Sune Technology QPI-Volvo-Main-V1.1 Manual

Your best partner for better driving
Release Date
2014.05.21
Model
QPI-Volvo-Main-V1.1
Product Code
131022-N
SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-Tech

Warning
When installing the main unit, do not remove or alter existing
vehicle fasteners, including nuts, bolts, screw, clips, and fittings.
Never detach, move or alter existing vehicle wiring, including
electrical grounds and straps. Alteration of existing vehicle
components may make vehicle unsafe to operate. Should be
no any electronic devices or magnetic pole around installation
place.
Air bags are vital part of a safety system. Never install main unit
in a way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
Before installing, check the location of pipe, tank, electrical
cables and others.
Read and follow the instruction manual.
Wiring location must not interfere driving, get in or out from car.
Use electrical tape to insulate the ends of all wires, even if they
are not used. Proper insulation prevents arcs, shocks and fires.
When installation is complete, test all vehicle electrical systems
to ensure they operate correctly, including lights, horn, brake
lights, and emergency flashers.
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
Caution
All steps of installation should be done by well-trained specialist.
During installation ignition key should be taken off and after all
installation finish connect power cable with interface for the last
step.
Do not install the main unit in places where it ma be exposed to
dew condensation (around the air conditioning hose, etc), or in
locations where it may come in contact with water, high levels of
moisture, dust or oily smoke
Install wiring in a manner in which cables will not come in contact
with metal parts. The wiring may be damaged by contact with
metal parts, resulting in fire and shocks. Avoid all contact with hot
surfaces when wiring the main unit. High temperatures may
damage wiring, causing shorts, arcing and fires.
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Warning / Caution
CarNavi-Tech

Table of Contents
1. Specifications
1.1 Main Specifications
1.2 Functions
1.3 System Diagram
1.4 Components
1.5 Exterior
2. Installation
2.1 Installation Diagram
2.2 Installation
2.3 CAN wire Installation
3. Settings
3.1 DIP Switch
3.2 Remote Control
3.3.1 Parking guidelines/3D PDC
3.3.2 PIP(picture in picture)
3.3.3 Factory Mode -IMAGE, PARK
3.3.4 Factory Mode –UTIL 1
3.3.5 Factory Mode –UTIL 2
3.3.6 Factory Mode –INFO
3.3.7 Factory Mode –OSD Analog RGB
3.3.8 Factory Mode –OSD Video
4. Trouble Shooting
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
19
20
21
22
CarNavi-Tech

1. Specifications
-1-
1.1 Main Specifications
1. Car Compatibility
Volvo S60, S80, V40, XC60(2014)
2. Components
Interface* 1EA
3. MULTIMEDIA INTERFACE input specification
3 * A/V input (video external input)
1 * CVBS(Rear Camera) input
2 * Analog RGB input (Navigation system, HDMI)
1 * LCD input (Car system input)
4. MULTIMEDIA INTERFACE output specification
1 * LCD output
5. Power specification
Input power : 8VDC ~ 18VDC
Consumed power : 5WATT
CarNavi-Tech

1. Dynamic PAS(Parking assistance system)+3D PDC(Parking
distance control)
- moving parking line according movement of steering
wheel
- Front / Rear car distance sensor display in external mode
2. Support PIP display –showing sources at the same time
(Picture in Picture)
1. Specifications
1.2 Functions
-2-
CarNavi-Tech

1. Specifications
-3-
1.3 System Diagram
DISPLAY
A/V 1
NAVIGATION Input
(Analog RGB)
CVBS
(Rear camera)
Car Screen Input
(CAR MAIN BOARD)
A/V 2
A/V 3
VIDEO
CIRCUIT
VIDEO MUX
MCU
Power Input
(+8VDC ~ +18VDC)
POWER
CIRCUIT
Dip S/W
A/V OUT HEADREST
MONITOR
Remote control Switch for source toggle
OEM Button (Can Signal)
Car Installation
OEM LCD
Rear Camera Power
(+12 VDC)
HDMI Input
(Analog RGB-2)
CarNavi-Tech

LVDS cable* 1ea
AV cable * 1ea
TOUCH OUT cable * 1ea
POWER cable (10P) * 1ea
(HPOWER0044)
REAR CAMERA
POWER cable * 1ea
(HARETC0002) (HAVCAB0002) Remote control * 1ea
(REMOTE0001)
MODE cable
* 1ea
(HARETC0001)
RGB_IN cable(9P) * 1ea
(HRGBCA0013)
IR cable * 1ea
(HIRCAB0002) (HTOUCH0004)
TOUCH IN cable * 1ea
(HTOUCH0007)
(HALVDSC0024) Bracket * 1ea
(PRESET00164)
* 6ea (3x6)
* 10ea (2x4)
Sub board 7” * 1ea
(QCPASS0000)
FFC cable * 1ea
(FFCABL0000)
1.4 Components
1. Specifications
-4-
CarNavi-Tech

