Sune Technology HMDI-3S-MNT User manual

SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-TechCarNavi-Tech

•Specification
Car Compatibility : BMW 3 series
Components : Monitor 1EA
Multimedia interface Input/output spec
Input : HDMI*1,
Output : To LCD*1, 5V USB power for Mirroring
Power spec
Input power : 8VDC ~ 18VDC
Consumption : 5WATT
Mode Switch feature
- Able to switch the mode by the OEM buttons
2
•Features
•Changing the monitor size from 6.5inch low resolution
to 8.8inch high resolution
•Possible to connect miracast via HDMI port
(Supporting 5V charge )
•Able to control the system via OEM buttons
CarNavi-TechCarNavi-Tech

3
•Product exterior
•Components
8.8inch Monitor
CAN IN / AUDIO OUT(Power cable ) | HDMI(HDMI cable)
HDMI Cable * 1ea
(HARETC0175)
POWER CABLE * 1ea
(HARETC0184)
CarNavi-TechCarNavi-Tech

4
•How to use OEM buttons
※ Short Press (OEM mode↔HDMI mode)
< Memory button #8 >
< Voice button on the
steering wheel >
※ Press the “back” button
longer than 7 seconds. Then
Factory Menu will appear
Short Press–Return
Spin towards left/right :
FACTORY MENU moves to up/down
Push : Select / Confirm
1
※ Memory #8 should be saved as AUX switching mode. Then, AUX will be switched
when the mode is changed.
<I-Drive>
※ Long Press - OEM mode ↔HDMI mode
Short Press –Return to OEM mode
※ Long Press : Activate thefactory reset
1
CarNavi-TechCarNavi-Tech

5
•Factory setting
Possible to change the screen color
BACK LIGHT : Adjust the screen brightness(10 stage)
HANDLE KEY : Activate or deactivate the function of voice button
on the steering wheel (mode switch)
(Default : ON)
MEMORY KEY : Activate or deactivate the function of Memory #8 button
(Mode switch + Aux switch).
(Default : ON)
FACTORY RESET : Activate the factory reset
Able to change other options
CONTRAST
BRIGHTNESS
CONTRAST
BRIGHTNESS
SHARPNESS
FACTORY HDMI 3S COM
INFO
UTIL1
BACK LIGHT
HANDLE KEY
MEMORY KEY
FACTORY RESET
FACTORY HDMI 3S COM
INFO
UTIL1
SYSTEM VERSION
(MAIN-130723)
FACTORY HDMI 3S COM
INFO
UTIL1
Able to check system version
CarNavi-TechCarNavi-Tech

6
•Installation Diagram
OEM CABLE
<OEM cable>
Remove OEM cable from the backside of
the radio system and connect the OEM
cable to the place where it is marked on
the picture above
<backside of the radio system>
Connection
Q-CAST
If there is no AUX wire on Plug&play cable,
Connect RCA cable to Vehilce’s Aux port
CarNavi-TechCarNavi-Tech

Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V
sources connected are working well.
(Second lamp indicates AV sources connected works well.)
Check interface connection has been done well.
Q. Set mode not appear
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps
on, inform to manufacturer.
Q. Screen displays only white color.
A. Check LCD out cable is connected well, if this status keeps, inform to
manufacturer.
Q. After connecting CAN wires, the screen shows no image while the gear
is shifted into “P”
A. Check whether plug&play cables are properly connected.
7
•Trouble shooting
CarNavi-TechCarNavi-Tech
