Sune Technology PCM3.1 User manual

Installation Manual
Multimedia Interface for Porsche PCM3.1
SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:[phone]
FAX:
[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99

Compatibility: Porsche PCM3.1 system
Components: Interface Main*1
Sub Board*1
Interface Input / Output specification :
Input: LVDS*1
CVBS(Front Camera)*1
CVBS(Rear Camera)*1
Output:
Power Spec:
Input Power: 8VDC ~ 18VDC
Consumption: 5WATT
Switch input mode:
1. External video sources skip function: Able to control input videos on and off
via Dip switches
2. Able to switch videos via the remote, button switch and original OEM button
3. Able to detect the rear view camera by CAN or rear lamp cable
2

MAIN BOARD
QCPASS1411
LVDS CABLE
HLVDSC0069
POWER CABLE
HPOWER0259
BUTTON CABLE
HARETC0001
REMOTE CTRL.
REMOTE0001
IR CABLE
HIRCAB0002
SUB BOARD
QCPASS1403
4Pin Touch CABLE
HTOUCH0022
FFC Cable*2ea
FFCABL 0008
3
FFC Cable*1ea
FFCABL0056
FFC Cable*1ea
FFCABL0057
POWER / CAN
J by J CABLE
HPOWER0045
Bracket
Touch cable*1ea
HTOUCH0027

ON: DOWN / OFF: UP
* Please make sure to disconnect the power cable
of interface and reconnect to apply dip switch
setting whenever changing DIP switch.
4
8POL DIP SWITCH SETTING
DIP S/W
STATUS
DESCRIPTION
DIP1
OFF
LVDS Navigation Mode
ON
LVDS Navigation Mode Skip
DIP2
OFF
Ext. Front Camera Mode
ON
Ext. Front Camera Mode Skip
DIP3
OFF
No Use
ON
DIP4
OFF
No Use
ON
DIP5
OFF
No Use
ON
DIP6
OFF
ON
DIP7
OFF
OEM Rear Camera Mode
ON
Ext. Rear Camera Mode
DIP8
OFF
No Use
ON

5
Key
FUNCTION
POWER & PIP N/C
MENU Activating OSD menu
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can access the
factory mode)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset all the
data about user environment)

6
H-POSITION/V-POSITION Setting
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
RADAR ENABLE
AUTO FCAM TIME
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
PAS TYPE: Select parking line type.
NOT USED: Do not use parking line
PAS ON: Use Flexible Parking Lines
PAS OFF: Use fixed parking line
PAS SETUP:
You can move the position of parking line.
REAR TYPE: Choose rear camera recognition.
CAN: Detecting the rear view camera by CAN signal. (Installer must connect
“CAN” cable of the power cable to the “CAN” cable of the car)
LAMP: Detecting the rear view camera via “Grey Rear” wire. (Installer must
connect “Rear-C” cable of the power cable to the rear lamp of the car)
RADAR ENABLE:
Setting up parking distance alarm sensor. (ON/OFF)
F-CAM TIME :
Time setting for the front camera display. (OFF, 3s, 5s, 10s, 15s)

7
UTIL1
LVDS MODEL: Android, car-play, navigation model
setting
CAR MODEL:
UTIL2
HANDLE BUTTON: Select the usage of handle button
FACTORY RESET: Factory mode reset (YES/NO)
INFO
System version information
PARK
UTIL1
UTIL2
INFO
LVDS MODEL
CAR MODEL
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
HANDLE BUTTON
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
<SYSTEM VERSION>
- MAIN : 191107
Menu of FACTORY
MENU to Return SEL to Select/Save

8
Monitor
*Press and hold Navi button for mode change
Steering Wheel
*Press and hold back button for 5seconds to do
mode change
*On rear Camera mode, please press Navi
button to show small PDC screen on the screen.

9
CARPLAY
BOX
LVDS Cable
4Pin touch cable
Touch generated by Uart
in HDMI connector
No Use
Android Navi
Box
OR
HPOWER0259
HPOWER0045
+
No Use

10
RCAM IN
FCAM IN Toggle button
Remote
control
F-DET
R-DET
CAM-12V
AUX L & R

①
②
11
①Disassemble the monitor and connect the
touch cable from the back of LCD as shown
on the left
- OEM Gold touch cable → Supplied touch cable
(HTOUCH0027)
- Supplied FFC cable → Supplied touch cable
(FFCABL0033) (HTOUCH0027)
- Supplied black FFC cable → Where OEM touch
(FFCABL0008) cable is connected
②Take out cables through the marked place and
assemble the plate.

③
④
12
③This picture is another side of LCD
Loosen 3 bolts which are marked on the left.
④Connect supplied FFC cable to marked place
- Supplied 50P FFC cable → ①
(FFCABL0057)
- Supplied 30P FFC cable → ②
(FFCABL0056)
①
②

⑤
⑥
13
⑤place the bracket where bolts were loosen and
tighten bolts again
⑥On the top of bracket, place the subboard and
connect the supplied FFC cables as shown on the
left

⑦
⑧
14
⑦Pull the cables on the backside of LCD
through the marked place.
⑧Connect cables as shown
on the left
- Black FFC cable → LCD OUT
- FFC cable → LCD IN
- Original 50P FFC cable → ①
- Original 30P FFC cable → ②
①
②

⑨
⑩
15
⑨After all FFC cables installed, the
looking is as left picture.
⑩Please connect 4Pin touch cable on
the sub board and then please
connect it to Main Interface.
After that, please connect LVDS cable
between sub board and Main Interface.

16
Q. I cannot change mode
A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not
check connection of POWER cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V sources
connected are working well. (Second lamp indicates AV sources connected works
well) Check interface connection has been done well.
Q. Displayed image color is not proper (too dark or unsuitable color)
A. Press ▶ button on the remote control for 2 seconds and check how it goes, if it
does not work, inform to manufacturer.
Q. I cannot watch the rear camera on the screen
A. Set the DIP switch #7 as state “ON”.
Q. Set mode not appear
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps on, inform to
manufacturer.
Q. Screen only displays white color.
A. Check LCD out cable is connected well, if this status keeps, inform to
manufacturer.
Q. If no image is shown on screen after connecting CAN wire with Park gear.
A. Go on the “FACTORY MODE”, check “UTIL-Rear Select”. If “LAMP”, change the
setting as “CAN” with the remote control. (* when connecting Rear-C wire of LAMP
power cable to Backup lights, Setting should be like this / CAN : if controlling rear
camera with CAN wire)