①⑥⑦
⑧
⑨
⑩⑪
②③④⑤
⑫
-5-
Dimension
Width 150.4mm
Length 99.4mm
Height 2.3.2mm
①MODE
②IR
③POWER
④REAR CAMERA
⑤RGB-IN(HDMI)
⑥RGB-IN(NAVI)
⑦AV IN/OUT
⑧TO NAVI T/S-OUT
⑨LVDS OUT
⑪LED
⑩TEST
⑫DIP S/W
1. Specifications
1.5 Exterior
CarNavi-Tech

ACC
REAR
GND
CAN-H-HS
CAN-L-HS
F-CAM-DET
SAFE
CAN-H-LS
CAN-L-LS
2. Installation
-6-
2.1 Installation Diagram
Monitor
Original LCD Cable
Provided LVDS Cable
Provided LCD Cable
Navigation
Touch cable
Provided TOUCH Cable
Behind of monitor
Touch screen
AV1 AV2 AV3
REAR C
Audio L
Audio R
AV/OUT Video
B DATA (blue) SYNC GND
IR-DTV
NAVI-VIDEO SYNC
IR-NAVI
IR-DVD
R DATA (red) G DATA (green)
REAR (9V OUT)
GND
※ Please connect ACC cable to B+ cable
CarNavi-Tech

2. Installation
-7-
2.2 Installation
Provided LCD FFC
cable
Provided LVDS cable
Monitor
Original LCD FFC cable
Provided Touch cable
Touch Screen
※Touch : Optional
CarNavi-Tech

CAN-Low
CAN-High
Power
cable
Connecting CAN cable respectively
The LCD cable in the back of monitor connect with offered powercable
Connect CAN-H cable (green+brown) enclosed in our package with the original
CAN-H cable (grey+orange).
And connect CAN-L cable (green) enclosed in our package with the original CAN-L
cable (violet+orange).
2. Installation
2.3 CAN wire Installation
-8-
CarNavi-Tech

3. Settings
-9-
3.1 DIP Switch
PIN
Function
Dip S/W Selection
1
Displaying RGB input
ON : RGB mode skip
OFF : RGB mode display
2
Displaying A/V 1
ON : A/V 1 mode skip
OFF : A/V1 mode display
3
Displaying A/V 2
ON : A/V 2 mode skip
OFF : A/V2 mode display
4
Displaying A/V 3
ON : A/V 3 mode skip
OFF : A/V3 mode display
5
Car Model
Model
#5
#6
S60
OFF
OFF
V40
ON
OFF
6
S80
OFF
ON
XC60(2014)
OFF
OFF
7
Setup of rear camera use
ON : CVBS4
OFF : MAIN
8
no use
※Example DIP S/W usage
- Use input mode : A/V2, A/V3
- Use original navigation
- External rear camera
▷DIP S/W : 1 ON (hide INPUT MODE)
▷DIP S/W : 2,3 OFF (A/V1,2 display)
▷DIP S/W : 4 OFF (A/V3 display)
▷DIP S/W : 5 ON/OFF
▷DIP S/W : 6 ON/OFF
▷DIP S/W : 7 ON (display external rear cam)
▷DIP S/W : 8 OFF
※ON : DOWN / OFF : UP
Default: #8 OFF
※Please make sure to disconnect the power cable of the interface and reconnect
the power cable again to apply the dip switch setting whenever changing DIP switch.
Otherwise, DIP switch setting will not be applied.
CarNavi-Tech

3. Settings
-10-
3.2 Remote Control
Key
Function
POWER Unavailable
PIP A/V 1~2 Mode : Remote control UI Display
HDMI, A/V 3 Mode : Mode switching UI Display
MENU Activating OSD menu
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can access the factory
mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset all the
data about user environment.)
CarNavi-Tech

3. Settings
-11-
3.3.1 Rear parking guidelines
< Rear camera full screen >
< PIP screen >
☞Mode switches :
NAV button - Long Press (Switch to external mode)
- Short Press (Switch to OEM mode)
☞Change the size of image : Press CAM button in Rear mode.
(V40 : Not applicable)
CarNavi-Tech

3. Settings
-12-
3.3.2 PIP(Picture in Picture)
< Before Approaching objects>
< After Approaching objects>
- PIP image will be shown as above.
(Car without Front sensor : Not applicable)
CarNavi-Tech

