Sunrise Medical Quickie Q100 R Configuration guide

000690995.UK
Powered Wheelchair
General Manual
Q100 R
Q200 R

2 Q100R Q200R Rev. A
04
UK
Wheelchair Components
We at SUNRISE MEDICAL have been awarded the ISO-9001 certificate, which affirms the quality of our products at every stage, from
R & D to production. This products meet the requirements in accordance with EC guidelines. Options or accessories shown are
available at extra cost.
EN
Dealer signature and stamp

Rev. A Q100R Q200R 3
QUICKSTART GUIDE
1
2
3
4
1
2
2
1
3
1
1
22
3

4 Q100R Q200R Rev. A
WARNING!
DO NOT USE YOUR WHEELCHAIR UNTIL
THIS MANUAL HAS BEEN READ AND
UNDERSTOOD.
User Information
Intended use power wheel chairs:
Power wheelchairs are exclusively for a user who is unable
to walk or has limited mobility, for their own personal use
in- and outdoor.
When an Attendant Control Module is fitted, the Power
Wheelchair may be operated by an assistant on behalf of
the user.
When a Dual Control Module is fitted the Power
Wheelchair may be operated by the user, or control may
be switched to an assistant to operate on behalf of the
user.
The maximum weight limit (includes both the user and any
weight of accessories fitted to the wheelchair) is marked
on the serial number label, which is affixed to the chassis
of the chair.
In the chair packaging there is an additional chair serial
number this can be affixed to the front page of the owners
manual supplied with the wheelchair.
Warranty can only be taken on if the product is used under
the specified conditions and for the intended purposes.
The intended lifetime of the wheelchair is 5 years. Please
DO NOT use or fit any 3rd party components to the
wheelchair unless they are officially approved by Sunrise
Medical.
Area of application
The variety of fitting variants as well as the modular
design mean that it can be used by those who cannot
walk or have limited mobility e.g. because of:
• Paralysis
• Loss of extremity (leg amputation)
• Extremity defect deformity
• Joint contractures/joint injuries
• Strokes and brain injuries
• Neurological disabilities (e.g. MS, Parkinson…)
• Illnesses such as heart and circulation deficiencies,
disturbance of equilibrium or cachexia as well as for
elderly people who still have the strength in the upper
body.
• Persons who are mentally and physically able to control
an input device to operate the chair and its functions in
a safe way.
When considering provision, please also note the body
size, weight including the distribution of body weight, the
user’s physical and psychological constitution, the age of
the user, their living conditions and their environment.
If in doubt a health care professional should be involved
to ensure the user is not exposed to unacceptable risks.
Sunrise Medical is ISO 9001 certified, which ensures
quality at all stages of the development and production of
this wheelchair.
Sunrise Medical declares under its sole responsibility that
this product is in conformity with the requirements of the
directive 93/42/EEC amended by 2007/47/EEC.”
Sunrise Medical declares that this product fulls the
performance requirements for a “Crash Test” to
ISO 7176 -19:2008.
The Serial Number and other important information may
be found on a label situated on the right-hand side, main
frame of the product.
If you are visually impaired,
this document can be viewed
in PDF format at
www.SunriseMedical.co.uk
or alternatively is available
on request in large text.

Rev. A Q100R Q200R 5
BACK UPHOLSTERY
Q100R/Q200R Features
CONTROL LEVER
HEIGHT/WIDTH
ADJUSTABLE
ARMRESTS
STABILISING
BAR
BATTERY BOX
DRIVE WHEEL
MOTORS
FOOTRESTS
CUSHION
HAND CONTROL
MODULE
JOYSTICK
Due to its modular design, simplicity and wide range of adjustments, the Quickie Q100R/Q200R is a
perfect choice for easy service, refurbishment and recycle requirements.
As a part of our ongoing product improvement initiative, Sunrise Medical reserves the right to change
specications and design without notice. Further, not all features and options offered are compatible with
all congurations of the wheelchair.
All dimensions are approximate and may be subject to change.
CASTORS

