sunjoe 24V-BBQ-LTE User manual
© 2021 by Snow Joe®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
1
A Division of Snow Joe®, LLC
OPERATOR’S MANUAL
Model 24V-BBQ-LTE Form No. SJ-24V-BBQ-LTE-880E-M
RCORDLESS FIRE STARTER
24V MAX* | 2.0 Ah | 1470 °F MAX
EN
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/
or serious injury.
General Safety WARNINGS!
Notice the personal safety alert symbol m used in this manual
to draw your attention to a WARNING given along with the
particular operating instruction. This means that the operation
requires special ATTENTION, CAUTION, and AWARENESS.
When using this re starter, basic safety precautions, including
the following, should always be followed to reduce the risk of
re, electric shock, personal injury and material damage.
mWARNING! To reduce the risk of re or electric shock,
do not expose this product to rain or moisture. Store indoors.
Do not leave it outdoors.
mWARNING! NEVER submerge the unit in any liquid.
mWARNING! Be aware that heat from this tool could
ignite ammable materials in hidden areas such as walls,
ceilings, oors or sot boards. The ignition of these materials
may not be obvious and could result in property damage and
personal injury.
1. Read all the instructions before using the appliance.
2. To reduce the risk of injury, close supervision is necessary
when an appliance is used near children.
3. Do not contact hot parts.
4. This appliance is not intended to be used by persons
(including children) with reduced physical, sensory or
mental capabilities, or persons with lack of experience
and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by
someone responsible for their safety.
5. Children should be supervised to ensure that they do not
play with the appliance.
6. Do not immerse in water.
7. For use only with Snow Joe®+ Sun Joe®24V iON+ series
batteries and chargers.
8. Ensure that the re starter is properly positioned before
turning on.
9. Allow the re starter to cool completely before storage.
10. Do not allow the hot parts of the re starter to touch any
ammable materials.
11. Remove the battery from the re starter before charging.
12. Do not mix dierent batteries, or new and used batteries.
13. Check the polarity of the battery before inserting into the
re starter.
14. Remove the battery before storing the re starter.
15. The supply terminals are not to be short-circuited.
Work Area Safety
1. Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
2. Do not operate the re starter in explosive atmospheres,
such as in the presence of ammable liquids, gases or
dust.
3. Keep children and bystanders away while operating a re
starter. Distractions can cause you to lose control.
Electrical Safety
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
1. Do not expose the re starter to rain or wet conditions.
Water entering the unit will increase the risk of electric
shock.
2. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
3. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
4. When the battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
2
5. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
6. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
7. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 104°F (40.5°C) may cause explosion.
8. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
9. Do not modify or attempt to repair the appliance or the
battery pack except as indicated in the instructions for
use and care.
Personal Safety
mWARNING! Do not touch the hot part while operating
and until unit is completely cooled down. Touching hot surface
can cause severe burns, personal injury or property damage.
1. Stay alert, watch what you are doing and use common
sense when operating the re starter. Do not use the
unit while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention while
operating the unit may result in serious personal injury.
2. Do not force the appliance. It will do the job better with
less likelihood of injury if it is used at the rate for which it
was designed.
3. Use the right appliance. Do not use the appliance for any
job except that for which it is intended.
4. Do not use the appliance if the switch does not turn
it on and o. Any appliance that cannot be controlled by
the switch is dangerous and must be repaired.
5. Disconnect the battery pack from the appliance
before making any adjustments, changing accessories
or storing the appliance. Such preventative safety
measures reduce the risk of starting the appliance
accidentally.
6. Store the idle appliance out of the children’s reach and
do not allow persons unfamiliar with the appliance or
these instructions to operate the appliance. Appliances
are dangerous in the hands of untrained users.
7. Maintain appliance with care. Check for misalignment or
binding of moving parts, breakage of parts and any other
condition that may aect the tool's operation. If damaged,
have the tool repaired before use. Many accidents are
caused by poorly maintained power tools.