3. Settings
-13-
3. Settings
3.3.3 FACTORY MODE-IMAGE, PARK
IMAGE
Adjust navigation position and size
H-POSITION : Move display horizontally
V-POSITION : Move display vertically
FACTORY mode –Press ◀button 2 seconds long on the remote control.
PARK
PAS TYPE : Selecting Type of parking guide line
- NOT USED : Not use Parking guide line
- PAS ON : Selecting Dynamic Parking guide
line
- PAS OFF : Selecting fixed Parking guide line
PAS SETUP : Adjusting the position of the parking
guide line
REAR TYPE : Choose rear camera recognition
* LAMP - Detecting the rear view camera
via rear lamp (Installer must connect
“Rear-C” cable of the power cable to the
rear lamp of the car.)
*CAN - Detecting the rear view camera by
CAN signal (Installer must connect “CAN”
cable of the power cable to the “CAN”
cable of the car.)
SAFE ENABLE : If your car is connected with CAN
cable and it is in ”ON” state, you
can NOT watch DVD or A/V
except original image or
navigation while driving. At that
time the screen get back to the
main (default : OFF)
RADAR ENABLE : When set the gear to “R”,
Display PDC
CarNavi-Tech

3. Settings
-14-
3.3.4 FACTORY MODE-UTIL1
FACTORY mode –Press ◀button 2 seconds long on the remote control.
UTIL1 –NAVI MODEL
Definition of the navigation
resolution
DEAFULT
NAV-506TP
MYVI
WP9200
HDMI
GI-8000N 3D
GI-5000A
I-ONE
KD-900
PAPAGO
LS-901
* Go into FACTORY/ IMAGE (as
shown right) and adjust the
position and the size of the
navigation after setting the
definition of the navigation
Setup for navigation
UTIL1 - CAR MODEL
Selecting model of the car
Volvo
Setup for car model
HDMI SKIP
HDMI SKIP
HDMI SKIP
HDMI SKIP
CarNavi-Tech

3. Settings
-15-
3.3.4 FACTORY MODE-UTIL1
FACTORY mode –Press ◀button 2 seconds long on the remote control.
UTIL1 –AVOUT SELECT
Selecting background sound
After
returning navigation or original
mode
DEFAULT : Selecting AV sound
just before changing
navigation or original mode
from the AV mode
AV 1~3 : Sound of the selected
AV source 1~3
UTIL1 - FACTORY RESET
FACTORY MODE RESET
UTIL1 –HDMI SKIP
Selecting whether to use
HDMI function or not
ON(Not use) / OFF(use)
HDMI SKIP
HDMI SKIP
HDMI SKIP
CarNavi-Tech

UTIL2 –IR MEMORY
To register DVD, DTV remote control, the
remote control value must be registered
and can be control with Jog shuttle
DVD(A/V1), DTV(A/V2)
※To use this function, in UTIL2-I_DRV
REMOTE select USER mode
DVD / DTV
3. Settings
-16-
3.3.5 FACTORY MODE-UTIL2
FACTORY mode –Press ◀button 2 seconds long on the remote control.
UTIL2 - I_DRV CONTROL
Selecting whether to use I_DRV
function or not
ON / OFF
A/V1 : Control DVD Remote control UI
A/V2 : Control DTV Remote control UI
UTIL2 - I_DRV REMOTE
Choose DTV and DVD model
to be control I_DRV function
LI-1DISC
NEC-6DISC
USER(when using IR MEMORY)
•Select DVD model: Setting on
AV1 Mode
•Select DTV model : Setting on
A/V2 mode
UTIL2 –CALIBRATE
Touch Calibration
YES / NO
CarNavi-Tech

3. Settings
-17-
3.3.5 FACTORY MODE-UTIL2
①First of all, press ◀button on
remote controller 2 seconds
long or press
UP→DOWN→UP→MENU button
in order to access Factory
mode. Choose IR MEMORY on
UTIL2.
In IR MEMORY, you can choose
AV source of DTV and DVD you
want to use.
②Picture above shows DVD
remote control button value
input, select menu you want
to save. (To register DVD
remote control button value,
select IR MEMORY –DTV and
follow below instructions.
Example)
a. After select OK button on
OSD menu, press intended I-
Drive button
b. Indicated part above will
flicker, and press POWER on
DVD remote control.
(continue to next page)
FACTORY mode –Press ◀button 2 seconds long on the remote control.
What is IR-MEMORY Mode?
Is to allow Jog shuttle and touch screen to control other DVD or DTV
(besides the existing,; for example : SANYO, NECVOX) by register
remote control value.
UTIL2 –IR MEMORY
CarNavi-Tech