6 Q100R Q200R Rev. A
1.0 Your Wheelchair: 7
2.0 How to use this manual: 7
2.1 Introduction: ........................................................................ 7
2.2 Guarantee .......................................................................... 8
3.0 Label Explantation / Word definitions: 9
3.1 Definitions of words used in this manual: ........................... 9
4.0 Safety: 11
4.1 General Warnings: ............................................................ 11
4.2 Features and options: ...................................................... 11
4.3 Preliminary checks: .......................................................... 11
4.4 Emergency braking: ......................................................... 11
4.5 Kerbs, (Fig 4.1): ................................................................ 11
4.6 Tyres: ................................................................................ 12
4.7 Freewheel device, (Fig.4.2): ............................................. 12
5.0 Transportation 13
5.1 Transport of the wheelchair in a car ................................. 13
5.2 The wheelchair as a passenger seat ............................... 15
5.3 Special transport requirements ........................................ 17
5.4 General transport warnings ............................................. 17
6.0 Maintenance & cleaning 18
6.1 Maintenance ..................................................................... 18
6.2 Sharp turns: ...................................................................... 19
6.3 Weight limit: ...................................................................... 19
6.4 Hot surfaces: .................................................................... 19
6.5 Road caution: ................................................................... 19
6.6 Adverse conditions: .......................................................... 19
6.7 Ramps: ............................................................................. 19
6.8 Transfer to and from the chair: ......................................... 19
6.9 Anti tips: ............................................................................ 19
6.10 Use on a slope: ...............................................................20
6.11 Gradients: ascents: .........................................................20
6.12 Gradients: descents: ...................................................... 20
6.13 Lap belt: .......................................................................... 20
6.14 Rear View Mirror: ............................................................22
7.0 Assembly: 23
7.1. Footrest (Fig. 7.0-7.1): ......................................................23
7.2. Armrest (Fig. 7.2): ...........................................................23
7.3. Anti-tip wheels (Fig.7.3): .................................................23
7.4. Kerb climber (Fig. 7.4): ....................................................23
7.5. Batteries (Fig.7.5): .......................................................... 24
7.6. Wheels (Fig.7.6 & 7.7): .................................................... 24
7.7. Fitting The Lap Belt : ........................................................ 25
7.8 Crutch Holder, (Fig.7.11): .................................................. 25
7.9 Lights and indicators, (Fig.7.12-7.13): ................................ 25
8.0 Using The Wheelchair: 26
8.1 Preparing for stowed transportation: ...............................26
8.2 To use the wheelchair again: ...........................................26
8.3 Mechanical Fixed Reclining back ( 90° to 102° - 4
positions) (Fig. 8.1) .........................................................26
8.4 Fixed Seat Tilt: ................................................................. 27
8.5 Freewheel device (Fig. 8.3): ............................................. 27
8.6. Tyre pressure: ................................................................ 27
8.7 Transfers (Fig.8.4): .......................................................... 28
8.8 Slopes (Fig.8.5): ..............................................................28
8.9 Laterals (Fig.8.7-8.8) ........................................................29
8.10 Mounting a kerb or step (Fig. 8.9): ................................. 29
8.11 Dismounting the kerb (Fig. 8.10): ....................................29
9.0 VR2 Control System (Fig.7.1): 30
9.1 On/Off button: ................................................................... 30
9.2 Battery Level Indicator: ....................................................30
9.3 Locking/unlocking the wheelchair: ................................... 30
9.4 Operating the control joystick: ......................................... 31
9.5 Maximum speed/profile indicator: .................................... 31
9.6 The horn button: ............................................................... 31
9.7 Speed/Profile decrease button: ....................................... 31
9.8 Speed/Profile increase button: ......................................... 31
9.9 VR2-L ............................................................................... 32
9.10 Charging and programming socket: ...............................33
9.11 VR2 dual control unit: .....................................................33
9.12 Control button and indicator: .......................................... 33
9.13 Actuator button and LED: ............................................... 33
9.14 Maximum speed button and indicator: ...........................34
10.0 Troubleshooting The VR2 Hand Control: 34
11.0 Batteries and Charging: 36
11.1. Battery & Charger Specification: ...................................36
11.2 Electrical fuses: .............................................................36
11.3 Batteries (Fig. 11.1 - 11.6): ..............................................36
11.4 General battery information: ........................................... 38
11.5 Maintenance-free batteries: ........................................... 38
11.6 Battery care: ...................................................................38
11.7 Maintenance-free battery care plan: ..............................38
11.8 General charger information: ..........................................39
11.9 Charger Specification: ...................................................39
11.10 Charger safety features: ...............................................39
11.11 Procedure for connecting the charger and charging: ...39
11.12 Charger safety and caution notes: ................................ 39
11.13 The range of your vehicle: .............................................40
11.14 Common battery statements: ........................................ 40
12.0 Adjustments: 41
12.1 Adjustment of the footrest (Fig. 12.1.1 & 12.1.2): .......... 41
12.2 Inner Or Outer Width Adjustment of the footrests: .......... 41
12.3 Adjustment of the armrests: ........................................... 41
12.5 Seat depth adjustments: (Fig. 12.5). ............................. 42
12.6 Control Adjustment (Fig. 12.6): ..................................... 42
12.7 Dual/Attendant control (Where fitted) ............................ 42
12.8 Parallel swing-away control (Fig.12.7): ........................... 42
12.9 Programming: ................................................................ 42
13.0 Cleaning: 43
13.1 Cleaning General: ...........................................................43
13.2 Cleaning seating: ........................................................... 43
13.3 Cleaning control system: ................................................ 43
13.4 Speciality controls: .........................................................43
14.0 Shipping & Storage Requirements: 43
14.1 Storage temperature & humidity: ................................... 43
14.2 Special shipping requirements: .....................................43
14.3 Medium to long term storage: ....................................... 43
15.0 Disposal: 43
16.0 Specification sheets (EN 12184 & ISO 7176-15) 44
17.0 Service Advice-Service History: 46
18.0 Performance checks: 47
18.1 Re-use ........................................................................... 47

