Sune Technology SUNE10-NTG55 User manual

Manual Date
Firmware Date
Main
Sub
Tw8823
Installation Manual
2019, 05, 16
2019, 05, 16
2019, 05, 16
20xx, xx, xx
SUNE10-NTG55
SUNE TECH

COMPONENTS
SUNE10-NTG55 SUNE10-NTG55Default-Power SUNE10-NTG55Power 1on1 SUNE10-NTG55LVDS-Cable
SUNE10-NTG55 UniversalCable SUNE10-NTG55 AV-Cable IR - Cable Capacitive Touch Cable
Key-Pad
SUNE TECH

COMPONENTS
Speaker GLONASS GPS WIFI/BT Antenna x 2 MIC
SUNE TECH

PIN ASSIGNMENT
POWER / CAN
1
ACC IN
2
Ground
3
4
5
12V output
6
7
Reverse input
8
Rear 12V output
9
10
Omni Key
11
ECU CAN High Input
12
ECU CAN Low Input
13
MON CAN High Input
14
MON CAN Low Input
15
MON CAN High Output
16
MON CAN Low Output
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
216
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
987654321 211
222
AV IN
1, 2
DVB-T Video
3, 4
DVB-T Audio R
5, 6
DVB-T Audio L
7, 8
DVD Video
9, 10
DVD Audio R
11, 12
DVD Audio L
13, 14
Front Camera
15, 16
Rear Camera
AV IN/OUT
1
Speaker P
2
Speaker N
3
Audio Out R
4
Ground
5
Audio Out L
6
Ground
7
Mic P
8
Mic N
9
CapTouch-I2C-SCL
10
CapTouch-Ground
11
CapTouch-I2C-SDA
12
CapTouch-Power 3.3V
13
CapTouch-Interrupt
14
CapTouch-Reset
15
UART Rx ( Interface )
16
UART –Ground
17
UART Tx ( Interface )
18
IR Receive –Signal
19
IR –DVB-T
20
IR Receive –Ground
21
IR - DVD
22
IR Receive –Power
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
216
SUNE TECH

ON1 2 3 4 5 6 7 8 9 10 ON1 ON1
OFF ON
DIP SWITCH SETTINGS
Switch
OFF
ON
SW1
Used HDMI Input
SW2
Used Rear Camera Input
SW3
Used Front Camera Input
SW4
Used DVB-T (CVBS) Input
SW5
Used DVD (CVBS) Input
SW6
reserved
SW7
List of Car Model
SW8
SW9
SW10
7
8
9
10
Model
Inch
OFF
OFF
OFF
OFF
W213
12.25
OFF
OFF
OFF
ON
W213
8.4
SUNE TECH

INSTALLATION DIAGRAM
R EAR 12V
R EVERSE IN
OU T 12V
OMNI KEY
HDMI DEVICE
AUX
CMD CAN IN H
CMD CAN IN L
CM D CAN OUT H
CM D CAN OUT L
From HEADUNIT
From HEADUNIT
SUNE TECH

OEM BUTTON –E-Class ( W213 )
1
1 1
Steer Remote
How to press
Description of operation
1
Hang Up
Press button for 1 second
Screen is switched in that order
switches are activated.
Touch Command
How to press
Description of operation
1
BACK
Press button for 1 second
Screen is switched in that order
switches are activated.
2
CAMERA
Press button for short time
Return back to OEM Screen form
Interface Screen
POWER
3
Touch
Command
Touch command softly
In Android mode,
It is working like mouse.
4
BACK
Press button for short time
In Android mode
Working like Back, Home Button
HOME
Steer Remote
How to press
Description of operation
1
NAVI
CAR
Press button for short time
Return back to OEM Screen form
Interface Screen
Press button for 1 second
Screen is switched in that order
switches are activated.
2
RADIO
Press button for short time
Return back to OEM Screen form
Interface Screen
MEDIA
TEL
1
3
2
2
4
