Sunny Health & Fitness SF-B1401 User manual

INDOOR CYCLING BIKE
SF-B1401
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED
US [email protected] or 1-877-90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this
equipment correctly. It is important to read this entire manual before assembling and using the
equipment. Safe and effective use can only be achieved if the equipment is assembled,
maintained and used properly. It is your responsibility to ensure that all users of the equipment are
informed of all warnings and precautions.
1. Before starting any exercise program, you should consult your physician to determine if you
have any medical or physical conditions that could put your health and safety at risk, or prevent
you from using the equipment properly. Your physician’s advice is essential if you are taking
medication that affects your heart rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest,
irregular heartbeat, shortness of breath, lightheadedness, dizziness or feelings of nausea. If
you do experience any of these conditions, you should consult your physician before
continuing with your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use
only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet.
To ensure safety, the equipment should have at least 4 feet (1.2 M) of free space all around it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of
the equipment can only be maintained if it is regularly examined for damage and/or wear and
tear.
6. Always use the equipment as indicated. If you find any defective components while assembling
or checking the equipment, or if you hear any unusual noises coming from the equipment
during exercise, discontinue use of the equipment immediately and do not use until the
problem has been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may
become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 275 pounds (125 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/or damage to the product or property, proper lifting and moving is
required.
12.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme
cold, hot or damp areas as this may lead to corrosion and other related problems.
13.This equipment is designed for indoor and home use only, it is not intended for commercial use!

2
EXPLODED DIAGRAM

3
HARDWARE PACKAGE
#34 (M10*25*S6) 4PCS
#66 (M10*25*S6) 2PCS
#67 (d10*Φ20*1.5) 2PCS
#33 (d10*Φ20*1.5) 4PCS
#75 (S13-15) 1PC
#74 (S6) 1PC
#76 (S14,15,17) 1PC
#78 (S8,14,22) 1PC

4
PARTS LIST
No.
Description
Spec.
Qty.
No.
Description
Spec.
Qty.
1
Main Frame
1
34
Flat Roundhead Screw
M10x25XS6
4
2
Seat Post
1
35L/R
Pedal
1 pr.
3
Seat Slider
1
36
Flywheel
1
4
Handlebar Post
1
37
Flywheel Spindle
1
5
Handlebar
1
38
Chain Adjuster Welding
M8*83* Ø12*5
2
6
Cap Nut
M12*1.0
2
39
Sleeve
Ø18*Ø12.1*18.5
1
7
Rear Stabilizer
1
40
Nylon Nut
M8*H7.5*S13
2
8
Front Stabilizer
1
41
Brake Pad
2
9
Brake Handle
1
42
Clamp Brake Holder
1
10
Washer
d10*Ø25*2
1
43
Washer
Ø11*Ø25*4
1
11
Tension Knob
1
44
Bearing
6001-2RZ
2
12
Left Crank
1
45
Bearing
6004-2RS
2
13
Cross Self-tapping Screw
ST4.8*16
7
46
Bearing
608ZZ
4
14
Chain Cover A
1
47
Small Chain Wheel
1
15
Chain Cover B
1
48
C-shaped Buckle
d20
2
16
Base Leveler
4
49
Hexagon Screw
M10*H7*S17
4
17
Post Housing
3
50
Inner Hexagon Hollow Bolt
Ø7.8*30
3
18
Square Caps
J80*40*1.5
4
51
Nut
M6*38*S5
1
19
Square Caps
F38*38*14
1
52
Flat Washer
d5* Ø 10*1
2
20
Front Cover
1
53
Hexagon Flange Nut
M10*1.25*H7.5*S14
2
21
Transportation Wheels
Ø71* Ø19*24
2
54
Cross Recessed Countersunk
Bolt
ST4.8*25
3
22
Seat
1
55
Hexagon Thin Nut
M12*1*H6*S19
3
23
Knob
3
56
Hexagon Flange Nut
M6 *H7*S10
1
24
Round End Cap
Φ22*16
1
57
Locknut
2
25
Square Cap
F45*45*24
1
58
Nylon Nut
M10*H9*S17
1
26
Washer
Ø8* Ø25*6
3
59
Cross Pan Head Bolt
M5*12* Ø 8
2
27
Screw
t0.6*10.6
5
60
Inner Hexagon Flat Round
Head Screw
M6*12*S5
3
28
Silent Chain
1
61
Pedal Strap
2
29
Washer
d12* Ø 24*1.5
2
62
Pedal Belt
2
30
Bottom Bracket Axle
1
63
Brake Cable
2
31
Right Crank With Chain Wheel
1
64
Clamp Brake Assembly
1
32
Crank Cover
Ø 25*7
2
65
Brake Pad Holder
2
33
Washer
d10*Φ20* 1.5
8
66
Hexagon Flat Roundhead
Screw
M10*25*S6
2

