOFTWARE VALIDATION.
• DO NOT use the thermometer if it malfunctions or
has been damaged in any matter.
• When the ambient temperature of the thermometer
changes too much, such as moving the
thermometer from one room at a lower temperature
to another room at a higher temperature, allow the
thermometer to remain in a room for 30 minutes
where the temperature is between 59℉ - 95℉
(15℃ - 35℃) before using.
• Remove primary batteries if equipment is not likely
to be used for long time.
• This product is not waterproof, DO NOT immerse
in water or other liquids; when cleaning and
disinfecting, please refer to and follow the "care
and storage" requirements.
• DO NOT touch the sensor of infrared detection with
your ngers.
• If a cold compress is used to cool down, the
temperature reading will be low and will not be
accurate.
• When measuring the forehead select "forehead"
mode. when measuring ear temperature, please
select the "ear" mode.
• This product should only be used in a room with
stable ambient temperature. Fluctuations in ambient
temperature may result in inaccurate readings.
• DO NOT use near strong electrostatic or magnetic
elds to avoid impact on the accuracy of the
measurement data.
• DO NOT mix the old and new batteries to avoid
damage to the product.

- 6 - - 7 -
• Brush aside any hair and make sure the forehead
is clean and free of perspiration, cosmetics, or any
coverings (hats, caps, scarves) that may interfere with
measuring.
• Measurement results are for reference only. Contact
your physician if you have or suspect a medical
condition.
• Ensure the ear canal is clean and dry before using
the "ear" mode as this may interfere with the
measurement.
WARNINGS
The device should be kept out of the reach
of children / pets. When not in use, store
the device in a dry room and protect against
extreme moisture, heat, lint, dust and direct
sunlight. Never place any heavy objects on the
thermometer.
DO NOT throw batteries into re.
DO NOT discard in household trash.
Only use recommended batteries. DO NOT use
rechargeable batteries.
This thermometer is not intended as replacement
for advice from a physician or medical professional.
DO NOT drop, disassemble or modify the device.
DO NOT use this device if you think it is damaged
or notice anything unusual.
SAFETY INFORMATION

- 8 - - 9 -
This device comprises sensitive components
and must be treated with caution. Observe the
storage and operating conditions described in the
’Technical Specications’ section.
DO NOTperform service or maintenance while the
Thermometer is in use.
While in use DO NOT touch the battery and the
person at the same time.
DO NOT use the Thermometer if it is damaged,
degraded or loosened in any way.
Continuous use of a damaged Thermometer may
cause injury, improper results, or serious danger.
Based on the current science and technology,
other potential allergic reactions are unknown.
This devise needs to be used and serviced in
accordance with the information provided in this
INSTRUCTION MANUAL.
WARNINGS INTENDED USE
The Infrared Body Thermometer, Model: HTD8216C, is an
electronic clinical thermometer using an infrared sensor to
detect body temperature from the forehead or auditory canal
in people of all ages for home setting use.
The Sunbeam Thermometer is a hand-held, reusable,
battery operated device, which can measure human body
temperature on the forehead and in the ear. It can also
measure the surface temperature of objects.
The operation principle is based on Infrared Sensor
technology. The IR sensor can output different signals when
measuring different object temperatures or in different
ambient temperatures, and the ASIC can turn the signal from
IR Sensor to a digital value and display it on the LCD.
CONTRAINDICATIONS:
1. DO NOT measure areas on the forehead with scar tissue
or tissue compromised by skin disorders as this can affect
the measurement accuracy.
2. DO NOT measure temperature of persons in trauma.
3. DO NOT use if being treated with drug therapies that can
increase the body temperature.
4. DO NOT measure temperature on sites of the skin exposed
to external sources of heat or cold such as direct sunlight,
replace heat, cold compress, air conditioner ow, etc.

