BPN-SAS3-827HQ Backplane User’s Guide
ii
Manual Revision 1.0
Release Date: January 23, 2015
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2015 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

Preface
iii
Table of Contents
Contacting Supermicro.......................................................................................iv
Returning Merchandise for Service.....................................................................v
Chapter 1 BPN-SAS3-827HQ Safety Guidelines
1-1 ESD Safety Guidelines ................................................................................... 1-1
1-2 General Safety Guidelines .............................................................................. 1-1
1-3 An Important Note to Users ............................................................................ 1-2
1-4 Introduction to the BPN-SAS3-827HQ Backplane.......................................... 1-2
Chapter 2 Connectors, Jumpers and LEDs
2-1 Front Connectors ............................................................................................ 2-1
2-2 FrontJumpersandPinDenitions.................................................................. 2-4
Explanation of Jumpers .................................................................................. 2-4
2-3 Front LED Indicator......................................................................................... 2-5
2-4 Rear Connectors and LED Indicators............................................................. 2-6
2-5 SAS Ports........................................................................................................ 2-8

BPN-SAS3-827HQ Backplane User’s Guide
iv
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Web Site: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web Site: www.supermicro.com.tw

Preface
v
Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required be-
fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning to
the manufacturer, the RMA number should be prominently displayed on the outside
of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling
charges will be applied for all orders that must be mailed when service is complete.
For faster service, RMA authorizations may be requested online (http://www.super-
micro.com/support/rma/).
Whenever possible, repack the backplane in the original Supermicro box, using the
original packaging materials. If these are no longer available, be sure to pack the
backplane in an anti-static bag and inside the box. Make sure that there is enough
packaging material surrounding the backplane so that it does not become damaged
during shipping.
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alteration, misuse, abuse or improper
maintenance of products.
Duringthewarrantyperiod,contactyourdistributorrstforanyproductproblems.

BPN-SAS3-827HQ Backplane User’s Guide
vi
Notes

1-1
Chapter 1: Safety Guidelines
Chapter 1
BPN-SAS3-827HQ Safety Guidelines
To avoid personal injury and property damage, carefully follow all the safety steps
listed below when accessing your system or handling the components.
1-1 ESD Safety Guidelines
Electrostatic Discharge (ESD) can damage electronic components. To prevent dam-
age to your system, it is important to handle it very carefully. The following measures
are generally sufcient to protect your equipment from ESD.
•Use a grounded wrist strap designed to prevent static discharge.
•Touch a grounded metal object before removing a component from the antistatic
bag.
•Handle the backplane by its edges only; do not touch its components, peripheral
chips, memory modules or gold contacts.
•When handling chips or modules, avoid touching their pins.
•Put the backplane and peripherals back into their antistatic bags when not in
use.
1-2 General Safety Guidelines
•Always disconnect power cables before installing or removing any components
from the computer, including the BPN-SAS3-827HQ backplane.
•Disconnect the power cable before installing or removing any cables from the
BPN-SAS3-827HQ backplane.
•Make sure that the BPN-SAS3-827HQ backplane is securely and properly
installed on the motherboard to prevent damage to the system due to power
shortage.

1-2
BPN-SAS3-827HQ Backplane User's Guide
1-3 An Important Note to Users
All images and layouts shown in this user's guide are based upon the latest PCB
Revision available at the time of publishing. The card you have received may or
may not look exactly the same as the graphics shown in this manual.
1-4 Introduction to the BPN-SAS3-827HQ Backplane
The BPN-SAS3-827HQ backplane has been designed to utilize the most up-to-date
technology available, providing your system with reliable, high-quality performance.
This manual reects BPN-SAS3-827HQ Revision 1.01, the most current release
available at the time of publication. Always refer to the Supermicro web site at
www.supermicro.com for the latest updates, compatible parts and supported con-
gurations.