5
67
Flat Washer
d10*Φ20* 1.5
2
75
Wrench
S13, S15
1
68
Front Packing Base
1
76
Spanner
S14, S15, S17
1
69
Rear Packing Base
1
77L
Left Nylon Nut
9/16*20*H9*S22
1
70
Flat Roundhead Screw
M10*16*S6
4
77R
Right Nylon Nut
9/16*20*H9*S22
1
71
Bottle Holder
1
78
Spanner
S8,14,22
1
72
Screw
M5*12
2
79
Screw
ST4.2*16
2
73
Flat Washer
D5*Φ13*1
2
80
Wave Washer
1
74
Allen Wrench
S6
1
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the part(s) needed:
✓The model number (found on cover of manual)
✓The product name (found on cover of manual)
✓The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST” (found near the
front of the manual)
Please contact us at [email protected] or 1- 877 - 90SUNNY (877-907-8669).

6
ASSEMBLY INSTRUCTIONS
STEP 1:
Unscrew the 4 Flat Roundhead Screws (No.
70) and 4 Washers (No. 33) from the Main
Frame (No. 1) with Allen Wrench (No. 74),
then remove the Front & Rear Packing
Bases (No. 68 & No. 69).
NOTE: You may discard the Front & Rear
Packing Bases (No. 68 & No. 69) or save
them for future packaging or transportation.
STEP 2:
Attach the Front & Rear Stabilizer (No. 8 &
No. 7) to the Main Frame (No. 1) using 4
Washers (No. 33) and 4 Flat Roundhead
Screws (No. 34). Tighten and secure with
Allen Wrench (No. 74).
NOTE: Always tighten parts by hand first then
finish securing with the provided Allen
Wrench (No. 74).

7
.
.
.
STEP 3:
IMPORTANT! Read instructions carefully,
failure to do so may cause permanent
damage to your bike.
Remove the 2 Left & Right Nylon Nuts
(No.77L & 77R) located on the 2 Pedals
(No.35L/R). The inside of the nuts are
different colors. Make sure you use the
correct pedal and nut for each side.
Screw the Pedal (No. 35L) COUNTER-
CLOCKWISE into the Left Crank (No. 12).
Once it is properly screwed into the place,
use the Wrench (No. 75) to hold the bolt of
the pedal and screw the Left Nylon Nut
(No. 77L) CLOCKWISE to the thread end of
the Left Pedal (No. 35L) securely with
Spanner (No. 78).
Screw the Pedal (No. 35R) CLOCKWISE
into the Right Crank (No. 31). Once
properly screwed into the place, use the
Wrench (No. 75) to hold the bolt of the
pedal and screw the Right Nylon Nut (No.
77R) COUNTER-CLOCKWISE to the thread
end of the Pedal (No. 35R) securely with
Spanner (No. 78).
STEP 4:
Loosen the [seat height adjustment] Knob
(No. 23) to slide the Seat Post (No. 2) into
the seat post housing on the Main Frame
(No. 1). Once you’ve located the desired
seat height, tighten and secure the Knob
(No. 23).
Loosen the [handlebar adjustment] Knob
(No. 23) to slide the Handlebar Post (No. 4)
into the post housing on the Main Frame
(No. 1). Once you’ve located the desired
height, retighten the Knob (No. 23).
Remove the 2 Screws (No. 72) and 2
Washers (No. 73) from the Main Frame
(No. 1). Reattach the parts [2 Screws (No.
72) and 2 Washers (No. 73)] along with the
Bottle Holder (No. 71) to the Main Frame
(No. 1) and tighten with Spanner (No. 76).

