Supermicro MicroBlade MBI-6219G-T8HX User manual

MBI-6219G-T8HX
MBI-6119G-T8HX
MicroBlade™ Module
User’s Manual
Revison 1.0a

MBI-6219G-T8HX /MBI-6119G-T8HX Blade Server Module User’s Manual
ii
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The
vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no
commitment to update or to keep current the information in this manual, or to notify any person or
organization of the updates. Please Note: For the most up-to-date version of this manual, please see
our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described
in this manual at any time and without notice. This product, including software and documentation, is the
property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction
of this product is not allowed, except as expressly permitted by the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE
THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY HARDWARE,
SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF
REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE,
SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara
County in the State of California, USA. The State of California, County of Santa Clara shall be the
exclusive venue for the resolution of any such disputes. Super Micro's total liability for all claims will not
exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the manufacturer’s instruction manual, may cause harmful interference with radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference,
in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning
applies only to products containing CR (Manganese Dioxide) Lithium coin cells. Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate for further
details.
WARNING: HANDLING OF LEAD SOLDER MATERIALS USED IN THIS PRODUCT MAY
EXPOSE YOU TO LEAD, A CHEMICAL KNOWN TO THE STATE OF CALIFORNIA TO
CAUSE BIRTH DEFECTS AND OTHER REPRODUCTIVE HARM.
Manual Revison 1.0a
Release Date: September 6, 2017
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy
any part of this document.
Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2016 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
:
Preface
About this Manual
This manual is written for professional system integrators, Information Technology
professionals, service personnel and technicians. It provides information for the
installation and use of both the Supermicro MBI-6219G-T8HX and
MBI-6119G-T8HXMicroBlade modules. Installation and maintenance should be
performed by experienced professionals only.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
MicroBlade modules and describes their main features.
Chapter 2: System Safety
You should familiarize yourself with this chapter for a general overview of safety
precautions that should be followed when installing and servicing the MicroBlade
modules.
Chapter 3: Setup and Installation
Refer to this chapter for details on installing the MicroBlade modules into the MicroBlade
chassis. Other sections cover the installation and placement of memory modules and
the installation of hard disk drives into the blade module.
Chapter 4: Blade Module Features
This chapter coves features and component information about the MicroBlade modules.
Included here are descriptions and information for mainboard components, connectors,
LEDs and other features of the blade module.
Chapter 5: BIOS
BIOS setup is covered in this chapter for the MicroBlade modules.
Appendix A: BIOS POST Codes
BIOS POST Codes for the MicroBlade modules are explained in this appendix.

MBI-6219G-T8HX /MBI-6119G-T8HX Blade Server Module User’s Manual
iv
Notes

v
Table of Contents
Chapter 1 Introduction.......................................................................1-1
1-1 Overview............................................................................................. 1-1
1-2 Blade Module Features .................................................................... 1-2
Blade Enclosures ....................................................................................1-3
Processors ..............................................................................................1-3
Memory ...................................................................................................1-3
Storage ...................................................................................................1-4
RAID .......................................................................................................1-4
Density ....................................................................................................1-4
1-3 Contacting Supermicro.....................................................................1-5
Chapter 2 Standardized Warning Statements.....................2-1
2-1 About Standardized Warning Statements .....................................2-1
Warning Definition...................................................................................2-1
Installation Instructions ...........................................................................2-3
Circuit Breaker ........................................................................................2-4
Power Disconnection Warning ................................................................2-5
Equipment Installation............................................................................. 2-6
Restricted Area .......................................................................................2-7
Battery Handling .....................................................................................2-9
Redundant Power Supplies ..................................................................2-10
Backplane Voltage ................................................................................2-11
Comply with Local and National Electrical Codes.................................2-12
Product Disposal...................................................................................2-13
Hot Swap Fan Warning.........................................................................2-14
Power Cable and AC Adapter ..............................................................2-15
Hot Swap Fan Warning ........................................................................2-17
Chapter 3 Setup and Installation.................................................3-1
3-1 Overview............................................................................................. 3-1
3-2 Installing MicroBlade Modules ........................................................ 3-1
Powering Up a MicroBlade Module Unit .................................................3-1
Powering Down a MicroBlade Module Unit.............................................3-1
Removing a MicroBlade Module Unit from the Enclosure ......................3-2
Installing a Blade Unit into the Enclosure ...............................................3-2
3-3 Onboard Battery Installation............................................................3-3