2-1
Chapter 2: Connectors, Jumpers and LEDs
26 50
51
75
76
20 1
20 1
1
13
12 24
3
21
1 2 3
AC
ACAC
ACAC
AC
A
C
A
C
A C
1
4
1
12 7
+
+
+
+
+
+
+++
++
+
+ +
+
B37 B32B33
A1 B1
A37
B37 B32B33
A1
B1
A37
B32
A1
B1
A37
B37
B32
B33
A1
44 34
11
12 22
23
33
11
12 22
23
33
1
2
5
6
1
2
5
6
1
2
5
6
1 11
A
C
A C
A
C
A
C
A
C
1
5
8
1
5
4
8
41
4
1
4
1
4
1
BPN-SAS3-827HQ
REV: 1.01
DESIGNED IN USA
BAR CODE
3
JF5
JF6
JPW1
C246
D62
D61 D60
D59 D58D57
D56
D55
LE1
U30
J25
JPW4
C45
C51
C75
C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C92C93 C94
JF1
JF2
JF3
JF4
U2
U8
JP71
JP70
JP69
JP39 JP38 JP36 D63
D51
D52
D54
F46
R402
R56
R32
JPI2C1
JPW3
JPW2
JP55 JP54
JP57
JP56
DEFAULT:SHORT3-5
DEBUG
SPIPROG
JP71:UPGRADE#2
JP70:UPGRADE#1
+5V
+12V
5V-SB
GND
+12V
JP39:
OPEN:DEFAULT
CLOSE:PS_ON
JF6-CD JF5-AB
MB-C
MB-D
MB-A
MB-B
JP36:
OPEN:DEFAULT
CLOSE:ANYPOWER BUTTON
JP38:
OPEN:DEFAULT
CLOSE:LEDTEST
FAN4 FAN3
FAN2 FAN1
Chapter 2
Connectors, Jumpers and LEDs
2-1 Front Connectors
1. Main Power Connector: JPW1
2. Secondary Power Connector:
JPW2
3. Secondary Power Connector:
JPW3
4. Secondary Power Connector:
JPW4
5. Chassis Fan Connector: Fan1
JP54
6. Chassis Fan Connector: Fan2
JP55
7. Chassis Fan Connector: Fan3
JP56
8. Chassis Fan Connector Fan4
JP57
9. Power Supply SM bus Connec-
tor: JPI2C1
10. MB-A hot plug connector: JF1
11. MB-B hot plug connector: JF2
12. MB-C hot plug connector: JF3
13. MB-D hot plug connector: JF4
14. Backplane to front panel connec-
tor for motherboards A and B:
JF5-AB
15. Backplane to front pannel con-
nector for motherboards C and
D: JF6-CD
16. Upgrade#1: JP70
17. Upgrade#2: JP71
18. MCU Debug port J25
19. MCUrmwareupgradeportJP69
1
3
1
4
1
11
5
1
6
1
8
1
9
1
7
1
2
1
13 1
14
1
15
1
16
1
17
1
11
1
12 1
10
Figure 2-1. Front Connectors
1
18
1
19

