Sunstech RPBT450 User manual

1. DO NOT place objects on top of the device, as objects may scratch the device.
2. DO NOT expose the device to dirty or
3. DO NOT place the device on an uneven or unstable surface.
4. DO NOT insert any foreign objects into the device.
5. DO NOT expose the device to strong magnetic or electrical eld.
6. DO NOT expose the device to direct sunlight as it can damage the device. Keep
it away from heat sources.
7. DO NOT store your device in temperatures higher than 40°C(104°F). The
internal operating temperature for this device is from 20°C(68°F) to 60°C(140°F).
8. DO NOT use the device in the rain.
9. Please check with your Local Authority or retailer for proper disposal of
electronic products.
10. The device and adaptor may product some heat during normal operation of
charging. To prevent discomfort or injury from heat exposure, DO NOT leave the
device on your lap.
11. POWER INPUT RATING: Refer to the rating label on the device and be sure that
the power adaptor complies with the rating. Only use accessories specied by the
manufacturer.
12. Clean the device with a soft cloth. If needed, dampen the cloth slightly before
cleaning. Never use abrasives or cleaning solutions.
01 02

RPBT450 Instruction manual
Front Panel Back Panel
13. Always power o the device to install or remove external devices that do not
support hot-plug.
14. Disconnect the device from an electrical outlet and power o before cleaning
the device.
15. DO NOT disassemble the device. Only a certied service technician should
perform repair.
16. The device has apertures to disperse heat. DO NOT block the device
ventilation, the device may become hot and malfunction as a result.
17. Risk of explosion if battery replaced by an incorrect type. Dispose of used
batteries according to the instruction.
18. PLUGGABLE EQUIPMENT: the socket-outlet shall be installed near the
equipment and shall be easily accessible.
13. Indicator
14. Auxilary Port
15. Micro SD Port
10. Micro USB Port
11. USB Port
12. Bass Boost
07. Volume Down
08. Volume Up
09. Power Switch
04. Last Track
05. Next Track
06. Input
01. Speaker
02. Display
03. Pause/play
03 04

Remote Control CHARGING THE BLUETOOTH DEVICE
PAIRING/RECONNECTING THE DEVICE
01. CBO Repeat
02. Power On/O
03. Equalizer
04. Volume Up
05. Volume Down
06. Pause/Play
07. A-B Repeat
08. FM Scan
09. Input
10. Last Track
11. Next Track
12. Numeric Pad
1.Connect the speaker’s Micro USB socket with the power source’s USB port through USB cable.
(Micro USB port is located on the back of the device)
2.The power indicator will show red while the battery is charging. When the speaker has reached a full
charge the LED indicator will turn o to indicate the battery is fully charged;
3.Disconnect the USB cable when it is fully charged.(A full charge will take approximately 6 hours)
1.Power the speaker on, when power on P30 will automatically enter the last input mode. You can access
Bluetooth mode by pressing the input button to cycle through available input modes.
2.Now, turn on the Bluetooth function of your device.
3.Search for“RPBT450”and select it to begin Bluetooth pairing, this is for the rst time pairing or pairing
a new mobile device.
4.The speaker will reconnect automatically if your mobile phone has been paired previously.(Note:
depending on the device’s type and conguration, manual reconnection may be require each time the
speaker is used.)
5.If pairing is successful, speaker will make a tone to conrm.
6.Slide the power switch to the“o”position to turn the unit o when nished.(Note: If you can not
search for the Speaker, this means the last device is reconnecting automatically. Choose to forget the
speaker from your Bluetooth menu and try to pair with the speaker again.)
05 06

AUXILIARY-IN FUNCTION
HANDS FREE DIALING FUNCTIONS
1.Connect the included Auxiliary cable into the speaker’s Auxiliary port and plug the other end into your
phones auxiliary port.
2.The device will automatically switch to auxiliary mode an alternatively you may manually switch into
auxiliary mode by pressing the input button.
3.Disconnect the Auxiliary cable when nished.
(Note: if there is no sound while auxiliary cable is connected to bluetooth device, ensure all other
bluetooth devices are not paired and repeat step one. If the problem persists replace your cable.)
●Press Pause/Play to answer the call, any music playing will automatically be paused until the call is
ended.
●Long press Pause/Play to reject the call.
●Press Pause/Play again to end the call when nished. The paused music will resume playing
automatically.
●Press Pause/Play twice to initiate redial functions.
SPEAKER CONTROLS AND FUNCTIONS
EQUALIZER MODES
●To pause and play media use the Pause/Play button.
●To increase the volume press and hold Volume Up button.
●To decrease the volume press and hold Volume Down button.
●Press the Next Track button to play next track.
●Press the Last Track button to play the last track.
You can change the equalization of your media by pressing the EQ button on your remote, changing the
dynamic range of the output to suit your media.
●Pressing the EQ button on the remote allows you to select various Equilizer modes as follows:
Displayed Operation
BASS
Bass Mode; Amplifies bass and deepens tones
BLUE Blues; Compliments rich mellow tones
CLAS Classical; Amplifies orchestral acoustics
HALL Hall; Best suited for reggae and dubplates
JAZZ
Jazz;best suited for jazz and similar assemblies
POP
Pop; Best suited for dominant vocals
NOA Normal; Flat equalization
SOFT
Soft; toned down for smooth and vibrant pitch
ROCK Rock; Amplifies the bass and treble
07 08