8. Keep the product dry, clean and free from oil and
grease. Always use a clean cloth when cleaning. Never
use brake uids, gasoline, petroleum-based products, or
any strong solvents to clean your product. Following this
rule will reduce the risk of loss of control and deterioration
of the enclosure plastic.
9. Use the appliance and accessories in accordance with
these instructions and in the manner intended for the
particular use of the appliance, taking into account
the working conditions and the work to be performed.
Using the tool for operations dierent from those intended
could result in a hazardous situation.
10. Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition.
Be aware of possible hazards when not using your battery
tool or when changing accessories. Following this rule will
reduce the risk of electric shock, re, or serious personal
injury.
11. The unit can becomes very hot. Do not lay the re starter
on ammable surfaces while operating or immediately
after shutting o. Always set it on the stand with the outlet
tip pointing in a safe direction.
12. Never point the tool at yourself or others.
Service
1. If your appliance requires service, contact an
authorized Snow Joe®+ Sun Joe®dealer or call the
Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563). Only identical
replacement parts should be utilized for repairs. This will
ensure that the safety of the power tool is maintained.
2. If the battery charger cable is damaged, it must be
immediately replaced to avoid a hazard. Contact
the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the power tool and cause it to
malfunction, which can lead to serious personal injury.
3
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
Sun Joe®24V lithium-ion battery pack only in its designated
Sun Joe®lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire a battery
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the battery outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger (24VCHRG-AC) is rated for 100 – 240 volt AC
only – The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to
disconnect battery pack from unplugged charger.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery pack – Battery pack
may explode, causing personal injury or damage. Toxic
fumes and materials are created when battery packs are
burned.
• Do not crush, drop or damage battery pack – Do not use
the battery pack or charger if they have sustained a sharp
blow, been dropped, run over or have been damaged in any
way (i.e. pierced with a nail, hit with a hammer, stepped on,
etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger is damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – When battery pack is not in use,
keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects
that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or
a re.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. The battery pack supplied with your cordless re starter is
only partially charged. The battery pack has to be charged
completely before you use the tool for the rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your cordless re
starter, and therefore pose a safety risk.
4
5. Do not throw the battery pack into an open re as this
poses a risk of explosion.
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
8. Protect the battery and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than
3 feet (1 meter) or those that have been exposed to violent
shocks, even if the housing of the battery pack appears to
be undamaged. The battery cells inside the battery may
have suered serious damage. In such instances, please
read the waste disposal information for proper battery
disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the power supply button any
more if the protective cut-o has been activated. This may
damage the battery pack.
11. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
12. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
13. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
14. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
15. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 265ºF (130°C) may cause explosion.
16. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before connecting with the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge the battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
5
Protection from environmental inuences
1. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
2. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
3. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
4. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
5. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
6. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
7. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
8. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
WARNING! Electrical shock hazard.
Symbols SymbolsDescriptions Descriptions
HOT SURFACE – To reduce the risk
of injury or damage, avoid contact
with any hot surface.
Indoor use only. Only use battery
charger indoors.
7
Know Your Cordless Fire Starter
Read the owner’s manual and safety instructions carefully before operating this cordless re starter. Compare the illustration
below to the cordless re starter in order to familiarize yourself with the location of the various controls and adjustments. Save
this manual for future reference.
13
4
5
678910 11 12
13
1. Heat shield
2. Mode switch
3. Power switch
4. Handle grip
5. Battery compartment
6. iON+ 24V lithium-ion battery
(24VBAT-LTE) featuring exclusive
EcoSharp®technology
7. Charge socket
8. Push lock buttons (2)
9. Push button for battery indicator
10. Battery indicator
11. Stand/Bottle opener
12. 24V iON+ lithium-ion charger
(24VCHRG-AC)
13. Charger plug
2
8
Technical Data
Motor .............................................................................. 480 W
Battery Voltage* Max .................................................. 24V D.C.