2-2
BPN-SAS3-827HQ Backplane User's Guide
1-4. Power Connectors
These connectors, designated JPW1, JPW2, JPW3 and JPW4 supply power to the
four motherboard nodes.
5-8. Chassis Fan Connectors
These connectors, designated JP54, JP55, JP56 and JP57 supply power to the
chassis. cooling fans.
4
4
26 50
51
75
76
20 1
20 1
1
13
12 24
3
21
1 2 3
AC
ACAC
ACAC
AC
A
C
A
C
A C
1
4
1
12 7
+
+
+
+
+
+
+++
++
+
+ +
+
B37 B32B33
A1 B1
A37
B37 B32B33
A1
B1
A37
B32
A1
B1
A37
B37
B32
B33
A1
44 34
11
12 22
23
33
11
12 22
23
33
1
2
5
6
1
2
5
6
1
2
5
6
1 11
A
C
A C
A
C
A
C
A
C
1
5
8
1
5
4
8
41
4
1
4
1
4
1
BPN-SAS3-827HQ
REV: 1.01
DESIGNED IN USA
BAR CODE
3
JF5
JF6
JPW1
C246
D62
D61 D60
D59 D58D57
D56
D55
LE1
U30
J25
JPW4
C45
C51
C75
C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C92C93 C94
JF1
JF2
JF3
JF4
U2
U8
JP71
JP70
JP69
JP39 JP38 JP36 D63
D51
D52
D54
F46
R402
R56
R32
JPI2C1
JPW3
JPW2
JP55 JP54
JP57
JP56
DEFAULT:SHORT3-5
DEBUG
SPIPROG
JP71:UPGRADE#2
JP70:UPGRADE#1
+5V
+12V
5V-SB
GND
+12V
JP39:
OPEN:DEFAULT
CLOSE:PS_ON
JF6-CD JF5-AB
MB-C
MB-D
MB-A
MB-B
JP36:
OPEN:DEFAULT
CLOSE:ANYPOWERBUTTON
JP38:
OPEN:DEFAULT
CLOSE:LEDTEST
FAN4 FAN3
FAN2 FAN1
FAN4 FAN3 FAN2 FAN1
Cables
BPN-SAS3-827HQ
Backplane
System Fans
Figure 2-2. Default Conguration - Fans Connected Directly to the Backplane
9. Power Supply Connector
The 5-pin connector, designated JPI2C1, connects the power supply SMbus to
the MCU.
10-13. Motherboard to Backplane Connectors
These connectors, designated JF1, JF2, JF3 and JF4 connect the motherboards
to the backplane on the chassis. JF1 connects to motherboard A. JF2 connects
to motherboard B. JF3 connects to motherboard C and JF4 connects to moth-
erboard D. See the table on the previous page to determine the locations of the
motherboards within the chassis.
14-15. Backplane to Front Panel Headers
These connectors are designated JF5 and JF6. They connect the backplane to
the front LED panels on the chassis. JF5 connects to the LED display panel for
motherboards A and B. JF6 connects to the LED display panel for motherboards
C and D.
16-18. Upgrade Connectors #1 - #2
These connectors are designated JP70 and JP71. They are for the manufac-
turer's diagnostic use only.

2-3
Chapter 2: Connectors, Jumpers and LEDs
19. Debug MCU
J25isaporttodebugtheMCUrmware.
20. Upgrade MCU
JP69isaporttoupgradetheMCUrmware.

2-4
BPN-SAS3-827HQ Backplane User's Guide
26 50
51
75
76
20 1
20 1
1
13
12 24
3
21
1 2 3
AC
ACAC
ACAC
AC
A
C
A
C
A C
1
4
1
12 7
+
+
+
+
+
+
+++
++
+
+ +
+
B37 B32B33
A1 B1
A37
B37 B32B33
A1
B1
A37
B32
A1
B1
A37
B37
B32
B33
A1
44 34
11
12 22
23
33
11
12 22
23
33
1
2
5
6
1
2
5
6
1
2
5
6
1 11
A
C
A C
A
C
A
C
A
C
1
5
8
1
5
4
8
41
4
1
4
1
4
1
BPN-SAS3-827HQ
REV: 1.01
DESIGNED IN USA
BAR CODE
3
JF5
JF6
JPW1
C246
D62
D61 D60
D59 D58D57
D56
D55
LE1
U30
J25
JPW4
C45
C51
C75
C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C92C93 C94
JF1
JF2
JF3
JF4
U2
U8
JP71
JP70
JP69
JP39 JP38 JP36 D63
D51
D52
D54
F46
R402
R56
R32
JPI2C1
JPW3
JPW2
JP55 JP54
JP57
JP56
DEFAULT:SHORT3-5
DEBUG
SPIPROG
JP71:UPGRADE#2
JP70:UPGRADE#1
+5V
+12V
5V-SB
GND
+12V
JP39:
OPEN:DEFAULT
CLOSE:PS_ON
JF6-CD JF5-AB
MB-C
MB-D
MB-A
MB-B
JP36:
OPEN:DEFAULT
CLOSE:ANYPOWER BUTTON
JP38:
OPEN:DEFAULT
CLOSE:LEDTEST
FAN4 FAN3
FAN2 FAN1
2-2 Front Jumpers and Pin Denitions
JP39JP36 JP38
Explanation of Jumpers
To modify the operation of the backplane,
jumpers can be used to choose between
optional settings. Jumpers create shorts
between two pins to change the function
of the connector. Pin 1 is identied with
a square solder pad on the printed circuit
board. Note: On two pin jumpers, "Closed"
means the jumper is on and "Open" means
the jumper is off the pins.
Connector
Pins
Jumper
Setting
3 2 1
3 2 1
Figure 2-3. Front Jumpers
Jumper Settings
Jumper Jumper Settings
JP36 Open: Default
Closed: Any one button for power on
JP38 Open: Default
Closed: LED test
JP39 Open: Default
Closed: Power supply on