- 10 - - 11 -
INFRARED BODY THERMOMETER
COMPONENTS
INFRARED BODY THERMOMETER
COMPONENTS
1
1
2
2
4
3
3
5
4
6
5
7
9
6
8
Cap
Ear mode
Measuring status indicator
Liquid crystal display (LCD)
Data indicator
Battery cover
Low battery indicator
Volume on/off indicator
Mode button (inside cover)
Indicator of measurement result
Memory indicator
Passive infrared probe
Forehead mode
START button
Measurement unit
3
6
4
5
1 2
Figure 1 Model : HTD8216C Figure 2 Model : HTD8216C
1
7 8
2 3 4
5
6
9

- 12 - - 13 -
Thermometer
Model #
Thermometer
Style
Adult Pediatric
Ear Forehead Ear Forehead
HTD8216C Infrared Body
Thermometer √ √ √ √
Warning Operating atmospheric
pressure
Non sterile Packaging Type BF (Body Floating)
Consult instructions for use Compliance with WEEE
Standard
Operating Temperature DO NOT THROW AWAY
Intended for multiple use
Operating Humidity Serial number
Manufacturer Restriction of Hazardous
Substances
Recyclable Batch code
This device compiles
with Part 15 of FCC
( Federal Communications
Commission) Rules
IP22: The rst number 2:
Protected against solid
foreign objects of
12.5mm Ø and greater.
The second number:
Protected against vertically
falling water drops when
enclosure titled up to 15º.
LOT
Measurement Unit ºF / ºC
Operating mode Forehead mode / Ear mode
Measuring site Forehead / Ear
Reference Body
Site Axillary
Output Range Body mode: 93.2°F - 109.2°F / 34.0ºC - 42.9ºC
Surface mode: 32°F - 212°F / 0ºC - 1 00.0ºC
Laboratory
Accuracy
Forehead mode/Ear mode:
93.2°F - 94.8°F: ±0.5°F / 34.0ºC - 34.9ºC: ±0.3ºC;
95.0°F - 107.6°F: ±0.4°F / 35.0 - 42.0ºC:±0.2ºC;
107.8°F - 109.2°F: ±0.5°F / 42.1 - 42.9ºC:±0.3ºC;
Display Resolution 0.1°F / 0.1ºC
Three-color
Backlight
(Color Alarm)
93.2°F - 99.1°F / 34°C - 37.3°C Green (Normal Temperature);
99.3°F - 100.4°F / 37.4°C - 38.0°C (Alarm point)
Yellow (Slight Fever)
100.6°F - 109.2°F / 38.1°C - 42.9°C Red (High Fever)
Note: Color Alarm is only for Body mode
Auto Power Off
Time ≤35s
Measuring Time ≤5s (under ear mode); ≤2s (under Forehead mode)
Memories 1
Power Supply Requirements
Batteries DC 3V (2 x 1.5V AAA batteries)
Environmental Conditions
Operating
Condition
Operating Temperature: 59°F - 95°F (15°C - 35°C),
Relative Humility≤85%, atmospheric pressure: 70 - 106Kpa
Transport and
Storage Condition
Storage Temperature: -4°F - 131°F / -20°C - 55°C
Relative Humility≤93%, atmospheric pressure: 70 - 106Kpa
THERMOMETER APPLICATIONS TECHNICAL SPECIFICATIONS
EQUIPMENT SYMBOLS
Note: not all symbols may appear in this instruction manual

- 14 - - 15 -
Weight
(without batteries) 2.3oz (65g)
Size 6.1" x 1.3" x 2" (154mm x 33mm x 51mm)
Item Compliant with
Equipment classication Safety Standards: EN 60601-1: 2006+A1:2013,
EN 60601-1-2: 2015
Type of protection Internally powered equipment (on battery power)
Degree of protection Non Applied part
Front panel and case
labeling EN ISO15223 -1:2012
Temperature EN ISO80601 - 2 - 56:2012
Home healthcare
environment EN 60601 - 1 - 11:2015
Accessory name Number
AAA battery 2
Instruction Manual 1
DIMENSION AND WEIGHTING
CALCULATED VALUES OF THE INDICATORS
ACCORDING TO ISO 80601-2-56-2012 EAR MODE:
FOREHEAD MODE:
SAFETY CLASSIFICATION OF ME EQUIPMENT
Indicators Calculated value
Clinical bias, Δcb 0.009
Standard deviation, ∑j 0.11
Limits of agreement, LA0.19
Clinical repeatability, ∑r 0.06
Indicators Calculated value
Clinical bias, Δcb -0.018
Standard deviation, ∑j 0.13
Limits of agreement, LA0.26
Clinical repeatability, ∑r 0.06
Protection against electric shock Internally powered ME equipment
Degree of protection Type BF - Applied part (the probe)
Protection against harmful ingress of
water or particulate matter IP22
Mode of operation Continuous operation
NOTE: Not intended to be sterilized. Not for use in an
OXYGEN RICH ENVIRONMENT

