Sune Technology QHLI-LVTX-5CH-ECLIPSE User manual

Installation Manual
HDMI Interface for Mitsubishi Eclipse

Compatibility: Eclipse/Outlander/Pajero/ASX/
Eclipse cross 2016~
Components: Interface*1
Sub Board*1 and Ex Board*1
Interface Input / Output specification:
Input: HDMI*2
LVDS*1
A/V*2
CVBS(Rear camera)*1
CVBS(Front camera)*1
Output: To LCD*1
Power Spec:
Input Power: 8VDC ~ 18VDC
Consumption: 5WATT
Switch input mode:
1. External video sources skip function: Able to control input videos on and off
via Dip switches
2. Able to switch videos via the remote and button switch
3. Able to detect the rear view camera by CAN
2
1. High-resolution display through HDMI input
2. Control EXT devices(DVD/DTV) via Multi Media Touch GUI
3. Adjustable screen position of external device
4. Mode switching with OEM button
5. Power output for rear camera drive
6. Dynamic PAS(parking assistance system)
7. Able to use OEM Touch and support multi touch with our QROI2-RGB Android
Navigation Box

3
MAIN BOARD
QCPASS1347
POWER CABLE
HPOWER0229
AV CABLE
HAVCAB0056
MULTI CABLE
HARETC0240
REMOTE CONTROL
REMOTE0001
IR CABLE 4P
HIRCAB0002
EX CABLE
HARETC0249
S/W CABLE
HARETC0001
ECLIP-5CH-SUB
QCPASS1342
FFC CABLE
FFCABL0017
HDMI Cable
HARETC0067
ECLIPSE BD SUPP BRKT
PRESET0870
ECLIPSE BACK COVER
PRESET0869
AUX CABLE
HARETC0316

PIN
FUNCTION
Dip S/W SELECT
1
LVDS
OFF : LVDS MODE
ON : LVDS MODE SKIP
2
HDMI1
OFF : HDMI1 MODE
ON : HDMI1 MODE SKIP
3
AV1
OFF : AV1 MODE
ON : AV1 MODE SKIP
4
AV2
OFF : AV2 MODE
ON : AV2 MODE SKIP
5
FRONT CAMERA
OFF: EXT FRONT CAMERA
ON: OEM FRONT CAMERA
6
N/C
7
REAR CAMERA SELECT
OFF : OEM REAR CAMERA MODE
ON : EXT REAR CAMERA MODE
8
CAN IN/OUT MODE
OFF : CAN IN/OUT MODE
ON : CAN IN/OUT MODE SKIP
※ON : DOWN / OFF : UP
※Please make sure to disconnect the power cable of the interface and reconnect
the power cable again to apply the dip switch setting whenever changing DIP switch.
Key
FUNCTION
POWER & PIP N/C
MENU Activating OSD menu
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can
access the factory mode)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset
all the data about user environment)
4

5
To Sub board
A
U
D
I
O
(R)
O
U
T
A
U
D
I
O
(L)
O
U
T
F
C
A
M
A
U
D
I
O
(R)
IN
1
A
U
D
I
O
(L)
IN
1
R
C
A
M
V
I
D
E
O
IN
1
V
I
D
E
O
O
U
T
1
V
I
D
E
O
O
U
T
2
A
U
D
I
O
(R)
IN
2
A
U
D
I
O
(L)
IN
2
V
I
D
E
O
IN
2
A/V CABLE
LVDS NAVI BOX
R
C
A
M
S
A
F
E
R
E
A
R
V
1
I
R
V
2
I
R
R
E
M
O
T
E
T
O
G
G
L
E
12
V
S
E
L
F
C
A
M
12
V
ADC No Use
Plug & Play
harness

※Main IF + Sub board Connection
※Power / CAN J BY J cable Connection
One pair of CAN H / L wires are added on the cable, but please do not use it.

