Sunny Health & Fitness SF-RB1202 Manual

Assembly & User Manual
Sunny Folding Recumbent Bike
SF-RB1202
For Customer Service, please contact: [email protected]
Please read this manual carefully before attempting to assemble or use
your new product, and retain for future use.

BeforeyouStart
Tools
Ifrequired,mostofourproductsaresuppliedwithbasictools,whichwillenableyoutosuccessfullyassembleyourproduct.However,
youmayfinditbeneficaltohaveasoft-headedhammerandperhapsan
adjustablespannerhandyasthismayhelp.
PreparetheWorkArea
Itisimportantthatyouassembleyourproductinaclean,clear,
unclutteredarea.Thiswillenableyoutomovearoundtheproduct
whileyouarefittingcomponentsandwillreducethepossibilityofinjuryduringassembly.
WorkwithaFriend
Youmayfinditquicker,saferandeasiertoassemblethisproductwiththehelpofafriendassomeofthecomponentsmaybelarge,heavyorawkwardtohandlealone.
OpentheCarton
Carefullyopenthecartonthatcontainsyourproduct,takingnoteof
thewarningsprintedonthecartontoensurethattheriskofinjuryisreduced.Beawareofsharpstaplesthatmaybeusedtofastenthe
flapsasthesemaycauseinjury.Besuretoopenthecartontheright
wayup,asthiswillbetheeasiestandsafestwaytoremoveallthecomponents.
UnpacktheComponents
Carefullyunpackeachcomponent,checkingagainstthepartslistthat
youhaveallthenecessarypartstocompletetheassemblyofyourproduct.
Pleasenotethatsomeofthepartsmaybepre-fittedtomajor
components,sopleasecheckcarefullybeforecontactingourCustomerSupportteam.
Page1

Safety
Beforeyouundertakeanyprogramofexercisethatwillincreasecardiovascularactivitypleasebesuretoconsultwithyourdoctor.Frequentstrenuousexerciseshouldbeapprovedbyyourdoctorandproperuseofyourproductisessential.Pleasereadthismanualcarefullybeforecommencingassemblyofyourproductorstartingtoexercise.
*Pleasekeepallchildrenawayfromexerciseproductwheninuse.Donotallowchildrentoclimborplayonthemwhentheyarenotinuse.
*Foryourownsafety,alwaysensurethatthereisatleast3feetoffreespaceinalldirectionsaroundyourproductwhileyouareexercising.
*Regularlychecktoseethatallnuts,bolts,andfitttingsaresecurelytightened.Periodicallycheckingallmovingpartsforobvioussignsofwearordamage.Ifyouareinanydoubt,donot
*Cleanonlywithdampcloth,donotusesolventcleaners.
useyourproduct.
*Beforeuse,alwaysensurethatyourproductispositionedonasolid,flatsurface.Ifnecessary,usearubbermatunderneathtoreducethepossibilityofslippinginuse.
*Alwayswearappropriateclothingandfootwearsuchastrainingshoeswhenexercising.Donotwearlooseclothingthatcouldbecomecaughtortrappedduringexercise.
StorageandUse
Yourproductisintendedforuseincleandryconditions.Youshouldavoidstorageinexcessivelycoldordampplacesasthismayleadtocorrosionandotherrelatedproblemsthatareoutsideourcontrol.
WeightLimit
Yourproductissuitableforusersweighing:220LBSorLess.
Page2

ExercisingInformation
Beginning
Howyoubegintoexercisewillvaryfrompersontoperson.Ifyouhavenotexercisedforalongperiodoftime,havebeeninactiveforawhile,orareseverelyoverweightyoumuststartslowly,increasingyourexercisetimegradually,byperhapsonlyafewminutesforeachsessionperweek.
Combineacarefullystructurednutritiousdietwithasimplebuteffectiveexerciseroutineandthiscanhelpmakeyoufeelbetter,lookbetterandwillalmostcertainlyenableyoutoenjoylifemore.
AerobicFitness
Aerobicexerciseissimplydefinedasanysustainedactivitythatincreasesthesupplyofoxygentoyourmusclesviathebloodpumpedbyyourheart.Withregularexercise,yourcardiovascularsystemwillbecomestrongerandmoreefficient.Yourrecoveryratei.e.thetimetakenforyourhearttoreachitsnormalrestinglevel,willalsodecrease.
Initiallyyoumayonlybeabletoexerciseforafewminuteseachday.Donothesitatetobreathethroughyourmouthshouldyouneedmoreoxygen.Usethe"talktest".Ifyoucannotcarryonaconversationwhileexercising,youareworkingtoohard!However,aerobicfitnesswillbegraduallybuiltupwithregularexercise,overthenextsixtoeightweeks.
Donotbediscouragedifittakeslongerthanthistobegintofeellesslethargic,everyoneisdifferentandsomewillachievetheirtargetsquickerthanothers.Workatyourown,comfortablepaceandtheresultwillcome.Thebetteryouraerobicfitnesstheharderyouwillhavetoworktostayinyourtargetzone.
Page3