- 16 - - 17 -
OPERATION
INSTALLING BATTERIES
1. Remove the battery access cover.
2. Insert two (2) AAA batteries aligned with the “+” and “-” icons.
3. Close the battery access cover.
• Install new batteries when the battery level indicator is low
• Dispose of/recycle used batteries following local
regulations to avoid environmental pollution.
BEFORE TAKING A TEMPERATURE
To maximize results:
• Choose a room or area with stable surrounding temperature,
away from direct sunlight or strong airow sources such as
fans or air conditioners.
• Allow the thermometer at least 30 minutes to adjust to
surrounding room temperature (if moving the device to or
from a warmer or cooler location) before use.
• Allow the body at least ve minutes to adjust to surrounding
room temperature.
• If a cool compress on the forehead or other measures are
taken to reduce fever, the temperature data will be low. You
may also try measuring behind the ear or in EAR MODE for
comparison.
• Brush aside any hair and make sure the forehead is free of
perspiration or head coverings (hats, caps, scarves) when
using FOREHEAD MODE.
• Make sure the ear canal and probe are clean when using
EAR MODE.
OPERATION
GETTING STARTED
Press the START button
• The thermometer will perform a self-test with all functions
displayed for 2 seconds. (See Figure 2)
• An audio signal (three “beeps”) will conrm the self-test is
complete.
• The display will show the last measured temperature stored
in memory. (See Figure 3)
• When the device is ready, the memory symbol will disappear
and the unit symbol will start ashing.
(See Figure 4)
Figure 2
Figure 4
Figure 3

- 18 - - 19 -
OPERATION
SELECTING FOREHEAD, EAR
To measure human BODY temperature (factory default):
• When the cap is off,the thermometer will measure in EAR MODE.
• When the cap is on, the thermometer will measure in
FOREHEAD MODE.
NOTE
To change back to FORHEAD MODE if the bottle icon
appears , follow the below steps:
• Open the battery access panel.
• With the thermometer ON, press the small MODE button
inside the battery compartment to select FOREHEAD MODE
(head icon appears on the display ).
• Replace the battery access cover.
OPERATION
MEASURING BODYTEMPERATURE IN FOREHEAD MODE
Note: Thermometer Cap should be on.
1. Press START to turn on
• A short beep will indicate ready to measure.
2. Hold the device vertically in front of the forehead.
3. Press START to begin measuring.
• A series of “beeps” will indicate measuring is complete.
4. The LCD display will show the target value of the measured
temperature.
5. The backlit screen will indicate a color alert for body
temperature (FOREHEAD AND EAR MODE) measurements.
Green - Normal Temperature/Ready for Measurement
Yellow - Slight Fever WARNING
Red - High Fever WARNING
Test at least 3 times and select the result that appears most.