Rev. A Q100R Q200R 7
1.0 Your Wheelchair:
We at Sunrise Medical want you to get the best out of
your Q100R/Q200R wheelchair. This Owner’s Manual will
familiarise you with the chair and its features. It contains
hints on everyday usage and general care in addition to
information on the high quality standards which we adhere
to and details about the guarantee.
Your wheelchair will be delivered ready for quick assembly
– refer to the quick start guide on the inside cover of this
user manual. There are a wide range of components and
adjustments available on the Q100R/Q200R. For further
information about these you should contact your Sunrise
Medical authorised dealer.
Your wheelchair will reach you in excellent condition having
been personally inspected before leaving our factory.
Following the guidelines for maintenance and cleaning
your wheelchair will maintain its first class condition and
give you complete satisfaction.
The Q100R/Q200R has been designed for use by an
individual on a daily basis. It is suitable for both indoor
and outdoor use (Class B). It is only intended for use as
a pavement vehicle, but may also be used when crossing
between pavements.
This vehicle has been designed for a single occupant
of limited mobility up to the weight of Q100R 125Kg and
Q200R 136Kg (dependant on options chosen for your chair)
who has the cognitive, physical and visual ability to control
the vehicle safely on a maximum slope – see section 16.0
Specification Sheet section for maximum slope details. If
you are in any doubt as to the suitability of the power chair,
contact your local Sunrise Medical approved supplier for
clarification, prior to commencing use.
It is very important to read the relevant section of the owner’s
manual when making any minor adjustments. Consult the
Technical Manual or your local Sunrise Medical authorised
dealer for more complex adjustments.
If you have any queries about the use, maintenance
or safety of your wheelchair, please contact your local
approved Sunrise Medical service agent. If you do not
know of an approved dealer in your area or have any other
questions please write or telephone:
Sunrise Medical
Thorns Road
Brierley Hill
West Midlands
DY5 2LD
England
Phone: [phone]
Fax: [phone]
www.SunriseMedical.co.uk
2.0 How to use this manual:
2.1 Introduction:
Please keep a note of your local service agent’s address
and telephone number in the space below.
In the event of a breakdown, contact them and try to give
all relevant details so they can help you quickly.
The wheelchairs shown and described in this manual
may not be exactly the same in every detail as your own
model. However, all instructions are still entirely relevant,
irrespective of detail differences.
NOTE: The manufacturer reserves the right to alter without
notice any weights, measurements or other technical data
shown in this manual. All figures, measurements and
capacities shown in this manual are approximate and do
not constitute specifications.

8 Q100R Q200R Rev. A
2.2 Guarantee
THIS GUARANTEE DOES NOT AFFECT YOUR LEGAL RIGHTS IN ANY WAY.
Sunrise Medical* provides a guarantee, as set out in the warranty conditions, for products to its customers covering the
following.
Warranty conditions:
1. Should a part or parts of the product require repair or replacement as a result of a manufacturing and/or material fault
within 24 months, then the affected part or parts will be repaired or replaced free of charge. The warranty will only
cover manufacturing defects
2. To enforce the warranty, please contact Sunrise Medical Customer Service with the exact details of the nature of the
difculty. Should you be using the product outside the area covered by the Sunrise Medical customer service agent,
repairs or replacement will be carried out by another agency as designated by the manufacturer The product must be
repaired by a Sunrise Medical designated Customer Service agent, (dealer).
3. For parts, which have been repaired or exchanged within the scope of this warranty, we provide a warranty in
accordance with these warranty conditions for the remaining warranty period for the product in accordance with point 1.
4. For original spare parts which have been tted at the customer’s expense, these will have a 12 months guarantee,
(following the tting), in accordance with these warranty conditions.
5. Claims from this warranty shall not arise, if a repair or replacement of a product or a part is required for the following
reasons:
a. Normal wear and tear, which include but is not limited to the following parts where tted; batteries, armrest pads,
upholstery, tyres, brakes shoes, ferrules, etc.
b. Any overloading of the product, please check the EC label for maximum user weight.
c. The product or part has not been maintained or serviced in accordance with the manufacturer’s recommendations
as shown in the user instructions and/or the service instructions.
d. Accessories have been used which are not specied as original accessories.
e. The product or part having been damaged by neglect, accident or improper use.
f. Changes/modications have been made to the product or parts, which deviate from the manufacturer’s
specications.
g. Repairs have been carried out, before our Customer Service has been informed of the circumstances.
6. This guarantee is subject to the law of the country in which the product was purchased from Sunrise Medical“
* Means the Sunrise Medical facility from which the product was purchased.
Additional Notes For Australia Only:
i. For goods provided by Sunrise medical Pty Ltd in Australia, our goods come with a guarantee by Sunrise Medical that
cannot be excluded under Australian Consumer Law.
ii. You are entitled to a replacement or refund for a major failure and for compensation for any foreseeable loss or
damage.
iii. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
iv. The benets to you given by this warranty are in addition to your other rights and remedies under a law in relation to
the goods to which the warranty relates.

