SuperTek SteamTek 3 User manual

OPERATING
INSTRUCTIONS
&
IMPORTANT
SAFETY
INFORMATION
USER’S GUIDE
Please read all the instructions
carefully prior to using the
SteamTek3 Mop for the first time.
Keep this manual in a safe place for
future reference.

Congratulations for choosing the
3 – in – 1 Steam Mop
It cleans, shines, sanitizes and deodorizes
hard floor surfaces, carpets, and
now features a detachable, hand-held steamer
for tough to reach areas, even fabric.
The powerful SteamTek3
releases 1500W of high pressure steam
at 90 – 100ºC (194-212ºF)
to help disinfect, destroy fungus, mildew and dust mites
without chemicals or detergents.

1
CAUTION:
1. Make sure to connect unit to a grounded outlet only which corresponds to these voltage
specifications: - 110-120V, 60HZ, 1500W
- 220-230V, 50/60HZ, 1500W
2. DO NOT use unit if the cord or plug is damaged. If the power cord is damaged, it must
be replaced by a qualified electrician to avoid shock or injury.
3. DO NOT force the plug into an outlet.
4. DO NOT use with outlets or extension cords that do not have adequate current carrying
capacity.
5. DO NOT unplug unit by the cord. Pull the plug only to unplug unit from power outlet.
6. DO NOT leave the SteamTek3 Mop unattended while in the ON position.
7. DO NOT leave the SteamTek3 Mop in a stationary position while in the ON position to
avoid any possible damage to your floor/carpet.
8. DO NOT allow children to operate the SteamTek3 Mop.
9. DO NOT carry/pull the unit by the cord or use the cord as a handle.
10. Be careful to not damage cord while closing doors, while using near sharp edges and
corners, and keep away from heaters and heated surfaces.
11. DO NOT use the SteamTek3 Mop or handle the plug with wet hands.
12. DO NOT operate while barefoot.
13. EXERCISE CAUTION when using the SteamTek3 Mop around children, pets and plants.
14. DO NOT use without floor pad in place.
15. DO NOT use without water in the tank.
16. DO NOT put cleaning products into the SteamTek3 Mop water tank as this will cause
unsafe operation and will damage the unit.
17. DO NOT block the steam openings of the unit. Check frequently for lint, hair, and other
blockages which could block the steam opening.
18. The SteamTek3 Mop is designed for domestic use only.
19. USE ONLY as outlined in this booklet.
20. DO NOT use the SteamTek3 Mop outside.
21. DO NOT use on walls, windows or ceilings. The SteamTek3 Mop is to be used only on
floors.
22. DO NOT use on unsealed wood floors or cork-tiled floors as the heat and steam will
remove the finish from the surface.
23. Store in a cool, dry place.
24. DO NOT immerse unit in water or other liquids. DO NOT expose unit to rain.
WARNING - DANGER OF SCALDING
IMPORTANT SAFETY CAUTIONS
PLEASE READ ALL INSTRUCTIONS BEFORE USING THE STEAMTEK3

2
25. Always make sure that the steam outlets are kept clear. DO NOT insert any objects into
steam openings. DO NOT use unit with any blocked openings.
26. DO NOT aim steam directly at people or pets.
27. Use mop only as directed in this manual and use only with the included accessories.
Use of other attachments may cause fire, electric shock or injury.
28. DO NOT direct steam towards equipment containing electrical components such as
oven interiors.
29. DO NOT use the SteamTek3 in enclosed spaces where flammable, explosive or toxic vapors
may be present. (Paint thinner, oil-based paints, etc.)
30. DO NOT use unit on leather, wax polished furniture and floors, unsealed hardwood or
parquet floors, synthetic fabrics, velvet or other steam-sensitive materials.
31. DO NOT use for any space heating purposes.
32. ALWAYS UNPLUG UNIT before servicing.
33. DO NOT MODIFY the plug. If it does not fit your outlet, have one installed by a licensed
electrician.
34. DO NOT USE any plug adapters.
35. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instructions concerning use of the appliance by a
person responsible for their safety.
THE STEAMTEK3 IS INTENDED FOR HOUSEHOLD USE ONLY.
Commercial/industrial use of this unit will void the manufacturer’s warranty.
The SteamTek3 Mop is designed to clean carpets, vinyl, ceramic, stone, linoleum, sealed
hardwood and parquet floor surfaces. The steam reaches temperatures of between 90 – 100ºC
(194 – 212ºF). Exercise caution when using on vinyl, linoleum or any other heat sensitive floors
as too much heat can melt the glue in the flooring. DO NOT use on unsealed wood floors or let
unit stand on any wood floor for an extended period as this could cause the wood grain to swell.
DO NOT use on any floor surfaces that have been treated as the steam and heat could remove
the finish. DO NOT use the carpet glider (14) on floor surfaces other than carpeting as it could
possibly streak, scratch or otherwise damage the floor surface. DO NOT operate on any surface
for an extended time as this could cause water marks, discolouration or otherwise damage the
surface.
Prior to using, we recommend that you test a floor surface area on an isolated floor area. If
uncertain, contact the floor manufacturer for specific floor care instructions and suitability for
steam cleaning.
The SteamTek3 Mop works with water only. If you live in an area with hard water, we
recommend that you use distilled water for optimal performance.

