Surly ASTM 3 User manual

1
SURLY |6400 W 105th STREET |BLOOMINGTON MN, USA 55438 |1.877.773.3191 |[email protected] |www.surlybikes.com
Framesheet - ASTM 3
256625 7/19 | 85-001136_INST_A
Hi there. Thanks for spending your hard-earned cash on this Surly product.
Surly stuff is designed to be useful and durable. We’re confident it will serve
you well for years to come.
RETAILER: This frame sheet MUST BE provided to the end user.
WARNING: Cycling can be dangerous. Bicycle products should be installed
and serviced by a professional mechanic. Never modify your bicycle or
accessories. Read and follow all product instructions and warnings including
information on the manufacturer’s website. Inspect your bicycle before every
use. Always wear a helmet.
• An improperly modified frame, fork, or component can cause you to lose
control and fall. NEVER MODIFY YOUR FRAMESET
• Attaching incompatible clamping devices to a fork can lead to product
failure causing a loss of control. Consult your dealer if you are not sure
a device is compatible
• Inspect your bike before every ride and do not ride a bicycle with any
cracks or other damage
Important information about use and maintenance of bicycles is contained
in the Surly Bicycle Owner’s Manual, available online at:
www.surlybikes.com/safety.
SERIAL NUMBER: _____________________________ Write down the serial
number for your Surly bike immediately. The serial number is marked on the
bottom of your frame’s bottom bracket shell. In the event of theft, the serial
number is crucial to the identification and return of the stolen bicycle. Serial
numbers are also important when contacting us with any questions about
the product.
Intended Use
Compatibility
Frame Specification - For current frame specifications visit
www.surlybikes.com and the product page.
WARNING: Do not use forks exceeding your frames maximum axle-to-
crown dimension, see www.surlybikes.com and the product page for posted
maximum axle-to-crown requirements. Exceeding the maximum axle-to-crown
will void the frame warranty and may result in damage to or failure of the
frame, causing serious injury.
WARNING: Always check for 6mm of clearance between the fork and the
tires, fenders, and any accessories. If accessories are mounted to the
underside of the downtube, fully compress suspension frames and forks,
then check for 6mm of clearance through the entire steering range.
WARNING: Failure of a front rack or entanglement of cargo or straps in
either wheel could stop the rotation of the wheel, causing a loss of control or
crash that could lead to serious injury. If you have a front rack mounted to your
frame, check the security of all mounting hardware and fasteners before every
ride, and retighten to manufacturer specifications if necessary. Never exceed
the load limits of a front rack or carry passengers. Make sure your cargo and
straps do not interfere with the function of your bicycle BEFORE attempting
to ride. Ensure even cargo distribution, and confirm lights and reflectors are
not obstructed.
NOTE: This frame is only compatible with quick-release fenders. Do not use
this frame with fenders that lack a quick release feature that will release the
fender in case an object becomes lodged in your wheel or spokes.
Inspection
Before every ride carefully inspect your frame for signs of fatigue. If any frame
part shows signs of damage or fatigue, consult your dealer or replace the
frame before riding the bicycle. Important information about the useful life
of your bicycle frame may be found in the Surly Bicycle Owner’s Manual,
available online at: www.surlybikes.com/safety.
WARNING: Improper installation of bolts may lead to product failure, causing
serious injury. Do not exceed specified torque values. Periodically inspect bolts
and retighten if required.
Care and Maintenance
Keep your frame clean. Dirt and road grime lead to oxidation and fading of the
finish, and they make it hard to do a thorough inspection. Dirt will accelerate
any abrasion of the paint that comes from rubbing, such as places where the
cable housing touches the frame. In extreme cases, this type of abrasion could
remove frame material.
For more specific information regarding the care and maintenance of this
product please visit www.surlybikes.com or contact us at 1-877-743-3191.
If your bicycle was exposed to moisture during a ride, thoroughly dry the
bicycle before storing it. If water got inside the frame, tilt the bicycle to drain
the water. If necessary, remove the seatpost and turn the bicycle upside down.
This is especially critical if there is a large amount of water inside. If water
freezes inside your frame, the expansion of the ice can crack and rupture
the structure.
Storage
When your bicycle is not being ridden, store it where it will be protected from
the elements. Moisture or road salt may cause a metal frame to corrode.
Before storing your bicycle for an extended period of time, clean and lubricate
the frame with a frame wax, polish, or protectant. Do not store the bicycle near
electric motors, as ozone from motors destroys paint. Before riding the bicycle
again, follow the pre-ride checklist in part C of the Bicycle Owner’s Manual to
be certain it is in good working order.
CONDITION DESCRIPTION
This is a set of conditions for operation of a bicycle that includes
Condition 1 and Condition 2 as well as rough trails, rough unpaved
roads, and rough terrain and unimproved trails that require technical
skills. Jumps and drops are intended to be less than 61cm (24").

2
SURLY |6400 W 105th STREET |BLOOMINGTON MN, USA 55438 |1.877.773.3191 |[email protected] |www.surlybikes.com
Framesheet - ASTM 3
256625 7/19 | 85-001136_INST_A
Limited Warranty
This product is warranted against defects in materials and workmanship
for 3 years from the date of retail purchase of the product, subject to the
limitations detailed below. Save your dated receipt for proof of purchase.
This warranty does NOT cover the following:
• Damage due to improper assembly or follow-up maintenance or lack
of skill, competence or experience of the user or assembler
• Products that have been modified, neglected, used in competition
or for commercial purposes, misused or abused, involved in accidents
or anything other than normal use
• Installation of components, parts or accessories not originally intended
for or compatible with product as sold
• Damage or deterioration to the paint, surface finish, aesthetics
or appearance of the product
• Normal wear and tear
• Labor required to remove and/or refit and re-adjust the product within
the bicycle assembly
This limited warranty is expressly limited to the repair or replacement of the
original product, at the option of Surly, and is the sole remedy of the warranty.
This limited warranty applies only to the original purchaser of the Surly product
and is not transferable. This warranty applies only to products purchased
through an authorized dealer or distributor. In no event shall Surly be liable for
any loss, inconvenience or damage, whether direct, incidental, consequential,
or otherwise resulting from breach of any express or implied warranty or
condition, of merchantability, fitness for a particular purpose, or otherwise
with respect to Surly products except as set forth herein.
This warranty gives the consumer specific legal rights, and those rights and
other rights may vary from place to place. This warranty does not affect your
statutory rights.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE
EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR
CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
Warranty Registration: Proof of purchase is required before a warranty claim
is processed. Surly therefore strongly encourages warranty registration at
surlybikes.com. Failure to register will not affect consumer rights under the
limited warranty stated above, so long as the consumer can show in a
reasonable manner proof of original ownership and the date the Surly product
was purchased. If you have any questions contact warranty@ surlybikes.com.
Submitting a Claim can be made anywhere Surly products are sold. When in
doubt, contact your local shop. Please provide details about what happened
including but not limited to other components used in conjunction with the
alleged defective Surly part.
NOTE: The term of the Warranty is not a guarantee of the product’s useful life.
Product life is influenced by how the product is used, stored, and maintained
over time. The Warranty is not meant to suggest the product cannot be broken
or that the product will last forever. The Warranty only means the product is
covered subject to the terms of the Warranty.