Exercising Information
Warm Up
A successful exercise program consists of three parts, Warm Up,
Aerobic Exercise and Cool Down. Never start a training session
without warming up. Never finish one without cooling down correctly.
Perform between five and ten minutes of stretching before starting
your workout to prevent muscle strains, pulls and cramps.
Aerobic Exercise Session
Those new to exercise should exercise no more than every other day
to start with.
As your fitness level increases, increase this to 2 in every 3 days.
When you are comfortable with your routine, exercise for 6 days per
week. Always take at least one day off per week.
Exercising in your Target Zone
To ensure that your heart is working in its exercise target zone, you
you will need to locate the pulse in your carotid artery. This is
situated in the side of the neck and can be felt by using the index and
middle fingers. Simply count the number of beats you feel in 10
seconds and then multiply by six to get your pulse rate. This should
be taken before you start to exercise for easy reference.
People who have a greater aerobic fitness, have a lower resting pulse
level and will also be able to exercise with a higher pulse level.
Page 4
need to be able to take your pulse. If you do not have a pulse monitor,

Exercising Information
Cool
To decrease fatigue and muscle soreness, you should also cool down
by walking at a slow relaxed pace for a minute or so, to allow your
heart rate to return to normal.
Warm Up and Cool Down Exercise
Hold each stretch for a minimum of ten seconds and then relax.
Repeat each stretch two or three times. Do this before your Aerobic
Exercise session and also after you have finished.
Head Roll
Rotate your head to the right for one count, feeling a slight pull on the
left side of your neck. Next, rotate your head back for one count,
stretching your chin. Then rotate your head to the left for one count,
feeling a slight pull on the right side of your neck. Lastly, drop your
head to your chest for one count. Repeat 2 to 3 times.
Toe Touch
Slowly bend forward from your waist, letting your back and shoulders
relax as you lower your trunk. Gently stretch down as far as is
comfortable and hold for 10 seconds.
Shoulder Lift
Rotate and lift your right shoulder up towards your ear for one count.
Relax then repeat for the left shoulder.
Repeat 3 - 4 times.
Page 5
Down

Exercising Information
Side Stretch
Open both arm to the side and gently lift them above your head.
Reach your right arm as high as you can for one count, gently
stretching the muscles of the stomach and lower back. Repeat the
action with your left arm.
Repeat 3 - 4 times.
Inner Thigh Stretch
Sit on the floor and pull your legs toward your groin, the soles of your
feet together. Hold your back straight and lean forward over your feet.
Tighten the thigh muscles and hold for 5 seconds. Release and repeat
3 - 4 times.
Hamstring Stretch
Sit on the floor with your right leg extended and place your left foot
flat against the right inner thigh. Stretch forward toward the right foot
and hold for 10 seconds. Relax and then repeat with the left leg
extended.
Repeat 2 -3 times.
Calf / Achilles Stretch
Turn towards the wall and place both hands on it. Support yourself
with one leg while the other is placed behind you with the sole flat on
the floor. Bend the front leg and lean towards the wall, keeping the
rear leg straight so that the calf and Achilles tendon are stretched
hold for 5 seconds. Repeat with the other leg.
Repeat 2 - 3 times.
Page 6

Exercising Information
RESISTANCE ADJUSTMENT
To ensure smooth efficient cycling action, the tension belt braking
system on your Exercise Cycle has been correctly adjusted by
our factory during production.
To adjust the pedaling resistance during use, start by turning the
Tension Control (32) fully COUNTER-CLOCKWISE at the start of
your workout. Gradually increase the pedalling resistance by turning
the Tension Controller Knob CLOCKWISE as required.
LEVELING THE CYCLE
For security and stability, your Cycle has a factory welded frame and
once fully assembled correctly, should not need further alignment.
However, in the interest of safety, please always ensure that your
Cycle is positioned on a solid, flat surface.
Page 7
32

Assembly & Adjustments
EXERCISE MONITOR FUNCTIONS
The 6 function Exercise Monitor is set to start automatically when you begin
to cycle. However, it is possible to switch on the monitor by pressing the
Mode Button at the bottom of the monitor. To save battery consumption,
the monitor will also switch off after it has been idle for approximately four
minutes.
Please refer to the leaflet supplied with the Exercise Monitor for all
operational functions.
LUBRICATION and MAINTENANCE
The moving parts in your Cycle are all pre-lubricated at assembly and
should not require further attention. We recommend however that the
cycle is used inside and stored in a dry condition. To clean the metal
and plastic components, a general household cleaner can be used, but
please be sure to dry the cycle and any attachments before use.
Page 8
In the interest of safety, do not use polish or use any lubricant on the
saddle, foam handgrips or pedals.