3
1
2
4
16
12
11
8
5
6
15
17
23
3
7
19
20
21
18
13
14
9
22
1. Microfiber Mop Pads (2)
2. Microfiber Cleaning Pads For Fabric Tool
(Acc. Caddy) (2)
3. Mop Head
4. Mop Handle
5. Measuring Cup
6. Water Tank
7. Detachable Hand-held Steamer Body
8. Mop Body
9. Small Screw
10. Short Jet Nozzle
11. Hand-held Steamer Lock
12. Hand-held Steamer Release Tab
13. Swivel Joint
14. Carpet Glider
15. Cord Holder
16. ON/OFF Mop Trigger
17. Carrying Handle
18. Power Indicator
19. ON/OFF Hand-Held Steamer Switch
20. Ready to Use Indicator
21. Hand-held Steamer Handle
22. Power Cord
23. Hand-held Steamer Accessory Adapter
PARTS:
10

4
1. Lift up the Hand-held Steamer lock (11)
(Illust.1) then push the Hand-Held
Steamer release tab (12) up. (Illust. 2)
to detach the Hand-Held Steamer (7)
from the mop body (8).
2. Attach Mop Head (3) to Mop Body (8)
by inserting the Swivel Joint (13) into
the hole in the Mop Body. (Illust. 3)
Illust.1 Illust.2
Illust.3 Illust.4
Illust.7 Illust.8
ASSEMBLY:
Illust.6
Illust.5
3. Fix the Screw (9) on the Mop
Head with a Philips screwdriver
until tight. (Illust.4)
4. Re-attach the Hand-Held
Steamer (7) to the Mop Body (8)
and lock into place with the
Hand-held Steamer Lock. (11)
(Illust. 5 & 6).
5. Slide the Mop Handle (4) into the Mop Body (8)
until it clicks into place. (Illust 7)
NOTE: To remove the Handle (4) from the Body (8), press the button and pull handle up.
(Illust. 8).

5
For Use on Hard Floor
Surfaces:
Put the Microfiber Pad (1) onto
the Mop Head (3). (Illust. 9), then
pull the toggle cord to secure it in
place. (Illust. 10).
NOTE: DO NOT use the Carpet
Glider (14) on hard floor
surfaces as it could cause
damage.
INSTRUCTIONS FOR USE:
Illust.9 Illust.10
Illust.11
Illust.13
Illust.15
Illust.14
Illust.12
For Use On Carpeting:
Place the Mop Head (3) with Microfiber Pad (1) in place over the
Carpet Glider (14). (Illust. 11 & 12).
NOTE: DO NOT use a pad which has any noticeable holes,
abrasions or that is otherwise damaged as streaking and
scratching of floor surfaces could occur.
NOTE: DO NOT OPERATE UNIT WITHOUT THE PAD IN PLACE
The Microfiber pads (1) are machine washable in warm water.
AIR DRY ONLY – DO NOT DRY IN MACHINE
DO NOT BLEACH
DO NOT USE FABRIC SOFTENER
To clean the SteamTek3 unit, simple wipe with a soft cloth.
Filling the Water Tank:
NOTE: BEFORE FILLING THE WATER TANK, MAKE SURE THAT
THE UNIT IS UNPLUGGED.
Filling with the Measuring Cup:
1. Open rubber plug on water tank (6). (Illust.13)
2. Fill the included measuring cup (5) to the MAX line
indicated on the measuring cup. (Illust. 14) FILL TO
MAX LEVEL INDICATED ON THE TANK. DO NOT
OVERFILL THE WATER TANK. (Illust.15)

6
Filling directly from tap:
1. Detach the Hand-Held Steamer by
releasing the Lock (11) by lifting it up.
(Illust.16)
2. Push Hand-Held Steamer Release tab
(12) up. (Illust. 17)
3. Remove Hand-Held Steamer from
Steamer Body by lifting upwards and
away from Steamer Body.
4. Press Water Tank Release Button down to
remove tank. (Illust. 18A & 18B)
Illust.16 Illust.17
Illust.18A Illust.18B
Illust.19 Illust.20
5. Open rubber plug, then fill from tap.
(Illust. 19)
Close plug and wipe off any spilled
water. Block the valve hole on the
water tank with a finger to prevent
water from dripping from tank before
re-attaching to the Hand Held
Steamer body. (Illust. 20)
6. Re-attach the tank to
the Hand-held Steamer
body by sliding it into
the slots. (Illust. 21)
NOTE: Although the SteamTek3 uses tap water, in areas with
hard water, we recommend using distilled water for better
performance.
Illust.21
IMPORTANT!
MAKE SURE THAT THE COPPER BALL INSIDE THE WATER TANK IS ALWAYS SUBMERGED
IN WATER WHEN MOP IS BEING USED.
WARNING!
DO NOT ADD ANY CLEANING DETERGENTS, SOAPS, OR SCENTED PRODUCTS INTO THE
WATER RESERVOIR OF YOUR MOP! THIS WILL CAUSE UNSAFE OPERATION OF THE MOP
AND COULD DAMAGE THE UNIT.