Rev. A Q100R Q200R 9
3.0 Label Explantation / Word definitions:
3.1 Denitions of words used in this manual:
Word Definition
DANGER!
Advice to the user of Potential Risk
of serious injury or death if the
advice is not followed
WARNING!
Advice to the user of a potential risk
of injury if the advice is not followed
CAUTION!
Advice to user that potential
damage to equipment may occur if
the advice is not followed
NOTE: General advice or best practice
RWD Rear Wheel Drive
Reference To Additional
Documentation

10 Q100R Q200R Rev. A
WARNING! – DO NOT TOUCH - HOT
RED
BLACK
RED
RED
Controller connector
YELLOW
Battery connector
Battery wiring schematic
BLACK BLACK
Battery connector
BATTERY LABEL (UNDER COVER)
CIRCUIT DIAGRAM
TRANSIT TIE-DOWN POSITION
BRAKE RELEASE
DRIVE
FREEWHEEL
Fig.3.1
Fig.3.2

Rev. A Q100R Q200R 11
4.0 Safety:
If you follow the instructions given in this manual, you will
enjoy many trouble-free years of use:
WARNING!
• This vehicle is not designed for use on the road except
for crossing from one kerb to another.
• Load data always refers to one single person as
operator.
• The wheelchair is authorised for use by one person or
one seated person and their attendant if using a Dual or
Attendant control unit.
WARNINGS!
4.1 General Warnings:
• Always ensure that your wheelchair is switched off
before attempting to mount or dismount.
• Always ensure that you are able to operate all controls
from a comfortable position. Paying attention to your
posture is essential to ensure your continued comfort
and well being.
• Always make sure that you can be seen clearly,
especially if you intend using your wheelchair in poor
light.
• This wheelchair has been built to match the needs of a
particular user. If used by another user then it may need
to be adjusted and reprogrammed.
• Do not let children or others use your wheelchair.
• Do not lift or hoist the wheelchair by any detachable
parts such as leg rests, arm rests etc.
CAUTION!
4.2 Features and options:
Some of the options shown in this manual may not be
available in your country and may also restrict the overall
physical limits of the standard product (e.g. max. speed,
user weight limit, etc.). Those limitations are marked on
the order form, in the technical manual and in this owner’s
manual.
For further information please consult your Sunrise
Medical authorised dealer.
WARNING!
CHOKING HAZARD – This mobility aid uses small parts
which under certain circumstances may present a choking
hazard to young children.
DANGER!
4.3 Preliminary checks:
• You should not try to manoeuvre at full speed.
• If you have to make a sudden turn, slow down first using
the joystick or the speed control knob.
• This is very important if you are going down a hill.
• Lack of attention to this point may result in your
overturning the wheelchair.
• Always check that the wheelchair is switched off before
trying to get in or out.
• Always check that you can operate all the controls from
a comfortable seated position. It is essential to pay
attention to posture in order to assure comfort and well-
being.
• Always check that the freewheel device is switched off
before setting the chair in motion.
• Always check that you can be seen clearly, especially
if you are using the wheelchair in conditions of low
visibility.
WARNING!
4.4 Emergency braking:
If power is cut by means of the ON/OFF button, braking
will be immediate and total. This method of stopping is not
recommended except for emergencies, since the stop will
be extremely sudden.
4.5 Kerbs, (Fig 4.1):
• Always cross the road as rapidly as possible, since
other vehicles may appear.
• Do not attempt to climb or to descend from, a kerb of
more than 100 mm. height.
• Do not attempt to ascend high kerbs, steep slopes or
cambers due to the risk of falling out of the chair or
tipping over.
• Do not attempt to ascend any kerb in the vicinity of a
drain cover, uneven surfaces, or gravel covering.
• Do not attempt to descend a kerb of more than 50 mm
in forward position.
• Do not attempt to climb or descend any kerb at an
oblique angle. Approach only at an angle of 90° with at
least 500mm run-up.
Fig.4.1

