Sundstrom SR540 User manual

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
1 of 26
Operating instruction
SR 540 Face Shield

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
2 of 26
General information
The SR 540 together with fan unit SR 500 and approved filters are
included in the Sundström fan-assisted respiratory protective device
system conforming to EN 12941/EN 12942:1998 class TH3.
SR 540 together with compressed air attachment SR 507 and
breathing hose SR 358/SR 359/SR 360 are included in the
Sundström compressed air-fed respiratory device system
conforming to EN 14594:2005 class 3A/3B.
This combination gets a respiratory with continuous flow to a
compressed air fed respiratory device.
SR 540 is in one size.
When selecting equipment for SR 540 some of the factors that
should be taken into account are as follows:
•Type of pollutant
•Concentrations
•Work intensity
•Protection requirements in addition to respiratory protective advice.
Risk analysis should be carried by a person who has suitable
training and experience in the area.
Instructions for use for SR 540 should be read before use.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
3 of 26
2.1 Unpacking SR 540
2.2 Packing list
Check that the equipment is complete in
accordance with the packing list and
has not been damaged in transport.
Packing list:
•Face shield
•Breathing hose.
•Visor
•User instructions
•Cleaning tissue
•Protective film
2.3 Assembly
Check that the O-ring of the hose is in
place.
Check that the flat gasket is ok and in
place at the other end.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
4 of 26
Connect the end with the flat gasket to
the face shield.
Turn it clockwise about 1/8 of a turn.
The hose is now connected to the face
shield.
Visor
Remove the closing panels by pushing
them forward with your thumb.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
5 of 26
Remove the protective film from the
visor.
Secure the visor to the fixed mounting.
Then put the visor to the over-centre
mounting.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
6 of 26
Tension the visor by moving the lever
downward as far as it will go.
Check that the visor is firmly in contact
with the visor opening seal all around.
Fit the closing panels by pushing them
into place with your fingers. A clicking
sound indicates that they are in place.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
7 of 26
Connect the hose to the fan unit and turn
it clockwise about 1/ 8 of a turn.
Flow control
Place the head top in the flow meter and
start the fan unit.
Grip the lower part of the bag to seal
around the breathing hose.
Grip the flow meter tube with the other
hand so that the tube points vertically
upwards from the bag.
Read the position of the ball in the tube.
This should hover at a level with or
slightly above the upper marking on the
tube.
If minimum flow is not achieved,
check that:
–The flow meter is held upright.
–The ball moves freely.
–The bag seals well around the hose.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
8 of 26
2.4 Putting the face shield on
Raise the visor and put the face shield
on.
If necessary, adjust the head harness in
height by lengthening or shortening the
strap for the top of the head.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
9 of 26
If necessary, adjust the circumference of
the head harness by means of the knob
at the rear of the head harness.
Lower the visor unit by pulling the face
seal down under your chin.
A clicking sound indicates that the visor
unit has been lowered fully.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
10 of 26
Insert a finger between your chin and the
face seal and run the finger along the
contact surface of the face seal all the
way round to check that it fits well
against the face.
Check that the breathing hose runs
along your back and that it is not twisted.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
11 of 26
4 Maintenance
4.1 Cleaning/Disinfecting
Sundström cleaning tissues SR 5226
that clean and disinfect are
recommended for daily care.
Clean face shield and visor
If the equipment is more heavily fouled,
use a soft brush or sponge moistened
with a solution of water and dishwashing
detergent or the like.
Rinse the equipment and leave it to dry.
Clean left and right closing panel.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
12 of 26
Clean the valve seat and check that the
valve seat is ok.
Clean the exhalation membrane.
Clean the valve cover on the inside and
outside.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
13 of 26
Clean around the mounting points for the
visor.
Clean around the opening seal.
Clean the seal.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
14 of 26
Clean the face seal.
4.2 Storage
After cleaning, store the equipment in a
dry and clean place at room
temperature. Avoid exposing it to direct
sunlight. The flow meter can be turned
inside out and can be used as storage
bag for the head top.
4.3 Maintenance schedule
The schedule represents the minimum
requirements for maintenance routines in
order to ensure that equipment will
always be in functional condition.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
15 of 26
4.4.1 To change the exhalation membrane
Snap of the valve cover from the valve
seat.
Slip off the membrane.
Check that the valve seat is ok

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
16 of 26
Press the new membrane onto the pin.
Carefully check that the membrane is in
contact with the valve seat all way round.
Press the valve cover into place. A
clicking sound indicates that it is in
place.
4.4.2 To change the visor
Remove the closing panels (two) by
pushing them forward with your thumb.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
17 of 26
Release the visor by moving the lever of
the over-centre lock upwards through
about 180 degrees.
Remove the visor.
Remove the protective film from the new
visor.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
18 of 26
Secure the visor to the fixed mounting.
Then put the visor to the over-centre
mounting.
Tension the visor by moving the lever
downward as far as it will go.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
19 of 26
Check that the visor is firmly in contact
with the visor opening seal all around.
Fit the closing panels by pushing them
into place with your fingers.
A clicking sound indicates that they are
in place.
4.4.3 To change the face seal on the SR 540
Release the hooks from the head
harness.

Drawn up by:
2009-01-26 / RK
OI06H-0518 SR 540
Revision:
02
Reviewed:
2014-02-05 / PA
Page:
20 of 26
Release the face seal by pulling it´s
frame so that its pins are released from
the visor unit holes.
Remove the face seal.
Thread the new face seal over the visor
unit flange, with the centre markings in
line with one other.