- 20 - - 21 -
OPERATION
MEASURING BODY TEMPERATURE IN EAR MODE
Note: Remove Thermometer Cap to access ear probe.
If the patient is more than one year old, pull the ear up and
back gently. If the patient is less than one year old, pull the ear
back gently. (See Figure 5)
1. Press START to turn on. Insert the thermometer probe slowly
into the ear canal
• A short beep will conrm ready to measure.
2. Press START to begin measuring.
• A series of “beeps” will conrm measuring is complete.
3. The LCD display will show the target value of the measured
temperature.
4. The backlit screen will indicate a color alert for body
temperature (FOREHEAD AND EAR MODE) measurements.
Green - Normal Temperature / Ready for Measurement
Yellow - Slight Fever WARNING
Red - High Fever WARNING
Test at least 3 times and select the result that appears most.
TROUBLESHOOTING
MESSAGE SITUATION SOURCE OR SOLUTION
Temperature taken in is higher than
Typical human temperature
Body mode: detected target temperature
higher than 109.2°F (42.9°C)
Temperature taken in is lower than
Typical human temperature
Body mode: detected target
temperature lower than 93.2°F (34°C)
Operating temperature exceeds the
range of specied temperature
Environment temperature higher than
95°F (35°C) or lower than 59°F (15°C)
Wrong function indicated
System failure found when System
auto-check, the screen flicker, and
automatic turn off.
Battery capacity is too low. Taking
Temperature is not allowed Install new batteries
Ambient temperature is unstable
Ambient temperature is unstable.
Please allow it to acclimate for at
least 30 minutes before using it.
Blank screen indicate
• Press ON button again
• Check the battery polarity
• Replace with new batteries
The internal time from the rst
measurement to next measurement is
less than 5 seconds under ear mode.
Please wait 5 seconds to take next
measurement.
Measurement results unavailable
because the thermometer was removed
from position too quickly or was not in
place properly (for the ear mode).
1. Hold the thermometer in place
until it signals the measurement is
complete for forehead mode.
2. Ensure the probe is correctly inserted
in the ear canal under ear mode.
Mode switch error
Check if the thermometer cap is securely
in place under forehead scan mode.
Ensure the cap is completely removed
under ear mode.
Figure 5
>1 year <1 year

- 22 - - 23 -
REPLACING THE BATTERIES
1. Open and release battery cover following indicator on the
surface of shell. Before changing the batteries be sure the
system is already power off.
2. Press the battery holder lock to release the batteries.
3. Remove the batteries and replace with 2 new, type AAA.
Make sure the positive pole of the battery facing up.
4. Slide the battery cover back in until it snaps in place.
WARNING
DO NOT RECHARGE, DISASSEMBLE OR DISPOSE OF
BATTERIES IN FIRE.
DISPOSAL AND RECYCLING
• At the end of this device’s useful product life, follow local
regulations for appropriate and environmentally-friendly
recycling or disposal.
• Do not discard thermometers or used batteries in regular
household trash. Please follow local regulations for appropriate
and environmentally-friendly recycling or disposal.
LIMITED 3-YEAR WARRANTY
This product has a limited warranty of 3 years from the original
date of purchase against workmanship and defects in material.
If under normal use, your product fails to operate, please
contact our customer service department at info@stareliteinc.
com. A refund or replacement will be provided to you with proof
of purchase. Star Elite Inc. may deny claims of damage caused
by misuse or modications of this product.
CLEANING, CARE AND STORAGE
Note: The thermometer lens and infrared probe are delicate.
Handle with care and keep them protected from dirt and
damage. Do not touch the lens or probe with ngers or tools.
1. Gently wipe the thermometer probe, lens, device surface and
LCD screen with a soft, clean cloth or cotton ball moistened
with 70 - 75% isopropyl sterilizing alcohol.
• Do not use solvents or immerse the device in water or
other liquids.
2. Clean and sterilize the thermometer before and after each
use to avoid cross-contamination.
3. If the thermometer will not be used regularly, remove the
batteries to prevent damage during storage.
4. Store the thermometer in a clean, dry location free from dust,
humidity, and temperature extremes.
• Recommended storage temperature range is
-4°F - 131°F / -20°C - 55°C relative humidity ≤93%,
atmospheric pressure: 70 - 106KPA
5. When removing from storage, allow at least 30 minutes for
the thermometer to reach stable room temperature before it
is ready for use.
6. Periodically inspect the device and discontinue use if you
notice visible damage.