MICRO SD & USB MODE
FM RADIO MODE
1.Insert a USB and /or Micro SD device into the back of your speaker(Note: You can have both devices
inserted at the same time.)(Note: You can have both devices inserted at the same time.)
2.The speaker will switch automatically into USB/Micro SD mode and will display USB or SD on the
display accordingly.(Note: manually select each mode by pressing the input select button on your
speaker or remote.)
3.If both devices are connected you can use the Input Select to choose which to play media from.(Note:
The speaker will read MP3 format media ONLY and cannot play other sound le formats.)
Track Selection
●Use the Next and Last track buttons to cycle through the media stored on your device.’
●To select a specic track use the Numeric pad to input the desired track number.
Repeat and Shue Functions
CBO Repeat Function
Press the CBO button on the remote to shue through carious repeat functions.
A-B Repeat Mode
A-B Repeat function allows for you to select custom parameters for a repeat cycle. This allows for the
user to repeat a custom set of tracks from a larger collection of media.
●Press the A-B button to initialized the beginning of the repeat cycle. P-A will appear on the display
indicating that this will be the beginning of the cycle.
●Press A-B button again to mark the end of the loop point for the repeat. P-B will appear on the display
indicating that this is the end.
●Press the A-B a third time to end A-B repeat function or to reprogram the parameters of your loop. P-E
will appear on the display indicating the A-B repeat function has been turned o.
1.With the speaker powered on, press the input button to enter into FM Mode.
2.To navigate to through the available FM channels use the next and last track.(Next track to go navigate
up& last track to navigate down stations)
3.To exit FM Radio Mode press the Input button.
Displayed Operation
ALL
Repeat All media on the selected device
SING
Repeat Single track that is currently selected
RAND All media on device will play in a random order
09 10

BASS BOOST
TROUBLE SHOOTING
FM Settings & Functions
●When entering FM mode for the rst time press and hold the Pause/Play button or press and hold
the search button on the remote to initiate the auto-search function. Auto-Search will seek all channels
in your vicinity and store them for easy access in the future.
●To navigate channels you can use the next and last track buttons or select a specic channel with the
included remote. This function also allows you to cycle through your favorite FM stations automatically.
●Press and hold the next and last track buttons to use the seek through the stations available in the
area.
●To add channels to your favorites press the EQ button on the remote.
●Use the numeric pad to select favorite channels or navigate to a specic channel or frequency.
No power
●Recharge your speaker using the micro USB cable. If the problem persists try using another
micro USB cable
No Response From the Unit
●Ensure your bluetooth device has an A2DP prole
●Check if both devices are paired and connected
●Restart the device and try to reconnect
Bluetooth device will not reconnect with the speaker
●From your devices bluetooth menu select the P30 speaker and choose“Forget”. Now repeat the
steps to pair the speaker with your device.
Can not hear my media or it has very low volume
●Ensure the volume is turned up on your device
●If problem persists, power o the speaker and charge it to fully battery capacity
Sound quality is weak or is being distorted
●Connect and recharge the speaker, best sound quality will come from a fully charged speaker.
Press the Bass Boost button on the back of the P30 to turn the passive bass amplier on and o. This
passive amplier increases the rich deep tones of the bass in all of your favorite media.
SPECIFICATIONS:
●Model No.: RPBT450
●Driver Unite size: DIA 2”
●DC Power Input: 5V
●Bluetooth Version: CSR4.0
●Output power: RMS 3W
●Frequency: 100Hz-18KHz
●Workin distance: 30ft
●Power Supply: Lithium battery
●Rechargeable Battery: 1800 mAh
●Playback Time: 7 hrs
●Playback Time: 7 hrs
●Charging Time: 6 hrs
11 12

Correct disposal of this Product
(Waste Electrical & Electronic Equipment(WEEE)
Your product is designed and manufactured with high quality materials and
components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their end of-
life should be disposed of separately from your household waste.
Please dispose of this equipment at your local community waste collection/
recycling centre.
In the European Union there are separate collection systems for used
electrical and electronic products.Please help us to conserve the
environment we live in!
Warranty conditions
- The warranty of this product is for 2 years since the purchase date.
- The warranty will exclude breakdowns caused by bad use of the product, wrong installation or
installation in not desirable places for a proper maintenance of the product, rips, updates of the
products
that are not the supplied by the brand, pieces wore away for its use or for not domestic or inappropriate
use. Also are excluded breakdowns caused for manipulations of the products by people or companies
alien to our company.
- For any request regarding the warranty terms, the purchase receipt must be attached.
13 14

Made in China
15

1. NO coloque objetos encima del aparato porque podrían rayarlo.
2. NO exponga el aparato a entornos sucios o polvorientos.
3. NO coloque el aparato en una supercie desigual o inestable.
4. NO introduzca ningún objeto extraño en el aparato.
5. NO exponga el aparato a un campo magnético o eléctrico fuerte.
6. NO exponga el aparato directamente a la luz del sol porque podría dañarlo.
Manténgalo apartado de supercies calientes.
7. NO guarde el aparato a temperaturas superiores a los 40 ºC (104 ºF). La
temperatura interna de funcionamiento de este aparato es de 20 °C (68 °F) a 60 °C
8. NO utilice el aparato bajo la lluvia.
9. Consulte con su ayuntamiento o vendedor para saber cómo eliminar de forma
correcta los aparatos electrónicos.
10. El aparato y el adaptador pueden producir algo de calor durante el
funcionamiento normal de la carga. Para evitar la incomodidad o un daño debido
a la exposición al calor NO deje el aparato en su regazo.
11. CAPACIDAD DE LA POTENCIA DE ENTRADA: Véase la etiqueta del aparato y
asegúrese de que el adaptador de potencia corresponde a la capacidad. Utilice
únicamente los accesorios especicados por el fabricante.
12. Limpie el aparato con un paño suave. Si fuera necesario, humedezca
ligeramente el paño antes de limpiar. No utilice nunca mezclas abrasivas o
productos de limpieza.
16 17