Battery Capacity ............................................................. 2.0 Ah
Battery Runtime Max ..................................................... 6.5 min
Continuous heating
Charger Input ................................................... 100 – 240 V AC,
50 – 60 Hz, 50 W
Charger Output ......................................... 25.2V DC | 1400 mA
Charge Time Max .................................................... 1 hr 20 min
Air Speed Max .............................................................. 35 Mph
Max Temperature ............................................ 1470 °F (800 °C)
Working Temperature ..................................... 1380 °F (750 °C)
Heating Speed ........................... Up to 1380 °F (750 °C) in 30 s
2 Working Modes ............................................... Heat + blower
Blower only
Heating Element .......................... Ferrochrome resistance wire
Net Weight ......................................................... 2.8 lbs (1.3 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless re starter
• iON+ 24V lithium-ion battery
• iON+ 24V lithium-ion battery charger
• Manual with registration card
1. Carefully remove the cordless re starter and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless re
starter. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils or small
parts. These items can be swallowed and pose a suocation
risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Turn o the re starter as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Turn o the re
starter IMMEDIATELY and charge the battery. Otherwise
the battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only Sun Joe®24V lithium-ion
battery pack with its compatible Sun Joe®24V lithium-ion
charger. Other types of batteries may cause personal injury
and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT-LTE
Lithium-iON Battery
NOTE: The iON+ 24VBAT-LTE lithium-ion battery pack does
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before inserting the charger plug.
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights
9
• Use the battery indicator lights to determine when to charge
your iON+ 24VBAT-LTE lithium-ion battery pack.
• You can "top-o" your battery pack's charge before or after
a long day of use.
Charging the Battery
1. Push the push lock buttons on the battery to pull the
battery pack out from the battery compartment (Fig. 1).
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, plug the
charger adapter into an appropriate AC power outlet.
Connect the charger plug into the charge socket of the
battery to start charging (Fig. 2).
3. The battery will take approximately 1 hr 20 min to charge.
The battery indicator LEDs will twinkle and illuminate one
by one during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery.
mWARNING! This charger does not automatically
turn o when the battery is fully charged. Please take care
not to leave the battery plugged into the charger. Switch
o or unplug the charger at the mains when charging is
complete.
4. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
Operation
Sun Joe® cordless re starter ignites charcoal with super
heated air, then uses the built-in blower to fan the ames. This
safe and eco-friendly starter can light charcoal, paper, and
wood in 60 seconds (depending on the fuel type) without using
any dangerous chemicals.
mWARNING! Do not allow familiarity with products to
make you careless. Remember that a careless fraction of a
second is sucient to inict serious injury.
Starting and Stopping
1. Insert the battery in the battery compartment. Push to
make sure it is locked in place (Fig. 3).
2. Set up a pile of fuel you like – charcoal, twigs and sticks,
wood chips, or logs. Make sure the mode switch is
pushed forward and the re starter is set in heat + blower
mode, touch the fuel with the tip of the cordless re starter
nozzle and slide the power switch forward (Fig. 4).
Fig. 1
Battery pack
Battery lock button
Fig. 2
Battery
indicators
Fig. 3
Battery pack
Battery
compartment
10
3. Keep the cordless re starter aimed towards the same
spot. There should be a glowing spot in about 15 to 30
seconds.
4. When the fuel starts to burn, slide the mode switch back
to the blower only mode, and pull the re starter a few
inches back. Giving it space will help the heated air to
spread out (Fig. 5).
NOTE: Get the grill ready to cook faster by continuing
on blower only mode until the grill reaches the desired
temperature.
5. When the grill is ready, slide back the power switch to turn
o the re starter. Remove the battery. Rest the re starter
on its stand to let it cool down completely.
NOTE: When the machine is shut down the fan will
continue to work for couple seconds to cool down the
machine.
