Sune Technology NTG5 User manual

Manual Date
Firmware Date
Main
Sub
Tw8823
Installation Manual
2019, 02, 13
2020, 01, 17
2019, 12, 30
2019, 12, 30
NTG5
SUNE TECH

COMPONENTS
NTG50 Default-Power LVDS-Cable x 1pcs Key-Pad
NTG50 Universal Cable NTG50 AV-Cable IR - Cable
Capacitive Touch Cable
Option
Capacitive Touch Cable
SUNE TECH

PIN ASSIGNMENT
POWER / CAN
1ACC IN 2Ground
3 4 IR –DVD-T
512V output 6
7Reverse input 8Rear 12V output
910 Omni Key
11 ECU CAN High Input 12 ECU CAN Low Input
13 MON CAN High Input 14 MON CAN Low Input
15 MON CAN High Output 16 MON CAN Low Output
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
216
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
987654321 211
222
AV IN
1, 2 DVB-T Video
3, 4 DVB-T Audio R
5, 6 DVB-T Audio L
7, 8 DVD Video
9, 10 DVD Audio R
11, 12 DVD Audio L
13, 14 Front Camera
15, 16 Rear Camera
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
216
AV IN/OUT
1 Navi Audio In R 2 Ground
3 Navi Audio In L 4 Ground
5 Audio Out R 6 Ground
7 Audio Out L 8 Ground
9 CapTouch-I2C-SCL 10 CapTouch-Ground
11 CapTouch-I2C-SDA 12 CapTouch-Power 3.3V
13 CapTouch-Interrupt 14 CapTouch-Reset
15 ResistiveTouch X- 16 IR –DVB-T
17 ResistiveTouch Y- 18 IR Receive –Signal
19 ResistiveTouch X+ 20 IR Receive –Ground
21 ResistiveTouch Y+ 22 IR Receive –Power
SUNE TECH

ON1 2 3 4 5 6 7 8 9 10 ON1 ON1
OFF ON
DIP SWITCH SETTINGS
Switch OFF ON
SW1 Used HDMI Input
SW2 Used Rear Camera Input
SW3 Used Front Camera Input
SW4 Used DVB-T (CVBS) Input
SW5 Used DVD (CVBS) Input
SW6
SW7
List of Car Model
SW8
SW9
SW10
7 8 9 10 Model Inch
OFF OFF OFF OFF GLE (C292), E (W212), CLS (W218),
B (W246), CLA (C117) 7
OFF OFF OFF ON C (W205), GLC (x253), V (W447) 8.4
OFF OFF ON OFF S (W222) 12.25
OFF OFF ON ON C (W205), GLC (X253), V (W447) 7
OFF ON OFF OFF S (W222) 2016 year 12.25
This interface is upgrading to include car model for NTG5
SUNE TECH

INSTALLATION DIAGRAM
HDMI DEVICE NAVIGATION
AUX REAR / FRONT
DVB-T DVD
CMD CAN IN H
CMD CAN IN L
CMD CAN OUT H
CMD CAN OUT L
Please connect ‘C’ housing of OEM with
supplied housing.
Ground
Battery
C
From Headunit
12V OUT
DVD IR
REVERSE
REAR 12V
OMNI KEY
SUNE TECH

MICROCITY
OEM BUTTON
COMAND
Controller How to press Description of operation
1, Back Press button for short time Return back to OEM Screen form
Interface Screen
Press button for 1 second Screen is switched in that order
switches are activated.
Press button for 10 second System would be reset.
2, Favorite Press button for short time Return back to OEM Screen form
Interface Screen
3 Up of Dial Press Up for 1 second
Switch Rear screen between OEM
and Interface screen during gear ‘R’.
* This function is saved.
Steer
Remote How to press Description of operation
1, Back Press button for short time Return back to OEM Screen form
Front Screen
Press button for 1 second screen is switched to Front Screen
2, Hang Up Press button for short time Return back to OEM Screen form
Interface Screen
Press button for 1 second Screen is switched in that order
switches are activated.
1
2
1
3
2
1
3
222 2

CONNECTION Touch Panel
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
987654321
CAP-TOUCH- SUB
SELECT TOUCH PANEL
When need to set touch panel settings.
Select touch panel which you want to use.
1. Enter settings mode.
2. Press up button of k-pad for 3 sec.
3. Press the 5 cross in order to make
calibration for touch.
4. Press screen to save value of calibration.
5. System would be reset.
How to make calibration for touch:
SUNE TECH