- 24 - - 25 -
Guidance and manufacture’s declaration - Electromagnetic emission
The Infrared Body Thermometer is intended for use in the electromagnetic
environment specied below. The customer of the user of the Infrared Body
Thermometer should assure that it is used in such an environment.
Emission test Compliance Electromagnetic
environment – guidance
RF emissions
CISPR 11 Group 1
The Infrared Body Thermometer use
RF energy only for its internal function.
Therefore, its RF emissions are very
low and are not likely to cause any
interference in nearby electronic
equipment.
RF emissions
CISPR 11 Class B The Infrared Body Thermometer is
suitable for use in all establishments,
other than domestic and those directly
connected to the public low-voltage
power supply network that supplies
buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Not
applicable
Voltage uctuations/
icker emissions
IEC 61000-3-3
Not
applicable
Guidance and manufacture’s declaration - Electromagnetic immunity
The Infrared Body Thermometer is intended for use in the electromagnetic
environment specied below. The customer or the user of Infrared Body
Thermometer should assure that it is used in such an environment.
Immunity
test IEC 60601 test level Compliance level Electromagnetic environment – guidance
Electrostatic
discharge
(ESD)
IEC61000-4-2
±6kV contact
±8 kV air ±6kV contact ±8 kV air
Floors should be wood,
concrete or ceramic tile.
If oor are covered with
synthetic material, the
relative humidity should be
at least 30%.
Electrical fast
transient /
burst IEC
61000-4-4
±2 kV for
power supply lines
±1 kV for
input/output lines
Not
applicable
Mains power quality should
be that of a typical commercial
or hospital environment.
NOTE: The thermometer is initially calibrated at the time of
manufacture. If this thermometer is used according to the
use instructions, periodic re-adjustment is not required. If
at any time you question the accuracy of the temperature
measurements, please contact our customer service
department.
EMC DECLARATION
1. This equipment needs to be installed and put into service
in accordance with the information provided in the
ACCOMPANYING DOCUMENTS; This product needs special
precautions regarding EMC and needs to be installed and
put into service according to the EMC information provided,
and this unit can be affected by portable and mobile RF
communications equipment.
2. Do not use a mobile phone or other devices that emit
electromagnetic elds, near the unit. This may result in
incorrect operation of the unit.
3. Caution: This unit has been thoroughly tested and inspected
to assure proper performance and operation!
4. Caution: this machine should not be used adjacent to or
stacked with other equipment and that if adjacent or stacked
use is necessary, this machine should be observed to verify
normal operation in the conguration in which it will
be used.

- 26 - - 27 -
Guidance and manufacture’s declaration - Electromagnetic immunity
The Infrared Body Thermometer is intended for use in the electromagnetic
environment specied below. The customer or the user of Infrared Body
Thermometer should assure that it is used in such an environment.
Immunity
test IEC 60601 test level Compliance level Electromagnetic environment – guidance
Surge IEC
61000-4-5
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
Not
applicable
Mains power quality should
be that of a typical
commercial or hospital
environment.
Electrical fast
transient /
burst IEC
61000-4-4
±2 kV for
power supply lines
±1 kV for
input/output lines
Not
applicable
Mains power quality should
be that of a typical commercial
or hospital environment.
Voltage
dips, short
interruptions
and voltage
variations
on power
supply
input lines
IEC
61000-4-11
<5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT)
for 5 cycles
70% UT
(30% dip in UT)
for 25 cycles
<5% UT
(>95% dip in UT)
for 5 sec
Not
applicable
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user
of the Infrared Body
Thermometer requires
continued operation during
power mains interruptions,
it is recommended that the
Infrared Body Thermometer
be powered from an
uninterrupted power supply
or a battery.
Power
frequency
(50Hz/60Hz)
magnetic
eld IEC
61000-4-8
3 A/m 3 A/m
Power frequency magnetic
elds should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE: UT is the a.c. mains voltage prior to application of the test level.
Guidance and manufacture’s declaration - Electromagnetic immunity
The Infrared Body Thermometer is intended for use in the electromagnetic
environment specied below. The customer or the user of Infrared Body
Thermometer should assure that it is used in such an environment.
Immunity
test IEC 60601 test level Compliance level Electromagnetic environment – guidance
Conducted
RF IEC
61000-4-6
3 Vrms
150 kHz to
80 MHz
Not
applicable
Portable and mobile RF
communications equipment
should be used no closer to
any part of the Infrared Body
Thermometer, including cables,
than the recommended
separation distance calculated
from the equation applicable to
the frequency of the transmitter.
Recommended
separation distance
d= 1.2
d= 1.2 80MHz to 800MHz
d= 2.3 80MHz to 2.5GHz
Where P is the maximum
output power rating of the
transmitter in watts (W)
according to the transmitter
manufacturer and d is the
recommended separation
distance in metres (m).
Field strengths from xed RF
transmitters, as determined
by an electromagnetic site
survey,ashould be less than
the compliance level in each
frequency range.bInterference
may occur in the vicinity of
equipment marked with the
following symbol:
Radiated
RF IEC
61000-4-3
3 V/m
80 MHz to
2.5 GHz 3 V/m
P
P
P