※Power / CAN cable connection
On this J by J cable, you can find ADC cable. Please plug it to ADC port on the
Interface.
①You can use End call button on the steering wheel for mode change
②Mode Change by OEM Button : App button on the monitor

8
Please disassemble the monitor as above
picture.
Please disconnect black OEM FPC cable
and connect supplied FPC cable as
above.
Please install supplied sub board
bracket as above.
Please connect another side of supplied FPC cable
to supplied sub board and install supplied sub board
above the bracket as above.
Please connect another side of black
OEM FPC cable as above.
Please connect supplied HDMI cable and
EX cable to sub board as above.
Please assemble supplied back cover
bracket as above.
It will be shown as above after assembly.
①②
③④
⑤⑥
⑦⑧

9
※Mode switch via long press on End Call button
After connecting ADC cable, it will be able to use the end call button for mode
switch.

10
※Use APPS button for mode switch
After connecting CAN J BY J cable, it will be able to use the APPS button for
mode switch.

PAS TYPE: Select parking line type.
- NOT USED: Do not use parking line
- PAS ON: Use Flexible Parking Lines
- PAS OFF: Use fixed parking line
PAS SETUP: You can move the position of parking line.
REAR TYPE : Choose rear camera recognition.
- CAN : By connecting to “CAN” cable of the car gear, changing to rear camera
mode when shifting into reverse. (Connect “CAN” cable of the power cable to the
“CAN” cable of the car gear)
- LAMP : By connecting to the rear lamp of the car, switch to rear camera mode
when shifting into rear. (Connect “Rear-C” cable of the power cable to the rear
lamp of the car)
SAFE ENABLE : If it is enable, HDMI, RGB, and A/V mode doesn’t show up while
driving. (YES/NO)
F-CAM TIME: Front camera operation time setting (OFF, 3s, 5s, 10s, 15s)
PARK SETTING
IMAGE SETTING
H-POSITION: Move the screen left and right.
V-POSITION: Move the screen up and down.
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
FCAM TIME
Menu of FACTORY
MENU to Return SEL to Select/Save
11

UITL1
AVOUT SELECT: Select audio channel
transmitted through AUX (DEFAULT/AV1/AV2/AV3)
LVDS MODEL: LVDS setting (CARPLAY)
CAR MODEL: Car model setting
HD2 SKIP: HDMI2 skip setting (YES/NO)
FACTORY RESET: Factory mode reset
PARK
UTIL1
UTIL2
INFO
AVOUT SELECT
LVDS MODEL
CAR MODEL
HD2 SKIP
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
TOUCH REMOTE
TOUCH ENABLE
IR MEMORY
OEM KEY
CALIBRATE
Menu of FACTORY
MENU to Return SEL to Select/Save
12
PARK
UTIL1
UTIL2
INFO
SYSTEM VERSION
MAIN -190612
MCU: S1.9.06.12
SUB: S3.9.04.10
Menu of FACTORY
MENU to Return SEL to Select/Save
INFO
SYSTEM VERSION INFORMATION
UTIL2
TOUCH REMOTE : Able to use remote control on DVD,
DTV by selecting “User” after IR memory registered
TOUCH ENABLE: (No/OEM Touch)
IR MEMORY : Register IR memory of DTV and DVD
※Refer to “IR MANUAL” for more details
OEM KEY: Select handle DISP KEY ON/OFF
CALIBRATE: Not support, Use OEM Touch

Q. I cannot change mode
A. Check connection of Ground cable and IR Cable. Check LED lamp
is on, if not check connection of POWER cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V
sources connected are working well.
(Second lamp indicates AV sources connected works well)
Check interface connection has been done well.
Q. Displayed image color is not proper (too dark or unsuitable color)
A. Press ▶button on the remote control for 2 seconds and check how
it goes, if it does not work, inform to manufacturer.
Q. I cannot watch the rear camera on the screen
A. Set the DIP switch #7 as state “ON”.
Q. Set mode not appear
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps
on, inform to manufacturer.
Q. Screen only displays white color.
A. Check LCD out cable is connected well, if this status keeps, inform to
manufacturer.
Q. If no image is shown on screen after connecting CAN wire with Park
gear.
A. Go on the “FACTORY MODE”, check “UTIL-Rear Select”. If “LAMP”,
change the setting as “CAN” with the remote control. (※when
connecting Rear-C wire of LAMP power cable to Backup lights,
Setting should be like this / CAN : if controlling rear camera with
CAN wire)
13

14