7
Illust.22
Illust.23
OPERATION:
1. Plug unit into a correctly grounded electrical outlet.
The Red Power Indicator Light (18) will light up indicating that the unit is connected.
2. Wait approximately 30 seconds for the Ready To Use Indicator Light (20) to turn GREEN
indicating that the mop is ready for use.
NOTE: DO NOT press the ON/OFF Trigger (16) until the Indicator Light (20) is green in
case any residual water from previous use has remained in the unit. This water will
not be heated and will be forced out which could cause water pooling and puddling.
3. Press and hold the Mop Trigger (16) to release steam. Steam will be emitted as long as the
trigger is pressed. (Illust. 22) To stop emitting steam, release
the trigger. (Illust. 23)
4. Slowly pass the mop over the area you wish to clean.
NOTE: For best results, sweep or vacuum floor prior to using
the SteamTek3 Mop. To avoid water pooling/puddling, the
mirofiber pad (1) must be clean and dry before use.
CAUTION: To sanitize an area, leave the mop over the area for
aminimum of 8 seconds and a maximum of 15 seconds.
DO NOT leave the mop in a stationary position for longer than
15 seconds as this could cause a build-up of pale residue. If
this happens, the residue can be removed by using a
decalcifying product or with a few drops of vinegar.
NOTE: Use a cloth to wipe off residue build-up. Do not use
the mop.
5. Your SteamTek3 Mop will emit steam for approx. 20 minutes.
When it stops emitting steam, unplug the unit, remove the
water tank (or fill with cup), refill, replace tank, plug unit in, and
resume cleaning.
CAUTION: NEVER USE THE STEAMTEK 3 MOP WITHOUT
WATER!
6. When finished cleaning, unplug unit from outlet (by holding the
plug and not by the power cord), empty the water tank, REMOVE THE PAD FROM THE MOP
HEAD CAREFULLY AS THE PAD MAY STILL BE VERY HOT, wind the power cord around the
Cord Holder (15) and store it upright in a cool, dry area or by the Carrying Handle/Hook (17).
IMPORTANT!
• DO NOT STEAM ONE AREA FOR OVER 15 SECONDS AS THIS COULD RESULT IN FLOOR
SURFACE DAMAGE.
• During initial use, it may take several seconds for the SteamTek3 Mop to emit steam as the
water needs to flow through the filter to reach the heater. This will only occur the first time
you use your unit.
• When unit is filled with water the first time, you may hear a grinding sound indicating that
the pump is warming up. This will stop when the Green Indicator Light (20) lights up
indicating that the unit is ready for use.

8
• The Green Indicator Light (20) will go on and off during use. This is a normal function which
happens as the heater heats up or has reached its optimal temperature. This will not affect
cleaning performance and you can continue cleaning as usual.
• A little water may “spit” when mixed with steam. This is normal.
• Prior to using, we recommend that you test a floor surface area on an isolated floor area. If
uncertain, contact the floor manufacturer for specific floor care instructions and suitability
for steam cleaning.
HAND-HELD STEAMER
Use this detachable portable steamer on work surfaces, kitchen countertops, sinks, bathrooms,
windows, mirrors, tiles, and for spot cleaning on carpets and rugs. Use the attachments to
steam away dirt, grease and mold. Use the fabric cleaning attachment to remove wrinkles from
NOTE: To remove
or replace
attachments, rotate
them
counter-clockwise
and pull out.
Illust.24 Illust.25
clothes, curtains, fabric upholsteries, and
more.
OPERATION:
1. First detach the Hand-Held Steamer (7)
from the main Mop Body (8) by lifting up
the lock. (Illust. 24)
2. Push the Hand-Held Steamer release tab
(12) upwards to remove it from the Mop
Body. (Illust. 25)
INSTALLATION OF THE SHORT JET NOZZLE ATTACHMENT (10)
Prior to installation, make sure the Hand-Held Steamer has been detached from the main Mop
Body.
1. Pull Adapter (23) out of Hand-Held Steamer body. (Illust. 26)
2. Turn the adapter away from the steamer opening to ensure it is open. (Illust. 27)
3. Align the Short Jet Nozzle Attachment (10) with the slots inside the opening. (Illust. 28)
4. Push the Short Jet Nozzle Attachment (10) into the opening until it reaches the end, then
turn clock-wise to lock it into place. (Illust. 29)
Illust.26 Illust.27 Illust.28 Illust.29