Mode Switch (Fig. 6)
The re starter is equipped with 2 working modes:
• Heat + blower mode will heat the air and increase the
temperature around the nozzle tip, therefore ignite the fuel.
• Blower only mode will increase the airow and spread the
heat after the fuel is ignited, to create strong ame.
Adjust the unit's mode with the mode switch next to the power
switch. Slide it forward to set the re starter to heat + blower
mode. Slide it backward to set the re starter to blower only
mode.
Operating Tips
mDANGER! Do not operate near explosive or ammable
materials unless extraordinary safety precautions are
observed. The re starter produces air at extremely high
temperatures and if exposed to explosive or ammable
materials, will result in ame or possible explosion, causing
serious personal injury, death or property damage.
1. Always make sure ammable objects are kept at a safe
distance.
2. Never use near gas, petroleum products, or other
explosive substances.
3. Do not use near combustible materials such as dry grass,
leaves, and paper, which can scorch and catch re.
mDANGER! Use extreme caution when starting a re.
Some charcoal contains impurities that cause sparks and
popping. Sparks could cause minor or moderate injury or
property damage.
4. Never bury tip under charcoal or wood.
5. Never leave the unit in the re.
6. Sparks can be generated and y towards you and others.
7. Sparks and ash can be blown out of designated burning
area.
Power
switch
Fig. 4
ON OFF
Mode
switch
About 3 inches
Fig. 5
Mode switch
Fig. 6
Heat + blower
Blower only
11
Maintenance
mWARNING! Always switch the product o, remove the
battery and wait until the appliance is completely cool down
before performing inspection, maintenance, and cleaning work.
mWARNING! When servicing, use only identical
replacement parts. Use of any other parts could create a
hazard or cause product damage.
General Cleaning Tips
Use a soft, dry brush to clean the air inlet area. Use only mild
soap and a damp cloth to clean the housing. Do not use
house-hold cleaners, since many contain chemicals, which
could seriously damage the plastic housing of the re starter.
Do not use gasoline, turpentine, lacquer thinner, paint thinner,
dry cleaning uids or similar products on the re starter.
mWARNING! Never allow any liquid to get inside the
re starter or immerse any part of the re starter into a liquid.
Ensure the air inlet and the housing are clean and free of
obstructions.
mWARNING! Do not at any time let brake uids, gasoline,
petroleum based products, penetrating oils, etc., come in
contact with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal injury.
Storage
mWARNING! Let the re starter cool to room temperature
before placing it in storage.
• Switch o the unit, remove the battery. Wait until it is
completely cooled down. Thoroughly clean the housing.
• Store the re starter, with the battery and charger indoors in
a safe location out of the reach of children. Keep away from
corrosive agents, such as garden chemicals and de-icing
salt.
Disposal
Recycling the tool
• Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If electrical appliances are disposed of in landlls
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Recycling + Disposal
The product comes in a package that protects it against
damage during shipping. Keep the package until you are
sure that all parts have been delivered and the product is
functioning properly. Recycle the package afterwards or keep it
for long-term storage.
WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority
or local store for recycling regulations.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert the battery in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the battery or cause the battery to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
12
Service + Support
If your Sun Joe® cordless re starter needs service or
maintenance, please call the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
Model + Serial Numbers
When contacting the company or reordering parts, you will
need to provide the model and serial numbers of your product.
These are found on the decal axed to the housing of your
cordless re starter. Copy these numbers into the space
provided below.
24V iON+ Lithium-Ion
Charger (24VCHRG-AC)
Federal Communications Commission
(FCC)
mWARNING! Any changes or modications to this
unit not expressly approved by the party responsible for
compliance could void the user's authority to operate
the equipment.
Class B device:
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Record the following numbers from the housing or handle of your
new product: Model #:
2 4 V - B B Q - L T E
Serial #:
Other manuals for 24V-BBQ-LTE
1
Table of contents
Other sunjoe Power Tools manuals
