Sven SRP-355 User manual

www.sven.fi
USER’S MANUAL
Portable Radio
SRP-355

ENG
2
Portable Radio
Congratulations on your purchase of the SVEN portable radio!
COPYRIGHT
© 2018. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
BUYER RECOMMENDATIONSЮ
• Unpack the device carefully. Make sure there are no accessories left in the box. Check
up the device for damage; if the product was damaged during transportation, address
the firm which carried out the delivery; if the product functions incorrectly, address the
dealer at once.
• Shipping and transportation equipment is permitted only in the original container.
• Does not require special conditions for realization.
• Dispose of in accordance with regulations for the disposal of household and com-
puter equipment.
PACKAGE CONTENTS
• Portable radio – 1 pc
• Carrying strap – 1 pc
• Power cable – 1 pc
• User’s Manual – 1 pc
• Warranty card – 1 pc
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
SAFETY PRECAUTIONS
• To avoid electric shock, do not open the MSS and do not perform repairs by yourself.
Service and repairs should be performed only by qualified specialists in an authorized
service center. The list of authorized service centers is available at www.sven.fi.
• Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the
mains.
• Do not put foreign objects inside the holes of the MSS.
• Protect the MSS from high humidity, water and dust.
• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do
not expose it to direct sunlight.
• Do not place any open flame sources on or close to MSS.
• Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more.
When operating the MSS, do not put any devices on it, do not cover it with cloth or other
objects preventing it from cooling.
• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

ENG
3
User’s Manual SRP-355
SPECIAL FEATURES
• Built-in FM/AM/SW-6 radio
• 8-band radio receiver
• Built-in audio files player from USB-flash, microSD and SD card storage devices
• Telescopic swivel antenna
• Built-in battery
• Wired connection
Speaker system description (Fig. 1.)
a On/off flashlight button
b USB: USB-flash card slot
c Telescopic swivel antenna
d Mode select button (Рlayer/FM/AM/SW1-6 radio)
e Previous track (in Рlayer mode)
f Next track (in Рlayer mode)
g Portable radio on/off knob/volume control knob
h Repeat mode selection button (in Player mode):
– repeats the current track;
– plays all tracks in the sequential order
i Play/Pause button (in Рlayer mode)
j Station tuning knob
k MP3: Рlayer mode indicator
l AUX IN: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
m CHARGE: LED charge indicator
n Connector for charging AC from 4.5V charger
o Connector for charging AC from mains ~ 230V
p Micro SD card slot
q SD card slot
r Flashlight
s Battery compartment type D/UM-1 (rear)

ENG
4
Portable Radio
g
q
r
p
s
(rear)
Fig. 1. Speaker system description
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior to the application.
Speaker system battery charging
• Connect the speaker to the 230V mains socket via the jack n using the power cord
(included) or via the jack o to the 4.5V battery charger (not included). During battery
charging the indicator m is red.
• The battery is used in the speaker system as an integral part of the device, therefore
do not try to extract or replace it, because this can result in the warranty cancellation or
the device damage.
Attention! For powering the speaker, it is possible to use D/UM-1 batteries (2
pcs.) (not included). Install them into the battery compartment s. Observe the
polarity.
ON OFF
d
b
a
g
e
f
c
j
h
i
m
k
l
o
n

Mobile device
Power cable
Mini-jack to mini-jack signal cable
(not included)
5
SRP-355
ENG
User’s Manual
Fig. 2. Connection diagram
Socket
PC
ON OFF
TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot
give occasion to claims.
• Technical specifications and package contents are subject to change without notice
due to the improvement of SVEN production.
Technical support is on www.sven.fi.
Parameter, measurement unit
Frequency range, Hz
Output power (RMS), W:
Membrane, mm
Battery capacity, mA * h
Power supply, V
Weight, kg
Dimensions, mm
Value
150 – 20 000
3
Ø 76
900
~230V / 50Hz, DC4.5V, battery, battery
type D / UM-1 (1.5V) - 2 pcs.
0,6
126 × 142 × 85

Model: SRP-355
Импортер в России: ООО «РЕГАРД», 105082,
г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Уполномоченная организация в России: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. SRP-355
Portable Radio