Assembly
ACCESSORY FITMENT LIST
These are all the accessories you will need to complete the assembly of your
product. The following accessories are supplied in a pack and should be
checked before attempting assembly.
Page 9
Item 11
Qty 4 Item 26
Qty 2 Item 24
Qty 4 Item 17
Qty 4
Item 25
Qty 2 Item 12
Qty 6 Item 19
Qty 1 Item 22
Qty 1
Item 14
Qty 6 Item 31
Qty 1 Item 30
Qty 4 Item 23 Qty 7 Item 13
Qty 8
Allen wrench
Qty 1 Item 21 Qty 1 Wrench
Qty 1

(14). Repeat for the Rear Stabilizer (3) and tighten all Nuts and Bolts securely.
Page 10
1.
Assembly & Adjustments
Unfold the Main Frame (1), Lock into position using 1 x Locking Pin (15). Connect
the Front Stabilizer (2) to the Main Frame (1) with 2 x M8*65 mm Carriage Bolts (11),
Assemble the Pedals *(Left and Right)(10) to the Pedal Crank (28 and 27) *(See note).
Both Pedals must be tightened securely otherwise damage may occur to the Crank.
2.
15
1
1
14
13
12
11
13
12
14
13
12
11
3
2
Both Pedal and Crank are marked with L&R, please ensure that you insert the
corresponding Pedal.
2 x M8 Curved Washers (12), 2 x M8 Spring Washers (13) and 2 x M8 Dome Nuts
Failure to follow these procedures can result in permanent
damage to your equipment.
One Pedal is marked "R". It has a RIGHT HAND THREAD
for the RIGHT HAND SIDE of the cycle and must be fitted
by turning CLOCKWISE. The Left Pedal is marked "L"
and has reversed threading for the LEFT HAND SIDE.
You must screw to tighten.
IMPORTANT
*
COUNTER-CLOCKWISE
10R
10L
28
27

3.
Page 11
1
19
20
22
31
23
Connect the Supporting T ube (20) to the Main Frame (1) with 1 x M8* 4 0 mm
Connect the other side of Supporting Tube (20) to
the Main Frame (1) using the Ball Head Bolt (19).
Allen Bolt (22), 1 x M8 Flat Washer (23), and 1 x M8 Nylon Nut (31).
8
7
29
1
21
24
23
13
14
23
6
30
26
17
5
4.
Connect the Backrest Stem Support (6) to the
Saddle Support (29) with 2 x M8*35 mm Carriage
Bolts (26), and 2 x M8 Flat Washers (23), and 2 x M8
Spring Washers (13), and 2 x M8 Dome Nuts (14).
Then connect the Backrest (7) to the Backrest
Stem (5), using the Flat Head Screw (17) and the
Flat Washers (30). Using the 4 x M8 Flat Washers
Saddle to the desired height, allowing for a slight
(23) and 4 x M8 Allen Bolts (24), connect the
Saddle (8) to the Saddle Support (29). Using the
bend in the knee at the bottom of the cycle rotation.
Re-tighten the Adjuster Knob.
Adjuster Knob (21), connect the Saddle Support
(29) and Backrest to the Main Frame (1). Set the

Page 12
5. Connect the Handlebar (4) to the Backrest Stem Support (6) using 2 x M8 Curved
Washers (12), 2 x M8 Spring Washers (13), and 2 x M8*35 mm Allen Bolts (25).
Next attach the Exercise Monitor (9) to the Main Frame (1) with the Flat Bolts (18).
Connect the Sensor Wire (16) and Exercise Monitor (9) together.
Installation completed.
6.
* NOTE
Flat Bolts (18) come preassembled on the monitor.
Simply remove them from the monitor. Then use
them to attach monitor to the Main Frame (1).
9
16
18
1
25
13
12
4
6
*

Page 13
1
14
13 12
11
13
12
10R
15
14
13
12
10L
18
9
11
19
20
22
21
4
14
6
26
8
16
3
23
24
31
23
23
29
7
17
5
27
28
30
32
33
34
13
14
12
2
Exploded Diagram

PARTS LIST
Page 14
PART NO. DESCRIPTION QTY
1 Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Handlebar 1
5 Backrest Stem 1
6 Backrest Stem Support 1
7 Backrest 1
8 Saddle 1
9 Exercise Monitor 1
10 Pedal（L&R）2
11 M8*65 Carriage Bolt 4
12 Curved Washer 4
13 M8 Spring Washer 8
14 M8 Dome Nut 6
15 Locking Pin 1
16 Sensor Wire 1
17 Flat Head Screw 4
18 M4*10 Screw 2
19 Ball Head Bolt 1
20 Support Tube 1
21 Adjuster Knob 1
22 Allen Bolt 1

23 Flat Washer(8*16*1.2) 7
24 M8*15mm Allen Bolt 4
25 M8*35mm Allen Bolt 2
26 M8*35mm Carriage Bolt 2
27 Left Crank 1
28 Right Crank 1
29 Saddle Support 1
30 Flat Washer(6*16*1.2) 4
31 1
32 Tension Knob 1
33 Rear Stabilizer Caps 2
34 Front Stabilizer Caps 2
Page 15
Ny lon Nut
