Sune Technology NTG5.0 User manual

Installation Manual
Multimedia Interface for Mercedes Benz
NTG5.0/NTG5.1

Compatibility: Mercedes Benz NTG5.0, NTG5.1 2014~
S-CLASS (W222) 2014~
C-CLASS (W205) 2014~
E-Class, GLE, GLC, A, V class 2015~
B-Class (W246) 2015~
CLS Class 2015~
Components: Interface Main*1
Sub Board*1
Interface Input / Output specification :
Input: LVDS*1
CVBS(Front Camera)*1
CVBS(Rear Camera)*1
Output:To LCD*1
Power Spec:
Input Power: 8VDC ~ 18VDC
Consumption: 5WATT
Switch input mode:
1. External video sources skip function: Able to control input videos on and off
via Dip switches
2. Able to switch videos via the remote, button switch and original OEM button
3. Able to detect the rear view camera by CAN or rear lamp cable
2

Main Board
QCPASS1411
LVDS Cable
HLVDSC0069
Power Cable
HPOWER0240
UART T/S Out Cable
HTOUCH0015
Button Cable
HARETC0001
Remote Controller
REMOTE0001
IR Cable
HIRCAB0002
Sub Board
QCPASS1403
T/S Out Cable
HTOUCH0009
Res. T/S Cable
HTOUCH0029
Cap. T/S Cable
HTOUCH0036
LCD Out Cable
HLCDCA0017
QLI J BY J Cable
HPOWER0248
3

ON: DOWN / OFF: UP
* Please make sure to disconnect the power cable
of interface and reconnect to apply dip switch
setting whenever changing DIP switch.
4
8POL DIP SWITCH SETTING
DIP S/W
STATUS
DESCRIPTION
DIP1
OFF
LVDS Navigation Mode
ON
LVDS Navigation Mode Skip
DIP2
OFF
Ext. Front Camera Mode
ON
Ext. Front Camera Mode Skip
DIP3
OFF
NTG5.0 CAN Speed
ON
NTG5.1 CAN Speed
DIP4
OFF
No Use
ON
DIP5
OFF
Please refer below chart
ON
DIP6
OFF
ON
DIP7
OFF
OEM Rear Camera Mode
ON
Ext. Rear Camera Mode
DIP8
OFF
CAN Data In/Out Mode for Jog Dial
ON
CAN Data Bypass Mode for Jog Dial
MONITOR TYPE
DIP S/W SETTING
DIP #5
DIP #6
7”/8”
800*480
ON
OFF
8.4”
965*540
OFF
OFF
12.3”
1440*540
OFF
ON
12.3”
1440*540 DUAL
ON
ON

5
Key
FUNCTION
POWER & PIP N/C
MENU Activating OSD menu
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can access the
factory mode)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset all the
data about user environment)

6
H-POSITION/V-POSITION Setting
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
RADAR ENABLE
AUTO FCAM TIME
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
PAS TYPE: Select parking line type.
NOT USED: Do not use parking line
PAS ON: Use Flexible Parking Lines
PAS OFF: Use fixed parking line
PAS SETUP:
You can move the position of parking line.
REAR TYPE: Choose rear camera recognition.
CAN: Detecting the rear view camera by CAN signal. (Installer must connect
“CAN” cable of the power cable to the “CAN” cable of the car)
LAMP: Detecting the rear view camera via “Grey Rear” wire. (Installer must
connect “Rear-C” cable of the power cable to the rear lamp of the car)
RADAR ENABLE:
Setting up parking distance alarm sensor. (ON/OFF)
F-CAM TIME :
Time setting for the front camera display. (OFF, 3s, 5s, 10s, 15s)

7
UTIL1
LVDS MODEL: Android, car-play, navigation model
setting
CAR MODEL: Select the car model
ASTON(TYPE1)
ASTON(TYPE2)
NTG5.1 CLS
NTG5.1 CLA
NTG5.1 B-CLASS
NTG5.0(TYPE2)
NTG5.0(TYPE1)
UTIL2
HANDLE BUTTON: Select the usage of handle button
FACTORY RESET: Factory mode reset (YES/NO)
INFO
System version information
PARK
UTIL1
UTIL2
INFO
LVDS MODEL
CAR MODEL
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
HANDLE BUTTON
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
<SYSTEM VERSION>
- MAIN : 191107
Menu of FACTORY
MENU to Return SEL to Select/Save

8
* Press high lighted OEM button for 3 seconds long to mode switch
S Class
C Class

9
CARPLAY
BOX
OEM
Monitor
OEM
Command
1. QDIS supplied LCD out cable from OEM Command to
sub-board “LVDS IN”
2. OEM LCD cable from back side of OEM Monitor to
sub-board “To Monitor”
3. QDIS supplied LVDS cable from sub-board “LVDS OUT”
to interface “LVDS OUT(B)”
Supplied Res. Touch in cable
EXT. touch
screen
Power/CAN in/out
Rear camera input *1
Front camera input *1
UART Touch Cable
Pin assignment
RX
TX
GND
* Please refer to next page
for power/CAN connection
Supplied Cap. touch in cable
Supplied touch out cable from sub-board
“Res. T/S OUT” to interface “T/S IN”
❶
❷
❸

Disassemble the black plastic cover Connect OEM cables to the supplied CAN
IN/OUT cables
Put the black plastic cover and the supplied CAN
IN/OUT cables together
Insert the supplied CAN cables into the marked
place
①②
③④
⑤⑥
Find the connector behind the command Remove the black connector which is marked in
Red
10

11
* These functions can be used when SE-CP or NV-CP is installed with.
S ClassC Class GLA
⑥
②
④⑤
①
⑦③⑥
②
④⑤
①
⑦③
⑥
②
④⑤
①
⑦③
Section
No.
Button
Operation
Function
IDRV
1
IDRV WHEEL PUSH
Short press
Selection/Enter
Long press (3sec)
Si-ri Call
2
IDRV WHEEL DOWN
Moving left
Left
3
IDRV WHEEL UP
Moving right
Right
4
IDRV LEFT
Short press
Left/Track +
5
IDRV RIGHT
Short press
Right/Track -
6
IDRV UP
Short press
Up
Long press (3sec)
Home
7
IDRV DOWN
Short press
Down
Long press (3sec)
Moving to Android Auto
Down Side Menu
8
IDRV BACK
Short press

12
Q. I cannot change mode
A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not
check connection of POWER cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V sources
connected are working well. (Second lamp indicates AV sources connected works
well) Check interface connection has been done well.
Q. Displayed image color is not proper (too dark or unsuitable color)
A. Press ▶ button on the remote control for 2 seconds and check how it goes, if it
does not work, inform to manufacturer.
Q. I cannot watch the rear camera on the screen
A. Set the DIP switch #7 as state “ON”.
Q. Set mode not appear
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps on, inform to
manufacturer.
Q. Screen only displays white color.
A. Check LCD out cable is connected well, if this status keeps, inform to
manufacturer.
Q. If no image is shown on screen after connecting CAN wire with Park gear.
A. Go on the “FACTORY MODE”, check “UTIL-Rear Select”. If “LAMP”, change the
setting as “CAN” with the remote control. (* when connecting Rear-C wire of LAMP
power cable to Backup lights, Setting should be like this / CAN : if controlling rear
camera with CAN wire)

13
