Supra TRAC-Vault BT User manual

Introduction
TheTRAC-Vault BT is an intelligent storage device
that holds multiple keys or access cards and records a
comprehensive audit trail of who accessed it and when.
The following hardware is recommended for this
installation:
• Four HECO MMS-SS 10 x 100 screws
For best results, consult with a local fastener or
hardware store.
You can order an installation kit from Supra that contains
all the necessary hardware for installing the TRAC-Vault
BT. An interior cover plate is also available.
TRAC-Vault BT installation
Install the TRAC-Vault BT in a location convenient for
your keyholders. To meet ADA requirements, the unit
must be installed 48 inches from the ground to the
center of the device.
To install the TRAC-Vault BT, you will need the
following equipment:
• Drill
• Drill bits
• Wrenches
• Pliers or vice grips
• Level or punch
• Pen or pencil
• Dremel tool or hacksaw
To install the TRAC-Vault BT on a rendered wall:
1. Hold the vault in the desired postion on the wall,
being careful to locate the four mounting holes away
from mortar lines and away from the edge of the wall
as well as possible.
2. Using a marker, trace the location of all 4 mounting
holes.
3. Using a drill with an 8 mm masonry drill bit, drill each
hole to a depth of 105 mm. After drilling each hole,
P/N10103266P1•August2012
© 2012 UTC Fire & Security. All rights reserved.
TRAC-Vault BT • Surface Mount
Installation Instructions
Figure 2. TRAC-Vault, side view
ensure that each hole aligns with the 4 holes in the
back of the vault.
4. Clean out the debris from all 4 holes.
5. Insert one of the HECO mounting screws onto the
chain mounting bracket.
6. Place the TRAC-Vault up to the wall (drain hole
Figure 1. Mounting holes
13
42
Tighten bolts in the sequence
indicated by these numbers
Mounting holes
for 5/16” bolts
(4 places)
Hole for tamper
switch wires
Drain hole
Lock washer
Nut
TRAC-Vault
TRAC-Lid BT
Drain hole
Lid chain
attachment
Vault
chain bracket

2
Figure 4. Installed TRAC-Lid
down) and insert each mounting screw all the way
through the mounting holes in the vault, with the
chain mounting bracket in the lower left hole.
7. Tighten all 4 screw heads in the order shown in
Figure1untiltheyareushwiththebackofthe
vault, and behind the vault lip.
8. Using the appropriate driver, drive all 4 screws into
the wall a little at a time until all 4 screws are driven
completely in and the vault is tight against the wall.
To install the TRAC-Vault BT through the wall:
1. Before drilling, ensure that no interference will
occurwithanyplumbing,electrical,reorsecurity
systems, etc.
2. Once the location for the unit has been decided,
level the template on the wall and punch or mark the
holes for drilling (see Figure 1).
3. Using the correct bit for the type of wall, drill
sufcientlylargeholestoaccommodatethe5/16”
all-thread rod.
4. Insert a lock washer and a nut on three of the four
all-thread rods. On the fourth, install a lock washer,
the chain mounting bracket, and then the nut. It is
importantthattheendofall-threadrodisushwith
the nut.
5. Put the Vault up to the wall (drain hole down)
and insert two all-thread rods through the top two
mounting holes. Insert the all-thread rod that you
have attached the chain mounting bracket to through
the lower left hole. Insert the last all-thread rod into
the bottom right hole. (See Figure 5.)
6. On the other side of the wall, mount the interior
cover plate (optional) onto the all-thread rods. Put
a5/16”fenderwasher,anda5/16”lockwasheron
Figure 3. Optional Tamper Switch
Figure 5. Side view, TRAC-Vault BT installed through the wall
Lock washer
Nut
TRAC-Vault
TRAC-Lid BT
Drain hole
Lid chain
attachment
Vault
chain bracket
Wall
Back plate
All-thread rod
Nut
Lock nut
Fender washer
Indicator
light
TRAC-Lid BT
TRAC-Vault
Thumb lever

3
eachoftheall-threadrods.Last,puta5/16”nuton
each rod and hand tighten without letting the rod
rotate. (See Figure 5.)
7. With one hand, grip the end of the all-thread rod with
either a plier, or vice grip. Then, with the other hand,
tightenthenutwitha1/2”wrenchwhilemakingsure
the Vault stays level. Repeat this procedure for all
four rods, and tighten to approximately 50-75in-lb
oruntilrmlysnug.Cutofftheexcessall-threadrod
using an appropriate tool.
Tamper Switch (Optional)
If you are using the optional tamper switch, attach the
tamper switch to the wiring in the wall (see Figure 3).
Note: Tamper switch wiring must conform to NEC class 2
or 3; or UL class 634 standards. Electrical range should
be 30 VDC at 50 MA. Use AMP FDVH 187C (14/16
AWG) crimp connectors, or equivalent.
TRAC-Lid BT installation
To install the TRAC-Lid BT in the TRAC-Vault BT, attach
the provided chain to the TRAC-Lid BT. Insert the loose
end of the chain through the eyehole on the back of the
TRAC-Lid BT, then crimp the end of the chain to the
bracket inside the TRAC-Vault BT.
To place the TRAC-Lid BT in the TRAC-Vault BT, the
lock blades on the side of the TRAC-Lid BT must be
retracted.
To retract the blades on the TRAC-Lid BT, do
the following:
1. Use a DisplayKEY or eKEY to perform the open
device function. Refer to the user instructions
provided with your key for step by step operation.
2. WhentheindicatorlightontheTRAC-LidBTashes
green, rotate the thumb lever 90° down until it stops.
Important: When installing a TRAC-Lid BT you MUST
record the serial number of the TRAC-Lid BT installed at
each location. This important information is necessary
for the integrity of the TRACcess database.
Regulatory Compliance
United States (FCC)
This device complies with part 15 of the FCC rules. Operation
is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation
Changesormodicationsnotexpresslyapprovedbytheparty
responsible for compliance could void the user’s authority to
operate the equipment.
Canada (IC)
This Class B digital apparatus complies with Canadian ICES-
003. Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
Cet appareil se conforme à l’Industrie la norme (s) RSS
exempte du permis du Canada. L’opération est soumise
aux deux conditions suivantes : (1) cet appareil peut ne pas
provoquer l’interférence et (2) cet appareil doit accepter toute
interférence, en incluant l’interférence qui peut provoquer
l’opération indésirable de l’appareil.
European Union (CE)
This Class B digital apparatus conforms to the requirements of
the following EU directives:
1. R&TTTE Directive (1999/5/EC)
2. WEEE Directive (2002/96/EC)
Warranty
UTC Fire & Security (UTCFS) warrants that this product will
be free of defects in material and workmanship for one year
from the date of purchase. This warranty is limited to repair
or replacement at the option of UTCFS. Damages caused
bymodication,abuseormisuse,wearandtear,improper
installation, application, storage, or fault or negligence of
a party other than UTCFS are not covered. UTCFS will be
responsible for labor costs of removal or reinstallation of
products. The repaired or replaced product is then warranted
under the terms of this limited warranty for the balance of
the term of the warranty or for 90 days, whichever is longer.
UTCFS MAKES NO OTHER WARRANTY, EXPRESS OR
IMPLIED, OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL UTCFS
BE LIABLE FOR LOSS OF USE; LOST PROFITS; THEFT;
PROPERTY DAMAGE; OR SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES. To obtain repair or
replacement information under the terms of this warranty,
please contact your local supplier.