12 Q100R Q200R Rev. A
4.6 Tyres:
The tyres of a wheelchair suffer wear depending on how
much the chair is used. Check them regularly, especially
for inflation pressure, according to the service instructions
in this manual.
WARNING!
Where fitted NEVER inflate pneumatic tyres with the air
hose of a service station.
WARNING!
4.7 Freewheel device, (Fig.4.2):
Also see Fig.3.1
• Only use this function to push the chair manually from
one spot to another.
• Keep in mind that while the freewheel system is in
operation, the chair is without a braking system.
• Disengaging the motor causes an error message to
appear in the control, which is indicated when the LED
display flashes rapidly.
• For safety reasons the wheelchair can no longer be
moved using the joystick.
• Do not operate the freewheel device whilst seated in the
wheelchair.
• The freewheel device should only be operated by a
person who has the strength and agility to be able to
fully manoeuvre the wheelchair safely, during freewheel.
Fig. 4.2

Rev. A Q100R Q200R 13
5.0 Transportation
5.1 Transport of the wheelchair in a car
Getting in and out of the vehicle
DANGER!
• Confirm that the vehicle is suitably equipped to transport
a passenger in a wheelchair, and ensure the method
of access/egress is suitable for your wheelchair type.
The vehicle should have the floor strength to take the
combined weight of the occupant, the wheelchair and
accessories.
• Use a ramp (or lifting device) suitable for the entire weight
of the wheelchair (including user) for entering the vehicle.
• The wheelchair should be secured in a forward facing
direction. This wheelchair is approved for use in cars and
meets the requirements for forward facing transport and
head on collisions. The wheelchair has not been tested
for other positions in a vehicle (Fig. 5.1).
CAUTION!
• Sufficient space should be available around the
wheelchair to enable clear access to attach, tighten and
release the wheelchair and occupant tie down restraints
and safety belts.
• Ease of access to, and manoeuvrability in, motor vehicles
can be significantly affected by wheelchair size and
turning radius; smaller wheelchairs and/ or wheelchairs
with a shorter turning radius will generally provide greater
ease of vehicle access and manoeuvrability to a forward-
facing position.
Securing the wheelchair with a strap restraint system
This wheelchair has been successfully crash tested in
accordance to: ISO 7176-19:2008, using a representing
restraint system.
• Secured with a 4-point strap restraint system (2 in the
front, 2 in the back, Fig.5.2), that conforms to:
i. ISO 10542 (international) or
ii. SAE J2249 (USA).
NOTE: Wheelchair secured with a 4-point strap restraint
system; suitable for the total weight of the wheelchair
(including any options) in accordance with the WTORS1)
manufacturers instruction.
Terminology explained:
1) WTORS: Wheelchair Tie-down Occupant Restraint
System
Fig. 5.1
AFront Tie Down Points.
BRear Tie Down Points.
CDirection of Travel.
Fig. 5.2
A A
BB
C

14 Q100R Q200R Rev. A
DANGER!
• The wheelchair can only be secured by using the tie-
down points on the wheelchair’s frame (Fig. 5.2 - 5.8).
• The tie-down points (2 in the front, 2 in the back) are
indicated by the tie-down symbol (Fig. 5.5). Fit the front
straps first, then the rear. Tension the straps to secure
the wheelchair. The wheelchair may not be secured
onto any accessories (wishbones, armrests, anti-tip
brackets etc.).
• No changes or replacements must be made to the
anchorage points/car fastenings on the wheelchair, or
to constructional elements or parts of the frame without
consulting the manufacturer.
• When the wheelchair is transported in a vehicle without
occupant and no restraint system is available then the
wheelchair should be properly stored and secured in the
cargo area during travel.
A
C
Fig. 5.3
C
Fig. 5.4
B
AFront Tie Down Points.
BRear Tie Down Points.
CDirection of Travel.
Fig. 5.5
Fig. 5.6
Fig. 5.7
Fig. 5.8
A
B
Position of the Front tie down restraint., (Fig.5.7 - A).
Position of the Rear tie down label & bracket,
(Fig.5.8 - B).