2-5
Chapter 2: Connectors, Jumpers and LEDs
26 50
51
75
76
20 1
20 1
1
13
12 24
3
21
1 2 3
AC
ACAC
ACAC
AC
A
C
A
C
A C
1
4
1
12 7
+
+
+
+
+
+
+++
++
+
+ +
+
B37 B32B33
A1 B1
A37
B37 B32B33
A1
B1
A37
B32
A1
B1
A37
B37
B32
B33
A1
44 34
11
12 22
23
33
11
12 22
23
33
1
2
5
6
1
2
5
6
1
2
5
6
1 11
A
C
A C
A
C
A
C
A
C
1
5
8
1
5
4
8
41
4
1
4
1
4
1
BPN-SAS3-827HQ
REV: 1.01
DESIGNED IN USA
BAR CODE
3
JF5
JF6
JPW1
C246
D62
D61 D60
D59 D58D57
D56
D55
LE1
U30
J25
JPW4
C45
C51
C75
C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C92C93 C94
JF1
JF2
JF3
JF4
U2
U8
JP71
JP70
JP69
JP39 JP38 JP36 D63
D51
D52
D54
F46
R402
R56
R32
JPI2C1
JPW3
JPW2
JP55 JP54
JP57
JP56
DEFAULT:SHORT3-5
DEBUG
SPIPROG
JP71:UPGRADE#2
JP70:UPGRADE#1
+5V
+12V
5V-SB
GND
+12V
JP39:
OPEN:DEFAULT
CLOSE:PS_ON
JF6-CD JF5-AB
MB-C
MB-D
MB-A
MB-B
JP36:
OPEN:DEFAULT
CLOSE:ANYPOWER BUTTON
JP38:
OPEN:DEFAULT
CLOSE:LEDTEST
FAN4 FAN3
FAN2 FAN1
LE1
Front Panel LED
LED State Specication
Heartbeat LED: LE1 Blinking MCU heartbeat LED
2-3 Front LED Indicator
Figure 2-4. Front LED

