Sune Technology SUNE10 PLUS-20ALPHARD/20 LM300h User manual

Installation Manual
SUNE10 PLUS-20ALPHARD/20 LM300h
SUNE TECH
Manual Date
Firmware Date
Main
Sub
Tw8823
2020,05,08
2020, 05, 07
2020, 04, 08
2020, 03, 10

COMPONENTS
ALPHARD/LM Key-Pad
A10-LC200 Universal AV-Cable
Speaker GLONASS GPS WIFI/BT Antenna x 2 MIC
ALPHARD/LM Universal
WiFi/BT Antenna x 2
AV-Cable
SUNE TECH

COMPONENTS option
New GVIF Cable
ALPHARD/LM Power 1on1
SUNE TECH

PIN ASSIGNMENT
SUNE TECH
POWER / CAN
1 ACC IN 2 Ground
3 Aux Detect 4 ADC 2
5 ADC 1 6
7 ECU CAN H 8 ECU CAN L
9 IEBus1 H 10 IEBus1 L
11 IEBus2 H 12 IEBus2 L
13 PAD_CAN_OUT_H 14 PAD_CAN_OUT_L
15 PAD_CAN_IN_H 16 PAD_CAN_IN_H
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
2 16
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
987654321 211
22
AV IN
1, 2 DVB-T Video
3, 4 DVB-T Audio R
5, 6 DVB-T Audio L
7, 8 DVD Video
9, 10 DVD Audio R
11, 12 DVD Audio L
13, 14 Front Camera
15, 16 Rear Camera
2
AV IN/OUT
1 Speaker P 2 Speaker N
3 Audio Out R 4 Ground
5 Audio Out L 6 Ground
7 Mic P 8 Mic N
9 10
11 12
13 14 REAR 12V
15 16 REVERSE
17 OMNI KEY 18 IR Receive –Signal
19 IR –DVB-T 20 IR Receive –Ground
21 IR - DVD 22 IR Receive –Power
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
87654321 151
2 16

ON1 2 3 4 5 6 7 8 9 10 ON1 ON1
OFF ON
DIP SWITCH SETTINGS
Switch OFF ON
SW1 Used HDMI Input
SW2 Used Rear Camera Input
SW3 Used Front Camera Input
SW4 Used DVB-T (CVBS) Input
SW5 Used DVD (CVBS) Input
SW6 reserved
SW7
List of Car Model
SW8
SW9
SW10
7 8 9 10 Model Inch
OFF OFF LM 2020 ~10.5
OFF OFF OFFON ALPHARD 2020 ~
SUNE TECH
ON ON
10.5

INSTALLATION DIAGRAM
From HEADUNIT
From HEADUNIT
SUNE TECH

OEM BUTTON LM300h
Steer
Remote How to press Description of operation
1, End call button Press button for long time OEM-NAVI-DVD-DTV
TouchPad How to press Description of operation
1, HOME
( MAP )
Press button for short time Return back to OEM Screen form
Interface Screen
Press button for 1 second Screen is switched in that order
switches are activated.
2. MENU Press button for short time Return back to OEM Screen form
Interface Screen
Steering wheel
1
Touch Pad
12

OEM BUTTON ALPHARD
Steer
Remote How to press Description of operation
1, End call button Press button for long time OEM-NAVI-DVD-DTV
TouchPad
1, HOME
How to press
Press button for short time
Description of operation
Return back to OEM Screen form
Interface Screen
Press button for 1 second Screen is switched in that order
switches are activated.
Steering wheel
control panel

Copyright ⓒ2019 by SUNE TECHNOLOGY
SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan
City 70849,TAIWAN TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
