SUNPAN JADE SIDEBOARD User manual

A01
CABINET
1/2
JADE SIDEBOARD
ASSEMBLY
INSTRUCTION
B02
LEG FRAME
C
D
DESCRIPTION QUANTITY ILLUSTRATION No.
102927
Sunpan Item No:
Sunpan Product Name:
Please visit our web-site : www.sunpan.com for more great products.
For assembly questions please call: 1-800-787-1019 (or [phone]) outside North America or email to: [e-mail]
1
2
24
BOLT M6 x 15
4 01
5
LOCK WASHER Ø8
ALLEN KEY K4
16
02
ANTI-TIP KIT
STRETCHER
01
SUPPORT LEG
02
3WASHER Ø8 x 16 16
104943

2/2
1Connect the 2 Legs "B" to
the 2 Stretchers "C" as in the drawing.
Use 08 Bolts "1" snap to the
appropriate locations, as shown.
Use Allen Key "4" when assembling
the bolts.
ASSEMBLY INSTRUCTIONS
DESCRIPTION ILLUSTRATION STEP
Turn the table on legs.
Adjust the adjustable leveler.
Attach the ANTI - TIP KIT (5)
at the back of the cabinet.
Follow instructions in the hardware bag.
Finished.
ASSEMBLY TIPS:
Please check parts and hardware before assembling. Follow each instruction step by step.
Place a protective pad or piece of cardboard on the floor while assembling your item on top of it.
Remove all parts from the carton and separate them into part numbers/groups as indicated on the part list.
Please follow instructions in the sequence as numbered to assure fast/easy assembly.
WARNING:
Do not attempt to repair or modify parts that are broken or defective - if you find a broken part please contact us for replacement.
Keep all hardware parts out of the reach of children.
FURNITURE CARE:
Following these few basis steps will help to ensure that you enjoy your furniture for a long time:
Do not expose your furniture to direct sunlight, dampness or any heat, like a hot cup of coffee or tea. Always use a coaster.
Excessive exposure to sunlight may cause fading.
Excessive temperature and humidity or cold may cause cracking or splitting.
Dust with a clean, damp, lint free cloth.
Use a damp cloth with water or mild detergent to clean all surfaces - do not use chemicals or paint thinner which will fade the surface.
Place a piece of felt or a pad under the legs of your furniture to avoid scratching the floor.