2-6
BPN-SAS3-827HQ Backplane User's Guide
1
12
13
24
4
1
1
7
6
12
S1 S7 P1 P15S8 S14
S1 S7 P1
P15
S8 S14
S1
S7 P1
P15
S8 S14
S1
S7 P1
P15
S8 S14
S1 S7 P1
P15
S8 S14
S1
S7 P1 P15S8 S14
S1
S7 P1 P15S8 S14
S1 S7 P1
P15
S8 S14
S1
S7 P1 P15S8 S14
S1 S7 P1
P15
S8 S14
S1 S7 P1
P15
S8 S14
S1 S7 P1
P15
S8 S14
A37
B37
A33
B33
A37
B37
A33
B33
A37 B37
A33 B33
A37
B37
A33 B33
1
11
A
C
A
C
A
C
A
C
A
C
A
C
A
C
A
C
A
C AC
A
C
A
CA
CA
C
A
C
A
C
A
C
A
C
A
CA
C
A
C
A
C
A
CAC
A
C
AC
1
5
1 4
5 8
1 4
58
14
14 1414
J1
J11
J13
J15
J17
J18
J19
J2
J20
J3
J4
J9
D49
D50
D28 D27 D26
D25
D24
D22
D21
D18 D15
D14
D13
D12
D8
D7 D6 D5
D33 D32 D31
D30
D29
D23
D20
D19
6
5
2
1
26
5 1
2 6
5
1
FAIL#A0
FAIL#A1
FAIL#A2
FAIL#B0
FAIL#B1
FAIL#B2
FAIL#C0
FAIL#C1
FAIL#C2
FAIL#D0
FAIL#D1
FAIL#D2
#D0
#D1
#D2
#A0
#A1
#A2
#B2
#B1
#B0
#C0
#C1
#C2
ACT#D2
ACT#D1
ACT#D0
ACT#C2 ACT#C0
ACT#C1
ACT#B2
ACT#B1
ACT#B0
ACT#A2
ACT#A1 ACT#A0
Figure 2-5. Rear Connectors and LEDs
2-4 Rear Connectors and LED Indicators
Rear SAS/SATA Connectors
Rear
Connector
SAS Drive
Number
Rear
Connector
SAS Drive
Number
SAS-#A0 SAS/SATA-A0 SAS-#C0 SAS/SATA-C0
SAS-#A1 SAS/SATA-A1 SAS-#C1 SAS/SATA-C1
SAS-#A2 SAS/SATA-A2 SAS-#C2 SAS/SATA-C2
SAS-#B0 SAS/SATA-B0 SAS-#D0 SAS/SATA-D0
SAS-#B1 SAS/SATA-B1 SAS-#D1 SAS/SATA-D1
SAS-#B2 SAS/SATA-B2 SAS-#D2 SAS/SATA-D2
Rear LED Indicators
Rear Connector FAIL
LED
ACT
LED Rear Connector FAIL LED
ACT
LED
SAS-#A0 D2 D1 SAS-#C0 D26 D25
SAS-#A1 D4 D3 SAS-#C1 D28 D27
SAS-#A2 D6 D5 SAS-#C2 D30 D29
SAS-#B0 D14 D13 SAS-#D0 D38 D37
SAS-#B1 D16 D15 SAS-#D1 D40 D39
SAS-#B2 D18 D17 SAS-#D2 D42 D41
D14 D21 D25 D28
D13 D18 D24 D27
D12 D15 D22 D26
D7 D20 D30 D33
D6 D19 D29 D32
D5 D8 D23 D31
A0
A1
A2
B0
B1
B2
C0
C1
C2
D0
D1
D2

2-7
Chapter 2: Connectors, Jumpers and LEDs
2-5 SAS Ports
The BPN-SAS3-827HQ backplane is designed with four separate nodes, which sup-
port from one to four motherboards indepentdently of each other. The SAS ports are
used to connect the SAS drive cables. The 24 ports are designated A0, A1, A2, A3,
A4, A5, B0, B1, B2, B3, B4, B5, C0, C1, C2, C3, C4, C5, D0, D1, D2, D3, D4, and
D5. Each port is also compatible with SATA drives. Use the table below to deter-
minetheSASporttomotherboardcongurationthatisappropriateforyoursystem.
SAS Port to Motherboard Congurations
Number of
Motherboards
SAS Port
Connectors
Connect to
Motherboard
Using 1 MB A0, A1, A2 MB-A
Using 2 MBs A0, A1, A2
B0, B1, B2
MB-A
MB-B
Using 3 MBs
A0, A1, A2
B0, B1, B2
C0, C1, C2
MB-A
MB-B
MB-C
Using 4 MBs
A0, A1, A2
B0, B1, B2
C0, C1, C2
D0, D1, D2
MB-A
MB-B
MB-C
MB-D
Figure 2-6. Motherboard Locations In the Chassis

2-8
BPN-SAS3-827HQ Backplane User's Guide
Disclaimer (cont.)
The products sold by Supermicro are not intended for and will not be used in life sup-
port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices,
aircraft/emergency communication devices or other critical systems whose failure to per-
formbereasonablyexpectedtoresultinsignicantinjuryorlossoflifeorcatastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should
buyer use or sell such products for use in such ultra-hazardous applications, it does so
entirely at its own risk. Furthermore, buyer agrees to fully indemnify, defend and hold
Supermicro harmless for and against any and all claims, demands, actions, litigation,
and proceedings of any kind arising out of or related to such ultra-hazardous use or
sale.