8
STEP 5:
Loosen the [seat adjustment] Knob (No. 23)
and slide the Seat Slider (No. 3) into the
Seat Post (No. 2). Retighten the Knob (No.
23) to fix the Seat (No. 22) onto the Seat
Slider (No. 3) with Wrench (No.75).
Attach the Handlebar (No. 5) onto the
Handlebar Post (No. 4) using 2 Hexagon
Flat Roundhead Screws (No. 66) and 2
Flat Washers (No. 67). Tighten and secure
with Allen Wrench (No. 74).
The assembly is complete!

9
ADJUSTMENTS & USAGE GUIDE
ADJUSTING THE BALANCE
In order to achieve a smooth and comfortable ride, during
use you must ensure that the stability of the bike is correct. If
during use you notice that the bike is unbalanced you can
adjust the base levelers located beneath the front and rear
bases. To do so, use Spanner (No. 76) to loosen the
Hexagon Screw (No. 49)by turning it clockwise (direction
A). With the nut loosened, rotate the Base Leveler (No. 16)
until it sits level with the surface that the bike is on. When
you have finished adjusting the base leveler, re-tighten the
Hexagon Screw (No. 49)by turning it counter-clockwise
(direction B) using Spanner (No. 76). If required, repeat this
process to adjust the remaining base levelers.
RESISTANCE AND BRAKING
You may adjust the tension level of the bike by rotating the
Tension Knob (No. 11). To increase the level of resistance,
rotate the tension knob clockwise,to decrease the level of
resistance, rotate the tension knob counter-clockwise.
During an exercise, users may stop the bike immediately by
pushing down on the Brake Handle (No. 9). This is the
emergency brake.
PEDAL STRAP ADJUSTMENT
Your feet should be secured in the toe clips during exercise.
Place your feet as far forward into the toe-clips as you can.
With your feet in place, turn the crank to bring one foot to
within arm’s reach, grasp the pedal strap and pull it upward
to tighten the toe-clip cage, then insert the strap back into
the hoop of the toe-clip. Repeat this process to secure your
other foot.
TRANSPORTING THE BIKE
To move the bike, first ensure that the Handlebar (No. 5) is
properly secured. If the handlebar is loose, tighten the Knob
(No. 23)to secure it. Next, stand at the front of the bike so
that you’re directly in front of the handlebar. Firmly grasp and
hold each side of the handlebar, place one foot on the front
base and tilt the bike towards you until the transport wheels
on the front base touch the ground. With the wheels on the
ground, you can transport the bike to the desired location
with ease. NOTE: When moving the bike, always move with
caution as unexpected impact, such as dropping the bike,
may cause injury and affect the bike’s operation.