Rev. A Q100R Q200R 15
Occupant restraint Instrucon
DANGER!
• Use a 3-point occupant restraint system to secure the
occupant.
• Both pelvic and upper torso restraint belts must be used
to restrain the occupant (Fig. 5.5) to reduce the possibility
of head and chest impacts with the vehicle components.
• Restraints should be mounted to the appropriate vehicle
pillar and should not be held away from the body by
wheelchair components such as armrest or wheels (Fig.
5.7).
• Use a suitable positioned headrest when being
transported in a wheelchair.
• Postural supports (lap straps, lap belts) should not be
used or relied on for occupant restraint in a moving vehicle
unless they are labelled as meeting the requirements
specified in ISO 7176-19:2008 or SAE J2249.
5.2 The wheelchair as a passenger seat
A wheelchair secured in a vehicle will not provide the
equivalent level of safety and security as a vehicle seating
system. Sunrise Medical recommends that the user
transfers to the vehicle seating and uses the vehicle-
installed restraint system wherever possible. Sunrise
Medical recognizes that it is not always practical for the
user to be transferred and in these circumstances, where
the user must be transported whilst in the wheelchair, the
following advice must be followed:
DANGER!
• The safety of the user during transportation depends
upon the diligence of the person securing the tie down
restraints and they should have received appropriate
instructions and/or training in their use.
• Wherever possible remove and stow safely away from
the wheelchair all auxiliary equipment, e.g. : crutches,
loose cushions, tray tables, etc.
i. Removed and secured separately in the vehicle, or
ii. Secured to the wheelchair, but with energy-absorbing
padding placed between the table and the user.
• Articulating/elevating leg rest should not be used in the
elevated position when the wheelchair and user are
being transported.
• If applicable: Reclining backrests should be returned to
an upright position.
• If applicable: Seat elevators should be in the lowest
position.
• If applicable: The manual brakes must be firmly applied.

16 Q100R Q200R Rev. A
Posioning the occupant restraint
DANGER!
• The pelvic restraint belt must be worn low across the
front of the pelvis so that the angle of the pelvic belt is
within the preferred zone of 30° to 75° to the horizontal.
• A steeper (greater) angle within the preferred zone is
desirable i.e. closer to, but never exceeding 75° degrees
(Fig. 5.10).
i. The upper torso restraint belt must t over the
shoulder and across the chest as illustrated (Fig. 5.9).
Restraint belts must be adjusted as tightly as possible
consistent with user comfort.
• Restraint belt webbing must not be twisted when in use.
• Care should be taken when applying the occupant
restraint to position the seatbelt buckle so that the release
button will not be contacted by wheelchair components
during a crash.
Passenger with a user weight < 22 kg.
When the user being transported is a child, less than 22 kg
mass and the vehicle involved has less than eight (8) seated
passengers it is recommended that they be transferred to
an UNCE Regulation 44 compliant child restraint system
(CRS).
This type of restraint system provides a more effective
occupant restraint system than the conventional 3 point
occupant restraint system and some CRS systems also
include additional postural supports to assist in maintaining
the position of the child when seated.
Parents or care providers may consider the option, in some
circumstances, for their child is to remain in their wheelchair
whilst in transport due to the level of posture control and
comfort provided by the set up in the wheelchair.
We would recommend in such circumstances that a risk
assessment be carried out by your healthcare professional
and relevant competent persons.
x
✓
55°
100 mm
✓
x
75°
30°
Fig. 5.9
Fig. 5.10