- 28 - - 29 -
Guidance and manufacture’s declaration - Electromagnetic immunity
The Infrared Body Thermometer is intended for use in the electromagnetic
environment specied below. The customer or the user of Infrared Body
Thermometer should assure that it is used in such an environment.
Immunity
test IEC 60601 test level Compliance level Electromagnetic environment – guidance
NOTE 1
At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2
These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reection from structures, objects and people.
aField strengths from xed transmitters, such as base stations for radio (cellular/
cordless) telephones and land mobile radios, amateur radio,AM and FM radio
broadcast and TV broadcast cannot be predicted theoretically with accuracy.To assess
the electromagnetic environment due to xed RF transmitters, an electromagnetic
site survey should be considered. If the measured eld strength in the location in
which the Infrared Body Thermometer is used exceeds the applicable RF compliance
level above, the Infrared Body Thermometer should be observed to verify normal
operation. If abnormal performance is observed, additional measures may be
necessary, such as re-orienting or relocating the Infrared Body Thermometer.
bOver the frequency range 150 kHz to 80 MHz, eld strengths should be less than
3 V/m.
Recommended separation distances between portable and mobile RF
communications equipment and the Infrared Body Thermometer.
The Infrared Body Thermometer is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled.The customer or
the user of the Infrared Body Thermometer can help prevent electromagnetic
interference by maintaining a minimum distance between portable and
mobile RF communications equipment (transmitters) and the Infrared Body
Thermometer as recommended below, according to the maximum output power
of the communications equipment.
Rated maximum
output power of
transmitter (W)
Separation distance according to frequency of transmitter (m)
150 KHz to
80 MHz
d= 1.2
80 MHz to
800 MHz
d= 1.2
800 MHz to
2.5 GHz
d= 2.3
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
11.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the
recommended separation distanced in metres (m) can be estimated using the
equation applicable to the frequency of the transmitter, where P is the maximum
output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
NOTE 1
At 80 MHz and 800 MHz, the separation distance for the higher frequency range
applies.
NOTE 2
These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reection from structures, objects and people.
P P P

- 30 - - 31 -
BODY TEMPERATURE
For consumer use only, not for professional use.
• Body temperature varies from person to person and
uctuates during the course of the day. For this reason,
it is suggested to know one's normal, healthy forehead
temperature to correctly determine the temperature.
• Body temperature runs approximately from 95.9°F - 100°F
• (35.5°C - 37.8°C). To determine if one has a fever, compare
the temperature detected with the person's normal
temperature. A rise over the reference body temperature of
1°F (1°C) or more is generally indication of fever.
• Different measurement sites (rectal, axillary, oral, frontal,
auricular) will give different readings.Therefore it is wrong to
compare the measurement taken from different sites.
• Here below are typical temperatures for adults, based on
different measurement sites:
Rectal: 97.9°F - 100.4°F / 36.6°C - 38°C
- Axillary: 94.5°F - 99.1°F / 34.7°C - 37.3°C
BODY TEMPERATURE
ASTM laboratory accuracy requirements in the display range
of 96.8°F - 102.2°F (36°C - 39°C) for IR thermometers is
±0.4°F (±0.2°C), whereas for mercury in-glass and electronic
thermometers, the requirement per ASTM Standards E667-86
and E1112-86 is ±0.2°F (±0.1°C).
Caution: This infrared thermometer meets requirements
established in ASTM Standard (E1965-98) Except of clause
5.2.2. It displays subject’s temperature over a range of
93.2°F - 109.2°F (34.0°C - 42.9°C). Full responsibility for the
conformance of this product to the standard is assumed by Star
Elite Inc. 1175 Place du Frère André, Montreal, QC, Canada H3B
3X9

If you have any problems, please do not contact the store.
Contact our customer service at 1-877-383-6399
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at
[email protected]
Our customer service will be happy to assist you.
© 2021 Sunbeam Products, Inc.All rights reserved.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9.
SE003-062821
Infrared Body Thermometer Model HTD8216C
Printed in China