10
ADJUSTING THE SEAT
The seat of this bike is fully adjustable as it moves Up,
Down, Fore (forward), Aft (backward).
To adjust the height of the Seat Post (No. 2), loosen and
pull the Knob (No. 23)outward, then raise or lower the seat
to the desired height. Once adjusted, re-insert and tighten
the Knob (No. 23)to secure the seat in place.
To adjust the seat back and forth, loosen and pull Knob (No.
23) outward, then slide the Seat Slider (No. 3) to the desired
position. Once positioned, re-insert and tighten the Knob
(No. 23) to secure the seat slider tube in place.
ADJUSTING THE HANDLEBAR
It is important that the handlebar and seat are both set to the
correct height of your body. To adjust the handlebar height,
loosen and pull the Knob (No. 23) outward, then slide the
Handlebar Post (No. 4) up or down to the desired height.
Once adjusted re-insert and tighten the Knob (No. 23) to
secure the handlebar post in place.
CHECKING BRAKE PADS AND PEDALS
Ensure all the Nuts, Nut Caps and Pedals are secured and
inspect the equipment regularly. If you should find any
defective parts, do not exercise until they’ve been repaired.
Pay close attention to easily damaged parts due to wear and
tear. Please inspect Brake Pads (No. 41) to ensure there is
still adequate padding on each side before exercising. Make
sure to replace brake pads as necessary. Also, inspect the
Pedals before exercise. If they have become loose, please
re-tighten.
TIGHTENING THE SEAT
Please adjust the Hexagon Nut by using the Opening
Spanner if the Seat (No. 22) is loose.
NOTE: In order to properly tighten the seat, it is important to
note that you will need two open faced wrenches (1 for each
side) and will need to tighten the nut on each side
simultaneously working in opposite direction of each other.

11
MAINTENANCE INSTRUCTIONS
This is general information for daily, weekly and monthly maintenance to be performed on your
bike.
Version 1.2
Version 1.4
DAILY MAINTENANCE
After each exercise session, wipe down all
the equipment: seat, frame, handlebars. Pay
special attention to the seat post, handlebar
post and belt/chain guard. Sweat is very
corrosive and may cause problems that
require parts replacement later.
1. Get on the bike and engage the drive
train.
2. Pay attention to any vibrations felt
through the pedals. If you feel any
vibrations, you may need to tighten the
pedals, bottom bracket, or adjust the drive
belt/chain tension.
3. Use a wrench to tighten the pedals until
they are secure.
MONTHLY MAINTENANCE
1. Check all hardware is secure, such as: water
bottle holder, flywheel nuts, belt/chain guard
bolts, brake caliper lock nuts and brake
caliper tension rod nuts.
2. Inspect the brake tension rod for signs of
wear such as missing threads. Clean and
lubricate the brake tension rod.
3. Clean and lubricate the seat post, handlebar
post and seat slider. Remove any build up of
foreign material.
WEEKLY MAINTENANCE
1. Inspect moving parts and tighten the
hardware.
2. Inspect pull pin frame fittings, making
sure the fittings are snug. Loose frame
fittings may strip out threads over time
and cause extensive damage.
3. Clean and lubricate pop pin assemblies.
Pull on the pin and spray a small amount
of lubricant onto the shaft.
4. Tighten the seat hardware, making sure
the seat is level and centered.
5. Brush and treat the resistance pads.
Remove any foreign material that may
have collected on the pads. Spray the
pads with silicone lubricant. This helps to
reduce noise from friction between the
pads and the flywheel.
6. Visually inspect the bottom bracket, toe
clips and toe straps. If any of them are
loose or disconnected, attach and tighten.
LEATHER BRAKE PAD CARE (If Applicable)
1. Perform this maintenance when the brake
pad is first installed and for the life of the
brake pad. Following these simple guidelines
can increase the life of your brake pads.
2. Some brake pad assemblies are pre-
lubricated. Squeeze the brake pad. If
lubricant is released, then the pad has been
pre-lubricated.
3. If the brake pad is dry, then coat the brake
pad with 3-n-1 oil. Brush the leather with a
clean, wire bristle brush, and then apply the
oil. The oil should be allowed to soak in to
the pad. Repeat 4-5 times until the pad is
saturated, but not dripping with oil. When the
pad is saturated, it will no longer absorb oil.
4. Inspect the brake pad weekly and lubricate if
needed. The pad should not have a glazed
appearance. If the pad appears glazed, then
brush it with wire brush and apply lubricant
as needed. If any of the sponge padding is
showing through the leather pad, the brake
pad should be replaced.