Rev. A Q100R Q200R 17
• Take this user manual, the seating system user manual
(& Seating System) and the controller user manual (&
Controller) with you. The carrier will need to refer to the
following sections:
i. Pushing the wheelchair.
ii. How to lock/unlock the controller.
iii. How to disconnect the batteries.
iv. How to disconnect the drive.
• Transporting the chair.
• Medium to long term storage, follow the instructions.
Hoisting the wheelchair (Fig. 5.11)
The most forward seat depth holes provide a reference
balance position for 2 point lifting systems (individual
chair configuration and options may require alternative
position).
Fig. 5.11
5.4 General transport warnings
WARNING!
• No changes or replacements must be made to the
anchorage points/car fastenings on the wheelchair, or
to constructional elements or parts of the frame without
consulting Sunrise Medical.
• The wheelchair should be inspected by a Sunrise
Medical authorised dealer/service agent, before reuse
following involvement in any type of vehicle collision.
5.3 Special transport requirements
Using your wheelchair on the train.
Before you travel, please contact the train operator. They
will be able to supply details of any special requirements/
instructions. We advise you to check the following:
• Is there a suitable and intended “wheelchair” area in the
train for wheelchair users (with adequate turning space to
manoeuvre)?
• Is there a suitable or designated area on the platform
for wheelchair users (with adequate turning space to
manoeuvre)?
• Is there suitable boarding access available to allow you to
access the railway carriage and the intended “wheelchair”
area?
• Is the boarding access suitable for the combined mass of
the wheelchair and the occupant?
• Make sure the slope of the boarding access is not greater
than the dynamic safe slope. (See Section 16)
• Any obstacles or thresholds should not exceed the max
kerb climbing capability of your wheelchair. (See Section
16)
Most train operators will provide assistance provided that
arrangements have been made in advance. We suggest
you have you Owner’s Manual ready when planning your
journey and contacted them.
Transporting the wheelchair as luggage.
Parts of the wheelchair that can easily be detached should
be removed when transporting the wheelchair. Store these
parts securely. E.g.:
A. Remove the leg rests
B. Remove the armrests
C. Fold down the backrest
• Ensure that any detachable parts are secured with your
mobility aid or separately packed and labelled so they do
not get lost during loading and unloading.
• The wheelchair may be transported by road, rail, sea or
air.
• Before you travel, please contact the appropriate carrier.
The travel operator will be able to supply details of any
special requirements/instructions.
• For information about dimensions and weight of the
wheelchair, see (Section 16).
• For information about the batteries in your wheelchair
see (Section 6).
• Ensure that any detachable parts are secured with your
mobility aid or separately packed and labelled so they do
not get lost during loading and unloading.

18 Q100R Q200R Rev. A
6.0 Maintenance & cleaning
The wheelchair’s lifespan is dependent on it being well
maintained.
For information concerning specific settings, maintenance
or repair work, please contact your authorized Sunrise
dealer. Always be sure to mention the model, year of
manufacture and identification number provided on the
identification plate of the wheelchair when contacting your
dealer.
CAUTION!
The wheelchair should be serviced by your authorized
Sunrise dealer once a year or, in the case of intensive
use, every six months. For a list of approved authorised
dealers in your area please contact Sunrise Medical
Service Centre.
The contact details of your local Sunrise medical service
centre can be found on the inside front cover of this
booklet.
National and International Website addresses are on the
back cover.
6.1 Maintenance
WARNING!
• Loose fasteners should be re-tightened according to the
installation instructions.
• Chest straps should be replaced at the first indication of
damage and/or excessive wear.
• If a broken or loose component is found, discontinue
use immediately and contact your authorised Sunrise
Medical supplier for replacement.
• Check all Velcro fastening straps for correct adhesion
when pressed together.
• Ensure that any contamination, such as fluff, hair, etc
is removed from the Velcro straps. Such contamination
may affect adhesion.
WARNING!
• If you are in any doubt about the performance
requirements of your wheelchair contact your Sunrise
Medical authorised dealer.
• After performing any maintenance or repairs on the
wheelchair you must make sure that it is functioning
correctly before it is used.
• All fasteners must be replaced like for like using the
correct length, tensile strength and materials.
• When replacing self-locking nuts, or nuts/studs secured
with a thread locking solution, ensure that a suitable
thread locking solution is reapplied to the fastener.
Daily checks
Perform the daily check routine before driving as
described in chapter 18.0.
Weekly checks
Perform the weekly check routine before driving as
described below.
Checking Parking brake:
This test should be carried out on a level floor with at least
one meter clearance all around the chair.
• Switch on the control system.
• Check that the battery gauge remains on, or flashes
slowly, after one second.
• Push the joystick slowly forwards until you hear the
parking brakes operate.
• The chair may start to move.
• Immediately release the joystick. You must be able to
hear each parking brake operate, (click), within a few
seconds.
• Repeat the test a further 3 times, pushing the joystick
slowly backwards, left and right.
Checking connectors & cables:
• Make sure that all connectors are securely mated.
• Check the condition of all cables and connectors for
damage.