MBI-6219G-T8HX /MBI-6119G-T8HX Blade Server Module User’s Manual
vi
3-4 Memory Installation...........................................................................3-4
Populating Memory Slots ........................................................................3-4
Memory Support .....................................................................................3-4
DIMM Installation .................................................................................... 3-5
3-5 Hard Disk Drive Installation .............................................................3-7
3-6 Installing the Operating System......................................................3-7
Installing with a SATA-DOM Module .......................................................3-7
Installing via PXE Boot............................................................................3-7
Installing via Virtual Media (Drive Redirection) .......................................3-7
Chapter 4 MicroBlade Module Features .................................4-1
4-1 Control Panel .....................................................................................4-2
Power Button ..........................................................................................4-3
LED Indicators ........................................................................................4-3
4-2 Serverboard .......................................................................................4-4
Jumpers ..................................................................................................4-6
CMOS Clear............................................................................................4-6
4-3 Blade Unit Components ...................................................................4-7
Memory Support .....................................................................................4-8
Hard Disk Drives .....................................................................................4-9
Blade Power Consumption Page............................................................4-9
Chapter 5 BIOS.......................................................................................5-1
5-1 Introduction.........................................................................................5-1
System BIOS ..........................................................................................5-1
How To Change the Configuration Data .................................................5-1
Starting the Setup Utility .........................................................................5-1
5-2 BIOS Updates.................................................................................... 5-2
Flashing a BIOS using a Floppy Image File............................................5-2
5-3 Running Setup...................................................................................5-2
5-4 Main BIOS Setup...............................................................................5-3
5-5 Advanced Setup ................................................................................5-5
5-6 Event Logs Setup............................................................................5-17
5-7 IPMI Setup........................................................................................5-18
5-8 Security .............................................................................................5-19
5-9 Boot ...................................................................................................5-19
5-10 Save & Exit.....................................................................................5-20

vii
:
Appendix A AMI UEFI BIOS POST Codes..............................A-1
A-1 Checkpoint Ranges ..........................................................................A-1
A-2 Standard Checkpoints......................................................................A-2
A-3 OEM-Reserved Checkpoint Ranges .............................................A-9

MBI-6219G-T8HX /MBI-6119G-T8HX Blade Server Module User’s Manual
viii
Notes

1-1
Chapter 1: Introduction
Chapter 1
Introduction
1-1 Overview
This user’s manual covers the MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade module.
This MicroBlade module is a compact self-contained server that connects into a
pre-cabled enclosure that provides power, cooling, management and networking
functions. One enclosure for the MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade
module can hold twenty-eight blade units.
In this manual, “blade system” refers to the entire system (including the enclosure and
blades units), “blade”, “MicroBlade” or “blade unit” refers to a single MicroBlade module
and “blade enclosure” is the chassis that the MicroBlades, power supplies and
MicroBlade modules are housed within.
Please refer to our web site for information on operating systems that have been
certified for use with the MicroBlade (http://www.supermicro.com/products/nfo/
microblade.cfm).
Note: For your system to work properly, please follow the links below to download all
necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.MicroBlade.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety information: http://www.supermicro.com/about/policies/
safety_information.cfm
• If you have any questions, please contact our support team at:
[e-mail]
Note: A complete list of safety warnings is provided on the Supermicro web site at
http://www.supermicro.com/about/policies/safety_information.cfm.

MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade Module User’s Manual
1-2
1-2 Blade Module Features
Table 1-1 lists the main features of the MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade
module. See the proceeding section for components typically included in a blade system
and other optional components. Specific details for the MBI-6219G-T8HX/
MBI-6119G-T8HX MicroBlade module are found in Chapter 4: "MicroBlade Module
Features" on page 4-1. The only difference between the two MicroBlade modules is that
the MBI-6119G-T8HX MicroBlade module has one node and the B2SS1-H-MTF
serverboard, while the MBI-6219G-T8HXMicroBlade module has two nodes and the
B2SS2-H-MTF serverboard.
Table 1-1. MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade Module
Specification Features
Serverboard B2SS1-H-MTF (MBI-6119G-T8HX), B2SS2-H-MTF (MBI-6219G-T8HX)/
(proprietary form factor)
Blade System Enclosures See the Blade Enclosures section below for a full list of MicroBlade
enclosures.
Chassis Specifications Chassis Dimensions (HxWxD): 1.2" x 4.94" x 23.2" (30.48-mm x
125.476-mm x 589.28-mm), Gross Weight: 7.5 lbs (3.4 kg)
Processors
One (1) or Two (2) Intel®Xeon®E3-1585 V5 embedded processor in an
FCBGA1440 socket on the serverboard. See Processors section below for
details.
Chipset Intel C236
BIOS 128 MB SPI Flash EEPROM with AMI® BIOS
Memory Capacity Supports up to 32 GB SODIMM DDR4 2133 MHz speed and 16 GB size
SODIMM memory in two (2) FCBGA1440 DIMM sockets
Hard Drive Bays
The blade module supports one (1) 2.5" SATA3 HDD/SSD disk drive per
node. Additionally, two (2) M.2 and one (1) SATA-DOM connectors are
also available per node.

1-3
Chapter 1: Introduction
Blade Enclosures
The MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade module can be mounted in any of
the following MicroBlade Enclosures:
•6U:
• MBE-628E-416
• MBE-628E-420
• MBE-628E-816
• MBE-628E-820(D)
• MBE-628EB-422
• MBE-628EB-622
• MBE-628EB-822
•3U:
• MBE-314E-420(D)
• MBE-314E-220(D)
• MBE-314E-416
Processors
The MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade module supports the E3-1585 V5
series processor in an FCBGA1440 socket. The MBI-6219G-T8HX supports two
processors while the MBI-6119G-T8HX supports only one processor
Refer to the Supermicro web site for a complete listing of supported processors (http://
www.supermicro.com/products/microblade). Please note that you will need to check the
detailed specifications of a particular blade module for a list of the CPUs it supports.
Details on installation of the processor into the MBI-6219G-T8HX/MBI-6119G-T8HX
MicroBlade module are found in Chapter 3: " Setup and Installation" on page 3-1.
Memory
Each of the MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade module’s nodes have two
(2) FCBGA1440 DIMM sockets that can support up to 32 GB SODIMM of DDR4 2133
MHz speed, 16 GB size SODIMM memory. Memory is interleaved, which requires both
modules to be of the same size and speed.
Please refer to the Supermicro web site for a list of supported memory http://
www.supermicro.com/products/microblade The detailed specifications for a blade
module will contain a link to a list of recommended memory sizes and manufacturers.
Details on installation of memory modules into the MBI-6219G-T8HX/MBI-6119G-T8HX
MicroBlade module are found in Chapter 3: " Setup and Installation" on page 3-1.

MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade Module User’s Manual
1-4
Storage
The MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade module has one (1) 2.5" SATA3
HDD/SSD for an internally mounted drive per node. Additionally, two (2) M.2 and one (1)
SATA-DOM connectors are available that can be used for connection to drives for
storage or for installation of the node’s operating system for each node. See Chapter 3:
" Setup and Installation" on page 3-1 for storage installation details.
RAID
The MBI-6219G-T8HX/MBI-6119G-T8HX MicroBlade module has only one hard drive
per node, so no RAID array is possible.
Density
A maximum of twenty-eight blade modules may be installed into a single blade
enclosure. Each blade enclosure is a 6U form factor, so a standard 42U rack may
accommodate up to seven enclosures with 196 blade modules, the equivalent of 392 1U
servers. With the inclusion of up to fourteen CMM modules and up to twenty-eight
Gigabit Ethernet switches this would occupy up to 434U space in a conventional 1U
server configuration.
