Sune Technology SUNE10 PLUS-NTG5 User manual

Manual Date
Firmware Date
Main
Sub
Tw8823
2019, 10, 21
2019, 10, 21
2019, 10, 18
2019, 10, 18
InstallationManual
SUNE10 PLUS-NTG5

COMPONENTS
SUNE10-NTG50 Power 1on1
SUNE10-NTG5 SUNE10-NTG5 Default-Power SUNE10-NTG5LVDS-Cable Key-Pad
SUNE10-NTG5 Universal Cable SUNE10-NTG5AV-Cable IR - Cable Capacitive Touch Cable

COMPONENTS
Speaker GLONASS GPS WIFI/BT Antenna x 2 MIC

PIN ASSIGNMENT
POWER / CAN
1 ACC IN 2 Ground
3 4 IR –DVD-T
5 12V output 6
7 Reverse input 8 Rear 12V output
9 10 Omni Key
11 ECU CAN High Input 12 ECU CAN Low Input
13 MON CAN High Input 14 MON CAN Low Input
15 MON CAN High Output 16 MON CAN Low Output
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
2 16
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
987654321 211
2 22
AV IN
1, 2 DVB-T Video
3, 4 DVB-T Audio R
5, 6 DVB-T Audio L
7, 8 DVD Video
9, 10 DVD Audio R
11, 12 DVD Audio L
13, 14 Front Camera
15, 16 Rear Camera
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
2 16
AV IN/OUT
1 Speaker P 2 Speaker N
3 Audio Out R 4 Ground
5 Audio Out L 6 Ground
7 Mic P 8 Mic N
9 CapTouch-I2C-SCL 10 CapTouch-Ground
11 CapTouch-I2C-SDA 12 CapTouch-Power 3.3V
13 CapTouch-Interrupt 14 CapTouch-Reset
15 Resistive Touch X- 16 IR –DVB-T
17 Resistive Touch Y- 18 IR Receive –Signal
19 Resistive Touch X+ 20 IR Receive –Ground
21 Resistive Touch Y+ 22 IR Receive –Power

ON1 2 3 4 5 6 7 8 9 10 ON1 ON1
OFF ON
DIP SWITCH SETTINGS
Switch OFF ON
SW1 Used HDMI Input
SW2 Used Rear Camera Input
SW3 Used Front Camera Input
SW4 Used DVB-T (CVBS) Input
SW5 Used DVD (CVBS) Input
SW6
SW7
List of Car Model
SW8
SW9
SW10
7 8 9 10 Model Inch
OFF OFF OFF OFF GLE (C292), E (W212), CLS (W218),
B (W246), CLA (C117) 7
OFF OFF OFF ON C (W205), GLC (x253), V (W447) 8.4
OFF OFF ON OFF S (W222) 12.25
OFF OFF ON ON C (W205), GLC (X253), V (W447) 7
This interface is upgrading to include car model for NTG5

INSTALLATION DIAGRAM
C MD CAN IN H C MD CAN IN L
C MD CAN OUT H
C MD CAN OUT L
HDMI DEVICE
AUX REAR / FRONT
DVB-T DVD
Please connect ‘C’ housing of OEM with
supplied housing.
Ground
Battery
C
From Headunit
1 2 V OUT
DV D IR
R E VERSE R E AR 12V
OM NI KEY

OEM BUTTON
COMAND
Controller How to press Description of operation
1, Back Press button for short time Return back to OEM Screen form Interface
Screen
Press button for 1 second Screen is switched in that order switches are
activated.
Press button for 10 second System would be reset.
2, Favorite Press button for short time Return back to OEM Screen form Interface
Screen
3 Up of Dial Press Up for 1 second
Switch Rear screen between OEM and
Interface screen during gear ‘R’.
* This function is saved.
Steer Remote How to press Description of operation
1, Back Press button for short time Return back to OEM Screen form Front
Screen
Press button for 1 second screen is switched to Front Screen
2, Hang Up Press button for short time Return back to OEM Screen form Interface
Screen
Press button for 1 second Screen is switched in that order switches are
activated.
1
2
1
3
2
1
3
2 2 2 2

CONNECTION Touch Panel / Screen for Booting
SELECT TOUCH PANEL
When need to set touch panel settings.
Select touch panel which you want to use.
* Most panel types do not need to be selected.
* Panel has default settings value for each panel.
1. Enter settings mode.
2. Press up button of k-pad for 3 sec.
3. Press the 5 cross in order to make
calibration for touch.
4. Press screen to save value of calibration.
5. System would be reset.
How to make calibration for touch:
SELECT Screen for booting.
If you selectandroid screen as booting screen.
Turn acc on and then screen would be changed to android screen in 5
sec automatically.

CONNECTION REAR CAM / FRONT CAM / 360 AVM
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321
REAR CAMERA / OEM / 360 AVM
FRONT CAMERA / OEM
HDMI AVM
Monitor resolution : 960 x 540 Monitor resolution : 800 x 480

INTERFACE SETTINGS
1920 x 720
HDMI INPUT SOURCE DEFAULT
NAVIGATION BRIGHT 128
REAR VIEW CONSTRAST RED 128
FRONT VIEW CONSTRAST GREEN 128
DTV CONSTRAST BLUE 128
DVD
CUSTOM
EXIT
DIP SWITCH INFO : FIRMWARE DATE :
MAIN : 2019, 02, 03
SUB : 2019, 02, 03
TW23 : 2019, 02, 03
How to press In not settings menu. In settings menu.
MENU Press button for 1 sec
Screen is switched in that order switches
are activated. Return back to the previous menu.
SEL Press button for short time Enter into the settings menu. Select the settings menu, and values
UP
Move the menu or Increase values
Press button for 5 sec Enter Calibration Mode For Touch.
DOWN Move the menu or decrease values