CONNECTION LVDS SUNE10
How to use SUNE10 as navigation mode
SUNE10 is controlled by Touch panel
800 x 480
HDMI GPS BOX MODEL SUNE10
NAVIGATION BRIGHT SE-CP (RGB)
REAR VIEW CONSTRAST RED NV17
FRONT VIEW CONSTRAST GREEN QROI (RGB)
DTV CONSTRAST BLUE SE-NAV (RGB)
DVD SE-CP (LVDS)
CUSTOM SE-NAV2 (LVDS)
EXIT SE-NAV2 (RGB)
DIP SWITCH INFO : FIRMWARE DATE :
MAIN : 2019, 02, 03
SUB : 2019, 02, 03
TW23 : 2019, 02, 03
SUNE 10 SETTOP V1.6
SUNE 10 SETTOP V1.6
SUNE TECH

CONECTION RGB SE-NAV
How to use SE-NAV (RGB) as navigation mode
800 x 480
HDMI GPS BOX MODEL SUNE10
NAVIGATION BRIGHT SE-CP (RGB)
REAR VIEW CONSTRAST RED NV17
FRONT VIEW CONSTRAST GREEN QROI (RGB)
DTV CONSTRAST BLUE SE-NAV (RGB)
DVD SE-CP (LVDS)
CUSTOM SE-NAV2 (LVDS)
EXIT SE-NAV2 (RGB)
DIP SWITCH INFO : FIRMWARE DATE :
MAIN : 2019, 02, 03
SUB : 2019, 02, 03
TW23 : 2019, 02, 03
RGB Input
1 Analog Red
2 Analog Green
3 Analog Blue
4 Analog CSYNC
5 Analog Ground
6 UART RX <- Device
7 UART TX -> Device
SE-NAV is controlled by Touch panel
SUNE TECH

CONECTION LVDS NV17
How to use SECP as navigation mode
800 x 480
HDMI GPS BOX MODEL SUNE10
NAVIGATION BRIGHT SE-CP (RGB)
REAR VIEW CONSTRAST RED NV17
FRONT VIEW CONSTRAST GREEN QROI (RGB)
DTV CONSTRAST BLUE SE-NAV (RGB)
DVD SE-CP (LVDS)
CUSTOM SE-NAV2 (LVDS)
EXIT SE-NAV2 (RGB)
DIP SWITCH INFO : FIRMWARE DATE :
MAIN : 2019, 02, 03
SUB : 2019, 02, 03
TW23 : 2019, 02, 03
SE-CP is controlled by Touch panel or TURN RIGHT/LEFT/OK
SUNE TECH
S Class GLA C Class

CONNECTION DTV-ASUAK
How to use Asuka DTV as HDMI mode.
In CVBS mode, be able to use Asuka DTV too.
1 6
1 5
1 4
1 3
1 2
1 1
1 0
9
87654321
2 2
2 1
2 0
1 9
1 8
1 7
1 6
1 5
1 4
1 3
1 2
1 1
1 0
987654321
DVB-T IR
HDMI
or
CVBS
Asuka DTV is controlled by Touch panel or IDRIVE
SUNE TECH
S Class GLA C Class

CONNECTION REAR CAM / FRONT CAM / 360 AVM
REAR CAMERA / OEM / 360 AVM
FRONT CAMERA / OEM
HDMI AVM
Monitor resolution : 960 x 540 Monitor resolution : 800 x 480
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321
360AVM is controlled by
touch on monitor or
IDRIVE
S Class GLA C Class

INTERFACE SETTINGS
1920 x 720
HDMI INPUT SOURCE DEFAULT
NAVIGATION BRIGHT 128
REAR VIEW CONSTRAST RED 128
FRONT VIEW CONSTRAST GREEN 128
DTV CONSTRAST BLUE 128
DVD
CUSTOM
EXIT
DIP SWITCH INFO : FIRMWARE DATE :
MAIN : 2019, 02, 03
SUB : 2019, 02, 03
TW23 : 2019, 02, 03
How to press In not settings menu. In settings menu.
MENU Press button for 1 sec Screen is switched in that order
switches are activated.
Return back to the previous
menu.
SEL Press button for short time Enter into the settings menu. Select the settings menu, and
values
UP
Move the menu or Increase
values
Press button for 5 sec Enter Calibration Mode For
Touch.
DOWN Move the menu or decrease
values