Rev. A Q100R Q200R 19
DANGER!
6.2 Sharp turns:
Full speed turns should not be attempted. If you need to
turn sharply you must reduce your speed with the joystick
or speed setting. This is particularly important when
travelling across or down a slope. Disregarding this advice
could lead to your wheelchair tipping over.
DANGER!
6.3 Weight limit:
• For Q100R The user plus items carried should never
exceed a total weight of 125 kgs.
• For Q200R The user plus items carried should never
exceed a total weight of 136 kgs.
• Never use this chair for weight training if the total weight
(user plus additional weights) exceed a total weight as
listed above.
• Exceeding the weight limit is likely to damage the seat,
frame or fasteners and may cause severe injury to you
or others from chair failure
• Exceeding the weight limit will void the warranty
Wheelchair motors:
6.4 Hot surfaces:
WARNING!
After prolonged use, the motors will produce heat, which
is radiated through the motors’ outer casing. Do not touch
the motors’ outer casing for at least 30 minutes after using
the wheelchair, to allow it to cool.
WARNING!
Not only motors can become hot during the operation of
the chair, the upholstery material and armrests may heat
up when standing in the sun.
DANGER!
6.5 Road caution:
• Please show the utmost consideration for the other
traffic on the road.
• Remember that the last thing a car or lorry driver expects
to see is a wheelchair backing off the kerb into the road.
• If in any doubt, do not risk crossing the road until you
are certain that it is safe.
• Always cross the road as quickly as possible; there may
be other traffic.
WARNING!
6.6 Adverse conditions:
• Please be aware that when driving your wheelchair
in adverse conditions, e.g. on wet grass, mud, ice,
snow or other slippery surfaces, you may experience
a reduction in the grip and traction of your wheelchair.
We recommend you take extra precautions in these
conditions, particularly on hills and slopes; your
wheelchair could become unstable or skid causing
possible injury. Extreme variances in temperature may
trigger the self protect mechanism in the control system.
If this occurs the control system will temporarily shut
down to prevent damage to the electronics or the chair.
• When you are using a Powered Scooter or Wheelchair,
take extra care with loose or long items of clothing.
Moving parts, such as wheels, can be potentially
dangerous or even fatal if clothing becomes entangled.
WARNING!
6.7 Ramps:
• When using a ramp, please ensure that it is capable
of taking the combined weight of the power chair and
yourself.
• If a ramp is being used to load a chair into a vehicle,
please ensure the ramp is properly secured to the
vehicle.
• Always approach the ramp head-on and exercise
caution.
• Please ensure your ramp is suitable for the product you
are transporting.
WARNING!
Maximum ramp angle is defined in Section 16 Specification
Sheets
6.8 Transfer to and from the chair:
Sunrise Medical recommend that you consult your
healthcare professional for assistance in developing your
personal front or side transfer technique to best suit your
needs and avoid any personal injury.
WARNING!
6.9 Anti tips:
• Make sure that anti tips are not damaged or worn before
using your chair.
• Check the anti tips are functioning correctly on a regular
basis.
• Attendants must be aware of the location of the anti tips
to prevent feet being trapped underneath causing injury.
• Attendants - Do not stand on the anti tips, this could
cause the wheelchair to become unstable.

20 Q100R Q200R Rev. A
WARNING!
6.10 Use on a slope:
Your wheelchair has been designed and tested to allow
its use on slopes or gradients as defined in Section 16
Specification Sheets.
• Before attempting to climb or descend a slope or a kerb,
caution should be taken when using weight shift options
(e.g. powered recline) of the seat where fitted and/or
your body for a counter balance weight.
• To improve stability lean forward when driving uphill,
with the seat and back in an upright position.
• Alternatively sit in an upright position when travelling
in a forward, downhill direction or recline the seat
backwards. We strongly recommend that you return
back to an upright lowered position before attempting to
climb or descend a slope.
• Failure to do this may cause the wheelchair to become
unstable.
• If you are in any doubt about the capabilities of your
wheelchair on a slope then do not attempt to drive up or
down the slope/kerb; try to find an alternative route.
WARNING!
6.11 Gradients: ascents:
• When going uphill, keep the chair moving.
• Steer by moving the joystick from side to side.
• If you have stopped on a hill, you should start slowly.
• On a RWD chair, if necessary lean forward to prevent
the tendency for the front wheels to lift.
WARNING!
6.12 Gradients: descents:
• On descents, it is important not to let the wheelchair
accelerate beyond its normal level of ground speed.
• It is safer to proceed slowly down steep descents
(below the speed of 5kph) and stop, if any anxiety arises
regarding directional control.
• If the chair picks up speed, centre the control to slow it
or to stop all forward movement, then restart slowly and
do not allow the speed to increase.
WARNING!
6.13 Lap belt:
Before using your wheelchair ensure the Lap belt is worn
and correctly adjusted before use.
The lap belt is fitted to the wheelchair as shown in the
fitting instructions in section 5 .7. It is important that the
belt is secured around the back of the wheelchair. The
straps can be fed between the armrest and backrest.
Adjust the belt position so that the buckles are in the
centre of the seat. See section 5.7.
Adjust the lap belt to suit the user’s needs as follows:
To increase the belt length:
Feed the belt through slide adjusters and male buckle to
provide more belt length, (Fig.6.1).
Fig.6.1
To reduce the belt length:
Feed the belt back through male buckle and slide
adjusters, (Fig.6.2).
Fig.6.2
